WARRANTY INFORMATION:
All SSV Works enclosures are covered by alimited lifetime warranty against defects in
material or workmanship. All SSVWorks Electronics are covered bya li mited 1 year warranty
against defects in materia l or workmanship. All SSV Works Spea k ers are co vere dbya
limited 1 yearwarranty against defects in material or workmanship. Labor for replacemen tof
defective components is not covered. Contact SSV Works for further warranty infonnation.
RG4-DM3
Polaris Ranger
MRB3 Dash Kit
A
Please read and understand these
instructions completely before
. installation to avoid possible injury, or
damage to the accessory or vehicle.
-9/16" Bit -Phillips
Screwdriver
-Scribe
PARTS LIST IMAGES
1. MRB3 Dash Kit 2. MRB3 Dash Screws x6
A. Use a panel tool to extract push pins on the top of the center
cup holders.
INSTALLATION NOTES
Please refer to the MRB3 User Guide for
instructions for wiring and operation.
B. With push pins extracted, lift to remove the cup holder.

C. Place MRB3 dash mount onto the center cup holder panel,
and scribe the 4 comer mounting points.
E. Drill out the center of the cup holder for the controller cable to
be routed through with a9/16" drill bit
NOTE: Control drill bit depth to avoid puncturing through other
side of cup holder.
_ II
G. Route MRB3 controller cable through cup holder
D. Make pilot holes using a 3/32" drill bit
F. Place MRB3 controller in controller mount and fasten down
with provided screws.
H. Fasten the dash mount to cup holder with provided screws.
Refer to the MRB3 User Guide for instructions on how to complete wiring for the controller. Replace the cup holder panel.
UJCIRKS
• RG4-DM3
© 2018 SSVWorks, Oxnard ,CA93030 RG4-DM3 Rev. A 8-2-18
