1
Introduction

Forklift data
We recommend that you record the principal
forklift data in the following table so that they
are available if required by the sales network
or authorised service centre.
Type
Serial number
Date of delivery
General information
●
This manual contains "Original Instructions"
provided by the manufacturer.
●
The "operator" is defined as the person
driving the forklift.
●
The "user" is the physical or legal person
who has the forklift truck used by the opera-
tors.
●
For correct use of the truck and in order to
avoid accidents, the operator is obliged to
read, understand and apply the contents of
this manual and the plates and stickers ap-
plied to the truck.
●
This manual must be stored carefully and
remain on board the truck for quick consul-
tation.
●
The manufacturer assumes no responsibili-
ty for any accidents to persons or damage
to things due to failure to observe the con-
tents of this manual and the plates and
stickers applied to the truck.
●
The forklift may not be put to any use other
that than indicated in this manual.
●
The forklift must be used by appropriately
trained operators only. For the necessary
operator training, contact the authorised
sales network.
●
Persons working near the forklift must also
be instructed in the risks associated with
use of the forklift.
●
In the interests of clear information, some il-
lustrations in this manual show the forklift
without the safety equipment (guards, pan-
els, etc.). The forklift may not be used with-
out safety equipment.
How to Consult the Manual
There is a table of contents at the beginning of
the manual for ease of use. The manual is
divided into chapters with specific topics. The
name and title of the chapter are given at the
top of each page The following is found at the
bottom of each page: the type of manual, the
identifying code, the language and the manual
version.
Some general information is provided in this
manual. Please only consider the information
relevant for your specific forklift.
The following symbols have been used to
highlight some parts of this manual.
DANGER
Failure to observe the instructions highlighted with
this symbol may jeopardise safety.
CAUTION
Failure to observe the instructions highlighted with
this symbol may cause damage to the forklift and, in
some cases, result in warranty invalidity.
Introduction
1
Forklift data
2 45378043433 EN - 11/2021 - 05

ENVIRONMENT NOTE
Failure to observe the instructions highlighted
with this symbol may cause environmental
damage.
NOTE
This symbol is used to provide additional infor-
mation.
Introduction
1
How to Consult the Manual
345378043433 EN - 11/2021 - 05

Date of edition and latest up-
date of this manual
The publication date of these operating in-
structions is printed on the cover sheet.
The manufacturer makes continuous efforts to
improve its industrial trucks, and therefore re-
serves the right to implement changes and to
accept no claims concerning the information
provided in this manual.
To receive technical assistance, please con-
tact the service centre authorised by your
closest manufacturer.
Copyright and trademark
rights
These instructions must not be reproduced,
translated or made accessible to third parties
—including as excerpts—except with the ex-
press written approval of the manufacturer.
Delivery of the forklift and documentation
Ensure that the truck has all of the options re-
quested and that it has been delivered with
the following documentation:
●
Original instructions
●
Declaration of conformity
If the truck has been delivered with a traction
battery and/or a battery charger, ensure that
these products conform to the order and that
the corresponding operating and maintenance
manuals are included, as well as the declara-
tion of conformity for the battery charger.
If there is applied equipment or other equip-
ment or devices, ensure that these products
conform to the order and that the correspond-
ing operating and maintenance manual and
the corresponding declaration of conformity (if
required by the applicable regulations) are in-
cluded.
All of the above documentation must be kept
for the entire operational life of the truck. In
the event that the documentation is lost or
damaged, contact the authorised sales net-
work for copies of the original documentation.
Introduction
1
Date of edition and latest update of this manual
4 45378043433 EN - 11/2021 - 05

Spare parts list
You can request to download the spare parts
list by copying and pasting the address
https://
sparepartlist.still.eu
into a web browser or by
scanning the QR code shown to the side.
On the web page, enter the following pass-
word:
Spareparts24!
On the next screen, enter your email address
and truck serial number to receive an email
with the link and download the spare parts list.
Conformity marking
The manufacturer uses the conformity mark-
ing to document the conformity of the industri-
al truck with the relevant directives at the time
of placing on the market:
●
CE: in the European Union (EU)
●
UKCA: in the United Kingdom (UK)
●
EAC: in the Eurasian Economic Union
The conformity marking is applied to the
nameplate. A declaration of conformity is is-
sued for the EU and UK markets.
An unauthorised structural change or addition
to the industrial truck can compromise safety,
thus invalidating the declaration of conformity.
2511

conformity symbols

Introduction
1
Spare parts list
545378043433 EN - 11/2021 - 05

Declaration that reflects the content of the declaration of con-
formity
Declaration
STILL GmbH
Berzeliusstraße 10
22113 Hamburg Germany
We declare that the specified machine conforms to the most recent valid version of the direc-
tives specified below:
Industrial truck type
corresponding to these operating instructions
Model corresponding to these operating instructions
− "Machinery Directive 2006/42/EC"
1)
− "Supply of Machinery Safety Regulations 2008, 2008 No. 1597"
2)
Personnel authorised to compile the technical documents:
See declaration of conformity
STILL GmbH
1)
For the markets of the European Union, the EU candidate countries, the EFTA States and
Switzerland.
2)
For the United Kingdom market.
The declaration of conformity document is
supplied with the industrial truck. The declara-
tion shown explains the conformity with the
provisions of the EC Machinery Directive and
the Supply of Machinery Safety Regulation
2008, 2008 No. 1597.
An unauthorised structural change or addition
to the industrial truck can compromise safety,
thus invalidating the declaration of conformity.
The declaration of conformity must be careful-
ly stored and made available to the responsi-
ble authorities if necessary. It must also be
Introduction
1
Declaration that reflects the content of the declaration of conformity
6 45378043433 EN - 11/2021 - 05

handed over to the new owner if the industrial
truck is sold on.
Introduction
1
Declaration that reflects the content of the declaration of conformity
745378043433 EN - 11/2021 - 05

Technical service and spare parts
For scheduled maintenance and any repairs to
the forklift, contact only the authorised service
network.
The authorised service network has personnel
trained by the manufacturer, original spare
parts and the tools necessary to carry out
maintenance and repairs.
Servicing by the authorised service network
and the use of original spare parts maintain
the technical characteristics of the forklift over
time.
Only original spare parts provided by the man-
ufacturer may be used for forklift maintenance
and repairs. The use of non-original spare
parts invalidates the warranty and renders the
user responsible for any accidents due to the
inappropriateness of the non-original parts.
Type of use
"Normal use conditions" of the forklift are un-
derstood as:
●
lifting and/or transport of loads using forks
with weight and load centre within the val-
ues provided (see Chapter 6 - Technical
Data).
●
transport and/or lifting on smooth, flat and
compact surfaces;
●
transport and/or lifting of stable loads uni-
formly distributed on the forks;
●
transport and/or lifting with the load centre
approximately on the forklift's median longi-
tudinal plane.
DANGER
The forklift must not be used for other purposes.
Any other use renders the user solely responsible for
injury/damage to persons and/or objects and voids
the warranty.
The following scenarios are examples of incor-
rect use of the forklift truck:
●
Transport on uneven (irregular or non-com-
pact) surfaces
●
loads that exceed the weight and/or load
centre limits;
●
transporting non-stable loads;
●
transporting loads not equally distributed on
the forks;
●
transporting swinging loads;
●
transporting loads whose load centre is
considerably displaced with respect to the
forklift's longitudinal median plane;
●
transporting loads of dimensions such as to
block the view of the operator when driving;
●
transporting loads piled so high that they
could fall onto the operator;
●
travelling with a load over 300 mm off the
ground;
●
transporting and/or lifting people;
●
Pushing loads
●
moving upwards or downwards on a slope
with the load facing downwards;
●
turning at high speed;
●
turning and/or moving sideways on slopes
(upwards or downwards);
●
colliding with stationary and/or mobile struc-
tures;
DANGER
Improper use of the forklift could cause it and/or at
the load to overturn.
Introduction
1
Technical service and spare parts
8 45378043433 EN - 11/2021 - 05

Working conditions
The truck has been designed and built for in-
ternal transport.
The truck must not be used outside the climat-
ic conditions indicated below:
●
Maximum ambient temperature: +40°C
●
Minimum ambient temperature: +5°C
●
Altitude up to 2000 m
●
Relative humidity between 30% and 95%
(without condensation).
CAUTION
Do not use the truck in dusty environments.
Using the truck in environments with high concentra-
tions of salty air or water could cause problems with
the truck and cause corrosion of metallic parts.
If the truck must be used in conditions outside
of the limits indicated or, in any case, under
extreme conditions (extreme weather, cold-
storage rooms, presence of strong magnetic
fields etc.), appropriate equipment and/or us-
age precautions are necessary. Contact the
authorised sales network for information.
DANGER
The truck must not be used in environments where
there is a risk of explosion and the truck must not
be used to handle explosive loads.
Trucks that must operate in environments
where there is a risk of explosion or trucks that
must handle explosive loads require the ap-
propriate equipment, which must be accompa-
nied by a specific declaration of conformity
that replaces that of the standard truck, and by
the corresponding operating and maintenance
manual.
Contact the authorised sales network for fur-
ther information.
Introduction
1
Working conditions
945378043433 EN - 11/2021 - 05

Modifications to Forklift
No modifications may be made to the forklift,
otherwise the EC certificate and the warranty
will become invalid, with the exception of:
●
Assembly of the options, only if provided by
the manufacturer
●
Assembly of applied equipment, only if pro-
vided by the manufacturer
WARNING
Before installing optional or additional equipment,
please exclusively contact the sales network author-
ised by the manufacturer.
DANGER
If the forklift is equipped at the factory or later with
devices that emit non-ionising radiation (such as ra-
dio transmitters, RFID players, data terminals,
scanners, etc), the compatibility of such devices
must be verified with the presence of operators us-
ing medical devices (such as heart pacemakers).
Applied equipment
To apply additional equipment after purchas-
ing, you must contact the sales network au-
thorised by the truck manufacturer, which will:
●
verify feasibility
●
install the equipment
●
add a label with the new residual capacity
●
provide documentation on the equipment
(operating and maintenance manual and
declaration of conformity)
CAUTION
The truck user must be trained in the operation and
correct use of the equipment
The user must check that the equipment is working
correctly before use.
User obligations
Users must comply with applicable local legis-
lation governing forklift use and maintenance.
Introduction
1
Modifications to Forklift
10 45378043433 EN - 11/2021 - 05

Environmental considerations
Disposal of components and
batteries
The truck is composed of different materials. If
components or batteries need to be replaced
and disposed of, they must be:
●
disposed of,
●
treated or
●
recycled in accordance with regional and
national regulations.
NOTE
The documentation provided by the battery
manufacturer must be observed when dispos-
ing of batteries.
ENVIRONMENT NOTE
We recommend working with a waste man-
agement company for disposal purposes.
Introduction
1
Environmental considerations
1145378043433 EN - 11/2021 - 05

Packaging
During delivery of the truck, certain parts are
packaged to provide protection during trans-
port. This packaging must be removed com-
pletely prior to initial start-up.
ENVIRONMENT NOTE
The packaging material must be disposed of
properly after delivery of the truck.
Introduction
1
Environmental considerations
12 45378043433 EN - 11/2021 - 05

2
Safety

Safety guidelines
General Precautions
NOTE
Some safety regulations to be followed when
using the forklift are listed below. These regu-
lations integrate those in the manual "
Rules
for approved use of industrial vehicles
".
General Safety Rules
●
Only allow qualified, trained and authorised
personnel to use the forklift.
●
Do not install equipment on the forklift un-
less supplied or indicated by the manufac-
turer.
●
Maintain the forklift in full working efficiency
in order to keep any type of risk to the mini-
mum.
●
Do not use the forklift with hoods and doors
open.
●
The data plates found on the forklift must be
kept in good condition and replaced if dam-
aged.
●
Carefully read and follow all of the safety in-
dications found on the forklift.
●
Make sure that the forklift has sufficient
overhead clearance.
●
Do not park the forklift in front of fire-fighting
devices or fire escapes or anywhere that it
blocks traffic.
●
If the forklift shows signs of failure or break-
age and there is reason to consider it un-
safe, stop, park it and notify the mainte-
nance manager.
●
Pay attention to the distances from high
voltage overhead cables. Comply with the
safety distances established by the compe-
tent authorities.
●
Never raise the load using just one fork.
●
Place the load on the fork carriage or in
such a way that the centre of gravity of the
load is as close as possible to the fork car-
riage.
●
The load must be placed on the forks so
that the centre of gravity falls on the mid
point between the forks.
●
Do not drive with loads decentralised later-
ally with respect to the forklift's median axis.
Lack of compliance with this regulation can
compromise forklift stability.
●
Make sure that the surface on which the
load rests is able to support its weight.
●
Always use safety clothing that complies
with the current regulations.
●
Do not travel on loose or hilly ground or on
steps.
●
Do not turn or stack on slopes.
●
Do not overload the forklift beyond the ca-
pacity limits indicated on the capacity
plates.
Flooring requirements
The work floor must be even and free of holes
or dips, which can be difficult to get around.
Any steps must be equipped with ramps to
prevent impacts with the wheels, which affect
the entire structure of the truck.
CAUTION
Passing over cracks or damaged parts of the floor
with the truck is prohibited. Dirt and any objects in
the work path must be removed immediately. The
employer must ensure that the flooring requirements
are met. For this reason, the manufacturer cannot be
held liable for any damage to the truck (especially to
wheels, hubs etc.) caused by use on unsuitable sur-
faces.
Safety
2
Safety guidelines
14 45378043433 EN - 11/2021 - 05
