SOMFY Roll Up 28 RTS User manual

Ref. 5130019A
EN Instructions
사용설명서
KO
www.somfy.com
Roll Up 28 RTS 447 MHz

2Copyright © 2016 Somfy SAS. All rights reserved.
CONTENTS
1. Prerequisite information 2
1.1. Fields of application 2
1.2. Liability 3
2. Installation 3
2.1. Installation 4
2.2. Wiring 5
2.3. Commissioning 5
3. Use and maintenance 7
3.1. Mode selection: Roller or
Tilting mode 7
3.2. Up, Down, My: In roller mode 7
3.3. Up, Down, My: In tilting mode 8
3.4. Additional settings 9
3.5.
Tips and recommendations 11
4. Technical data 12
1. PREREQUISITE INFORMATION
1.1 FIELDS OF APPLICATION
R28 drive are designed to drive all types of interior roller and roman blinds.
The installer, who must be a motorisation and home automation professional, must
ensure that the motorised product is installed in accordance with the standards in force
in the country in which it is installed such as EN 13120 relating to interior blinds.
Damaged electric products should not be disposed of with normal household
waste. Make sure to drop them in specially provided containers or at an
authorized organization that will ensure they are recycled.
TRANSLATED INSTRUCTIONS
The Roll Up 28 RTS 447 MHz is a motor specially dedicated to interior applications.
The Roll Up 28 RTS 447 MHz can motorize roller blinds, silhouette blinds, and zebra
blinds.
The Roll Up 28 RTS 447 MHz is a 12VDC operated motor, powered by a power supply.
Warning : The Roll Up 28 RTS 447 MHz cannot be used with sealed double glazing.

3Copyright © 2016 Somfy SAS. All rights reserved.
1.2 LIABILITY
Please read these instructions carefully before installing and using the drive. In addition
to following the instructions given in this guide, the instructions detailed in the attached
Safety instructions document must also be observed.
The drive must be installed by a motorisation and home automation professional,
according to instructions from Somfy and the regulations applicable in the country in
which it is commissioned.
It is prohibited to use the drive outside the eld of application described above. Such
use, and any failure to comply with the instructions given in this guide and in the
attached Safety instructions document, absolves Somfy of any liability and invalidates
the warranty.
The installer must inform its customers of the operating and maintenance conditions
for the drive and must provide them with the instructions for use and maintenance,
and the attached Safety instructions document, after installing the drive. Any After-Sales
Service operation on the drive must be performed by a motorisation and home automa-
tion professional.
If in doubt when installing the drive, or to obtain additional information, contact a Somfy
adviser or go to the website www.somfy.com.
2. INSTALLATION
These instructions must be followed by the motor manufacturer and home auto-
mation professional installing the motor.
Never drop, knock, drill or submerge the motor.
Install a separate control point for each motor.



Safety warning! Information
Caution!

4Copyright © 2016 Somfy SAS. All rights reserved.
2.1. INSTALLATION
2.1.1. Motor preparation
Check that the inner diameter of the tube
is greater than 26.6 mm.
1) Fit the crown (a) and drive wheel (b)
to the motor.
2) Measure the length (L) between the
end of the drive wheel and the head
end.
2.1.2. Tube preparation
Cut the tube to the required length.
Deburr the tube and remove the debris.
2.1.3. Motor/tube assembly
1) Slide the motor into the tube.
Insert the wheel by aligning the wheel
to the tube profile. Insert the motor half
way and then slide the crown down the
motor and insert it in the tube. Finally,
push the motor inside the tube.
2) Not required, but if needed, fix the
tube to the motor with self-tapping
screws or steel pop rivets depending on
the dimension (L).
2.1.4. Mounting the motorized tube on the brackets
1) Standard bracket
2) Motor plate for specific bracket
For optimal radio reception,
the motor antenna should be
kept straight and should be
positioned outside of headrail
(if used).
L
1
2
ab
Ø > 26.6 mm
L
1
2
1 2

5Copyright © 2016 Somfy SAS. All rights reserved.
2.2. WIRING
Cableswhich passthrough ametal wallmust beprotected andisolated usinga sheath
or sleeve.
Attach cables to prevent any contact with moving parts.
The cable for the Roll Up 28 RTS cannot be removed. If it is damaged, return the
drive to the After-Sales department.
Leave the motor power supply cable accessible: it must be possible to replace it easily.
Do not unplug the power supply when the motor is working.
To ensure electrical safety, this Class III motor must be powered by a «SELV»
voltage source (Safety Extra Low Voltage).
Plug the power supply with the motor supply
cable.
Do not unplug the power supply when
the motor is working.
2.3. COMMISSIONING
2.3.1. Programming the RTS transmitter
Press the UP and DOWN buttons
simultaneously on the RTS transmitter:
the shade jogs and the control point is
preprogrammed in the motor
2.3.2. Checking the rotation direction
Press the RTS transmitter UP button:
a) If the shade raises (a), the rotation
direction is correct: move to the section
entitled 5.3 «Adjusting the end limits».
b) If the shade is lowers (b), the rotation
direction is incorrect: move to the next step.
b1) Press the RTS transmitter MY button
until the shade jogs: the rotation direction
has been modied.
b2) Press the RTS transmitter UP button to
check the rotation direction.
a
b
=
=
b2b1



+
-

6Copyright © 2016 Somfy SAS. All rights reserved.
2.3.3. Adjusting the end limits
The end limits can be set in any order.
1)Press and hold the UP button to move the
shade to the desired position. If necessary
adjust the Up position, using the UP or
DOWN buttons.
2)Press the MY and DOWN buttons
simultaneously and release them once
the shade begins to move. The up limit is
memorized.
3)Press the MY button when the shade
reaches the desired Down position.
If necessary adjust the down position, using
the UP or DOWN buttons.
4)Press the MY and UP buttons
simultaneously and release them when the
shade begins to move.
The Down limit is memorized. The shade
moves up and will stop at its upper limit.
5)To confirm the end limits, press and hold
the MY button until the shade jogs.The end
limits are recorded.
2.3.4. Recording the RTS transmitter
After recording the end limits:
Briey press the programming button on the
back of the transmitter. The shade jogs.
The transmitter is recorded.
2.3.5. Favorite position: MY position / Recording MY position
If desired, to set the MY position, move the
shade to the desired position with the UP or
DOWN button then press the MY button until
the shade jogs.
1 2
3 4
5
PROG.

7Copyright © 2016 Somfy SAS. All rights reserved.
3. USE AND MAINTENANCE
3.1. MODE SELECTION: ROLLER OR TILTING MODE
The Roll Up 28 RTS is designed to work in 2 modes: Tilting mode or Roller mode.
This feature allows the Roll Up 28 RTS to be set according to the type of blind you are
working with.
The Roll Up 28 RTS is set by default to work in Roller mode.
1)Move the shade away from the end limits.
2)Simultaneously press the UP and DOWN
buttons until the shade jogs.
3)Press and hold the MY and DOWN
buttons simultaneously until the shade jogs
to change from Roller mode to Tilting mode.
3.2. UP, DOWN, MY: IN ROLLER MODE
1) To move the shade from a limit to the
other limit, press briefly the UP or DOWN
button.
2) To stop the shade, press the MY button.
3) If a MY position is recorded,To move the
shade to this MY position, press briefly the
MY button.
1
23
1
2
3

8Copyright © 2016 Somfy SAS. All rights reserved.
3.3. UP, DOWN, MY: IN TILTING MODE
1) To move the shade from a limit to the
other limit, briefly press (less than 0,5s) the
UP or DOWN button.
2) To stop the shade, press the MY button.
3) If a MY position is recorded,To move the
shade to this MY position, press briefly the
MY button.
The shade first goes to the down end limit,
then to the MY position.
4) To tilt the slats, press and hold the UP
or DOWN button until the slats reach the
desired position.
4
1
2
3

9Copyright © 2016 Somfy SAS. All rights reserved.
3.4. ADDITIONAL SETTINGS
3.4.1. Favortie position: MY position
1) Changing the MY position
To change the MY position, go to the new
desired MY position with the UP and DOWN
buttons then press the MY button until the
shade jogs.
2) Deleting the MY position
To delete the MY position, press the MY
button to move to this position and press the
MY button until the shade jogs.
3.4.2. End limit readjustment
Readjusting the upper end limit
1) Press the UP button, to move the shade
to the upper end limit.
2) Press and hold the UP and DOWN
buttons simultaneously until the shade jogs.
3) Press and hold the UP or DOWN button
to move the shade to the new desired
position.
4) To confirm the new limit press and hold
the MY button until the shade jogs.
Readjusting the lower end limit
1) Press the DOWN button to move the
shade to the lower end limit.
2) Press and hold the UP and DOWN
buttons simultaneously until the shade jogs.
3) Press and hold the UP or DOWN button
to move the shade to the new desired
position.
4) To confirm the new limit press and hold
the MY button until the shade jogs.
1
2
1 2
34
1 2
34

10 Copyright © 2016 Somfy SAS. All rights reserved.
3.4.3. Adjusting the tilting speed
1) To decrease the tilting speed, press
and hold the MY and DOWN buttons
simultaneously until the shade jogs. Repeat
as needed. If the shade does not jog, then
the minimum setting has been reached.
2) To increase the tilting speed, press
and hold the STOP and UP buttons
simultaneously until the shade jogs. Repeat
as needed. If the shade does not jog, then
the maximum setting has been reached.
3.4.4. Modifying the motor rotation direction
1) Move the shade away from the end limits.
2) Press the UP and DOWN buttons
simultaneously until the shade jogs.
3) Press the MY button until the shade jogs
to reverse the rotation direction.
4) Press the UP button to check the new
rotation direction.
The motor rotation direction is reversed.
3.4.5. Adding/Deleting RTS transmitter
Find an RTS transmitter (A) programmed in
the motor.
Press and hold the RTS programmed
transmitter (A) PROG button or the motor
PROG button until the shade jogs: the motor
is in programming mode.
Quickly press the RTS transmitter(B) PROG
button to add or delete: the shade jogs and the
RTS transmitter
is programmed or deleted from the motor.
1
2
1 2
34
A
B
A
A
A
B
B
PROG.
A
PROG.
B

11Copyright © 2016 Somfy SAS. All rights reserved.
3.4.6. Erasing the transmitters from the memory
To delete all the programmed transmitters,
press and hold the motor PROG button until
the shade jogs twice.
All the transmitters are deleted.
3.4.7. Erasing the memory of the motor
To reset the motor, press and hold the PROG
button on the motor head until the shade jogs
3 times.
All the settings are erased.
3.5. TIPS AND RECOMMENDATIONS
The motor doesn’t work:
Verify:
• The wiring of the motor.
• The compatibility of the control.
• The heat generated (wait for the cooling of the motor).
The equipment stops too soon:
Verify:
• The operation of end-limits during the motor rotation.
• The end-limits of the motor are properly adjusted.
• That the shade is within the recommended weight limit.
x2
x3
x2
x3

12 Copyright © 2016 Somfy SAS. All rights reserved.
4. TECHNICAL DATA
Power supply 12 Vdc SELV
Radio frequency 447 MHz
Torque 1.1 Nm
Electrical insulation III
Minimum distance between two end-limit 1 turn
Maximum distance between two end-limit 180 turns
Maximum running time 6 min
Operating temperature 0°C to + 60°C
Protection rating IP 20 (For indoor use only)
Maximum number of associated control 12
For additional information on the technical data for this drive contact your Somfy
representative.

13Copyright © 2016 Somfy SAS. All rights reserved.
목차
1. 필수 정보 13
1.1. 용도 13
1.2. 책임 14
2. 설치 14
2.1. 설치 15
2.2. 배선 16
2.3. 기본설정 16
3. 사용 및 유지보수 18
3.1. 모드선택:롤또는틸팅모드 18
3.2. 올리기, 내리기, My: 롤모드 18
3.3. 올리기, 내리기, My: 틸팅모드 19
3.4. 추가설정 20
3.5.
팁및권장사항 22
4. 기술 사양 23
1. 필수 정보
1.1 용도
R28 모터는모든유형의실내롤및로만블라인드에사용할수있습니다.
설치기사는모터및홈오토메이션전문가여야하고, 실내블라인드관련 EN 13120 등
설치된국가에서적용하는표준에따라개폐상품을설치해야합니다.
손상된 전기 제품을 일반 생활 폐기물과 함께 처리하면 안 됩니다. 전용
수거함에버리거나허가받은재활용전문업체로보내시기바랍니다.
사용 설명서
Roll Up 28 RTS 447 MHz는실내전용모터입니다.
Roll Up 28 RTS 447 MHz는롤블라인드, 실루엣블라인드및콤비블라인드의작동
에사용할수있습니다.
Roll Up 28 RTS 447 MHz는전원공급장치를통해전원을공급받는 12VDC 모터입
니다.
경고: Roll Up 28 RTS 447 MHz를밀폐된이중유리에사용할수없습니다.

14 Copyright © 2016 Somfy SAS. All rights reserved.
1.2 책임
모터를설치및사용하기전에본설명서를읽고숙지하십시오.본설명서의지침외에첨부된
안전지침의지시사항도반드시준수하십시오.
모터는Somfy가제공하는지침과사용국가의관련법규에따라모터및홈오토메이션설치
기사가설치해야합니다.
모터를앞에서설명한용도이외의목적으로사용하는것은금지됩니다. 용도를벗어
난사용이나본설명서와첨부된안전지침의지시사항을따르지않는행위로인한
결과에대해 Somfy는책임을지지않으며보증이무효화됩니다.
설치자는모터의사용및유지보수조건을고객에게알려야하고, 모터를설치한후사
용및유지보수지침과첨부된안전지침을고객에게제공해야합니다. 모터의 AS 작
업은모터및홈오토메이션설치기사가수행해야합니다.
모터의설치와관련해잘모르는사항이있거나추가정보가필요한경우에는 Somfy로
문의하거나웹사이트 www.somfy.co.kr을방문해확인하시기바랍니다.
2. 설치
모터및홈오토메이션설치기사는모터설치와관련된본지침을 반드시 따라
야합니다.
모터를떨어뜨리거나충격을가하거나구멍을뚫거나물에담그지마십시오.
모터마다별도의스위치를설치하십시오.



안전경고!정보
주의!

15Copyright © 2016 Somfy SAS. All rights reserved.
2.1. 설치
2.1.1. 모터 준비
샤프트내경이 26.6 mm보다큰지
확인하십시오.
1) 크라운(a)와구동휠(b)를모터에
장착하십시오.
2) 구동휠끝에서헤드끝까지길이(L)
을측정하십시오.
2.1.2. 샤프트 준비
샤프트를원하는길이만큼절단하십시오.
샤프트에서금속찌꺼기를제거하십시오.
2.1.3. 모터/샤프트 조립
1) 모터를샤프트로밀어넣으십시오.
휠을샤프트모양에맞춰끼우십시오.
모터를절반정도끼운다음크라운을
모터끝으로밀어넣고샤프트에
끼우십시오. 마지막으로모터를
샤프트로밀어넣으십시오.
2) 필수사항은아니지만,필요시치수
(L)에따라셀프태핑나사나스틸
팝리벳으로사프트를모터에
고정하십시오.
2.1.4. 모터/샤프트를 브라켓에 장착
1) 표준브라켓
2) 브라켓별모터플레이트
최상의무선수신을위해서는
모터안테나를곧은상태로
유지해야하고, 헤드레일사용
시헤드레일밖에두어야
합니다.
L
1
2
ab
Ø > 26.6 mm
L
1
2
1 2

16 Copyright © 2016 Somfy SAS. All rights reserved.
2.2. 배선
금속 벽을 통과하는 케이블은 피복이나 슬리브를 사용해 보호 및절연해야 합니다.
케이블이 움직이는 부품과 접촉하지 않도록 고정하십시오.
Roll Up 28 RTS의케이블은 제거할 수없습니다. 손상된 모터는 AS 부서로 반품하십시오.
모터 전원 케이블을 손쉽게 교체할 수있도록 접근이 가능한 곳에 두십시오.
모터가 작동하는 중에 전원 공급 장치를 분리하지 마십시오.
전기 안전을 위해 Class III 등급의 모터는 «SELV»(Safety Extra Low Voltage)
전원을 통해 작동해야 합니다.
전원 공급 장치에 전원 케이블을 연결하십
시오.
모터가 작동하는 중에 전원 공급 장치를
분리하지 마십시오.
2.3. 기본설정
2.3.1. RTS 송신기 프로그래밍
RTS 송신기의 상/하버튼을 동시에
누르십시오.
쉐이드가 짧게왕복하고 스위치가 모터에서
미리 프로그램됩니다.
2.3.2. 회전 방향 점검
RTS 송신기의 상버튼을 누르십시오.
a) 쉐이드가 올라가면(a), 회전 방향이 올바른
것입니다. 5.3 «상단/하단 리미트 조정»
항목으로 가십시오.
b) 쉐이드가 내려가면(b), 회전 방향이
올바르지 않은 것입니다. 다음 단계로
가십시오.
b1) 쉐이드가 짧게왕복할 때까지 RTS
송신기의
MY 버튼을 누르십시오. 회전 방향이 변경
됩니다.
b2) RTS 송신기의 상버튼을 눌러 회전
방향을 확인하십시오.


a
b
=
=
b2b1

+
-

17Copyright © 2016 Somfy SAS. All rights reserved.
2.3.3. 상단/하단 리미트 조정
순서에 상관없이 상단/하단 리미트를 설정할 수있습니다.
1) 상버튼을 길게 눌러 쉐이드를 원하는
위치까지 올리십시오. 필요 시상또는 하
버튼을 사용해 상단 리미트를 조정하십시오.
2) MY 버튼과 하버튼을 동시에 누르고,
쉐이드가 움직이기 시작할 때버튼을 한
번에 놓으십시오.
상단 리미트가 기억됩니다.
3) 쉐이드가 원하는 하단 리미트에 도달할
때MY 버튼을 누르십시오.
필요 시상또는 하버튼을 사용해 하단
리미트를 조정하십시오.
4) MY 버튼과 상버튼을 동시에 누르고,
쉐이드가 움직이기 시작할 때버튼을
놓으십시오.
하단 리미트가 기억됩니다. 쉐이드가 위로
움직이고 상단 리미트에서 멈춥니다.
5) 상단/하단 리미트를 확정하려면,
쉐이드가 짧게왕복할 때까지 MY 버튼을
길게 누르십시오. 상단/하단 리미트가
설정됩니다.
2.3.4. RTS 송신기 설정
상단/하단 리미트 설정 후:
송신기 뒤에 있는 프로그래밍 버튼을 짧게
누르십시오. 쉐이드가 짧게왕복합니다.
송신기가 설정됩니다.
2.3.5. 선호 위치: MY 위치 / MY 위치 설정
MY 위치를 설정하려면, 상또는 하버튼을
사용해 쉐이드를 원하는 위치로 이동한 다음,
쉐이드가 짧게왕복할 때까지 MY 버튼을
누르십시오.
1 2
3 4
5
PROG.

18 Copyright © 2016 Somfy SAS. All rights reserved.
3. 사용 및유지보수
3.1. 모드 선택: 롤또는 틸팅 모드
Roll Up 28 RTS는2가지 모드, 즉틸팅 모드와 롤모드를 지원합니다.
이기능을 사용하면 블라인드 유형에 따라 Roll Up 28 RTS를설정할 수있습니다.
기본적으로 Roll Up 28 RTS는롤모드로 설정되어 있습니다.
1) 쉐이드를 상단/하단 리미트로부터 멀리
이동하십시오.
2) 쉐이드가 짧게왕복할 때까지 상/하
버튼을 동시에 누르십시오.
3) 롤모드에서 틸팅 모드로 변경하려면
쉐이드가 짧게왕복할 때까지 MY 버튼과 하
버튼을 동시에 길게 누르십시오.
3.2. 올리기, 내리기, MY: 롤모드
1) 쉐이드를 한리미트에서 다른 리미트로
이동하려면, 상또는 하버튼을 짧게
누르십시오.
2) 쉐이드를 멈추려면, MY 버튼을
누르십시오.
3) MY 위치가 설정된 경우, 쉐이드를
MY 위치로 이동하려면 MY 버튼을 짧게
누르십시오.
1
23
1
2
3

19Copyright © 2016 Somfy SAS. All rights reserved.
3.3. 올리기, 내리기, MY: 틸팅 모드
1) 쉐이드를 한리미트에서 다른 리미트로
이동하려면, 상또는 하버튼을 짧게(0.5초
이하) 누르십시오.
2) 쉐이드를 멈추려면, MY 버튼을
누르십시오.
3) MY 위치가 설정된 경우, 쉐이드를
MY 위치로 이동하려면 MY 버튼을 짧게
누르십시오.
쉐이드가 먼저 하단 리미트로 이동한 다음,
MY 위치로 이동합니다.
4) 슬랫을 기울이려면, 슬랫이 원하는
위치에 도달할 때까지 상또는 하버튼을
길게 누르십시오.
4
1
2
3

20 Copyright © 2016 Somfy SAS. All rights reserved.
3.4. 추가 설정
3.4.1. 사용자 선호 위치: MY 위치
1) MY 위치 변경
MY 위치를 변경하려면, 상/하버튼을 사용해
원하는 새로운 MY 위치로 이동한 다음,
쉐이드가 짧게왕복할 때까지 MY 버튼을
누르십시오.
2) MY 위치 삭제
MY 위치를 삭제하려면, MY 버튼을 눌러
MY 위치로 이동한 다음, 쉐이드가 짧게
왕복할 때까지 MY 버튼을 누르십시오.
3.4.2. 리미트 재조정
상단 리미트 재조정
1) 상버튼을 눌러 쉐이드를 상단 리미트까지
이동하십시오.
2) 쉐이드가 짧게왕복할 때까지 상/하
버튼을 동시에 길게 누르십시오.
3) 상또는 하버튼을 길게 눌러 쉐이드를
원하는 새로운 위치까지 이동하십시오.
4) 새로운 상단/하단 리미트를 확정하려면,
쉐이드가 짧게왕복할 때까지 MY 버튼을
길게 누르십시오.
하단 리미트 재조정
1) 하버튼을 눌러 쉐이드를 하단 리미트까지
이동하십시오.
2) 쉐이드가 짧게왕복할 때까지 상/하
버튼을 동시에 길게 누르십시오.
3) 상또는 하버튼을 길게 눌러 쉐이드를
원하는 새로운 위치까지 이동하십시오.
4) 새로운 상단/하단 리미트를 확정하려면,
쉐이드가 짧게왕복할 때까지 MY 버튼을
길게 누르십시오.
1
2
1 2
34
1 2
34
