Sprout SOSTA Quick setup guide

SOSTA BUNK BED
Growing together through every stage
ASSEMBLY & USE GUIDE

Please reach out to our team if you need anything along the way!
We’re Here to Help
[phone] M-F 8-4 MST
[email protected]
Ensuring more than just a stylish addition to your space; the Sosta Bunk
Bed was meticulously hand-crafted with premium materials to make an
heirloom-quality piece that will grow with your family.
Crafted from
Solid Wood
American made
and sourced
Made to grow with
your little one

(2x)
(2x) (2x)
(12x)
PARTS
PLATFORM
SOSTA BED
ASSEMBLY GUIDE
Side
A
End
B
Slat Roll
C
Phillips Screw
F
REQUIRED
OR
Power
Drill
Phillips
Screwdriver
INCLUDED TOOLS
Lay out (2x) Sides and (2x) Ends as shown.
AB
1
Enjoy the best assembly experience
sprout-kids.com/platform
ASSEMBLY VIDEO
A
AB
B
Starting with one End , fully insert tabs of Sides into
slots on Ends until ush. Repeat with other End .
A
A
A
B
B
B
BB
2
OPTIONAL: A rubber mallet can
help push pieces together.
A hammer can also be used with
a scrap piece of wood or a
cutting board placed over the
surface being hammered for
protection.
Long
Phillips Bit

Screw a Phillips Screw into corner of End and Side .
Repeat with each corner.
A
A
B
B
4F
F
5With webbing face up, align the Slat Roll holes with the
Holes in Side as you lay one of the Slat Rolls onto
one half of the bed frame.
C
C
A
Insert the tips of (2x) Phillips Screws through the Slat
Roll holes and vertically into the holes of Side .
A
6F
C
A
A
C
A
A
F
F
C
Screw the (2x) Phillips Screws into the holes on the side
of the Slat Roll near the middle of the bed.
C
7F
F
C
F

Set the tips of the additional (2x) Phillips Screws through
the other Slat Roll holes and screw them into the holes
of Side .
9Repeat steps 10-13 to attach remaining Slat Roll .
10 You have completely assembled the platform. If you
are left with an extra screw, don’t worry! It was just
there in case one got lost.
F
8
A
F
F
A
A
C
C
C
C

PARTS
BUNK HEADBOARD
SOSTA BED
ASSEMBLY GUIDE
OPTIONAL
Power
Drill
INCLUDED TOOLS
Hex
Bit
4mm Hex
Wrench
1.2” Hex Screw 1.6” Hex Screw
C
C
D
Bracket
B
Headboard
A
(4x)
(2x)
(2x)
(2x)
Enjoy the best assembly experience
sprout-kids.com/headboard
ASSEMBLY VIDEO
If you already have an assembled Sosta Bed, then rst
remove any sideboards.
If installing a headboard for the rst time, skip to Step 5.
2
Next, remove any headboards. To remove, rst unscrew
the two 1.6” Hex Screws that secure the Headboard to
the bed frame.
3D
Remove the 1.2” Hex Screws
securing the brackets to the
headboard posts, and pop out
brackets.
4
D
1With the high-powered drills
available today, the most
signicant assembly issue that
can occur is rounding-out the
hex shape in the head of a hex
screw. If this occurs, it will be
very dicult to remove the screw. To avoid this, please
do the following:
I) Set the clutch on your drill to a LOW SETTING (we
recommend 3).
II) Attempt to install your rst hex screw. The clutch will
most likely start slipping before it screws all the way in.
III) Adjust your clutch up one setting at a time until the
screw goes completely in.
IV) After nding the appropriate setting per your
experience with the rst 3 screws, DO NOT adjust the
clutch setting any more.
V) Later in assembly, if a screw does not screw in all the
way, rst check the screw length to ensure you are using
the correct screw.
VI) If the screw is correct, then use the Hex Wrench to
complete the installation of that screw.
VII) If the screw won’t go in with the Hex Wrench, contact
Customer Support at [phone] Mon-Fri 9-4 MST.
3
4
2
2
3
3
4
2
1

5Place Bracket rmly into groove with the long tab
facing DOWN. Repeat for both sides of the
Headboard/Footboard .
With groove opening face up, set Headboard/Footboard
on ground, as shown.
A
A
B
6
B
A
A
B
B
With the help of another adult, set bed frame on side, as
shown, then insert Bracket ends rmly into bed frame
slots (using a rubber mallet if necessary). Ensure Head-
board is ush against bedframe before proceeding.
Insert (1x) 1.2” Hex Screw as shown to secure
Bracket . Repeat for both Brackets .
BB
B
7
8
C
A
B
C
C
B
C1.2” Hex Screw Actual Size.
Place screw on paper to verify
correct size.
Insert (2) 1.6” Hex Screws to secure Headboard to
bed frame.
9
Repeat for second Headboard.
10
DA
D1.6” Hex Screw Actual Size.
Place screw on paper to verify
correct size.
Long tab
facing down
Q
B
A

Phillips
Screwdriver
PARTS
FULL RAIL
SOSTA BED
ASSEMBLY GUIDE
OPTIONAL
Power
Drill
INCLUDED TOOLS
Hex
Bit
4mm Hex
Wrench
Full Side Rail
A
Enjoy the best assembly experience
sprout-kids.com/fullrail
ASSEMBLY VIDEO
Align the holes of the Full Side Rail with the holes in
the Headboard & Footboard.
2A
Holes on
bottom edge!
2” Hex Screw
C
1.6” Hex Screw
B
(2x)(4x)
1With the high-powered drills
available today, the most
signicant assembly issue that
can occur is rounding-out the
hex shape in the head of a hex
screw. If this occurs, it will be
very dicult to remove the screw. To avoid this, please
do the following:
I) Set the clutch on your drill to a LOW SETTING (we
recommend 3).
II) Attempt to install your rst hex screw. The clutch will
most likely start slipping before it screws all the way in.
III) Adjust your clutch up one setting at a time until the
screw goes completely in.
IV) After nding the appropriate setting per your
experience with the rst 3 screws, DO NOT adjust the
clutch setting any more.
V) Later in assembly, if a screw does not screw in all the
way, rst check the screw length to ensure you are using
the correct screw.
VI) If the screw is correct, then use the Hex Wrench to
complete the installation of that screw.
VII) If the screw won’t go in with the Hex Wrench, contact
Customer Support at [phone] Mon-Fri 9-4 MST.
3
4
2
2
3
3
4
2
1

3Screw the (2x) 2” Hex Screws into the center holes of
the Full Side Rail .
C
A
C2” Hex Screw Actual Size
Place screw on paper to verify
correct size.
CC
Screw (2x) 1.6” Hex Screws through the top holes of
the Full Side Rail and into the top holes of the Head-
board and Footboard.
A
4B
1.6” Hex Screw Actual Size.
Place screw on paper to verify
correct size.
B

PARTS
3/4 RAIL
SOSTA BED
ASSEMBLY GUIDE
OPTIONAL
Power
Drill
INCLUDED TOOLS
Hex
Bit
4mm Hex
Wrench
3/4 Side Rail
A
2” Hex Screw
C
1.6” Hex Screw
B
(2x)(2x)
Enjoy the best assembly experience
sprout-kids.com/3-4rail
ASSEMBLY VIDEO
Align the holes of the 3/4 Side Rail with the holes in
the Headboard and Platform.
2A
A
NOTE: The 3/4 Side
Rail can be installed
on the right side or
left side, as desired.
1With the high-powered drills
available today, the most
signicant assembly issue that
can occur is rounding-out the
hex shape in the head of a hex
screw. If this occurs, it will be
very dicult to remove the screw. To avoid this, please
do the following:
I) Set the clutch on your drill to a LOW SETTING (we
recommend 3).
II) Attempt to install your rst hex screw. The clutch will
most likely start slipping before it screws all the way in.
III) Adjust your clutch up one setting at a time until the
screw goes completely in.
IV) After nding the appropriate setting per your
experience with the rst 3 screws, DO NOT adjust the
clutch setting any more.
V) Later in assembly, if a screw does not screw in all the
way, rst check the screw length to ensure you are using
the correct screw.
VI) If the screw is correct, then use the Hex Wrench to
complete the installation of that screw.
VII) If the screw won’t go in with the Hex Wrench, contact
Customer Support at [phone] Mon-Fri 9-4 MST.
3
4
2
2
3
3
4
2
1

Partially screw (2x) 2” Hex Screws through the
bottom holes of the 3/4 Side Rail and into the holes of
the Platform.
Partially screw (2x) 1.6” Hex Screws through the side
holes of the 3/4 Side Rail and into the side holes of the
Headboard.
A
3B
A
4C
1.6” Screw Actual Size
Place screw on paper to verify
correct size.
B
B
B
C
C
A
A
C2” Screw Actual Size
Place screw on paper to verify
correct size.
5Fully screw in each of the Hex Screws.
B
B
A
C
C

WOOD PARTS
43” BUNK
SOSTA BED
ASSEMBLY GUIDE
INCLUDED TOOLS
(2x)
(2x)
(2x)
(2x)
(2x)
(3x)
(2x)
(2x)
(4x)
METAL BRACKETS
Post Bracket
L
Dovetail Bracket
M
L-Bracket
N
Platform
assembled per
Sosta Bed Platform Assembly Guide
A
Left Post
C
Full Side Rail
G
Right Post
D
Left Ladder Side
H
Right Ladder Side
J
Right Diagonal Brace
E
Left Diagonal Brace
F
Endboard
B
Ladder Rung
K
(8x)
2” Hex Screw
R(2x) Q
1.6” Hex Screw
(12x)
SCREWS & PINS
REQUIRED
4mm Ball-end
Hex Bit
Long
Phillips Bit
4mm Hex
Wrench
3.5” Hex Screw
S(4x)
4” Pins
T
(8x)
3/4” Phillips Screw
U
P
1.2” Hex Screw
(10x)
“L” etched on
top end of Left
Diagonal Brace
OR
Power
Drill
Phillips
Screwdriver

Insert Post Brackets into lower slot on Right Posts and
Left Posts . Secure with a single 1.2” Hex Screw in the
top hole, as shown.
2
L
L
D
E
E
P
P
1.2” Hex Screw Actual Size
Place screw on paper to verify
correct size.
P
1With the high-powered drills
available today, the most
signicant assembly issue that
can occur is rounding-out the
hex shape in the head of a hex
screw. If this occurs, it will be
very dicult to remove the screw. To avoid this, please
do the following:
I) Set the clutch on your drill to a LOW SETTING (we
recommend 3).
II) Attempt to install your rst hex screw. The clutch will
most likely start slipping before it screws all the way in.
III) Adjust your clutch up one setting at a time until the
screw goes completely in.
IV) After nding the appropriate setting per your
experience with the rst 3 screws, DO NOT adjust the
clutch setting any more.
V) Later in assembly, if a screw does not screw in all the
way, rst check the screw length to ensure you are using
the correct screw.
VI) If the screw is correct, then use the Hex Wrench to
complete the installation of that screw.
VII) If the screw won’t go in with the Hex Wrench, contact
Customer Support at [phone] Mon-Fri 9-4 MST.
3
4
2
2
3
3
4
2
1
NOTE: Place bracket in
higher slot to assemble
bottom bunk in higher
position.
NOTE: With bracket in
higher slot, insert screws
as shown above.
Use (4) 3.5” Hex Screws to attach Endboard to the
Right Post and Left Post . Repeat with other end.
3
S
S
D
D
E
E
B
B
3.5” Hex Screw Actual Size
Place screw on paper to verify
correct size.
S
S

Flip frame onto its side, then insert 1.6” Hex Screw to
secure end frame to bed frame. Repeat for the other (3)
corners.
5
Insert Post Brackets into bed frame slots. Ensure posts are
ush against bedframe before proceeding (using a rubber
mallet if necessary). Repeat with other side.
4
Remove all (4) 3.5” Hex Screws from one side of the
bed, then install the Full Side Rail with the same screws,
as shown. Last, install (2) 2” Hex Screws into holes on
lower rail of Full Side Rail.
6
OPTIONAL: A rubber
mallet can help push
pieces together.
A hammer can also be
used with a scrap
piece of wood or a
cutting board placed
over the surface
being hammered for
protection.
Remove 3.5”
Hex Screws,
then reinstall
with Full Side
Rail
R
R2” Hex Screw Actual Size
Place screw on paper to verify
correct size.
L
Q
Q
1.6” Hex Screw Actual Size
Place screw on paper to verify
correct size.
A
R
S
S
S
Q
C
C
Flip frame back up, then insert (4) 4” pins into top of all
four posts. Pins should insert approximately halfway
(about 2 inches).
7
T
T

NOTE: DO NOT put
your ngers or hands
between the posts!
NOTE: DO NOT put
your ngers or hands
between the posts!
NOTE: To
position pin
into hole, grab
post here
NOTE: Lift Top
Bunk from
underneath end
of platform
NOTE: If brackets don’t slide into slot
on top of post, then carefully insert
screwdriver and rotate against pin to
push the bracket outwards.
With help from another adult, lift up Top Bunk, and place
over 4” Pins on Posts.
8 Once each corner is correctly set over its pin, push down
until ush.
9
10 Tighten existing screw on downward-facing bracket, as
shown. Then insert additional 1.2” Screw into bottom
hole to secure the top bunk to the post frame. Repeat on
other (3) brackets.
1.2” Hex Screw Actual Size
Place screw on paper to verify
correct size.
P
P
P
Insert 1.2” Hex Screw through Ladder Side into hole on
end of Rungs , as shown. Tighten until ush.
11
1.2” Hex Screw Actual Size
Place screw on paper to verify
correct size.
P
P
P
P
P
J
K
K
K
K

15 Attach L-brackets to top platform with Phillips Screws ,
as shown. Phillips screws will go through hole in L-bracket
into pilot hole on underside of platform.
U
N
N
N
14 Place Ladder into position as shown, with L-brackets
tting underneath top platform, and Dovetail brackets
resting against bottom platform.
Repeat for the other Ladder Side. Ensure the ladder sides
are oriented with the large portion at the same end.
12
P
P
P
H
Long
Phillips Bit
13 Secure L-Brackets to top of ladder using Phillips Screw,
as shown. Secure (2) Dovetail Brackets to base of
Ladder Sides using Phillips Screw , as shown. Use the
Long Phillips Bit for the ladder assembly.
U
Dovetail
Bracket
M
M
M
M
U
3/4” Phillips ScrewL-Bracket
N
N
N
N
Dovetail
Bracket on
opposite side
Ensure bracket
is square when
fully tightened

RAISING THE BOTTOM BUNK
RR
19 Remove Phillips screws that connect ladder to bottom
platform, and Hex Screws & that connect Full Side
Rail & Lower Endboards to Posts. Then set aside
Endboards and Full Side Rail.
R
U
S
S
S
S
S
S
S
S
U
4mm Hex
Wrench
18 Hand-tighten all Hex Screws with the Hex Wrench to
prevent squeaking. Please see back panel for safety
information. You are done!
16 Attach Dovetail brackets to bottom platform with
Phillips Screws , as shown. Phillips screws will go
through hole in Dovetail bracket into pilot hole on side of
platform.
M
M
U17 Insert Left Diagonal Brace into hole on upper platform
in the orientation shown. Insert (2) 1.6” Hex Screws to
secure. Repeat with all (4) corners, using Right Diagonal
Braces on Right Posts, and Left Diagonal Braces on Left
Posts.
Q
Q
Q
Q1.6” Hex Screw Actual Size
Place screw on paper to verify
correct size.
G
G
NOTE: Left Diagonal
Brace has an L on it to
match L on platform

23 With help from another adult, lift up platform. Insert (4)
brackets with long-arm facing downward.
L
L
22 Using mallet or hammer, remove (4) brackets from
platform. Be careful to not hit the post.
L
L
20 Remove 1.2” Hex Screw holding bracket into post.
Then carefully push bunk post away from bracket,
removing bracket from slot. Repeat for other 3 posts.
P
P
21 Carefully remove (4) 1.6” Hex Screws holding brackets
into platform.
Q
Q

R2” Hex Screw Actual Size
27 Re-attach Endboards and Sideboards in upper position.
You’re done!
All other screws =
3.5” Hex Screw Actual Size
Place screw on paper to verify correct size.
S
R
S
26 Move (2) Dovetail Brackets to higher position, and
reattach to platform using Phillips Screws .
U
M
M
24 While still carefully supporting the platform, push the tip
of the Bracket l into its slot, then insert 1.2” Hex Screw
through Bracket into Post to secure. Repeat with the
other 3 Posts.
After the screw is
tightened at the bottom,
push or pop the bracket
into its slot at the top.
Just tip of bracket
pushed into slot
P
P
L
L25 Carefully re-install (4) 1.6” Hex Screws removed on
Step 21, securing the bracket to the platform.
Q
Q1.6” Hex Screw Actual Size
Place screw on paper to verify
correct size.

To ensure you have an enjoyable, safe Sosta Bunk Bed experience, please thoroughly read and
follow the information provided below. Sprout is not liable for any injury or damage caused by
mis-use or incorrect assembly.
Maress Guidelines for Safe Use
Bunk Bed Safe Use Guidelines
Keep these instructions for future reference.
Safety Information
Always use the recommended maress size to help prevent entrapment or falls.
The top & boom bunks of this bed are designed for Twin Maresses measuring
75" L x 38" W. For additional maress information visit sprout-kids.com/maress
Recommended Maress Thickness: 4"- 8"
Never use a maress that exceeds 8" on the top bunk. The top surface of the maress
must be at least 5" (127mm) below the upper edge of the guardrails.
Never use a bunkie board or a maress box spring.
Never use water or sleep rotation maresses.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Only 1 person on the top bunk at a time.
Never allow children under 6 years of age to use the upper bunk.
Always use the ladder for entering and leaving the upper bunk.
Use of a night light is recommended as an added safety precaution for the child using the
upper bunk.
Always use guardrails on both long sides of the upper bunk. If the bunk bed is placed
next to the wall, the guardrail that runs the full length of the bed should be placed
against the wall to prevent entrapment between the bed and the wall.
Never allow horseplay on or under the bed and prohibit jumping on the bed.
STRANGULATION HAZARD–Never aach or hang items to any part of the bunk bed that
are not designed for use with the bed; for example, but not limited to, hooks, belts, and
jump ropes.
Follow the information on the warnings appearing on the upper bunk end structure and
on the package. Do not remove the warning label from bed.
This Bunk Bed was NOT designed to be used as a Loft Bed, and cannot be converted into
a Loft Bed without the proper parts. Do not use this Bunk Bed without having both plat-
forms properly assembled and fully installed.
Periodically check and ensure that the guardrail, ladder, and other components are in
their proper position, free from damage, and that all connectors are tight.
To request replacement parts in cases of damage or defect, contact Sprout.
Email: [email protected], Phone: [phone] Mon-Fri 9-4 PM MST
Never use substitute parts.
Weight Limits: Top Bunk - 250 lbs., Boom Bunk - 400 lbs.
WWW.SPROUT-KIDS.COM
PO BOX 1123, PROVO, UT 84601
QUARK ENTERPRISES 2023
DOCUMENT: AI-SBT-43in-Bunk
