Sprout BMS User manual

Simple. Modern. American Made.
Tall, Narrow Back,
Adjustable Shelf
Adult assembly only
2 Adults required for assembly
Assemble completely before use

Has Groove On Bottom
Adjustable Shelves
(Qty dependent on order)
Toe (2)
A
Has Slots
Bottom (1)
B
Top (1)
C
G
Screws
H
Allen Wrench
I
Shelf Pins
J
GLUE
REQUIRED: For steps using glue,
apply a pea-sized amount to the
thin end of slots. With the tabs
orented vertically, apply a pea-sized
amount at the top of each tab
(inside its groove). The glue will run
down and coat the rest of the tab
during assembly.
Apply glue just before
connecting pieces.
2
BEFORE YOU START
PARTS
*
Glue helps make this shelving unit
rigid and it’s drying also makes this
assembly time-sensitive. To help the
process go smoothly, read all
instructions before proceeding.
RECCOMENDED: A rubber
mallet can help push
pieces together.
A hammer can also be
used with a scrap piece of
wood or a cutting board
placed over the surface
being hammered for
protection.
When inserting tabs into slots make
sure the side with the wider lip on
the tab faces the same direction as
the notch in the slot.
REQUIRED: Wood glue
is used to permanently
attach the shelving
pieces together.
This adds additional
rigidity to the unit.
Using other glue types
may aect curing and
workablity time.
2 people required for assembly.
Assemble on a hard oor.
NOTCH
WIDE LIP
SLOT TAB
QUARK ENTERPRISES, LLC PO BOX 1123, PROVO, UT 84601 MODEL NO. BMSPAGE 2 OF 8
Left Side (1)
D
Right Side (1)
E
Back (1)
F
*Tab will ‘pop’ into slot
when force is applied.
Slot
Tab

Frustrated?
Need Help?
STOP
ASSEMBLY INSTRUCTIONS
A
B
A
Push tabs on Toes a into slots on Bottom b . Tabs
and slots must be lined up correctly or they will not
properly tighten. See * for tab orientation.
1
*
B
A
Turning the part upright, push down on Toes a until
the ends are ush with the ends of Bottom B . Repeat
with second Toe.
A
B
2
A
A
B
DOCUMENT: AI-B.2-NoBack WWW.SPROUT-KIDS.COM COPYRIGHT QUARK ENTERPRISES 2022 PAGE 3 OF 8
Talk to our customer service agent at:
[phone]
Or email us at:
[email protected]
Watch our assembly video at:
sprout-kids.com/bmsa

4Press or hammer down Left Side D to tighten until
it makes contact with the ground. It will be ush
with the underside of Top C and Bottom B . Parts
will be snug. Remove excess glue from joints with a
damp cloth.
If unable to get parts to be ush with each other
dissassemble immediately. Remove glue with a
damp cloth and contact Customer Service.
C
D
BB
3A second adult is needed to hold parts in place. Refer
to * for tab orientation. Apply glue to slots on Left
Side D and tabs on Top C and Bottom B . Refer to !!
for glue. Pop tabs into corresponding slots.
B
C
D
*
Thin end of Slot
facing up
C
D
B
QUARK ENTERPRISES, LLC PO BOX 1123, PROVO, UT 84601 MODEL NO. BMSPAGE 4 OF 8
B
C
D

H
I
6To tighten, press or hammer down Right Side D until
it makes contact with the oor. Parts will be snug.
Remove excess glue from joints with a damp cloth.
Have one adult hold Side D , Top C and Bottom B
steady. Apply glue to the tabs on C and B and the
slots of Right Side D . Pop tabs into corresponding
slots.
5B
B
C
C
D
E
E
E
E
B
C
D
Thin end of
Slot facing up
DOCUMENT: AI-B.2-NoBack WWW.SPROUT-KIDS.COM COPYRIGHT QUARK ENTERPRISES 2022 PAGE 5 OF 8
B
C
D
7Carefully tilt unit up on Bottom B . Install Back E by
aligning with pilot holes on Sides. Thread Screw G
through pilot holes with provided Allen Wrench H .
F
B
B
H
I
F

6
3Using a drill or power screwdriver, install 2 screws into
the holes on the triangular face. Make the screws as
straight as possible.
QUARK ENTERPRISES, LLC PO BOX 1123, PROVO, UT 84601 MODEL NO. BMSPAGE 6 OF 8
2
1Tilt the assembled unit, minus the adjustable shelves,
on its back.
Place one of the brackets into the corner on the
underside of the shelf like so. The triangular face of the
bracket should be against the toe piece.
BRACKET INSTALLATION
Bracket (4) Screw (24)
Adult assembly only
Drill/power screwdriver required for assembly

1
Carefully set shelving unit upright. Remove excess
glue with damp cloth. Check that everything is fully
tightened.
Insert Pins F into holes at desired height. Place
Adjustable Shelf E on pins.
7
SHELF INSTALLATION
5Repeat for the other 3 corners.
Allow glue to set for 1 hour before use.
4Install 2 more screws into the holes on one of the
small sides of the bracket, then the other.
DOCUMENT: AI-B.2-NoBack WWW.SPROUT-KIDS.COM COPYRIGHT QUARK ENTERPRISES 2022 PAGE 7 OF 8
F
F
J

Simple. Modern. American Made.
QUARK ENTERPRISES, LLC PO BOX 1123, PROVO, UT 84601 MODEL NO. BMSPAGE 8 OF 8
