Sony CBK-UPG01 User manual

HARDWARE UPGRADE KEY
CBK-UPG01
INSTALLATION MANUAL
1st Edition
!警告
このマニュアルは，サービス専用です。
お客様が，このマニュアルに記載された設置や保守，点検，修理などを行うと感電や火災，人身
事故につながることがあります。
危険をさけるため，サービストレーニングを受けた技術者のみご使用ください。
設置や保守，点検，修理などを行う前に，PMW-500 に付属している下記マニュアルの「安全の
ために」を必ずお読みください。
.取扱説明書
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than
that contained in the operating instructions unless you are qualified to do so. Refer all
servicing to qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden.
Um die Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu
vermeiden, sind bei Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen.
Andere als die angegeben Wartungsarbeiten dürfen nur von Personen ausgeführt
werden, die eine spezielle Befähigung dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’
entretien. Afin de réduire les risques de décharge électrique, d’incendie ou de blessure
n’effectuer que les réparations indiquées dans le mode d’emploi à moins d’être qualifié
pour en effectuer d’autres. Pour toute réparation faire appel à une personne compétente
uniquement.

1-1 (E) CBK-UPG01
Section 1
Installation
Purpose of this manual
This manual is the installation manual of the Upgrade Key CBK-UPG01.
This manual is intended for use by trained system and service engineers, and describes
the information on installing the CBK-UPG01.
Related manuals
Besides this installation manual, the following manual is prepared for CBK-UPG01.
.PMW-500 Operating Instructions (Supplied with PWM-500)
This manual describes the application and operation of PWM-500.
.PMW-500 Maintenance Manual (Available upon request)
This manual describes the detailed maintenance information and repair information
of the PMW-500 that are required for parts-level service.
For obtaining, contact your local Sony Sales Office/Service Center.

1-2 (E)
CBK-UPG01
1-1. General Information for Installation
Parts configuration
The Upgrade Key CBK-UPG01 consists of the following parts.
.DU-540C board assembly
.Installation manual
.Installation guide
.Attaching screws (two)
On installation
Install the DU-540C board and check that the CBK-UPG01 is properly installed
according to the installation and check procedure described in section 1-2 and 1-3.

1-3 (E) CBK-UPG01
1-2. Installation Procedure
1. Loosen the four screws with stopper to detach the inside panel assembly.
Screw with stopper
Screw with stopper
Inside panel assembly
2. Turn over the insulation sheet and connect the DU-540C board connector CN1 to
the FP-169A board connector CN404.
3. Fix the DU-540C board with the two screws (PSW2.6 x5) supplied.
DU-540C board
Insulation sheet
FP-169A board
CN404
CN1
PSW2.6 x 5
4. Attach the inside panel assembly by reversing the steps of removal.

1-4 (E)
CBK-UPG01
1-3. Check after Installation
Check procedure
1. Turn on the power of PMW-500.
2. Display the “MAINTENANCE” menu on the viewfinder referring the operating
instructions supplied with PMW-500.
3. Confirm that is able to select “Wi-Fi Setting” in excluding the state of record and
playback.
MAINTENANCE
LensUs
Cu
Op
Pa
Ma
Fi
Auto Shading
Trigger Mode
Network Setting
Clock Set
Wi-Fi Setting

Sony Corporation
CBK-UPG01 (WW) J,E
4-282-565-01
Printed in Japan
2011. 1 08
©2011
