SSV Works CM-FKP65 User manual

CM-FKP65
Commander and Maverick
6.5” Speaker Front Kick Panels
SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: [phone] | Fax: [phone]
!
Please read and understand these
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects
in material or workmanship. All SSV Works Electronics are covered by a limited 1 year
warranty against defects in material or workmanship. All SSV Works Speakers are
covered by a limited 1 year warranty against defects in material or workmanship. Labor
for replacement of defective components is not covered. Contact SSV Works for further
warranty information.
1. CM2-FKP65-U Enclosures (1 pair)
2. 1/4” x 20 Allen Bolt x 6
TOOLS NEEDED FOR INSTALLATION
INSTALLATION NOTES
PARTS LIST
PARTS LIST IMAGES
3. 1/4” Washers x 6
4. 1/4” Nut x 6
The use of a thread locker is recommended on all screws to prevent loosening due to vibration. Sealing all wiring holes with a silicone sealer will
prevent moisture from entering the enclosure. The glove box does not need to be removed for Kick panel installation; ours was removed for photo
purposes only.
2. 1/4 x 20 Allen Bolt x 6
1. CM2-FKP65-U Enclosures
(1 pair)
3. 1/4” Washers x 6 4. 1/4” Nut x 6
-Wire Crimpers
- Wire Strippers
- 5/32 Allen Wrench
- 7/16” Open End Wrench
- Drill with 1/8” and ¼” Drill bit
- #2 Phillips Screwdriver
- T-30 Torx wrench
- Scribe or Marker

C. Drill a 1/4” hole in the enclosure for the speaker wire to run out
of, we recommend the at side toward the top of the enclosure.
D. Mount the enclosure into the vehicle using the supplied
hardware, putting the nut on the inside of the enclosure is
recommended. Removing the 4 - T-30 Torx along the side of
the vehicle will make this step easier.
E. Place the speaker into the enclosure and mark the 4 mounting holes with a
scribe or marker, Pre-drill the marked mounting locations using a 1/8” drill bit.
B. After marking the holes, drill the mounting holes with the
1/4” drill.
CM-FKP65
C D
B
A. Align the kick panel above the foot rest and ush against the
rewall and outside of the vehicle (under the glove box on the
passenger side & mid way up the rewall on the driver side);
the enclosure is in the correct mounting location when it sits
ush on all sides. Using a scribe mark the 3 mounting holes.
A
E E

F. Connect and install the speaker into the enclosure using the #2 Phillips screwdriver (be sure to connect the “+” speaker wire to the
“+” terminal on the speaker and the “-“ speaker wire to the “-“ terminal on the speaker), repeat for other side.
CM-FKP65
F F
G
WIRING INSTRUCTIONS
For proper sound, ensure the speaker polarity is correct connect the “+” to the “+” and the “-“to the “-“from the speaker wire to the amplier. If using with
an SSV Works complete system refer to the amplier wiring instructions for more detailed wiring information.
“+”
“+”
“+”
“+”
“ - ”
“ - ”
“ - ”
“ - ”
Amplier
© 2017 SSV Works, Oxnard, CA 93030 CM-FKP65 Rev. B 4-10-17
G. Route the speaker wire away from any moving parts and any
sharp metal, then connect to the amplier.
