ELIXO 500 3S RTS

EN
Installation instructions
TR
0RQWDMNÕODYX]X
FA
AR

EN
Elixo 500 3S RTS
Copyright © 2015 Somfy SAS. All rights reserved 1
CONTENTS
SAFETY INSTRUCTIONS 2
Caution - Important safety instructions 2
Introduction 2
Preliminary checks 2
Electrical pre-equipment 3
Safety instructions relating to installation 3
Regulations 4
Assistance 4
Risk prevention 4
PRODUCT DESCRIPTION 5
Area of application 5
Contents of the standard kit 5
Description of the motorisation 6
General motor size 6
Description of the interface 6
General view of a standard installation 7
Assembling the manual release handle 7
Unlocking the motor 7
Installing the motorisation 7
INSTALLATION 7
QUICK COMMISSIONING 9
Memorising the Keygo RTS remote controls for operation in complete opening mode 9
Self-learning 9
OPERATING TEST 10
Complete opening operation 10
Obstacle detection operation 10
Operation of the photoelectric cells 10
Safety edge operation (closing only) 10
6SHFL¿FRSHUDWLRQ 
GENERAL WIRING DIAGRAM 11
CONNECTING ADDITIONAL DEVICES 12
Description of the various additional devices 12
ADVANCED PARAMETER SETTING 15
Navigating the parameter list 15
Parameter value display 15
Meaning of different parameters 15
PROGRAMMING THE REMOTE CONTROLS 18
Memorising 2- or 4-button remote controls via the programming interface 18
Memorising 3-button remote controls via the programming interface 18
Memorising remote controls with no access to the programming interface 19
CLEARING THE REMOTE CONTROLS AND ALL SETTINGS 19
Clearing the memorised remote controls 19
Clearing all settings 19
LOCKING THE PROGRAMMING BUTTONS 19
DIAGNOSTICS 20
Operating code display 20
Programming code display 20
Fault and breakdown code display 20
Accessing memorised data 21
TECHNICAL DATA 21
Translated version of the guide

EN
Elixo 500 3S RTS
2 Copyright © 2015 Somfy SAS. All rights reserved
SAFETY INSTRUCTIONS
This symbol indicates a danger, the different degrees of which are described below.
DANGER
Indicates a danger which may result in immediate death or serious injury
WARNING
Indicates a danger which may result in death or serious injury
PRECAUTION
Indicates a danger which may result in minor or moderate injury
ATTENTION
Indicates a danger which may result in damage to or destruction of the product
Caution - Important safety instructions
For reasons of personal safety, it is important to follow all the instructions, as incorrect installation can lead to serious
injury. Retain these instructions.
The motorisation must be installed and adjusted by a professional motorisation and home automation installer, in
compliance with the regulations of the country in which it is to be used.
The user manual and installation manual must be given to the end user, explicitly stating that installation, adjustment and
maintenance of the motorisation must be performed by a professional motorisation and home automation installer.
Introduction
ƕImportant information
7KLVSURGXFWLVDPRWRULVDWLRQIRUVOLGLQJJDWHVIRUUHVLGHQWLDOXVHDVGH¿QHGLQVWDQGDUG(1ZLWKZKLFKLW
complies. The main purpose of these instructions is to satisfy the requirements of the aforementioned standard and to
ensure the safety of equipment and persons.
WARNING
Any use of this product outside the area of application described in this manual is prohibited (see «Area of application»
paragraph in the installation manual). Such use, and any failure to comply with the instructions given in this guide,
absolves Somfy of any liability and invalidates the warranty.
The use of any safety accessories not validated by Somfy is prohibited.
In case of any doubts when installing the motorisation, or to obtain additional information, consult the website
www.somfy.com.
7KHLQVWUXFWLRQVPD\EHPRGL¿HGLIDQGZKHQWKHUHLVDFKDQJHWRWKHVWDQGDUGVRUWRWKHPRWRULVDWLRQ
Preliminary checks
ƕInstallation environment
ATTENTION
Do not spray water onto the motorisation.
Do not install the motorisation in an explosive environment.
ƕCondition of the gate to be motorised
Do not motorise a gate which is in bad condition or incorrectly installed.
Before installing the motorisation, check that:
 the gate is in good mechanical condition
 it can be manoeuvred easily with no points of resistance
 the mountings for the gate are in good condition
 the gate is not equipped with any manual or electric locking system (unless compatible with the Somfy motorisation)
 the points where the motorisation will be attached are sturdy and in perfect condition.

EN
Elixo 500 3S RTS
Copyright © 2015 Somfy SAS. All rights reserved 3
Electrical pre-equipment
DANGER
The installation of the power supply must comply with the standards in force in the country in which the motorisation is
LQVWDOOHGDQGPXVWEHFDUULHGRXWE\TXDOL¿HGSHUVRQQHO
The electric line must be exclusively reserved for the motorisation and equipped with protection, comprising:
 D$IXVHRUEUHDNHU
 DGLIIHUHQWLDOW\SHGHYLFHP$
$QDOOSROHVXSSO\FXWRIIGHYLFHPXVWEHSURYLGHG
,WLVUHFRPPHQGHGWKDW\RX¿WDOLJKWQLQJFRQGXFWRUPD[LPXPUHVLGXDOYROWDJHN9
ƕCable feed
8QGHUJURXQGFDEOHVPXVWEHHTXLSSHGZLWKDSURWHFWLYHVKHDWKZLWKDVXI¿FLHQWGLDPHWHUWRFRQWDLQWKHPRWRUFDEOHDQG
the accessories cables.
)RURYHUJURXQGFDEOHVXVHDFDEOHJURPPHWWKDWZLOOZLWKVWDQGWKHZHLJKWRIYHKLFOHVUHI
Safety instructions relating to installation
DANGER
Do not connect the motorisation to a power source (mains, battery or solar) before installation is complete.
WARNING
(QVXUHWKDWDQ\GDQJHU]RQHVFUXVKLQJFXWWLQJWUDSSLQJEHWZHHQWKHGULYHQSDUWDQGWKHVXUURXQGLQJ¿[HGHOHPHQWV
caused by the opening movement of the driven part are avoided or indicated on the installation (see the section on risk
prevention).
WARNING
Modifying one of the elements provided in this kit or using an additional element not recommended in this manual is
strictly prohibited.
Monitor the gate as it moves and keep people away from it until installation is complete.
Do not use adhesive to secure the motorisation.
Manual back release device: see paragraph concerning this device in the user manual for the motorisation.
WARNING
Manual unlocking may result in uncontrolled movement of the gate.
ATTENTION
,QVWDOODQ\¿[HGFRQWUROGHYLFHDWDKHLJKWRIDWOHDVWPDQGZLWKLQVLJKWRIWKHJDWHEXWDZD\IURPPRYLQJSDUWV
After installation, ensure that:
 the mechanism is correctly adjusted
 the manual back release device is operating correctly
 WKHPRWRULVDWLRQFKDQJHVGLUHFWLRQZKHQWKHJDWHHQFRXQWHUVDQREMHFWPPKLJKSRVLWLRQHGKDOIZD\XSWKHOHDI
ƕSafety devices
WARNING
For operation in automatic mode or remote control, photoelectric cells must be installed.
For operation in automatic mode, or if the gate faces a public road, an orange light type signalling device may be required
to comply with the regulations in the country in which the motorisation is installed.
ƕClothing precautions
Take off any jewellery (bracelet, chain, etc.) during installation.
For manoeuvring, drilling and welding operations, wear appropriate protection (special glasses, gloves, ear protection,
etc.).

EN
Elixo 500 3S RTS
4 Copyright © 2015 Somfy SAS. All rights reserved
Regulations
620)<GHFODUHVWKDWWKLVSURGXFWFRPSOLHVZLWKWKHHVVHQWLDOUHTXLUHPHQWVRIDSSOLFDEOH(XURSHDQGLUHFWLYHV$
'HFODUDWLRQRI&RQIRUPLW\LVDYDLODEOHDWZZZVRPI\FRPFH(/,;26576
Assistance
<RXPD\HQFRXQWHUGLI¿FXOWLHVRUKDYHTXHVWLRQVZKHQLQVWDOOLQJ\RXUPRWRULVDWLRQ
Do not hesitate to contact us; our specialists are on hand to answer all your questions. Internet: www.somfy.com.
Risk prevention
WARNING
RISK PREVENTION - MOTORISATION OF A SLIDING GATE FOR RESIDENTIAL USE
ƕRisk zones: measures to be taken to eliminate risks.
RISK SOLUTION
=21(
Risk of crushing during closing
2EVWDFOHGHWHFWLRQEXLOWLQWRWKHPRWRULVDWLRQFRQ¿UPGHWHFWLRQXVLQJDIRUFH
PHDVXUHPHQWVHH)RUFHPHDVXUHPHQWSDUDJUDSK
For operation with automatic closing, install photoelectric cells (see
installation manual)
=21(
Risk of trapping and cutting on the
surface of the gate
2EVWDFOHGHWHFWLRQEXLOWLQWRWKHPRWRULVDWLRQFRQ¿UPGHWHFWLRQXVLQJDIRUFH
PHDVXUHPHQWVHH)RUFHPHDVXUHPHQWSDUDJUDSK
(OLPLQDWHDQ\JDSPP
=21(
Risk of crushing with an adjoining
¿[HGSDUWXSRQRSHQLQJ
2EVWDFOHGHWHFWLRQEXLOWLQWRWKHPRWRULVDWLRQFRQ¿UPGHWHFWLRQXVLQJDIRUFH
PHDVXUHPHQWVHH)RUFHPHDVXUHPHQWSDUDJUDSK
3URWHFWLRQYLDVDIHW\GLVWDQFHVVHH¿JXUH
=21(
Risk of trapping and crushing
between the roller rails and bearings
(OLPLQDWHDOOVKDUSHGJHVRQWKHJXLGHUDLOV
(OLPLQDWHDQ\JDSPPEHWZHHQWKHUDLOVDQGWKHEHDULQJV
=21(
Risk of movement force and crushing
at the pinion/rack connection
(OLPLQDWHDQ\JDSPPEHWZHHQWKHSLQLRQDQGWKHUDFN
No protection is required if the gate has continuous control or if the danger zone is more than 2.5 m
above ground or any other permanent access level.
Zone 1
Zone 2
Zone 3
Zone 4
Zone 4
Zone 5
)LJXUH6DIHW\GLVWDQFH

EN
Elixo 500 3S RTS
Copyright © 2015 Somfy SAS. All rights reserved 5
Td
Fd
25N
150N
400N
1400N
1
ƕForce measurement
7DNHWKHPLGKHLJKWPHDVXUHPHQWRIWKHJDWHE\SRVLWLRQLQJWKHPHDVXULQJWRROSHUSHQGLFXODU
to the panel that is closing.
The standard stipulates:
 G\QDPLFIRUFH1
 G\QDPLFWLPHPV
Other specifications set out in this standard are validated by Somfy during initial type testing.
PRODUCT DESCRIPTION
Area of application
The ELIXO 3S motorisation is designed to motorise a sliding gate weighing up to 500 kg.
Number of cycles per hour: 20 cycles/hour spread evenly throughout the hour
To ensure the safety of all equipment and persons, respect the information given in the table:
For a gate weighing ... use ... Ref.
0 to 300 kg a passive rubber block on the end of the gate 9014597
300 to 500 kg a passive rubber block on the end of the gate 9014598
If using a different rubber block to those listed above, ensure that the installation conforms with current regulations.
Contents of the standard kit
1 Elixo 24 V Motor x 1
2 Keygo RTS remote control x 2
Ground mounting kit:
3a Lag screws x 4
3b Nut x 8
3c Washer x 8
3d Plug x 4
4 Manual release handle assembly x 1
5 Handle locking key x 2
6 End limit brackets x 2
7 Drilling template x 1
12
6
7
3a
3d
3b3c
5
4

EN
Elixo 500 3S RTS
6 Copyright © 2015 Somfy SAS. All rights reserved
Description of the motorisation
1 Upper cover screw
2 Upper cover
3 Cover
4 24V motor
5 Reduction unit
6 Electro-mechanical end limit unit
7 Pinion
8 Manual release mechanism
9 Control unit
10 Battery pack (optional, ref. 9016732):
a 2 backup batteries
b Battery holder tray
c Battery power supply management card
11 Battery (option, ref. 9001001)
12 Fuse (250 V/5 A) for 230 V lighting output
13 Spare fuse (250 V/5 A)
General motor size
263 163
274
80,5
196
1
2
4
3
8
6
7
10a
10c 10b
11
12
13
9
5
Button Function Button Function
- navigate the parameters and codes list:
. short press = scroll through individual parameters
. press and hold = scroll rapidly through parameters
- Press 0.5 s: access and exit the parameter setting menu
- Press 2 s: trigger self-learning
- Press 7 s: clear self-learning and parameters
- interrupt self-learning
- start self-learning cycle
FRQ¿UPSDUDPHWHUVHOHFWLRQ
FRQ¿UPSDUDPHWHUYDOXH
- Press 2 s: memorise the remote controls
- Press 7 s: Clearing the remote controls
- modify a parameter value
. short press = scroll through individual parameters
. press and hold = scroll rapidly through parameters
- use of forced operating mode
Description of the interface
3-digit LCD screen
Display of parameters, codes (operation, programming, faults and breakdowns) and memorised data.
Parameter value display:
¿[HG YDOXHVHOHFWHGDXWRDGMXVWHG
ÀDVKLQJ YDOXHVHOHFWDEOHIRUSDUDPHWHU

EN
Elixo 500 3S RTS
Copyright © 2015 Somfy SAS. All rights reserved 7
Installing the motorisation
Fitting the mounting system
The motor mounting kit provided is to be used on a concrete base. For all
RWKHUW\SHVRIPRXQWLQJXVHWKHDSSURSULDWH¿WWLQJV
[1]. Position the template:
parallel to the gate,
with the symbol on the pinion pointing towards the gate,
by moving it by 25 mm in relation to the front line of the rack (if the
UDFNLV¿WWHGZLWKDFRYHUPHDVXUHIURPWKHOLQHRQWKHUDFNQRWRQWKH
cover),
so that it does not obstruct movement and to ensure the gate is able to
open and close completely.
[2]. Mark the location for the ground mountings.
[3]. Drill to a depth of 85 mm.
[4]. Insert the plugs.
[5]. Tighten the lag screws on:
the threaded section for a rack height of between 120 and 130 mm,
the threaded section + the unthreaded section for a rack height of
between 100 and 110 mm.
PPIRUPRXQWLQJRQWKHJURXQGRQDÀDWFRQFUHWHVXUIDFH
[6]. Screw a nut and a washer onto each lag screw.
:KHQ PRXQWLQJ RQ WKH JURXQG DIWHU VHFXULQJ WKH PRWRU ¿W D UDFN ZLWK
oblong mounting holes to allow the clearance between the rack and pinion
WREHDGMXVWHG
14 mm
25 mm
INSTALLATION
The motorisation must be disengaged during installation.
Assembling the manual release handle
To facilitate tightening of the lag screws, use 2 nuts to form a
"double nut".
h
25
23
100 ≤ h ≤ 130
85
77
45 mm
35 mm
60 mm
100 mm<h<110 mm
120 mm<h<130 mm
E
EF
G
C
D
A
B
C
E
E
D
F
G
i
i
H
General view of a standard installation
A Motor
B Rack
C Aerial
D Orange light
E Set of photoelectric cells
F Key lock
G Passive rubber block
H End limit brackets
i End stops in the ground
[1]. ,QVHUWWKHUHOHDVHKDQGOHLQWRWKHVSHFL¿FKRXVLQJRQWKHPRWRU
[2]. Tighten the release handle.
[3]. Fit the screw cover.
Unlocking the motor
[1]. Turn the key a quarter of a turn to the left.
[2]. Turn the release handle to the right.
Do not forcibly push the gate. Hold the gate over its entire travel during manual manoeuvres.

EN
Elixo 500 3S RTS
8 Copyright © 2015 Somfy SAS. All rights reserved
Fitting the end limit brackets
[1]. Manually move the gate to the open position.
[2]. Position a bracket onto the rack so that it activates the motor end limit contact.
[3]. Screw the bracket onto the rack.
[4]. 0DQXDOO\PRYHWKHJDWHWRWKHFORVHGSRVLWLRQWKHQUHSHDWVWHSVDQGWR¿WWKH
second bracket to the rack.
5
L N
230Vac
12
230Vac
DXSX
h
25
>23
h100 130
2 mm
50
NO OK
Mounting the motor
[1]. Position the motor on the lag screws, insert it and push it towards the gate.
[2]. Ensure the pinion is correctly positioned under the rack.
[3]. Set the height of the motor and/or the rack to ensure a clearance of approximately 2
mm between the rack and the pinion. This setting is important to prevent premature
wear of the pinion and rack; the pinion must not be supporting the weight of the gate.
[4]. Check:
that the setting nuts all come into contact with the base of the motor,
the motor is level,
the gate runs correctly,
WKHFOHDUDQFHEHWZHHQWKHUDFNDQGSLQLRQGRHVQRWYDU\VLJQL¿FDQWO\RYHUWKHJDWHV
travel.
[5]. )LWDZDVKHUDQGQXWRQWRHDFKODJVFUHZLQRUGHUWR¿WWKHPRWRU
Connection to the power supply
Connect the live (L) to terminal 1 on the motor.
Connect the neutral (N) to terminal 2 of the motor.
Connect the earth wire to the earth terminal on the base of the motor.
The earth wire must always be longer than the live and neutral to ensure
that it is the last to be disconnected if the connector is pulled out.
The transformer is wired to terminals 3 and 4. Do not alter the connections.
Switch on the power to the installation before commissioning.
Before quick commissioning
[1]. Ensure the rail is clean.
[2]. Manually move the gate to the intermediate position.
Re-engage the motorisation
[1]. Turn the release handle to the left.
[2]. Move the gate manually until the drive mechanism re-locks.
[3]. Turn the key a quarter of a turn to the right.
[1]
[2]

EN
Elixo 500 3S RTS
Copyright © 2015 Somfy SAS. All rights reserved 9
QUICK COMMISSIONING
Memorising the Keygo RTS remote controls for operation in complete opening mode
[1]. Press and hold the "PROG" button (2 s).
The screen displays "F0".
[2]. Press the button of the remote control that will open the gate fully.
The screen displays "Add".
It is possible to store up to 40 command channels.
If this procedure is carried out using a channel which has already been memorised,
this channel will be cleared.
2 s
H0 H0F0 Add
Self-learning
6HOIOHDUQLQJDOORZVWKHJDWHVVSHHGPD[WRUTXHDQGVORZGRZQ]RQHVWREHDGMXVWHG
- Self-learning the gate's travel is essential when commissioning the motor.
- The gate must be in the intermediate position before self-learning starts.
-During self-learning, the obstacle detection function is not active. Remove any objects or obstacles
and do not allow any persons near or inside the operating range of the motorisation.
- To carry out an emergency stop during self-learning, use a stored remote control or press one of the interface buttons.
Start self-learning
[1]. Press and hold the "SET" button (2 s).
Release the button when the screen displays "H1".
[2]. Press "OK" to start self-learning.
Self-learning must start with the gate being opened.
The gate performs two complete Opening and Closing cycles.
6HOIOHDUQLQJFRUUHFW
6HOIOHDUQLQJLQFRUUHFW
2 s
H0 H1
H2
H4
H2
H4
H0
C1
[1] [2]
2 s
...
...
If self-learning starts when the gate is closed, stop the self-learning in progress
(press a control button: motor electronics, memorised remote control, wired
control point, etc.), move the slide as shown opposite, then restart self-learning.
If self-learning is correct, the display indicates "C1".
If self-learning has not completed correctly, the display indicates "H0".
At the end of installation, it must be checked that the limitation of forces complies with appendix A of the standard EN 12 453.

EN
Elixo 500 3S RTS
10 Copyright © 2015 Somfy SAS. All rights reserved
OPERATING TEST
Self-learning can be interrupted by:
activating a safety input (photoelectric cells, etc.)
the appearance of a technical fault (thermal protection, etc.)
pressing a control button (motor electronics, memorised remote control, wired control point, etc.).
In case of interruption, the display indicates "H0" and the motor returns to "Awaiting setting" mode.
In "Awaiting setting" mode, the radio controls operate and the gate moves very slowly. This mode must only be used during installation. Self-learning must
be successfully performed before the gate can be used normally.
During self-learning, if the gate is stationary, pressing "SET" will exit self-learning mode.
It is possible to access self-learning mode at any time including when the self-learning cycle has already been completed and the display
indicates "C1".
STOP
STOP
C2
C4 C2
Complete opening operation
Obstacle detection operation
Obstacle detection when opening = stop + partial reversal.
Obstacle detection when closing = stop + complete reopening.
Operation of the photoelectric cells
With the photoelectric cells connected to the dry/Cell contact (terminals 19-20) and Cell safety input parameter P07 = 1.
Cells obscured with gate closed/open = the gate cannot be moved until the operating mode changes to deadman operation (after 3 minutes).
Cells obscured when opening = the state of the cells is not taken into account and the gate continues to move.
Cells obscured when closing = stop + complete reopening.
Safety edge operation (closing only)
Activation of the safety edge when closing = stop + complete reopening.
6SHFL¿FRSHUDWLRQ
See the user booklet.

EN
Elixo 500 3S RTS
Copyright © 2015 Somfy SAS. All rights reserved 11
Terminals Terminal
indications
Connection Comments
1
2
L
N
230 V power supply Note: Earth connection available on the motor body
3
4
L
N
Transformer primary supply output
5
6
N
L
230 V lighting output Max. power 500 W
Protected by 5A time-delay fuse
7
8
Conductor
Braid
Aerial
9
10
11
Contact
Shared
Contact
PEDESTRIAN/CLOSING control input
COMPLETE/CLOSING control input
PEDESTRIAN/OPENING cycle programmable (parameter P37)
COMPLETE/CLOSING cycle programmable (parameter P37)
12
13
Shared
Contact
Auxiliary contact output 24 V, 1.2 A outage
Safety Extra Low Voltage (SELV)
14
15
Contact
Shared
Safety input 3 - programmable
16 Contact Safety test output
17
18
Contact
Shared
Safety input 2 - safety edge Only compatible with a dry contact safety edge
19
20
21
22
Contact
Shared
24 V
0 V
Safety input 1 - Cells
Safety device power supply
BUS compatible (see parameter table)
Used to connect RX cell
Permanent if autotest not selected, controlled if autotest selected
23
24
24 V
0 V
24 V accessories power supply 1.2 A max for all accessories on all outputs
25
26
24 V - 15 W
0 V
24 V - 15 W orange light output
27
28
9 V - 24 V
0 V
9 V or 24 V low voltage supply input Compatible with 9.6V and 24V batteries or solar supply
At 9 V, degraded operation
At 24 V, normal operation
29
30
31
EOS O
Shared
EOS F
Motor end limit
32
33
1
2
Motor
34
35 24VAC Transformer
GENERAL WIRING DIAGRAM
TX RX
24 Vdc
230 V
50 Hz
... ...
230 V
500 W max.
0.75 mm² 0.75 mm² 1.5 mm²
1.5 mm²
Ant.
7 8
Sec Prog
12 13
Aux
14 15
9 10 11
Sec BP
Test
16 17 18 23
24V dc
-
24
+-+
19 21 22
24V Cell
-
20
+
Sec Cell EOS O EOS F
29 30 31
24Vac
34 35
Flash
25 26 32 33
Motor
M1
27 28
Batt.
+-
Lamp
5 6
L N
230Vac
1 2
230Vac
3 4
Motor end limit Motor Transformer

EN
Elixo 500 3S RTS
12 Copyright © 2015 Somfy SAS. All rights reserved
Description of the various additional devices
Photoelectric cells (Fig. 1)
Three types of connection are possible:
A: Without autotest: programme parameter "P07" = 1.
B: With autotest: programme parameter "P07" = 3.
Allows an automatic test to be carried out to check the operation of the photoelectric cells each time the gate moves.
If the operating test result is negative, the gate cannot be moved until the operating mode changes to deadman operation (after 3 minutes).
C: BUS: programme parameter "P07" = 4. Self-learning must be repeated after the cell BUS has been connected.
If cells are removed, it is essential to create the bridge between terminals 19 and 20.
It is compulsory to install photoelectric cells if:
- the automatic control device is being controlled remotely (user unable to see it),
- automatic closing is activated (P01 = 1, 3 or 4).
It is compulsory to install photoelectric cells WITH AUTOTEST (P07 = 3 or 4) if the automatic control device is being controlled by a Tahoma
control box.
5HÀH[SKRWRHOHFWULFFHOO)LJ
Without autotest: programme parameter "P07" = 1.
With autotest: programme parameter "P07" = 2.
Allows an automatic test to be carried out to check the operation of the photoelectric cell each time the gate moves.
If the operating test result is negative, the gate cannot be moved until the operating mode changes to deadman operation (after 3 minutes).
It is compulsory to install photoelectric cells WITH AUTOTEST (P07 = 2) if the automatic control device is being controlled by a Tahoma
control box.
Orange light (Fig. 3)
Programme parameter "P12" according to the required operating mode:
No warning prior to gate movement: "P12" = 0.
With 2 s warning prior to gate movement: "P12" = 1.
Connect the aerial cable to terminals 7 (conductor) and 8 (braid).
Wired code keypad (Fig. 4)
Not operational using solar power.
Aerial (Fig. 5)
Safety edge (Fig. 6)
Not operational using solar power.
Only active when closing (for a safety edge active when opening, use the programmable safety input and programme parameter "P10" = 1).
With autotest: programme parameter "P08" = 2.
Allows an automatic test to be carried out to check the operation of the safety edge each time the gate moves.
If the operating test result is negative, the gate cannot be moved until the operating mode changes to deadman operation (after 3 minutes).
If the safety edge is removed, it is essential to create the bridge between terminals 17 and 18.
24 V battery (Fig. 7)
[1]. Position and tighten the battery power supply management card.
[2]. Position the batteries.
[3]. Make the connections.
For more details, refer to the 24V battery instructions.
Normal operation: nominal speed, accessories functional.
Life: 5 cycles/24 hrs
9.6 V battery (Fig. 8)
Degraded operation: speed reduced and constant (no slowdown at end limit), 24 V accessories inactive (including cells).
Life: 5 cycles/24 hrs
Solar kit (Fig. 9)
$GMXVWWKHOHQJWKRIWKHFDEOHFRQQHFWLQJWKHPRWRUWRWKHEDWWHU\KRXVLQJ,WVKRXOGEHDVVKRUWDVSRVVLEOHWRSUHYHQWYROWDJHGURSV
5m cable provided with the solar kit.
Note: Join wires of the same colour to prevent polarity reversal.
Area lighting (Fig. 10)
For class I lighting, connect the earth wire to the earth terminal on the base of the motor.
Note: The earth wire must always be longer than the live and neutral wires in case of detachment.
Several lights may be connected provided the total power does not exceed 500 W.
CONNECTING ADDITIONAL DEVICES

EN
Elixo 500 3S RTS
Copyright © 2015 Somfy SAS. All rights reserved 13
1
2
21
22
22
TX
RX
1
2
3 20
21
5 19
1
1
2
21
22
24
TX
RX
1
2
3 20
23
5 19
3
TX RX
P
23
24V dc
-
24
+
19 21 22
24V Cell
-
20
+
Sec Cell Fla
25
+
TX1 RX1TX RX TX2 RX2
TX1 RX1 TX2 RX2
1
2
21
22
22
TX1
RX1
1
2
3 20
21
5 3 RX2
1
2
21
22
22
TX2
RX2
1
2
3 5 RX1
21
5 19
c BP
18 23
24V dc
-
24
+
19 21 22
24V Cell
-
20
+
Sec Cell
c BP
18 23
24V dc
-
24
+
19 21 22
24V Cell
-
20
+
Sec Cell
TX RX
1
2
20
19
19
TX
RX
1
2
3 -
20
5 -
Sec BP
17 18 23
24V dc
-
24
+
19 21 22
24V Cell
-
20
+
Sec Cell
4
C
Sec BP
17 18 23
24V dc
-
24
+
19 21 22
24V Cell
-
20
+
Sec Cell
1
2
20
19
19
TX1
RX1
1
2
3 -
20
5 -
1
2
20
19
19
TX2
RX2
1
2
3 -
20
5 -
1

EN
Elixo 500 3S RTS
14 Copyright © 2015 Somfy SAS. All rights reserved
5
Ant.
7 8 9 10
5 mm
15 mm
E
-
+
H -
H -
P2
M
-
-
P1
T3
-
-
C3 -
R3
T2
-
11
C2
R2
10
-
T1
C1
-
-
R1 -
V
V
24
23
Sec Prog
12 13
Aux
14 15
9 10 11
Sec BP
Test
16 17 18 23
24V dc
-
24
+
19 21 22
24V Cell
-
20
+
Sec Cell
4
2
K
M
24
23
L
G
16
18
J 17
Sec Prog
14 15
Sec BP
Test
16 17 18 23
24V dc
-
24
+
19 21 22
24V Cell
-
20
+
Sec Cell Fla
25 2
+
6
7
B1
B2
24V
230V
EOS F
31
24Vac
34 35
32 33
Motor
M1
2 ou 3
1
2
23
24
3
4
16
20
5 19
Sec Prog
14 15
Sec BP
Test
16 17 18 23
24V dc
-
24
+
19 21 22
24V Cell
-
20
+
Sec Cell Fla
25
+
3
24V dc
-
24
+
Flash
25 26 27 28
Batt.
+-
-+
2 3
+-
1
2
3
EOS O E
29 30
Flash
25 26 27 28
Batt.
+ -
- +
... ...
500 W max.
Lamp
5 6
0Vac
4
1098
EOS O E
29 30 3
Flash
5 26 27 28
Batt.
+-
-+
or

EN
Elixo 500 3S RTS
Copyright © 2015 Somfy SAS. All rights reserved 15
Meaning of different parameters
Code Description Values (bold = default) Setting
completed Comments
P01 Complete cycle
operating mode
0: sequential Each press on the remote control causes the motor to move (initial position: gate
closed) as per the following cycle: open, stop, close, stop, open, etc.
1: sequential + timed close Operation in
automatic closing
mode is only
authorised if the
photoelectric cells
DUH¿WWHG
i.e. P07=1 to 4.
In sequential mode with automatic timed close:
- the gate closes automatically after the time delay programmed
in parameter "P02",
- pressing a button on the remote control interrupts the
movement taking place and the timed close (the gate remains
open).
2: semiautomatic In semiautomatic mode:
- pressing a button on the remote control during opening has no effect,
- pressing a button on the remote control during closing causes it to reopen.
3: automatic
Operation in
automatic closing
mode is only
authorised if the
photoelectric cells
DUH¿WWHG
i.e. P07=1 to 4.
These operating
modes are not
compatible with
remote control using
a TaHoma unit
In automatic closure mode:
- the gate closes automatically after the time delay programmed
in parameter "P02",
- pressing a button on the remote control during opening has
no effect,
- pressing a button on the remote control during closing causes
it to reopen,
- pressing a button on the remote control during the closing time
delay restarts the time delay (the gate will close when the new
time delay has elapsed).
,IWKHUHLVDQREVWDFOHLQWKHFHOOVGHWHFWLRQ]RQHWKHJDWHZLOO
not close. It will close once the obstacle is removed.
4: automatic + cell blocking After the gate is opened, movement in front of the cells (safe
FORVXUHZLOOFORVHWKHJDWHDIWHUDVKRUWWLPHGHOD\¿[HGDW
seconds).
If there is no movement in front of the cells, the gate will close
automatically after the timed close programmed in parameter
"P02".
,IWKHUHLVDQREVWDFOHLQWKHFHOOVGHWHFWLRQ]RQHWKHJDWHZLOO
not close. It will close once the obstacle is removed.
GHDGPDQVFRQWUROZLUH In wired deadman mode*
- the gate can only be controlled by continuous action on a wired control,
- the radio controls are inactive.
P02 Complete operating
mode automatic timed
closing
0 to 30 (value x 10 s = time delay
value)
2: 20 s
If value 0 is selected, the gate immediately closes automatically.
ADVANCED PARAMETER SETTING
Navigating the parameter list
Press ... to...
Access and exit the parameter setting menu
Navigate the parameters and codes list:
. short press = normal scrolling through individual parameters
. press and hold = rapid scrolling through parameters
&RQ¿UP
. the parameter selection
. the parameter value
Increase/decrease the value of a parameter
. short press = normal scrolling through individual parameters
. press and hold = rapid scrolling through parameters
Parameter value display
If the display is ¿[HG, the displayed value is the value selected for this parameter.
If the display is ÀDVKLQJ, the displayed value is the value selectable for this parameter.
Press SET to exit the parameter setting menu.

EN
Elixo 500 3S RTS
16 Copyright © 2015 Somfy SAS. All rights reserved
Code Description Values (bold = default) Setting
completed Comments
P03 Pedestrian cycle
operating mode
0: identical to complete cycle
operating mode The pedestrian cycle
operating mode
parameters can only
be set if P01 = 0 to 2
The P03 = 2
operating mode is
not compatible with
remote control using a
TaHoma unit.
Pedestrian cycle operating mode is identical to the complete
cycle operating mode selected.
1: without automatic closing If P01=1, the gate does not close automatically following a
pedestrian opening command.
2: with automatic closing Operation in automatic closing mode is only authorised if the
SKRWRHOHFWULFFHOOVDUH¿WWHGLH3 WR
Irrespective of the value of P01, the gate does not close
automatically following a pedestrian opening command.
The automatic closing time delay can be programmed in
parameter "P04" (short time delay) or parameter "P05" (long
time delay).
P04 Short automatic closing
time delay in pedestrian
cycle
0 to 30 (value x 10 s = time delay
value)
2: 20 s
If value 0 is selected, the gate immediately closes automatically.
P05 Long automatic closing
time delay in pedestrian
cycle
0 to 99 (value x 5 min = time delay
value)
0: 0
Value 0 must be selected if the short automatic closing time delay in pedestrian cycle
is active.
P06 Pedestrian opening
amplitude
1 to 9
1: 80 cm
1: minimum pedestrian opening
...
PD[LPXPSHGHVWULDQRSHQLQJDSSUR[LPDWHO\RIWKHJDWHVWRWDOWUDYHO
P07 Cell safety input 0: inactive
1: active
2: active with autotest via test
output
3: active with autotest via power
supply switching
4: bus cells
0: the safety input is not taken into account.
1: safety device without autotest; it is essential to check that it is operating correctly
every 6 months.
WKHDXWRWHVWLVUXQRQWKHGHYLFHIRUHDFKRSHUDWLQJF\FOHYLDWKHWHVWRXWSXWUHÀH[
photocell application with autotest.
3: the autotest is run on the device for each operating cycle via power supply switching
of the cell power supply output (terminals 21 and 22).
4: bus cells application.
P08 Safety edge safety
input
0: inactive
1: active
2: active with auto-test
0: the safety input is not taken into account.
1: safety device without auto-test.
2: the autotest is run on the device for each operating cycle via the test output.
P09 Programmable safety
input
0: inactive
1: active
2: active with autotest via test
output
3: active with autotest via power
supply switching
0: the safety input is not taken into account.
1: safety device without auto-test.
2: the autotest is run on the device for each operating cycle via the test output.
3: the autotest is run on the device for each operating cycle via power supply switching
of the cell power supply output (terminals 21 and 22).
P10 Programmable safety
input - function
0: active closing
1: active opening
2: active closing + ADMAP
3: all movement disabled
0: the programmable safety input is only active when closing.
1: the programmable safety input is only active when opening.
2: the programmable safety input is only active when closing and, when activated, the
gate cannot be opened.
3: emergency stop application; if the programmable safety input is activated, the gate
cannot be moved.
P11 Programmable safety
input - action
0: stop
1: stop + partial reversal
2: stop + complete reversal
0: emergency stop application, compulsory if P10=3
disabled if a safety edge is connected to the programmable safety input.
1: recommended for a safety edge application.
2: recommended for a cell application.
P12 Orange warning light 0: no warning
1: with 2 s warning prior to
movement
,IWKHJDWHRSHQVRQWRDSXEOLFSDWKWKHZLWKZDUQLQJFRQ¿JXUDWLRQPXVWEHVHOHFWHG
P12=1.
P13 Area lighting output 0: inactive
1: controlled operation
2: automatic + controlled
operation
0: the area lighting output is not taken into account.
1: the area lighting is remotely controlled.
2: the area lighting is remotely controlled when the gate is stationary
+ the area lighting comes on automatically when the gate is moving, and remains
on when it stops moving for the duration of the time delay programmed in parameter
"P14".
P13=2 is compulsory for operation in automatic mode.
P14 Area lighting time delay 0 to 60 (value x 10 s = time delay
value)
6: 60 s
If value 0 is selected, the area lighting goes out as soon as the gate stops moving.
P15 Auxiliary output 0: inactive
1: automatic: gate open indicator
light
2: automatic: timed bistable
3: automatic: one-touch
4: controlled: bistable (ON-OFF)
5: controlled: one-touch
6: controlled: timed bistable
0: the auxiliary output is not taken into account.
WKHJDWHLQGLFDWRUOLJKWLVRIIZKHQWKHJDWHLVFORVHGÀDVKLQJZKHQWKHJDWHLV
moving and on when the gate is open.
2: output activated when movement starts, during movement then deactivated at the
end of the time delay programmed in parameter "P16".
3: one-touch at contact when movement starts.
4: operation changes as follows each time the memorised button on the radio control
point is pressed: ON, OFF, ON, OFF...
5: one-touch at contact by pressing the memorised button on the radio control point.
6: output activated by pressing the memorised button on the radio control point then
deactivated at the end of the time delay programmed in parameter "P16".
P16 Auxiliary output time
delay
0 to 60 (value x 10 s = time delay
value)
6: 60 s
The auxiliary output time delay is only active if the value selected for P15 is 2 or 6.

EN
Elixo 500 3S RTS
Copyright © 2015 Somfy SAS. All rights reserved 17
Code Description Values (bold = default) Setting
completed Comments
P19 Closing speed 1: slowest speed
at
10: fastest speed
Default value: 5
,IWKLVSDUDPHWHULVPRGL¿HGWKHLQVWDOOHUPXVWFKHFNWKDWWKHOLPLWDWLRQRIIRUFHV
complies with appendix A of the standard EN12 453 or install a safety edge.
P20 Opening speed 1: slowest speed
at
10: fastest speed
Default value: 5
P21 Closing slowdown zone 1: shortest slowdown zone
at
5: longest slowdown zone
Default value: 1
P22 Opening slowdown
zone
1: shortest slowdown zone
at
5: longest slowdown zone
Default value: 1
P25 Closing torque limitation 1: minimum torque
at
10: maximum torque
Adjusted at the end of self-learning
,IWKLVSDUDPHWHULVPRGL¿HGWKHLQVWDOOHUPXVWFKHFNWKDWWKHOLPLWDWLRQRIIRUFHV
complies with appendix A of the standard EN12 453 or install a safety edge.
If the torque is too low, there may be erratic obstacle detection.
If the torque is too high, the installation may not comply with the standard.
P26 Opening torque
limitation
1: minimum torque
at
10: maximum torque
Adjusted at the end of self-learning
P27 Closing slowdown
torque limitation
1: minimum torque
at
10: maximum torque
Adjusted at the end of self-learning
P28 Opening slowdown
torque limitation
1: minimum torque
at
10: maximum torque
Adjusted at the end of self-learning
P33 Obstacle detection
sensitivity
0: very low sensitivity
1: slightly sensitive
2: standard
3: very sensitive
,IWKLVSDUDPHWHULVPRGL¿HGWKHLQVWDOOHUPXVWFKHFNWKDWWKHOLPLWDWLRQRIIRUFHV
complies with appendix A of the standard EN12 453 or install a safety edge.
P37 Wired control inputs 0: complete cycle mode -
pedestrian cycle
1: opening mode - closing
0: terminal 9 input = pedestrian cycle, terminal 11 input = complete cycle
1: terminal 9 input = opening only, terminal 11 input = closing only
P40 Coupling speed when
closing
1: slowest speed
at
4: fastest speed
Default value: 2 ,IWKLVSDUDPHWHULVPRGL¿HGWKHLQVWDOOHUPXVWFKHFNWKDWWKHOLPLWDWLRQRIIRUFHV
complies with appendix A of the standard EN12 453 or install a safety edge.
P41 Coupling speed when
opening
1: slowest speed
at
4: fastest speed
Default value: 2

EN
Elixo 500 3S RTS
18 Copyright © 2015 Somfy SAS. All rights reserved
PROGRAMMING THE REMOTE CONTROLS
Memorising 2- or 4-button remote controls via the programming interface
Up to 40 command channels can be memorised and assigned as desired among the commands listed below. If the memory is full, the screen displays "FuL".
If this procedure is carried out using a channel which has already been memorised, this channel will be cleared. The screen displays "dEL".
Memorising 3-button remote controls via the programming interface
[1]. Press and hold the "PROG" button on the control box (2 s).
The screen displays "F0".
Note: pressing "PROG" again allows the next function to be memorised.
[2]. Press "PROG" at the rear of the 3-button remote control to memorise the
function.
The screen displays "Add".
<
my
<
F0 Complete opening Stop Complete closing
F1 Complete opening If gate is closed Æpedestrian opening Complete closing
Otherwise Æstop
F2 Lighting ON Lighting OFF
F3 Aux. output ON Aux. output OFF
Button functions on a 3-button remote control
COMPLETE opening control
2 s
C1 C1F0 Add
PEDESTRIAN opening control
2 s
C1 F0 F1 C1 Add
LIGHTING control
F1
2 s
C1 F0 F2 C1Add
AUXILIARY OUTPUT control (P15 = 4.5 or 6)
2 s
C1 F0 F3
F1 F2 C1
Add
2 s
C1 F0 C1 Add
