Steelcase Opus User manual

Opus™ End Filler Panel
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©2014 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
®
Page 1 of 10
939500168 Rev F

Page 2 of 10
939500168 Rev F
1. Turn base assembly on it's side.
Lower the side panel onto the base
assembly as shown (1a). Make
sure there is a 1/8" offset at the top
of the base assembly and make sure
the front of the side panel is 3/4" from
the front of the canopy (1b). The
bottom will be flush to the top of the
base.
2. Secure side panel to base
assembly using eight (8) 1-1/4"
wood screws.
1a
EIGHT (8) 1-1/4”
WOOD SCREWS
2
SIDE PANEL
1/8" OFFSET
1b
3/4"

Page 3 of 10
939500168 Rev F
3. Align gussets at end of toeboard
(3a) and secure using four (4) 5/8"
wood screws (3b).
4. Align toeboard side to side
panel (4a) and attach using three (3)
1-1/4" wood screws (4b).
3a
4a
4b
3b
FOUR (4) 5/8”
WOOD SCREWS
TOEBOARD
SIDE GUSSETS
THREE (3) 1-1/4”
WOOD SCREWS

Page 4 of 10
939500168 Rev F
5. Push base unit into place.
6. Level base unit.
7. Secure units together and
place in position against wall.
Refer to assembly direction
#939500801.
8. Install storage cabinet.
Refer to assembly direction
#939500811.
5
6
BASE
UNIT

Page 5 of 10
939500168 Rev F
9. Remove drawers from the lower
storage cabinet.
TIP: Mark all drawers so they can be
easily re-installed in their original
positions.
10. Secure lower storage cabinet to
side panel using two (2) 1-1/4" wood
screws.
11. Re-install drawers.
9
10
TWO (2) 1-1/4”
WOOD SCREWS

Page 6 of 10
939500168 Rev F
12. Measure distance from base
assembly to wall at top and bottom.
NOTE: Before running filler panel through saw,
subtract 1/8" from each measurement to allow for
foam tape.
13. Run the filler panel through a table saw. When
trimming with a table saw, make sure the GOOD side
is FACE UP for a less amount of splintering. When
trimming with a circular saw, make sure the GOOD
side is FACE DOWN for a less amount of splintering.
CUT EDGE AWAY FROM HOLES.
12
13
12
SCRAP SIDE
BOTTOM
MEASUREMENT
TOP
MEASUREMENT
FILLER
PANEL

Page 7 of 10
939500168 Rev F
14. Peel paper backing from foam
tape (14a). Place foam tape onto
side of filler panel as shown (14b).
Cut excess foam tape when finished.
15. Insert (5) shoulder screws into
the holes on filler panel.
16. Determine length (X) at which
the toeboard needs to be cut. Cut
toeboard to length.
PAPER
BACKING
FOAM TAPE
14a
14b
15
16
SHOULDER
SCREWS
X
FILLER
PANEL

Page 8 of 10
939500168 Rev F
17. Align toeboard with side panel,
toeboard side and gussets (17a).
Attach toeboard by inseting four (4)
5/8" wood screws though gussets
and into toeboard (17b).
FOUR (4) 5/8”
WOOD SCREWS
TOEBOARD
GUSSETS
17a
17b
TOEBOARD

Page 9 of 10
939500168 Rev F
18. Align filler panel with side
panel (18a) and insert the
shoulder screws into the modeeze
clips (18b) located on the front of
the side panel. Push the panel
downward (18c), until shoulder
screw is securely seated (18d).
18a
18b
18c
18d

Page 10 of 10
939500168 Rev F
19. Measure distance from base assembly to wall at front and rear for dust
cover dimensions (19a). Run dust cover through table saw. Lower dust cover
into place (19b) and attach using three (3) 1-1/4" wood screws (19c).
20. Cut wall trim to length. Remove double face backer
tape and install onto front of filler panel and snug
against wall.
DUST COVER
19b
19c
THREE (3) 1-1/4”
WOOD SCREWS
19a
REAR
MEASUREMENT
FRONT
MEASUREMENT
WALL TRIM
20
