SOMFY J4 RTS Assembly instructions

J4 RTS
Ref. 5072038B
Notice installateur
Installationsanleitung
Guida d’installazione
Installer Guide
EN DE FR
IT

64 © 2013 Somfy SAS. All rights reserved. 06/2013
EN
2. SAFETY
2.1. Safety and responsibility
- The motor, torque and operating time must be adjusted according to the complete installation.
- Only Somfy original accessories should be used (adapters, brackets, connectors, power cable, etc.).
 )LWWLQJ WHVWLQJ FRPPLVVLRQLQJ DQG UHSDLU RI WKH LQVWDOODWLRQ PXVW RQO\ EH FDUULHG RXW E\ TXDOL¿HG
personnel.
- Correct operation of the installation is only guaranteed if the installation and assembly have been
carried out according to best practices, if the electrical supply is adequate and if maintenance is carried
out.
- The installer must also comply with the current standards and legislation in the country in which the
product is being installed, and inform his customers of the usage and maintenance conditions relevant
to the product.
CONTENTS
1. Introduction 62
2. Safety 63
2.1. Safety and responsibility 63
6SHFL¿FVDIHW\DGYLFH 
3. Installation 64
3.1. 58 x 51 mm or 58 x 56 mm head rail,
open below 64
3.2. 58 x 56 mm head rail, open above 64
3.3. 57 x 51 mm head rail, open above 65
3.4. 78 X 67 mm head rail, open below 66
3.5. 67 X 66 mm head rail, open below 67
4. Wiring 67
5. Commissioning 68
5.1. Identifying setting steps already
completed 68
5.2. Pre-programming the Somfy local
control point 68
5.3. Checking the motor's direction of
rotation 69
5.4. Selecting the type of E.V.b. (type 1 or type
3) 69
5.5. Setting the end limits 70
3URJUDPPLQJWKH¿UVW6RPI\ORFDO
control point 71
5.7. Checking the settings 71
6. Operation 72
6.1. Standard operation 72
6.2. Operating with a Somfy sensor 73
7. Additional settings 74
7.1. Favourite position (my) 74
7.2. Adding/Deleting Somfy control points
and sensors 75
7.3. "Sun disappearing" position» 76
7.4. Modifying the slat tilt angle in relation
to the notches on the thumbwheel 77
7.5. Modifying the thumbwheel's direction
of rotation 77
7.6. Modifying the motor's direction of
rotation 77
7.7. Modifying the end limits 78
8. Tips and recommendations 79
8.1. Questions on the J4 RTS? 79
8.2. Replacing a lost or broken Somfy
control point 79
5HVWRULQJWKHRULJLQDOFRQ¿JXUDWLRQ 
9. Technical data 80
1. INTRODUCTION
The J4 RTS motor is designed to drive all types of external venetian blind.

65
© 2013 Somfy SAS. All rights reserved. 06/2013
EN
2. SAFETY
The moving parts of the motors must be protected if operating at less than 2.50 m from the ground or another
surface.
- The installation must not be used if it shows any signs of damage (for example wear, damaged cables and
springs or ill adjusted end limits).
- The installation must be protected from all unauthorised use. Take preventive measures to avoid any
spurious operation.
- Children must be supervised to ensure they do not play with the equipment. Keep remote controls out of
the reach of children.
- This equipment is not intended for use by persons (including children) with impaired physical or mental
capacities or those without the required knowledge or experience unless supervised by a person responsible
for their safety.
- Disconnect all the connection cables from the power supply before operating on the installation.
- Do not use the installation if operations (window cleaning for example) are being carried out nearby.
- Observe the assembly and use guidelines, in particular the safety instructions from the manufacturer of the
device to be used , since incorrect installation can lead to severe injury.
- Permanently mounted controls must be mounted visibly.
- The power supply cables of the motor must only be replaced by a cable of the same type, delivered by the
manufacturer of the motor.
- If the mushroom is used to stop the blind in the upper end limit position, the installer must check that the
PXVKURRPLVLQSODFHZKHQWKHFRPSOHWHLQVWDOODWLRQLVXVHGIRUWKH¿UVWWLPH
- To remove the motor power cable: Please use the «J4 cable dismantling tool» ref: 9017811
6XEMHFWWRWHFKQLFDOPRGL¿FDWLRQV
6SHFL¿FVDIHW\DGYLFH
In addition to the safety instructions described in this guide, be sure to also observe the
instructions set out in the attached document «Safety instructions to follow and keep».
1) Switch off the mains supply for the external venetian
blind before performing any service operation in the
vicinity.
To avoid damaging the product:
2) Never immerse it in liquid!
3) Avoid impacts!
4) Do not drop it!
5) Never drill holes in it!
6) Avoid moving the blind if ice has formed on it.
1
3
5 6
2
4
OFF

66 © 2013 Somfy SAS. All rights reserved. 06/2013
EN
Cutaway diagram of the head rail
)RUGHWDLOHGWHFKQLFDOLQIRUPDWLRQUHIHUWRWKHVSHFL¿FDWLRQVVKHHWVDQGGHGLFDWHGLQWHUIDFHSODQV
WT
20 mini
26 mini
Motor tilt
The J4 RTS motor has been designed to operate horizontally:
NOK OK OK 10°
maxi
36 mini
30 mini
Standard
mushroom
Mushroom for
extension
Check that during operation, none of the slats from the blind exert any radial pressure on the
mushroom.
If the EVB is equipped with a z-shaped slat, it will be necessary to adjust the upper end limit for
the motor. In this case, the mushroom is used to ensure the safety of the EVB.
Installation with the mushroom extension kit ref : 9017754

67
© 2013 Somfy SAS. All rights reserved. 06/2013
EN
3. INSTALLATION
 Screw the 2 adaptors (1) using 2 M3x8 bolts (2) on
the motor shaft.
Tightening torque = 1,35 N.m +/- 20%
 Connect the connection cable (3) to the motor.
Ensure that the cable does not pass over a rotating part
of the motor or mechanism.
 Compress the edge of the head rail (4) into the motor
zone.
 Insert the motor into the head rail (4).
 Using the clips (5), attach the motor in the head rail
(4) above the small acoustic tapes (6a).
 The shaft can be fitted into the adapter using a
headless screw (7).
Tightening torque = 2 N.m maximum
Installation with external clips
 Screw the 2 adaptors (1) using 2 M3x8 bolts (2) on
the motor shaft.
Tightening torque = 1,35 N.m +/- 20%
 Connect the connection cable (3) to the motor.
Ensure that the cable does not pass over
a rotating part of the motor or mechanism.
 Insert the motor into the head rail (4).
 Using the clips (5), attach the motor in the head rail
(4) above the small acoustic tapes (6a).
 The shaft can be fitted into the adapter using a
headless screw (7).
Tightening torque = 2 N.m maximum
54
7
3.1 57 X 51 mm or 58 x 56 mm head rail, open below
3.2 58 x 56 mm head rail, open above
27
11
3
7
2
6a
2
7
1
1
3
7
2
7
5
47
6a
5
6a

68 © 2013 Somfy SAS. All rights reserved. 06/2013
EN
Installation with external clips
 Screw the 2 adaptors (1) using 2 M3x8 bolts (2) on
the motor shaft.
Tightening torque = 1,35 N.m +/- 20%
 Connect the connection cable (3) to the motor.
Ensure that the cable does not pass over
a rotating part of the motor or mechanism.
 Insert the motor into the head rail (4).
 Using the clips (5), attach the motor in the head rail
(4) above the small acoustic tapes (6a).
 The shaft can be fitted into the adapter using a
headless screw (7)
Tightening torque = 2 N.m maximum
Installation with internal clips
 Screw the 2 adaptors (1) using 2 M3x8 bolts (2) on
the motor shaft.
Tightening torque = 1,35 N.m +/- 20%
 onnect the connection cable (3) to the motor.
Ensure that the cable does not pass over
a rotating part of the motor or mechanism.
 Insert the motor into the head rail (4).
 Using the clips (5), attach the motor in the head rail (4).
 The shaft can be fitted into the adapter using a
headless screw (7).
Tightening torque = 2 N.m maximum
The internal clips cannot be used with J418 motors
(J4 motors with a torque of 18 Nm).
3.3 57 x 51 mm head rail, open above
1
21
2
4
5
7
7
7
7
3
5
2
7
1
1
3
7
2
7
5
47
6a
5
6a

69
© 2013 Somfy SAS. All rights reserved. 06/2013
EN
Installation with J406/J410 motors (torque of 6 or
10 Nm)
 Screw the 2 adaptors (1) using 2 M3 x 8 bolts (2) on
the motor shaft.
Tightening torque = 1,35 N.m +/- 20%
 Connect the connection cable (3) to the motor.
Ensure that the cable does not pass over
a rotating part of the motor or mechanism.
 Fit the two head rail adaptors (8) on the motor.
 Insert the motor into the head rail (4).
 Using the clip (5), attach the motor in the head rail (4).
 The shaft can be fitted into the adapter using a
headless screw (7).
Tightening torque = 2 N.m maximum
For motors with torque greater than 10 Nm
 The additional clamp must be attached with a new
bolt -> tightening torque1P
3.4 78 x 67 mm head rail, open below
1
21
2
8
5
8
5
5
7
7
7
7
3
4

70 © 2013 Somfy SAS. All rights reserved. 06/2013
EN
 Screw the 2 adaptors (1) using 2 M3 x 8 bolts (2) on
the motor shaft.
Tightening torque = 1,35 N.m +/- 20%
 Connect the connection cable (3) to the motor.
Ensure that the cable does not pass over
a rotating part of the motor or mechanism.
 Fit the two head rail adaptors (8) on the motor.
 Insert the motor into the head rail (4).
 Using the clips (5), attach the motor in the head rail (4).
3.5 67 x 66 mm head rail, open below
1
2
12
8
5
5
8
7
7
77
3
4

71
© 2013 Somfy SAS. All rights reserved. 06/2013
EN
4. WIRING
 Cut off the mains power supply.
 Connect the motor according to the
information in the table below:
The phases and neutrals must be
connected together respectively.
In case of drive by a controller or any
automatisms, please refer to the dedi-
cated instructions manual.
1 2 3
M
Shared
Neutral
Earth
Motor
Black (2)
Blue (1)
Yellow/Green
M M M
Shared
Neutral
Earth
 It is prohibited to create a complete loop on the supply cable of the J4 RTS
plate.
 Do not interlace the supply cable of the J4 RTS plate with another cable.
To ensure that the radio signal is transmitted correctly, it is necessary to pull the J4 RTS plate supply
cable out of the head rail by at least 30 cm.
Shared
(Black)
Neutral
(Blue)
Earth (Yellow/Green)
/FP

72 © 2013 Somfy SAS. All rights reserved. 06/2013
EN
5. COMMISSIONING
3URJUDPPLQJWKH¿UVW
Somfy
local control point
Pre-programming the
Somfy local control
point
Operation
c or d
Only one motor should be powered at a time.
Switch on the power and follow procedure "a" or "b",
depending on the blind's reaction:
D7KH(9%PRYHVEULHÀ\
The end limits are set and no Somfy control point has
been programmed.
*RWRWKHVHFWLRQHQWLWOHG3URJUDPPLQJWKH¿UVW6RPI\
local control point".
or
b) The E.V.B. does not move
Press the Up or Down button and follow procedure
"c" or "d" depending on the blind's
reaction:
c) The E.V.B. still does not move
The end limits are not set and no Somfy control point has
been programmed.
Go to the section entitled "Pre-programming the
Somfy local control point".
or
d) The E.V.B.is fully raised or lowered
The end limits are set and the Somfy control
point has been programmed.
Go to the section entitled "Operation".
5.2. Pre-programming the Somfy local control point
The guide only describes commissioning using a Telis MOD/VAR type Somfy local control point. For
commissioning using any other Somfy local control point, refer to the corresponding guide.
5.1. Identifying setting steps already completed
 Press the Up and Down buttons simultaneously.
The E.V.B.PRYHVEULHÀ\WKH6RPI\ORFDOFRQWUROSRLQWKDV
been pre-programmed into the motor.

73
© 2013 Somfy SAS. All rights reserved. 06/2013
EN
a
b
=
=
5pJODJHGHV¿QVGH
course
 Press the Up button:
a) If the E.V.B. raises, the direction of rotation is correct:
go to the section entitled «Setting the end limits».
b) If the E.V.B. lowers, the direction of rotation is incorrect:
press the «my» button until the E.V.B.PRYHVWKHGLUHFWLRQ
RIURWDWLRQKDVEHHQPRGL¿HG
 Press the Up button to check the direction of rotation.
5.3. Checking the motor’s direction of rotation
 Press the Up and «my» buttons to switch between operating modes.
If the motor switches from normal kinematics mode to kinematics with
ZRUNLQJSRVLWLRQPRGHWKHEOLQGPRYHVEULHÀ\DWVORZVSHHG
If the motor switches from kinematics with working position mode to
QRUPDONLQHPDWLFVPRGHWKHEOLQGPRYHVEULHÀ\DWQRUPDOVSHHG
5.4. Choice of kinematics (Normal or with working position)
Normal kinematics: When the blind is lowered, the slats are closed.
:RUNLQJSRVLWLRQNLQHPDWLFV:KHQWKHEOLQGLVORZHUHGWKHVODWVDUHWLOWHGWRDVSHFL¿FDQJOH
XQWLOWKHRSHUDWLQJSRVLWLRQ7KLVDQJOHLVREWDLQHGHLWKHUE\DVSHFL¿FEOLQGPHFKDQLVPRUE\
tilters.
The J4 RTS actuator is factory set to operate with a blind with normal kinematics. However, the user can
choose between blind operation modes, either with normal kinematics or kinematics with working position.
Check that your J4 RTS actuator has been assembled in the blind in the lowered position with
the slats closed.
5.5. Setting the end limits
5.5.1. End limit (automatic adjustment)
 %ULHÀ\ SUHVV WKH 352* EXWWRQ RQ WKH pre-programmed
control: the E.V.B. PRYHV EULHÀ\ WKH FRQWURO SRLQW LV
programmed.
 The upper end limit is set by pressing the «mushroom».
 Go to the section entitled «Operation».
When using a blind with kinematics with w position (raising, lowering and slat direction movements
via a mechanism hidden inside the runners), it is essential to check that the apron’s top runner acti-
vates the mushroom to prevent damage to the blind.
Otherwise, set the upper end limit position below the mushroom or use mushroom extensions.

74 © 2013 Somfy SAS. All rights reserved. 06/2013
EN
5.5.2. Upper end limit (manual adjustment)
 Press the Up and Down buttons for 5 seconds the E.V.B.
PRYHVEULHÀ\
 Press the Up button.
The E.V.B. rotates in the up direction. Continue to press
the Up button until the desired upper end limit is reached
(the E.V.B. continues to be raised after the control point
button has been pressed for 2 seconds).
 Stop the E.V.B. in the desired position (the thumbwheel on
the Telis MOD/VAR type local control point can be used
to set the desired position) using the stop function on the
«mushroom».
 If the «mushroom» is not activated during setting, press
the Down button (the E.V.B. PRYHV EULHÀ\ WR FRQ¿UP
programming). If the «mushroom» is activated when the
upper end limit is set, the position is programmed just
below the «mushroom».
5.5.3. Lower end limit (manual adjustment)
 Press the Up and Down buttons for 5 seconds the blind
PRYHVEULHÀ\
 Press the Down button.
The E.V.B. rotates in the down direction. Continue to press
the Down button until the desired lower end limit is reached
(the E.V.B. continues to be lowered after the control point
button has been pressed for 2 seconds).
 Stop the E.V.B. in the desired position (the thumbwheel on
the Telis MOD/VAR local control point can be used to set
the desired position precisely).
 Press the Up button (the E.V.B.PRYHVEULHÀ\WRFRQ¿UP
programming).

75
© 2013 Somfy SAS. All rights reserved. 06/2013
EN
5.6. 3URJUDPPLQJWKH¿UVW6RPI\ORFDOFRQWUROSRLQW
5.6.1. Using a pre-programmed Somfy local control point
%ULHÀ\SUHVVWKH352*EXWWRQRQWKLVFRQWURO
point: the E.V.B.PRYHVEULHÀ\
the control point has been programmed.
5.6.2. After a power cut
 Press the Up and Down buttons on the new
control point simultaneously until the blind moves.
 %ULHÀ\SUHVVWKH352*EXWWRQRQWKLVFRQWURO
point: the E.V.B.PRYHVEULHÀ\WKHFRQWUROSRLQW
has been programmed.
5.7. Checking the settings
Check the settings of the upper and lower end limits using the Somfy local control point.
6. OPERATING
6.1. Standard operation
6.1.1. Favourite position (my)
Besides the upper and lower positions, an intermediate position known as the «favourite
position (my)» may be programmed in the motor. The “my” favourite position is pre-set in the
factory, and corresponds to the “slats lowered, sun protection” position.
To modify or delete the favourite position (my), see the section entitled «Modifying settings».
7RXVHWKHIDYRXULWHP\SRVLWLRQ%ULHÀ\SUHVVWKH©P\ª
button: the E.V.B. starts to move, then stops and angles
the slats in accordance with the angle programmed for the
favourite (my) position.
6.1.2. STOP function
The E.V.B. is moving.
%ULHÀ\SUHVVWKH©P\ªEXWWRQWKHE.V.B. stops
automatically.

76 © 2013 Somfy SAS. All rights reserved. 06/2013
EN
6.1.3. Up and Down buttons
 2Q D 7HOLV 02'9$5 W\SH ORFDO FRQWURO EULHÀ\ SUHVVLQJ
the Up or Down button raises or lowers the E.V.B. fully.
The thumbwheel is used to angle the slats.
 On a standard Telis type local control, 2 modes are
available: EU mode and US mode.
The J4 RTS motor is factory set to operate in US mode
,Q86PRGHEULHÀ\SUHVVLQJWKH8SRU'RZQEXWWRQUDLVHVRUORZHUVWKH(9%IXOO\SUHVVLQJDQG
holding the Up or Down button angles the slats.
,Q (8 PRGH SUHVVLQJ DQG KROGLQJ WKH 8S RU 'RZQ EXWWRQ UDLVHV RU ORZHUV WKH (9% IXOO\ EULHÀ\
pressing the Up or Down button angles the slats.
6.1.4. Selecting the mode. (EU mode or US mode)
 The J4 RTS motor is factory set to operate in US mode.
However, the user can choose between the EU and US
modes.
 Press the Up and Down buttons for 5 seconds the E.V.B.
PRYHVEULHÀ\
 7RFRQ¿UPWKHQHZPRGHSUHVVDQGKROGWKH©P\ªDQG
Down buttons for 2 seconds: the blindPRYHVEULHÀ\
 6.2. Operating with a Somfy sensor
The favourite (my) position
has not been programmed
and the sun disappearing
(SDP) position is not
activated.
The E.V.B. moves to the lower
end limit.
The E.V.B. moves to the upper
end limit.
The favourite (my) position
has been programmed
and the sun disappearing
(SDP) position is not
activated.
The E.V.B. moves to the
favourite (my) position.
The E.V.B. moves to the upper
end limit.
The favourite (my) position
has been programmed
and the sun disappearing
(SDP) position is activated.
The E.V.B. moves to the
favourite (my) position.
The E.V.B. moves to the sun
disappearing (SDP) position.
If the "privacy position" has been activated, the E.V.B. will not change position when the sun is
disappearing.

77
© 2013 Somfy SAS. All rights reserved. 06/2013
EN
7.1.3. Programming the “my” position
In the “my” position, press and hold the “my” button for 5
seconds: the E.V.B. PRYHV EULHÀ\ DQG WKH P\ SRVLWLRQ
has been programmed.
7.1.4. Deleting the favourite (my) position
 Press the Down button (the E.V.B. moves to the lowered
position with the slats closed).
 Press and hold the "my" and Up buttons for 2 seconds: the
slats will tilt to the programmed “My” position.
 Press and hold the "my" and Up buttons for 5 seconds: the
E.V.B.PRYHVEULHÀ\WKHP\SRVLWLRQLVGHOHWHGWKHP\
button now works only as a "STOP" button. If using a sun
sensor, the E.V.B. moves to the lowered position when the
sun appears).
7. ADDITIONAL SETTINGS
7.1. Favourite position (my)
7.1.1. Modifying/Activating the favourite (my) position
 Press the Down button (the E.V.B. moves to the lowered
position with the slats closed).
 Press and hold the "my" and Up buttons for 2 seconds (the
slats tilt to the pre-programmed "my" position).
 Position the slats as required, using the thumbwheel of the
RTS remote control to increase or decrease the slat angle.
Go to the section entitled "Testing the my position" or
"Programming the my position".
7.1.2. Testing the “my” position (optional step)
 %ULHÀ\SUHVVWKHP\EXWWRQ
On a type 1 E.V.B., the slats tilt to the closed position then
move to the newly set "my" position.
On a type 3 E.V.B., the slats move back to the horizontal
position then move to the newly set "my" position.

78 © 2013 Somfy SAS. All rights reserved. 06/2013
EN
7.2. Adding/Deleting Somfy RTS control points and sensors
7.2.2. Adding/Deleting an RTS sensor
 Find an RTS control point programmed in the motor.
 Press the PROG button on the RTS control point (A) until
the E.V.B. PRYHV EULHÀ\ WKH PRWRU LV LQ SURJUDPPLQJ
mode.
 3UHVVWKH352*EXWWRQRQWKH576VHQVRU&EULHÀ\7KH
E.V.B. PRYHVEULHÀ\
The RTS sensor is programmed or deleted from the motor.
7.2.3. Deleting all the RTS sensors
 Find an RTS control point programmed in the motor.
 Press the PROG button on the RTS control point (A) until
the E.V.B. PRYHV EULHÀ\ WKH PRWRU LV LQ SURJUDPPLQJ
mode.
 Press and hold the PROG button on the RTS sensor (C)
for 7 seconds. The E.V.B.PRYHVEULHÀ\WZLFH
The RTS sensors are deleted from the motor.
C
PROG.
C
CC
A
A
A
A
PROG.
A
PROG.
C
PROG.
A
+
-
+
7.2.1. Adding/Deleting an RTS control point
 Find an RTS control point programmed in the motor.
 Press the PROG button on the RTS control point (A) until
the E.V.B.PRYHV EULHÀ\ WKH PRWRU LV LQ SURJUDPPLQJ
mode.
 Press the PROG button on the RTS control point (B)
EULHÀ\7KHE.V.B.PRYHVEULHÀ\
The RTS control point has been programmed or deleted
from the motor.
PROG.
A
PROG.
B
A
B
A
A
A
B
B
PROG.
A
PROG.
B
-

79
© 2013 Somfy SAS. All rights reserved. 06/2013
EN
 Press the "my" button: the blind starts to move then stops
in the favourite (my) position.
 Press and hold the "my" and Up buttons for 2 seconds: the
E.V.B. is raised to the "sun disappearing" position.
 Position the slats as desired using the thumbwheel (Mod/
Var RTS remote control) or by pressing the Up and Down
buttons on a paired or temporarily assigned Mod/Var RTS
remote control to increase or reduce the slat angle.
7.3.2. Programming the “sun disappearing” position
In the "sun disappearing" position, press and hold the "my"
button on a paired RTS remote control for 5 seconds: the
E.V.B.PRYHVEULHÀ\WKHVXQGLVDSSHDULQJSRVLWLRQKDV
been programmed.
7.3.3. Deleting the "sun disappearing" position
 Press the "my" button: the blind starts to move then stops
in the favourite (my) position.
 Press and hold the "my" and Up buttons for 2 seconds: the
E.V.B. is raised to the "sun disappearing" position.
 Press and hold the "my" and Up buttons for 5 seconds:
the E.V.B.PRYHVEULHÀ\WKHVXQGLVDSSHDULQJSRVLWLRQ
is activated or deleted.
7.3.4. Activating and Deactivating the "privacy position"
the "privacy position" locks the E.V.B. in position if the sun
disappears.
 Press the "my" button: the E.V.B. starts to move then stops
in the favourite (my) position.
 Press and hold the "my" and Down buttons for 5 seconds:
the E.V.B.PRYHVEULHÀ\LWZLOOQRWFKDQJHSRVLWLRQZKHQ
the sun disappears.
7.3. Sun disappearing position (SDP)
7.3.1. Modifying/Activating the "sun disappearing" position
Note: The "sun disappearing" position is the position the slats adopt when the sun is
disappearing. This function requires the use of a sun sensor. The "sun disappearing" position
is preset in the factory but not activated, and corresponds to the "slats horizontal" position. It
is not possible to modify the “sun disappearing” position if the “my” position has been deleted.
SDP
SDP

80 © 2013 Somfy SAS. All rights reserved. 06/2013
EN
7.4. Adjusting the tilt angle of the slats in accordance with the thumbwheel
notches.
 Move the E.V.B. to a position other than the end limits.
 Press and hold the "my" and Down buttons for 5
seconds: the E.V.B.PRYHVEULHÀ\
 Press the Up button to increase the tilt angle of the slats
in accordance with the thumbwheel notches, or press
the Down button to reduce this angle. The presses are
controlled directly using the thumbwheel.
 7RFRQ¿UPWKHWLOWDQJOHRIWKHVODWVSUHVVDQGKROGWKH
“my” button for 5 seconds: the E.V.B.PRYHVEULHÀ\
7.6. Modifying the motor's direction of rotation
 Move the E.V.B. to a position other than the end limits.
 Press the Up and Down buttons for 5 seconds the E.V.B.
PRYHVEULHÀ\
 7RFRQ¿UPWKHPRWRUVQHZGLUHFWLRQRIURWDWLRQSUHVV
and hold the "my" button for 2 seconds: the E.V.B.
PRYHVEULHÀ\WKHPRWRUVGLUHFWLRQRIURWDWLRQKDVEHHQ
changed.
7.5. Modifying the thumbwheel's direction of rotation.
 Move the E.V.B. to a position other than the end limits.
 Press the Up and Down buttons for 5 seconds the E.V.B.
PRYHVEULHÀ\
 7RFRQ¿UPWKHWKXPEZKHHOVQHZGLUHFWLRQRIURWDWLRQ
press and hold the Up, "my" and Down buttons for 2
seconds: the E.V.B.PRYHVEULHÀ\WKHWKXPEZKHHOV
direction of rotation has been changed.

81
© 2013 Somfy SAS. All rights reserved. 06/2013
EN
7.7. Modifying the end limits
7.7.1. Modifying the upper end limit
 Place the E.V.B. in the intermediate position.
 Press the Up and Down buttons for 5 seconds the
E.V.B.PRYHVEULHÀ\
 Press the Up button.
The E.V.B. rotates in the up direction. Continue to press
the Up button until the desired upper end limit is reached
(the E.V.B. continues to be raised after the control point
button has been pressed for 2 seconds).
 Stop the E.V.B. in the desired position (the thumbwheel on
the Telis MOD/VAR type local control point can be used
to set the desired position) using the stop function on the
"mushroom".
 If the "mushroom" is not activated during setting, press
the Down button (the E.V.B. PRYHV EULHÀ\ WR FRQ¿UP
programming).
If the "mushroom" is activated when the upper end limit is
set, the position is programmed a few millimetres below
the "mushroom".
7.7.2. Modifying the lower end limit
 Place the E.V.B. in the intermediate position.
 Press the Up and Down buttons for 5 seconds the
E.V.B.PRYHVEULHÀ\
 Press the Down button.
The E.V.B. rotates in the down direction. Continue to press
the Down button until the desired lower end limit is reached
(the E.V.B. continues to be lowered after the control point
button has been pressed for 3 seconds).
 Stop the E.V.B. in the desired position (the thumbwheel on
the Telis MOD/VAR local control point can be used to set
the desired position precisely). With a type 3 EVB, stop the
EVB before the desired position, and adjust the limit with
the thumbwheel of the local control point.
 Press the Up button (the blind PRYHV EULHÀ\ WR FRQ¿UP
programming).

82 © 2013 Somfy SAS. All rights reserved. 06/2013
EN
8. TIPS AND RECOMMENDATIONS
8.1. Questions on the J4 RTS?
Observations Possible causes Solutions
The E.V.B. does
not operate. The wiring is incorrect. Check the wiring and modify it if
necessary.
The motor is in heat protection mode. Wait until the motor cools down.
An incorrect cable has been used. Check the cable and ensure it has 3
strands.
The Somfy control battery is weak. Check whether the battery is weak and
replace it if necessary.
The control point is not compatible. Check for compatibility and replace the
control point if necessary.
The Somfy control point used has not
been programmed into the motor.
Use a programmed control point or
program this control point.
The E.V.B. stops
too early.
The end limits have been incorrectly
set. Readjust the end limits.
I can't tilt the slats
easily The remote control is not compatible Pair then use a Telis Mod/VAR RTS remote
control
8.2. Replacing a lost or broken Somfy control point
This reset deletes all control points, however,
it does not delete the sensors and the favourite
position.
Only switch off the power for the motor to be reset.
Do not place the blind, in the Upper end limit !
 Cut the power supply for 2 seconds.
 Next:
Switch the power supply back on for 5 to 15
seconds.
Cut the power supply for 2 seconds.
Switch the power supply back on: the E.V.B.
starts to move for a few seconds.
 or
Switch the mains power supply back on.
Wait for 5s then press·and·hold·the·»mushroo
m»·for·10·seconds.
the E.V.B. PRYHVEULHÀ\.
If the E.V.B. is at the lower end limit, it will move
EULHÀ\
 Press the PROG button on the new control point
until the (9% PRYHV EULHÀ\ DOO 576 FRQWURO
points are deleted and the new RTS control point
is programmed into the motor.
A
B
2 sec.
2 sec.
15 sec.
15 sec.
5 sec.
2 sec.
2 sec.
O
F
F
F
O
F
F
F
O
N
O
N
O
N
A B
