SRAM Quarq ShocWiz User manual

User Manual
95-3018-014-000 Rev A © 2016 SRAM, LLC

2
2
Table of Contents
Tools and Supplies.................................. 4
ShockWiz™................................................5
Hose Connectors.............................................................6
Battery Installation........................................................... 7
Mounting Boot Installation.............................................11
Suspension Forks .......................................................... 12
Installation.........................................................................14
Check Clearance ...........................................................23
Rear Shocks ................................................................... 25
Installation........................................................................27
Check Clearance ...........................................................34
ShockWiz App........................................35
Connect to App............................................................. 36
Select Altitude ................................................................45
Calibration Wizard .........................................................47
Select Tuning Style....................................................... 50
Ride Session .................................................................. 53
Shock Tuning Score ..................................................... 56
Suggestions ................................................................... 58
Detections ........................................................................61
Removal .................................................64
Maintenance ..........................................65

3
3
ShockWiz™ is not compatible with
all air suspension forks and rear
shocks. For a complete list of
incompatible suspension, go to
www.shockwiz.com.
ShockWiz firmware must be
updated after each app update.
Use the ShockWiz app to update
device firmware.
The ShockWiz app is available in
iOS® and Android® formats.
For regulatory compliance,
please visit www.shockwiz.com.
For recycling and environmental
compliance information, please
visit www.sram.com.
iOS® is a registered trademark of Cisco Technology, Inc.
Android® is a registered trademark of Google Inc.

4
4
Tools and Supplies

5
5
ShockWiz™

b
c
d
e
f
g
Mounting boot
Battery cover
LED status indicator
ShockWiz body
Air valve cap
Air inflation valve (L - 28°)
Air inflation valve (R - 17.5°)
ee
h
f
h
g
b
a
c d

6
6

b
Hose connector (90°)
Short hose
Hose Connectors

b
c
Hose connector (90°)
Long hose
Hose connector (0°)
a
a
b
c
a
b

7
7
Battery Installation
⚠WARNING
Do not use sharp or conductive
objects to remove the battery.
Keep the battery out of reach of
children.
Do not put the battery in your
mouth. If ingested, seek medical
attention immediately.
Do not disassemble, damage, or
puncture the battery.
Consult the battery manufacturer
for safe handling instructions.

8
8
Battery Installation
Gently lift one battery cover tab outward, then
the other, and remove the battery cover from the
ShockWiz™ body.
NOTICE
Do not use metal tools to pry the battery cover tab.
Metal tools may damage the cover.
2
1
Adjust Remove/Loosen

9
9
Battery Installation
Insert a new CR2032 coin cell battery into the battery
slot, terminal side in, positive side (+) out.
3
Positive Side Terminal Side
Install

10
10
Battery Installation
Install the battery cover onto the ShockWiz™ body. The
cover is secure when the each tab snaps into place.
NOTICE
Ensure the battery cover o-ring seal is clean and in the
groove around the ShockWiz body. Remove, clean, and
reinstall the o-ring if it is contaminated.
To avoid permanent damage caused by moisture, verify
the battery cover is securely attached before use.
4
Install

11
11
Mounting Boot Installation
Install the rubber mounting boot onto ShockWiz™ in the
desired orientation.
The rubber mounting boot can be installed onto
ShockWiz in multiple orientations. Choose the
orientation that best fits your suspension. It may be
necessary to adjust the boot depending on suspension
mounting orientation.
NOTICE
Failure to install the included protective rubber
mounting boot onto ShockWiz™ may cause damage to
the fork and/or rear shock.
2
1
Adjust Install

12
12
Suspension Forks
c
a
b
de
d
a
c
b

b
c
d
Crown
Damper
Air spring inflation valve
Lower leg arch

b
c
d
e
Upper crown
Damper
Air spring inflation valve
Lower crown
Lower leg arch
Single Crown Dual Crown

13
13
Attachment Locations
ShockWiz™ is not compatible with all air suspension
forks. For a complete list of incompatible suspension,
go to www.shockwiz.com.
NOTICE
Do not attach ShockWiz to any part of the fork that
moves independent of the air valve. ShockWiz must
not contact the fork upper tube or any part of the fork
that moves during compression. The hose cannot
move when the fork is compressed.
Front Arch Reverse Arch Dual Crown

14
14
Installation
Remove the air valve caps from ShockWiz™.
NOTICE
To avoid air loss during use, one air cap must be
installed on the unused ShockWiz air valve.
1
Remove/Loosen

15
15
Installation
Remove the positive air inflation valve cap from the
fork.
2
Remove/Loosen

16
16
Installation
The ShockWiz™ air inflation valves are oriented at
differing angles for various mounting orientations.
Your suspension may vary. Choose the optimal air valve
orientation for your suspension. Test fit the position and
orientation of ShockWiz before installation. The rubber
mounting boot may need to be repositioned.
28° 17.5°
10° 0°

17
17
Installation
Front Arch
Front Arch Forks: Position ShockWiz™ on the back of
the fork crown on the damper side. Orient the optimal
ShockWiz air valve (A) toward the fork air inflation
valve (B).
Reverse Arch Forks: Position ShockWiz on the front of
the fork crown on the damper side. Orient the optimal
ShockWiz air valve toward the fork air valve.
3
A
B
Adjust

18
18
Installation
Fat Bike - Front Arch
Position ShockWiz™ on the back of the fork crown on
the air inflation valve side.
Orient the optimal ShockWiz air valve (A) toward the
fork air valve (B).
3
A
B
Adjust

19
19
Installation
Dual Crown
Position ShockWiz™ on the fork upper crown on either
the damper or spring side.
ShockWiz can be attached to any location and in any
orientation on the upper crown.
Orient the optimal ShockWiz air inflation valve (A)
toward the fork air inflation valve (B).
3
A
B
Adjust

20
20
Installation
Insert cable ties through the guide holes in the
ShockWiz™ body and attach ShockWiz tightly to the
fork crown. The device should not move.
Cut the excess ends of the cable ties.
Install
4
