SPX Power Team J58T User manual

MODEL B
HYDRAULIC TOE JACK
Model J58T Maximum Capacity: 5 Ton
Model J109T Maximum Capacity: 10 Ton
Read and carefully follow the warnings and operating instructions before using this jack. Most problems with new
equipment are caused by improper operation or setup.
NOTE: Inspect the jack upon arrival. The carrier, not the manufacturer, is responsible for any damage
resulting from shipment.
SAFETY PRECAUTIONS
WWAARRNNIINNGG::To help prevent personal injury or damage to equipment,
●●Do not exceed the maximum load capacity of the jack.
●●Do not add additional load to a lifted load.
●●Do not use in unstable or hazardous positions.
●●Unit must be used on flat surfaces able to carry the load.
●●Keep clear of lifted loads.
●●The load must be stable during lifing. An unstable load may cause the jack or load to slip.
●●Do not use the jack(s) if damaged, altered, or in poor condition.
●●Do not lift people or loads with people on them.
●●This hydraulic jack is for professional use only and should be used only by persons trained in its use.
●●Do not lift at the end of the toe. Fully engage the load with the toe.
●●Use only Power Team hydraulic fluid in this unit.
●●Do NOT, under any circumstances, tamper with the adjustment of the jack's internal relief valve screw. To
do so may cause the jack to fail.
●●When lifting by the toe, wedge the head of the jack
on the load to avoid bending the column.
Refer to illustration at right.
●●Read operating instructions and A.N.S.I. B30.1
safety code for jacks.
●●The owner of the jack must ensure that all safety-
related decals are maintained and replaced as they
become hard to read.
●●This guide cannot cover every situation,
so always do the job with safety first.
Form No. 102663
Parts List and
Operating Instructions
for:
J58T
J109T
Sheet No. 1 of 4
Rev 5 Date: 20 May 2003
Tech. Services: [phone]
Fax: [phone]
Order Entry: [phone]
Fax: [phone]
SPX Corporation
5885 11th Street
Rockford, IL 61109-3699 USA
Internet Address:
http://www.powerteam.com
®
© 2005 SPX Corporation

Parts List and Operating Instructions, Form No. 102663, Back sheet 1 of 4
OPERATION OF THE JACK
IMPORTANT: Do not carry the jack by the jacking lever.
Lifting a Load
1. Position the load on the toe of the jack.
WWAARRNNIINNGG::Do not lift a load on the end of the toe. Fully engage the load with the toe.
IMPORTANT: When lifting by the toe, wedge the head of the jack on the load to avoid bending the column.
2. Turn the release valve knob in a clockwise direction until it is snug.
3. Pump the jacking lever in an up and down motion.
Lowering a Load
1. Slowly loosen the release valve knob by turning it in a counterclockwise direction. The more the knob is loosened,
the faster the load will be lowered. To stop the jack from lowering a load, tighten the release valve knob by turning
it in a clockwise direction.
DISASSEMBLY OF THE JACK
NOTE: Refer to parts lists on pages 3 and 4.
Draining the Jack
1. Extend the jack to full stroke. Wedge the toe of the jack on the base to hold in this position.
2. Remove the cylinder plug (6) and drain oil.
Disassembly of the Pump
1. Remove the hinge pin (41).
2. Pull out the lever assembly (2), piston (25), and connecting link (5).
3. Remove the four screws (30) that hold the pump to the reservoir. Separate the pump from the reservoir.
4. Remove the bladder (21) and drain the oil from it. Using a clean, absorbent cloth, wipe any remaining oil out of the
bladder.
Disassembly of the Cylinder
1. Remove the spring clip (14) with a locking pliers.
2. Pull out the cylinder rod/base plate assembly (9) and the toe (16) from the jack body.
3. Heat the cylinder guide (8) slightly to soften the locking compound on the threads. Disassemble it from the cylinder
rod.
4. Remove the o-ring (13) and U-cup (15) from the toe.
Disassembly of the Pump
1. Unthread the inlet check valve body (23).
2. Remove the inlet check found at the bottom of the body by unscrewing the hollow lock screw (22). Remove the ball
(12) and spring (17).
3. Remove the breather valve screw (35) found at the top of the pump barrel (31) and remove the replaceable seat
(36), ball (38) and spring (37).
4. Remove the outlet check valve (11) found between the o-rings (27).
5. Remove allen screw (47), and remove the release valve knob (46).
6. Remove the retaining ring (45) before removing the release valve assembly (48).
7. Using a small press or a mallet and a piece of soft metal tubing, push the piston cartridge (32) out of the pump
body.
8. Remove the o-ring (29), wiper (33), and U-cup (28).
Disassembly of the Release Valve
WWAARRNNIINNGG::The release valve assembly should NOT be disassembled as it will affect the relief
valve setting which may result in damage to the jack or injury to the operator.
Lever Disassembly
1. Remove the pins (4) that will make it possible to separate the lever (2), piston (25) and link (5).
NOTE: Clean all jack parts (except o-rings, wipers, and bladder) with a degreasing agent and dry completely.

Parts List and Operating Instructions Form No. 102663
ASSEMBLY OF THE JACK
Assembly of the Cylinder
1. Replace o-ring (13) and U-cup (15) on the toe (16).
2. Grease the bore of the toe (16) with a non-silicone lubricant.
3. Mount the toe (16) on the cylinder rod (9).
4. Tighten the guide (8) on the cylinder rod using a thread locking compound. Remove any excess compound.
5. Grease the exterior machined portion of the toe (16) with a non-silicone lubricant.
6. Assemble the cylinder rod/base plate assembly (9), the toe (16), and the guide (8) into the body of the jack.
7. Grease the rounded end of the spring stock (14) and drive it round end first into the hole at the base of the jack
body using a pliers to guide the spring.
Assembly of the Pump
1. Install o-ring (29), U-cup (28), and wiper (33) on the piston cartridge (32). Grease the pump barrel with a suitable
lubricant.
2. Seat the piston cartridge assembly into its housing in the pump barrel (31) using a small mallet and a piece of soft
metal.
3. Install the inlet check ball (12), spring (17), and hollow lock screw (22) to the end of its travel into the inlet valve
body (23).
4. Replace copper washer (24) on the inlet valve body. Thread the valve body onto the pump barrel (31).
5. Reassemble the outlet check valve (11) into the pump barrel (31).
6. Reinstall the breather valve into the top of the pump barrel (31) by first installing the spring (37), then the ball (38)
and breather seat (3).
7. Coat the inside of the jack body with a suitable lubricant to accept the pump body.
Assembly of the Release Valve
1. Grease and replace o-ring (44).
2. Install the release valve assembly (48) in the pump body.
3. Install the retaining ring (45).
4. Install the release valve knob (46) and secure in place with allen screw (47).
Assembly of the Lever
1. Using two pins (4), attach the connecting link (5) and the piston (25) to the lever (2). IMPORTANT: Do NOT
damage the piston. Piston surface must be completely free of nicks, scratches, or dents in areas that
come in contact with the seals.
Final Assembly
1. Place the bladder (21) in the reservoir of the jack body.
2. Mount the pump into its housing on the jack body. Tap the pump into place with a mallet, while protecting the top of
the pump with a piece of wood. Secure with four screws (30).
3. Position the jack vertically and hold it in the extended position by wedging the toe on the base.
4. Close the release valve.
5. Using a funnel and filter, fill the jack with Power Team hydraulic fluid through the cylinder plug (6) hole until full to
the top of the cylinder cap thread.
6. Open the release valve and hold the breather valve ball (38) off its seat (36) with a pin or punch until oil with no air
bubbles flows from the breather valve. Release the breather ball and top off the jack with hydraulic fluid to the top
of the cylinder cap threads. Install the cylinder plug (6) and washer (7).
7. Fill the piston cavity with hydraulic fluid, open the release valve, and install the piston lever assembly with the pin,
nut and washer.
8. Remove the wedge from under the toe and allow the cylinder to retact half way. Again, carefully open the breather
ball (38) to expel any air still trapped in the bladder. Retract the piston completely.
9. Operate the pump lever several times. Close the release valve and operate the pump lever. If the pump piston
does not make a full stroke, there is still some air trapped in the pump chamber. Turn the jack 90° so that it is
resting on the back side of the hand grip and the jack column is horizontal. Operate the pump lever several times
with the release knob closed. This will expel any air left in the pump chamber into the column chamber.
Continued -
Sheet No. 2 of 4
Rev 5 Date: 20 May 2003

Parts List and Operating Instructions, Form No. 102663, Back sheet 2 of 4
Final Assembly (continued)
10. Turn the jack back up so that it is again resting on the column foot. Pump the jack to its maximum extension and
wedge the toe on the base. Loosen and remove the cylinder plug. Top off the cylinder again to the top of the
cylinder cap threads and open the release valve. Allow the oil level to drop approximately 1" and close the release
valve. Again, top off the cylinder with hydraulic fluid until flush with the top thread.
11. Reinstall the cylinder plug and tighten. Remove the wedge and allow the jack to fully retract. Close the valve
pump to full extension and build pressure. Check for leaks. Retract the jack. Check for leaks.
12. Install protective screw (35) and washer (34).
NOTE: To extend service life, periodically lubricate pivot pins 250547 and 250076.
PARTS LIST
TOE LIFT JACK SIDE VIEW

Item Part No.
No. No. Req’d Description
Parts List and Operating Instructions Form No. 102663
Sheet No. 3 of 4
Rev 5 Date: 20 May 2003
Key to Repair Kit No.'s
(See back of sheet 4 of 4 for descriptions of Repair Kits)
◆= No. 250591 ❇= No. 250595 ▲= No. 250598
❖= No. 250589 † = No. 250596 ✩= No. 250599
❚= No. 250592 ▼= No. 250597 ●= No. 250602
1250072 1 Tube
2●250546 1Lever
3250073 1 Straight Pin
4●250547 2 Pin (Lubricate periodically)
5●250557 1 Link
6250558 1 Plug
7◆❖250559 1 Special Washer
8❊▼250582 1 Guide (For J58T)
†▲250581 1 Guide (For J109T)
9❊250560 1 Cylinder and Base Plate (For J58T)
†250580 1 Cylinder and Base Plate (For J109T)
10 250561 1 Body (For J58T)
250579 1 Body (For J109T)
11 ❚✩250563 1 Valve
12 250087 2 Ball
13 ◆▼250574 1 O-ring (For J58T)
❖▲250577 1 O-ring (For J109T)
14 ◆▼250060 1 Retaining Ring (For J58T)
❖▲250105 1 Retaining Ring (For J109T)
15 ◆250064 1 U-cup (For J58T)
❖250109 1 U-cup (For J109T)
16 ▼250562 1 Toe (For J58T)
▲250578 1 Toe (For J109T)
17 250088 1 Spring
18 ❚✩250555 1 Filter
19 250068 2 Perforated Rubber Plug
20 ❚✩250554 1 Ring
21 250067 1 Bladder (For J58T)
250576 1 Bladder (For J109T)
22 ✩250090 1 Perforated Screw
23 ✩250553 1 Valve Body
24 ◆❖✩250552 1 O-ring
25 ●250551 1 Piston
26 250091 1 Screw
27 ◆❖✩250086 2 O-ring
28 ◆❖✩250085 1 U-cup
29 ◆❖✩250084 1 O-ring
30 250070 4 Screw
31 ✩250550 1 Pump Barrel
32 ✩250548 1 Piston Cartridge
33 ◆❖✩250549 1 Wiper
PARTS INCLUDED BUT NOT SHOWN
250536 2 Trade Name Decal (For J58T)
250537 1 Trade Name Decal (For J109T)
253234 1 Instruction Decal (Oil pivot points)

Parts List and Operating Instructions, Form No. 102663, Back sheet 3 of 4
TOE LIFT JACK
TOP VIEW, SECTION A & SECTION B
Item Part No.
No. No. Req’d Description
34 ◆❖✩250556 1 Washer
35 ✩250540 1 Screw
36 ❚250090 1 Breather Seat
37 ❚✩250088 1 Spring
38 ❚✩250087 1 Ball
39 250069 1 Plug
40 ●250564 2 Washer
41 ●250076 1 Hinge Pin (Lubricate periodically)
42 ●250077 3 Nut
43 ●250545 3 Washer
Key to Repair Kit No.'s
(See back of sheet 4 of 4 for
descriptions of Repair Kits)
◆= No. 250591
❖= No. 250589
❚= No. 250592
✩= No. 250599
●= No. 250602

Parts List and Operating Instructions Form No. 102663
RELEASE VALVE ASSEMBLY
Sheet No. 4 of 4
Rev 5 Date: 20 May 2003
44 ◆❖250542 1 O-ring
45 250099 1 Retaining Ring
46 250100 1 Knob
47 250543 1 Screw
48 250601 1 Release Valve Assembly (For J58T)
250593 1 Release Valve Assembly (For J109T)
Item Part No.
No. No. Req’d Description
Key to Repair Kit No.'s
(See back of sheet 4 of 4 for descriptions of Repair Kits)
◆= No. 250591 ❖= No. 250589

Parts List and Operating Instructions, Form No. 102663, Back sheet 4 of 4
REPAIR KITS
❚❚Repair Kit No. 250592
(Filter & Valve for J58T and J109T)
Includes:
3250087 Bearing
2250088 Spring
2250090 Screw
1250554 Ring
1250563 Valve
1250555 Filter
❖❖Repair Kit No. 250589 (O-ring Set for J109T)
Includes:
1250084 O-ring
1250085 O-ring
1250542 O-ring
2250086 O-ring
1250559 Special Washer
1250552 O-ring
1250549 Scraper Ring
1250556 O-ring
1250577 O-ring
1250109 O-ring
1250105 Spring Ring
◆◆Repair Kit No. 250591 (O-ring Set for J58T)
Includes:
1250084 O-ring
1250085 O-ring
1250542 O-ring
2250086 O-ring
1250559 Special Washer
1250552 O-ring
1250549 Scraper Ring
1250556 O-ring
1250574 O-ring
1250064 O-ring
1250060 Spring Ring
❇Repair Kit No. 250595
(Complete Column for J58T)
Includes:
1250560 Cylinder and
Base Plate
1250582 Guide
† Repair Kit No. 250596
(Complete Column for J109T)
Includes:
1250580 Cylinder and
Base Plate
1250581 Guide
▼▼Repair Kit No. 250597 (Toe for J58T)
Includes:
1250562 To e
1250060 Spring Ring
1250582 Guide
1250574 O-ring
▲▲Repair Kit No. 250598 (Toe for J109T)
Includes:
1250578 To e
1250105 Spring Ring
1250581 Guide
1250577 O-ring
✩✩Repair Kit No. 250599
(Complete Pump Barrel for J58T & J109T)
Includes:
1250550 Barrel of Pump
1250548 Sleeve
1250084 O-ring
2250090 Screw
1250555 Filter
1250554 Retaining Ring
1250540 Plug
1250556 O-ring
1250085 O-ring
1250549 O-ring
2250086 O-ring
1250553 Valve Body
1250552 O-ring
2250087 Ball
2250088 Spring
1250563 Valve
●●Repair Kit No. 250602
(Assembled Lever for J58T & J109T)
Includes:
1250546 Lever
1250551 Piston
1250557 Link
2250547 Pin
1250076 Pin
3250545 Washer
3250077 Nut
2250564 Washer

EC Declaration of Conformity
MANUFACTURER’S NAME:
MANUFACTURER’S ADDRESS: 5885 11th Street Telephone: [phone]
Rockford, Illinois 61109 Fax: [phone]
USA
TYPE OF EQUIPMENT: Hand operated hydraulic jacks
ORDER NUMBER OR PART NUMBER: J58T & J109T
APPLICATION OF EC COUNCIL DIRECTIVE(S): 89/392/EEC, 91/368/EEC, and 93/44/EEC, and
98/37/EEC.
STANDARD(S) TO WHICH CONFORMITY IS DECLARED: EN292-1, EN292-2, prEN1494:2000, and ANSI B30.1
I, the undersigned, hereby declare that the equipment specified above conforms to the above
European Communities Directive(s) and Standard(s).
PLACE: Rockford, Illinois USA ________________________________________
(Signature)
DATE: Rev. 29 AUG 2005 Don Blackman
(date / month / year) Director of Engineering
Appendix to 102663
®
SPX Fluid Power
Albert Thijsstraat 12
6471 WX. Eygelshoven
Netherlands
Telephone: [phone]
Fax: [phone]
FLUID POWE
R
FLUID POWE
R
SPX
