SOMFY SGS 501 User manual

5073893A
SGS 501
EN
Operating and installation guide
DE
Montage- und Gebrauchsanleitung

Copyright © 2013 Somfy SAS. All rights reserved.
COMPOSITION OF THE KIT
24V
24V
DRAFT
1
3 4
52
69
10 11
12
13 14
21
15 16
17
18
19 20
8
7
No. Designation Quantity No. Designation Quantity
124V cylinder 2 Control unit accessories pouch
2Control unit 1 13 Sealing strip 1
3Wall/pillar left-hand mounting bracket 1 14 Control unit label 2
4Wall/pillar right-hand mounting bracket 1 15 Unit cover screw 1
5Gate leaf mounting bracket 2 16 Unit cover unlocking key 1
6Disc for reading dimensions 1 17 Wall mounting bracket 1
7Summary label 1 18 Screw for securing the unit to the bracket 1
Cylinder accessories pouch 19 Cable clamp 1
8Unlocking mechanism 2 20 Cable clamp bolt 2
9Unlocking mechanism screw 2 21 2-button remote control 2
10 Pin for securing the cylinder to the wall/pillar
bracket 2
11 M8x22 flat washer 4
12 Remote control customisation clip 2

English
Copyright © 2013 Somfy SAS. All rights reserved.
DETAILED PRODUCT DESCRIPTION
24V
Control unit cover
Cover bolt
Bracket screw Bracket
Sealing strip
Cable clamp
Electronics
Cable clamp bolt
Cylinder bracket pin
Wall/pillar
mounting bracket
Cylinder
Gate leaf
bracket
Catch
Unlocking
mechanism screw
Unlocking
mechanism

Copyright © 2013 Somfy SAS. All rights reserved.
GENERAL CONTENTS
SAFETY INSTRUCTIONS.................................................................................................2
Introduction ................................................................................................................................................2
Preliminary checks.....................................................................................................................................2
Installation environment.................................................................................................................................................................... 2
Condition of the product to be motorised ......................................................................................................................................... 2
Specifications of the gate to be motorised ....................................................................................................................................... 2
Dimensions and maximum weight of the gate leaves which can be motorised, based on the wind strength ................................. 2
Electrical pre-equipment ...........................................................................................................................3
230V power supply input (not required for a solar power supply).................................................................................................... 3
Cable feed......................................................................................................................................................................................... 3
Safety instructions relating to installation ..............................................................................................3
Safety devices................................................................................................................................................................................... 3
Clothing precautions ......................................................................................................................................................................... 3
Safety instructions relating to operation.................................................................................................4
About the batteries............................................................................................................................................................................ 4
Safety instructions relating to maintenance ...........................................................................................4
Risk prevention ..........................................................................................................................................5
Identification of risk zones ................................................................................................................................................................ 5
Measures to be taken to counter risks ............................................................................................................................................. 5
Regulations.................................................................................................................................................6
Recycling and disposal .............................................................................................................................6
Protection of the environment........................................................................................................................................................... 6
Recycling .......................................................................................................................................................................................... 6
Assistance ..................................................................................................................................................6
GENERAL INFORMATION ...............................................................................................7
Welcome......................................................................................................................................................7
Who are Somfy? ............................................................................................................................................................................... 7
Product description ...................................................................................................................................7
Area of application ............................................................................................................................................................................ 7
Dimensions and maximum weight of the gate leaves ...................................................................................................................... 7
Space requirements for the motors and the control unit (in mm)..................................................................................................... 7
Technical data................................................................................................................................................................................... 8
Overview of your installation....................................................................................................................8
Tools and hardware required....................................................................................................................9
Tools ................................................................................................................................................................................................. 9
Hardware .......................................................................................................................................................................................... 9
Pre-installation checks ..............................................................................................................................9
Gate .................................................................................................................................................................................................. 9
Reinforcements................................................................................................................................................................................. 9
Closing end stops ........................................................................................................................................................................... 10
Mechanical lock .............................................................................................................................................................................. 10
Pillars .............................................................................................................................................................................................. 10
Electrical pre-equipment .........................................................................................................................10
230V power supply input (not required for a solar power supply).................................................................................................. 10
Linking the two motors ................................................................................................................................................................... 10
Linking the cells .............................................................................................................................................................................. 10
Linking the other accessories ......................................................................................................................................................... 10
INSTALLATION AND COMMISSIONING...................................................................... 11
Drilling the pillars....................................................................................................................................11
Taking dimensions.......................................................................................................................................................................... 11
Tracing the AM and AH axes.......................................................................................................................................................... 12
Drilling the pillars ............................................................................................................................................................................ 12
TRANSLATED VERSION OF THE GUIDE

English
1
Copyright © 2013 Somfy SAS. All rights reserved.
Securing the motors to the pillars..........................................................................................................13
Securing the pillar mounting bracket .............................................................................................................................................. 13
Fitting the cylinder on the mounting bracket................................................................................................................................... 13
Securing the motors to the gate leaves.................................................................................................14
Installing the control unit ........................................................................................................................16
Positioning the control unit on the pillar.......................................................................................................................................... 16
Fitting the sealing strip.................................................................................................................................................................... 16
Securing the control unit to the pillar .............................................................................................................................................. 16
Connecting the motors............................................................................................................................18
Connecting to the mains power supply.................................................................................................18
Connecting the control unit to the power supply ............................................................................................................................ 18
Other connections (optional)........................................................................................................................................................... 18
Commissioning ........................................................................................................................................19
Presenting the remote controls....................................................................................................................................................... 19
Attaching the control unit label ....................................................................................................................................................... 19
Switching the installation on ........................................................................................................................................................... 19
Adjusting the opening stop ............................................................................................................................................................. 19
Programming the gate leaf travel ................................................................................................................................................... 20
Finishing mounting the gate leaf bracket........................................................................................................................................ 21
Checking the position of the aerial ................................................................................................................................................. 21
Closing the control unit ................................................................................................................................................................... 21
CUSTOMISING YOUR INSTALLATION........................................................................ 22
Default operation......................................................................................................................................22
Operating your gate in sequential mode and complete opening mode.......................................................................................... 22
Detecting obstacles......................................................................................................................................................................... 22
Automatic closing ....................................................................................................................................22
Precautions for use......................................................................................................................................................................... 22
Activating automatic closing mode ................................................................................................................................................. 22
Deactivating automatic closing mode ............................................................................................................................................. 23
Operating your gate in automatic closure mode............................................................................................................................. 23
Pedestrian opening..................................................................................................................................23
Activating pedestrian opening........................................................................................................................................................ 23
Deactivating pedestrian opening .................................................................................................................................................... 23
Operating your gate in pedestrian opening mode .......................................................................................................................... 23
Memorising remote controls...................................................................................................................24
Selecting the buttons of your 2- or 4-button remote control........................................................................................................... 24
Memorising a 2- or 4-button remote control ................................................................................................................................... 24
3-button remote controls................................................................................................................................................................. 24
Wiring the accessories ............................................................................................................................25
Accessories general wiring diagram............................................................................................................................................... 25
Cells ................................................................................................................................................................................................ 25
Orange light .................................................................................................................................................................................... 26
Area lighting.................................................................................................................................................................................... 26
Backup battery................................................................................................................................................................................ 27
Key lock .......................................................................................................................................................................................... 27
Video entry phone........................................................................................................................................................................... 28
Wired code keypad ......................................................................................................................................................................... 28
Offset aerial..................................................................................................................................................................................... 28
Solar ..........................................................................................................................................................29
Connection to the solar power supply ............................................................................................................................................ 29
Advice for use ................................................................................................................................................................................. 29
TROUBLESHOOTING GUIDE........................................................................................ 30
Diagnostics ..................................................................................................................................................................................... 30
Assistance....................................................................................................................................................................................... 30
Replacing the remote control battery.............................................................................................................................................. 30
Clearing the settings ....................................................................................................................................................................... 31
Clearing the memorised settings and remote controls ................................................................................................................... 31
Unlocking/locking the motors.......................................................................................................................................................... 31

2Copyright © 2013 Somfy SAS. All rights reserved.
Important information
The installation must comply with the current standards and regulations in force in the country in which the product is being
installed.
Failure to follow these installation instructions may result in serious injury or damage to the equipment. Somfy shall not
be held liable in this event.
If installed and used correctly, the motorisation system conforms to the required safety standards. It is recommended that
these rules of conduct be respected to prevent the risk of danger or accidents.
Any use outside the scope of application dened by Somfy is forbidden. Any incorrect use will invalidate the
warranty and Somfy's liability.
Installation environment
To be able to access the motors and unlock them in the event of a fault, additional access must be provided within the
property.
The position in which the motorisation mechanism will be tted must allow for safe and easy manual release of the
product.
The product must not be installed in an explosive environment (presence of gas, ammable fumes).
Condition of the product to be motorised
Do not motorise a product which is in bad condition or incorrectly installed.
Before installing the motor, ensure that the driven part is in good mechanical condition, that it is correctly balanced and
that it opens and closes correctly.
Check that:
• the mountings for the product are in good condition
• the product is not equipped with a manual or electric locking system
• the points where the motorisation will be attached are sturdy and in perfect condition. Otherwise, masonry work will
have to be carried out to embed the motors in accordance with the measurements given.
Specications of the gate to be motorised
The motor cannot be used with a driven part incorporating a small gate (unless the motor is inhibited when the small
gate is in the safety position).
Check that this automatic control system is suitable for your type of product and for its dimensions. Otherwise, the
automatic control system cannot be installed unless modications are made to the structure.
This automatic control system has been designed to motorise residential double door gates.
With solid gates, and in windy conditions, the automatic control system cannot operate correctly.
For more detailed information on the types of gates which can be motorised, refer to the table below.
Dimensions and maximum weight of the gate leaves which can be motorised, based on the wind strength
INTRODUCTION
PRELIMINARY CHECKS
Solid gate
Wind strength Effect Product SGS 201 SGS 400 SGS 501 EXAVIA 500
≥ 80 Km/h The wind is too strong
to walk against Max width
Max weight
1.5 m
200 kg
1.5 m
200 kg
1.5 m
250 kg
1.5 m
250 kg
< 80 Km/h
> 40 Km/h The branches of the
trees are moving
Max width
Max weight
1.8 m
200 kg
2.5 m
200 kg
2.5 m
250 kg
2.5 m
250 kg
Max width
Max weight
1.5 m
200 kg
1.5 m
200 kg
1.5 m
250 kg
1.5 m
250 kg
≤ 40 Km/h Sand is flying Max width
Max weight
1.8 m
200 kg
2.5 m
200 kg
2.5 m
250 kg
2.5 m
250 kg
Openworked
gate Semi-openworked
gate
CAUTION: Important safety instructions. It is important that these instructions are followed to ensure the safety of all
persons. Retain these instructions.
CAUTION: Important safety instructions. Follow all the instructions as incorrect installation can lead to serious injury.
SAFETY INSTRUCTIONS

English
3
Copyright © 2013 Somfy SAS. All rights reserved.
All connections must be made with the power off and the battery disconnected.
Do not connect to a power source (mains, battery or solar) before installation is complete.
Ensure that any danger zones (crushing, cutting, trapping) between the driven part and the surrounding xed
elements caused by the opening movement of the driven part are avoided or indicated on the installation (see the
section on risk prevention).
Modifying one of the elements provided in this kit or using an additional element not recommended in the installation
guide for the motorisation is strictly prohibited.
During installation, particularly when setting the motorisation, it is crucial to ensure that no-one is in the product's
movement zone both at the start of and during the setting operation.
Do not use adhesive to secure the motorisation.
Ensure you can see the product when it is in movement.
Be careful when handling the motorisation to prevent any risk of injury.
Manual unlocking may result in uncontrolled movement of the product.
The control devices must be moved away from the moving parts and installed at a minimum height of 1.5 m.
After installation, ensure that the mechanism is correctly adjusted and that the protection system and any manual
release mechanism operate correctly.
Permanently afx the label concerning the manual back release device near to its mobile component.
If the installation does not correspond to one of the scenarios described in this guide, it is crucial to contact us so
that we can provide all the elements required to ensure correct installation with no risk of damage.
Safety devices
The use of any safety accessories not validated by Somfy is prohibited.
For gate and garage door motorisations, the cells and the orange light are mandatory for operation in automatic
mode and out of sight of the automated product. The orange light must be visible from both inside and outside the
property.
As stated in EN 12453, which relates to the safe use of motorised doors and gates, the use of a TAHOMA/Somfy
Box unit for controlling an automatic garage door or gate control system, where the user cannot be seen, requires
the mandatory installation of a photoelectric cell type safety device on this automatic control system.
The correct operation of the photoelectric cells must be checked every 6 months.
Clothing precautions
Take off your jewellery (bracelet, chain, etc.) during installation.
For drilling and welding operations, wear special glasses and appropriate protection (gloves, ear protection).
SAFETY INSTRUCTIONS RELATING TO INSTALLATION
230V power supply input (not required for a solar power supply)
The installation of the power supply must comply with the standards in force in the country where the product is
installed (NF C 15-100 for France) and must be carried out by qualied personnel whenever possible.
Use a 3 x 1.5 mm² cable, of a maximum length of 300 m. If the installation requires the cable to be longer than
300 m, use a solar power supply.
The electrical line must be:
• used solely for the motorisation.
• tted with protection: – a 10 A fuse or breaker,
– a differential type device (30 mA).
An all-pole supply cut-off device must be provided.
Provide a connection to earth when class 1 peripheral devices are connected (zone lighting).
It is recommended that you t a lightning conductor (maximum residual voltage 2 kV).
Cable feed
If you intend to bury the cables, use a protective sheath with a sufcient diameter to feed the motor cable and the
cables for the accessories that you wish to install.
If a cable conduit cannot be made between the pillars, use a cable grommet which will withstand the passage of
vehicles (ref. 2400484).
ELECTRICAL PRE-EQUIPMENT

4Copyright © 2013 Somfy SAS. All rights reserved.
CAUTION: the motorisation must be disconnected from its power supply during cleaning and maintenance and
when parts are replaced.
The instructions given in this guide must be read carefully before any work is carried out on the motorisation.
Check the installation frequently to detect any imbalance or signs of wear or damage to the cables or springs or
to the tting. Do not use the device if it needs repairing or adjusting. Motorised products in poor condition must
be repaired, reinforced or even replaced. Check that the various motorisation component's screws and ttings
are correctly tightened.
Only use original parts for maintenance or repair work.
Any technical, electronic or mechanical alteration to the motorisation must be carried out with the agreement of
our technical department; otherwise, the warranty will be immediately invalidated and safety will no longer be
guaranteed.
Never clean the motorisation system with high pressure water cleaning equipment.
Have the motorisation checked every year by a qualied technician.
Contact Somfy assistance for any direct intervention on the motorisation.
If the installation is equipped with photoelectric cells and/or an orange light, regularly clean the photoelectric cell
optical units and the orange light. Ensure that no branches or shrubs are obscuring the photoelectric cells.
This device may be used by children aged 8 and over and by persons whose physical, sensory or mental capacity
is impaired, or persons with little experience or knowledge, as long as they are under supervision or have received
instructions on safe use of the device and fully understand the associated risks. Children must not be allowed to
play with the device. The cleaning and maintenance operations performed by the user must not be carried out by
unsupervised children.
The A-weighted sound pressure level of the motorisation is 70 dB(A) or below. The noise emitted by the structure
to which the motorisation will be connected is not taken into account.
Any potential user must be instructed on the use of the automatic control system, by reading the guide supplied
with the automatic control system. It is essential to ensure that no untrained persons (including children) are able
to put the product into motion.
The opening and closing control must always be activated with a clear view of the motorised product
Before starting to move the motorised product, check that no-one is within the motorised product's movement zone.
Monitor the movement of the motorised product and ensure no-one comes near until the movement has come to
an end.
Do not allow children to play with the xed control devices. Remote controls must be placed out of the reach of
children. Children should be supervised to ensure they do not play with the motorisation or close to the motorisation.
When using a non-locking switch, ensure that other people keep well away.
Do not deliberately obstruct the movement of the motorised product.
If not operating correctly, switch off the power supply, use emergency unlocking to gain access and contact Somfy
assistance.
Do not attempt to manually open the motorised product if the motorisation has not been unlocked. Activating the
manual back release system could cause uncontrolled movement of the driven part due to mechanical faults or a
loss of balance.
Do not modify the motorisation components.
Ensure that no natural obstacles (branch, stone, tall grasses, etc.) are able to obstruct the movement of the
motorised product.
About the batteries
Do not leave batteries of any kind within reach of children. Keep them somewhere children cannot access. There
is a risk that they could be swallowed by children or pets. Danger of death! If this does occur, seek medical advice
immediately or go to hospital.
Ensure that the batteries are not short-circuited, thrown in the re or recharged. There is a risk of explosion.
SAFETY INSTRUCTIONS RELATING TO USE
SAFETY INSTRUCTIONS RELATING TO MAINTENANCE

English
5
Copyright © 2013 Somfy SAS. All rights reserved.
10 cm mini
Entaille
du pilier
10 cm mini
Entaille
du pilier
STOP
Cellules photoélectriques
ZONE 1
Risks of impact and crushing
ZONE 2
Risks of crushing and
cutting of hands
ZONE 3
Risk of impact
Solution:
If there is a cutting zone on your
installation, you must either:
- leave a minimum distance of
10 cm between the gate leaf
and the pillar/wall
- cut off the corner of the pillar,
without weakening it
Solution:
Obstacle detection
built into the motor
Solution:
Obstacle detection built into the
motor
Photoelectric cells
STOP
Zone 5
Identication of risk zones
Measures to be taken to counter risks
RISK PREVENTION
Zone 1
Zone 2 Zone 2
Zone 4 Zone 4
Zone 3
Zone 3
Photoelectric cells
Removed
edge of the
pillar

6Copyright © 2013 Somfy SAS. All rights reserved.
50 cm
mini
50 cm
mini
Protection of the environment
This automatic gate control system and its packaging are formed of different materials, some of which must be
recycled and some disposed of.
None of the elements must be dumped in unauthorised areas or thrown away with domestic waste.
The dismantling of the various elements of kit, to separate the different materials, must be performed by qualied
personnel.
The elements must be sorted by type: Batteries/Circuit boards/Plastics/Scrap iron/Card and paper/Other
The sorted elements must be handed over to a certied recycling company and the other materials taken to a waste
disposal site.
Recycling
Never dispose of used batteries with household waste. It is your responsibility to dispose of your electronic
equipment at the relevant recycling points.
Do not dispose of your device with household waste at the end of its life. The hazardous substances that
it may contain could pose a risk to health and the environment. Ensure that your distributor takes back the
device or use the separate collection services provided by your local authority.
Despite the care taken in the design of our products and the creation of our guides, you may encounter difculties
during the installation of your automatic control device or have some unanswered questions.
Do not hesitate to contact us; our specialists are on hand to answer all your questions.
This product complies with the essential requirements of the Machinery Directive 2006/42/EC and the RTT&E
Directive 1999/5/EC. A declaration of conformity is available from www.somfy.com/ce (EXAVIA 500 / SGS201 / SGS
400 / SGS 501 / WISPA 800). Product can be used in the European Union, Switzerland and Norway.
ZONE 4
Risk of trapping and crushing
ZONE 5
Risk of feet being trapped
Solution:
Obstacle detection built into the motor
If there is an area between the gate
leaves and the surrounding xed
elements where someone could get
trapped, you must leave a minimum
distance of 50 cm between the gate
leaves and the xed sections.
Solution:
If there is an area where feet could be
trapped between the bottom of the gate
leaves and the ground, you must leave a
distance between the bottom of the gate
leaves and the ground of a minimum of
12 cm or a maximum of 5 mm.
REGULATIONS
RECYCLING AND DISPOSAL
ASSISTANCE
12 cm 5 mm
12 cm 5 mm

English
7
Copyright © 2013 Somfy SAS. All rights reserved.
85 mm
76 mm
786 mm
208 mm
187 mm
72 mm
30,00 mm
104,70 mm
177,11 mm
149,59 mm
105,05 mm
164,49 mm
GENERAL INFORMATION
Thank you for choosing a Somfy product. This product has been designed, manufactured and distributed by Somfy in accordance with
a quality policy complying with the ISO 9001 standard.
Who are Somfy?
Somfy develops, manufactures and sells motors and automatic control devices for domestic equipment. Motorisation systems for gates,
garage doors and roller shutters, alarm systems, lighting controls, heating thermostats; all Somfy products are designed to meet your
expectations in terms of safety, comfort and energy efficiency.
At Somfy, the pursuit of quality is a continuous process of improvement. Somfy's reputation has been built upon the reliability of its
products and the Somfy brand is synonymous with innovation and technological expertise worldwide.
This product fully complies with the essential safety guidelines and specifications set out by the directive according to standard EN
60335-2-103 of July 2004.
Product description
Welcome
Dimensions and maximum weight of the gate leaves
Area of application
This automatic control system has been designed to motorise residential double door gates for a detached house.
Space requirements for the motors and the control unit (in mm)
The type of gate (solid/openworked) and the weather conditions (presence of
strong winds) can reduce these maximum values (see "Preliminary checks" on
page 2 for more information on this subject).
Max weight per gate leaf (P)250 kg
Max height per gate leaf (H)2 m
Min width per gate leaf (L)1 m
Max width per gate leaf (L)2.5 m

8Copyright © 2013 Somfy SAS. All rights reserved.
Technical specifications
Power supply 230 V-50Hz / 24V (with solar power)
Motor type 24 V
Motor output 120 W
Max. power consumed
(with area lighting)
600 W
Standby consumption 3 W (with accessories)
Maximum frequency of movements per day 20 cycles per day
10 cycles per day using solar power
Opening time* 20 s minimum to 90°
Automatic obstacle detection Compliant with standard EN 12 453
Operating temperature -20°C to +60°C
Thermal protection Yes
Index protection rating IP 44
Integrated radio receiver Yes
Remote controls:
- Radio frequency
- Range in field of use
- Storage quantity
433.42 MHz
~ 30 m
16
Possible connections:
- Output for orange light
- Lighting output
- Accessories supply output
- Backup battery input
- Input for photoelectric cells
- Dry contact control input
Flashing, 24 V, 10 W
500 W max with 230 V
24 VDC / 15 W max
Yes
Yes
Yes, 230 V only
* For a 50 kg gate, self-learning of the gate speed based on its weight.
Overview of your installation
Cylinders
Key lock
Photoelectric cells
Offset aerial
Orange light
Control unit
Code keypad
Area lighting

English
9
Copyright © 2013 Somfy SAS. All rights reserved.
Renfort
Patte de
fixation
Tools and hardware required
Tools
Hardware
The hardware elements are not supplied with the product.
Use hardware elements suitable for the motor mounting bracket.
For securing the... Quantity
BRACKETS TO THE PILLARS/WALLS
Hardware adapted to the material of the pillar/wall (screws, studs, chemical seals, etc.):
- diameter: 8 to 10 mm
- hex head
6
Washers:
- internal diameter: 8 to 10 mm
- external diameter: 16 to 20 mm
Nuts:
- diameter: 17 mm
6
BRACKETS TO THE GATE LEAVES
Hardware adapted to the material of the gate leaf reinforcement:
- diameter: 8 mm
- length adapted to the thickness of the gate leaf reinforcement 6
Washers supplied
- internal diameter: 8 mm
- external diameter: 22 mm 6
CONTROL UNIT
Hardware adapted to the material of the pillar/wall
- screw diameter: 3.5 to 4.5 mm - raised or flat-head screws
- Type "S" rawl plug for concrete: S5, S6 or S8
4
PH PZ2
Reinforcements
The motors must be secured to the horizontal reinforcements for the gate leaves.
These reinforcements must ideally be placed 1/3 of the way up the gate.
If there are no reinforcements, provide metal reinforcement plates approximately
4 mm thick.
Gate
Your gate is in good condition: it opens and closes normally with ease.
It remains horizontal throughout its travel. It opens inwards towards your property.
10 19
17
Drill
Hammer
Spirit level
Tape measure
Pencil
Phillips screwdriver
Flat-blade screwdriver
Allen key,
diameter 3
Open-end spanner
Socket spanner
Cutting pliers
Stripping pliers
Pre-installation checks
Junction box
IP 55
Reinforcement
Mounting
bracket

10 Copyright © 2013 Somfy SAS. All rights reserved.
Closing end stops
Stops fixed securely to the ground should stop the travel of the gate leaves when
closing.
The opening stops are integrated into the motor (see page 19).
Mechanical lock
If your gate is equipped with a mechanical lock, it must be removed.
Pillars
The pillars must have a robust structure and be at least 21 cm wide. If not, improvements may have to be made to your pillar to
guarantee correct installation and to ensure that the bracket holds in place.
It is not recommended to mount the bracket level with the pillar: risk of spalling.
Electrical pre-equipment
230V power supply input (not required for a solar power supply)
Fit a 230 V electrical input with a 3 x 1.5 mm² cable to one of the pillars, as close as possible to where the control unit is located.
• For the cell cables, route a sheath across each pillar.
Côté Propriété
Côté Chaussée
Cellule réceptrice Cellule émettrice
Receiver cell
Pavement side
Property side
Top view
Transmitter cell
Flexible ICT sheath
The cables are not supplied with the product.
Linking the other accessories
See page 25.
Linking the two motors
Connect the pillars using a 2 x 1 mm²cable.
Use an IP 55 junction box to connect the motors.
Linking the cells
• Connect the pillars using a 2 x 0.75 mm² cable.
• The cable should be routed underneath the cells.

English
11
Copyright © 2013 Somfy SAS. All rights reserved.
= 0 cm
< 0 cm
INSTALLATION AND COMMISSIONING
Drilling the pillars
Taking dimensions
Take the dimensions using the disc (6) to determine the position of the motors on the pillars.
Note: For these measurements, the gate leaves and their hinge pins are assumed to be on the same axis.
N.B.: you must leave a minimum distance of 50 cm between the gate leaves and the fixed sections (see page 6).
1
Measure dimension A.
1
Find the measured
dimension A on the disc.
Obtain the maximum
opening angle α.
4
Determine dimension B
3
The direction of fitting (E or e) for the bracket for mounting
the cylinder on the pillar.
2
Specific case: dimension A is negative
If dimension A is negative, the gate leaf hinge is located in
front of the pillar. Add a shim so that the cylinder mounting
bracket is aligned with the gate leaf hinge and A is 0 cm.
Take care to ensure the
bracket is fitted the right way
up.
Correct
orientation
Incorrect
orientation
WARNING
Dimensions not recommended for
gate leaves > 2 metres
Angle up to
Bracket direction of fitting "e" or "E"
Direction "e"
Direction "E"
Right-hand pillarLeft-hand pillar

12 Copyright © 2013 Somfy SAS. All rights reserved.
AH
Transfer the dimension B onto the pillar using the hinge axis
and mark a vertical axis AM on the pillar.
Mark the horizontal axis AH on the pillar, halfway up the
reinforcement.
Tracing the AM and AH axes
1
2
Check before proceeding to the next step
Have you marked the AM and AH axes?
Drilling the pillars
Drill 3 holes in each pillar at the marked locations (see page 9 for the
drilling diameter corresponding to suitable hardware).
Check that the bracket is horizontal, then mark the mounting holes for
the bracket.
Align the markers made on the bracket with the AH axis and align the
edge of the bracket with the AM axis.
Note: The markers marked on the bracket are underneath the oblong
holes.
1
3
2
AH
5 7 8
Take care to ensure the bracket is
fitted the right way up.
Correct orientation Incorrect orientation
Position the bracket in orientation e or E defined in step
2 of taking the dimensions (see page 11)
Pilier gauche
Sens E
ou ou
Sens e
Pilier droit
Sens e Sens E
Right-hand pillar
Left-hand pillar
Direction “e”
or or
Direction “e” Direction “E”Direction “E”

English
13
Copyright © 2013 Somfy SAS. All rights reserved.
1
Securing the motors to the pillars
Securing the pillar mounting bracket
Check that the bracket is at the right level. Retighten if necessary.
Secure the mounting bracket to the pillar with hardware adapted to the
mounting support.
2
Check before proceeding to the next step
Have you checked that the brackets are perfectly horizontal on the cylinders?
2
Fitting the cylinder on the mounting bracket
Immobilise it with the pin (10).
2
Fit the cylinder on its mounting bracket.
1

14 Copyright © 2013 Somfy SAS. All rights reserved.
In the closed position, the gate leaves must
be firmly against the ground stop and the
cylinder against its internal stop.
Securing the motors to the gate leaves
Secure the unlocking mechanism (8) on the gate leaf
mounting bracket (5) using the screw (9).
Fit the cylinder on the gate leaf mounting bracket.
Clip the unlocking mechanism on the cylinder catch to
secure it.
Close the gate.
1
2
3
Never operate the cylinder before correctly mounting it on the gate leaf. If this happens, the internal end stop setting will
be incorrect and malfunctions could occur.
The cylinders are supplied (default factory setting) on their internal closing end stop.
To ensure correct operation of the
unlocking mechanism, the direction of
fitting shown opposite must be respected.
Do not fit the screw from below.
3
Unclip the unlocking mechanism, then remove the cylinder from the
gate leaf mounting bracket.
6
Push the gate leaf mounting bracket against the gate leaf
reinforcement.
Check that the cylinder is horizontal.
4
5Mark the markings on the sides of the gate leaf mounting bracket.

English
15
Copyright © 2013 Somfy SAS. All rights reserved.
5 7
8
Drill a hole in the gate leaves with a diameter of 8.
Install the cylinder.
Clip the unlocking mechanism on the catch to secure it.
Reposition the gate leaf mounting bracket then mark the mounting
holes in the centre of the oblong holes.
8
10
7
9
The third mounting hole must only be drilled after self-
learning of the gate leaf travel.
The washers (11) provided must be fitted.
Check before proceeding to the next step
Have you checked that the cylinders are perfectly horizontal?
Secure the gate leaf mounting bracket to the two points on the gate
leaves using screws suited to the reinforcement material and the
washers (11) supplied.

16 Copyright © 2013 Somfy SAS. All rights reserved.
230V
Installing the control unit
Positioning the control unit on the pillar/wall
The unit should be mounted next to the power supply input.
Fitting the sealing strip
Fit the sealing strip (13) inside the top of the control unit.
Securing the control unit to the pillar
Position the unit mounting bracket (17) against the pillar/wall.
Check it is horizontal by placing a spirit level in the space provided.
Remove the bracket and drill the pillar/wall.
The drilling diameter is to be defined based on the type of screws
used for mounting (see page 9).
Position the base of the unit to mark the 2 mounting points at the
bottom of the unit.
Mark the mounting points for the bracket.
Secure the bracket to the pillar/wall.
1
3
5
2
4
4
