SOMFY Glydea Operating instructions

GLYDEA MOTOR with RS485
Programming Guide
1COMMUNICATION SETTINGS
4800 BAUD
8 DATA BITS
ODD PARITY
1 STOP BIT
1. Select the correct COM port.
2. Click on “RTS”, then click on CONNECT
3. Click on “Get MTR Addr.” The default address, ABCDEF, will appear if unprogrammed.
4. Under Group Addresses, Assign an address to Group 1. It should be a 6bit Hex Address. This will then become the Motor Address for
the Glydea.
5. Up to 5 Group Address can also be assigned at this time in locations 2 through 6.
6. Click on “Set”. Allow 10 seconds for data transfer between PC and Motor.
7. Click on “Get MTR Addr” and verify the motor address has been updated.
8. Click on “Get” under GROUP ADDRESSES and verify the group addresses are set correctly.
Somfy’s configuration software is located on-line at: http://www.somfy.us/Apps/SDNSoftware/ILT2-ST30-3.5.2.exe
A USB to RS485 converter is recommended (Part 9015260).
2ASSIGN ADDRESS

1. Click on “Group Motor Address.”
2. Enter the Motor Address just assigned. Click on “All Commands”.
3. Click on “Calculate”. All the command strings will be filled in automatically.
4. Only the following commands can be used with the Glydea Motor:
UP, STOP and DOWN
Somfy’s command calculator is located on-line at:
http://www.somfy.us/Apps/SDNSoftware/ILT%20Command%20Calc.exe
3GET COMMANDS
4CONNECTION DIAGRAM
MOTOR HEAD
RJ45
MODULAR
PLUG
Power Plug
120v AC
CAT5 CABLE
SDN BUS
CAT5 CABLE
RS485
24V DC
Bus Power Supply
RS485 Interface
1870127
SOMFY SYSTEMS, INC. 9/11
Ref. No.: 2500129 C
SOMFY SYSTEMS, INC.
121 Herrod Boulevard
Dayton, NJ 08810
SOMFY CANADA
6315 Shawson Drive, Unit #1
Mississauga, Ontario L5T1J2
SOMFY SYSTEMS, INC. reserves the right to change,
update or improve this document without prior notice.
5RESET TO DEFAULT
To change the Motor Address back to the default (ABCDEF), press and hold the reset button until the LED turns on.
LED
Reset
Button
