Foreword
Congratulations on the purchase of your snom 360 Voice over IP
telephone!
Telephony is part of our everyday life. Over a period of more than
100 years, a form of communication has evolved which we feel cannot be
ignored. In spite of the new technology base of the snom 360, most of its
look and feel will be very familiar to you and you should be able to use it
intuitively.
On the other hand, the world of the Internet has opened a whole
range of new possibilities. Many users are using web browsers and own
one or more e-mail accounts. They will find it easy to manage the phone
via its web interface or to make a call to “sip:[email protected]”, for
example.
We are confident that developments in the computer industry will
follow those in the telecom world.
VoIP is not only about transporting speech over data networks.
It is about interoperability and breaking up a vertical market, as well as
streamlining business processes by seamlessly integrating the telephone
into computer networks and applications. With its technical flexibility,
our commitment to all open and relevant standards and our cooperation
with other vendors in the VoIP industry, the snom 360 represents a safe
investment for the future.
We would like to take this opportunity to wish you a great
experience in the VoIP world.
snom technology AG
VoIPon www.voipon.co.uk [email protected] Tel: [phone] Fax: [phone]

4 •
[ SNOM 360 USER MANUAL V1.00 ]
Note to the reader
This manual describes the snom 360 running in administrator mode.
The phone supports SIP protocol only!
The default password to reach administrator mode is “0000” (four zeros).
The current version of this manual can be obtained from:
http://www.snom.com
