Strong SRT 5001 User manual

www.strong.tv
User manual
Picture similar
Digital Terrestrial
Receiver SRT 5001

PART 1 • English
1
English
TABLE OF CONTENTS
1.0 INSTRUCTION 2
1.1 Safety Instructions 2
1.2 Storage 4
1.3 Equipment Set-up 4
1.4 Features & Accessories 4
2.0 CONNECTION 6
2.1 Connecting to Terrestrial Antenna 6
2.2 Connecting to TV and VCR 6
2.3 Connecting to a Digital Audio Amplifier 6
3.0 YOUR RECEIVER 6
3.1 Front Panel 6
3.2 Rear Panel 6
3.3 Remote Control 6
4.0 FIRST TIME INSTALLATION 7
5.0 MAIN MENU 7
5.1 Channel 7
5.2 Installation 9
5.3 Setup 10
5.4 Tools 12
5.5 Media+ 13
6.0 OPERATION 14
6.1 Changing Channels 14
6.2 Accessing the Electronic Program Guide (EPG) 14
6.3 Accessing the favourite channels 15
A.1 TROUBLESHOOTING 15
A.2 SPECIFICATIONS 16

PART 1 • English
2
1.0 INSTRUCTION
1.1 Safety Instructions
The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of not isolated dangerous voltage with
the inside of the product that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and servicing instructions in the literature
accompanying the appliance.
Read All Instructions - Before you use the product, read all operation instructions,
For more information on accessories such as the lithium ion battery, refer to the
manuals provided with those products.
Save These Instructions- Save all safety and operating instructions for future reference.
Heat Warnings - Read carefully and follow all warning labels on the product and
those described in the instructions.
Follow Instructions- Follow all instructions provided with this product.
Cleaning - Always unplug this product from the wall outlet before cleaning. Use
only a damp cloth for cleaning. Never use any type of liquid or aerosol cleaner, or
any type of organic solvent to clean this product.
Attachments - For your safety, and to avoid damaging the product, use only
accessories recommended by STRONG.
Water and Moisture - Never use this product around water (near a bathtub, kitchen
sink, laundry tub, wet basement. swimming pool or in the rain)
Location -To avoid damage to the product and prevent personal injury, never place
this product on an unstable stand, tripod, bracket, Follow the instructions that
describe how to safely mount the product, and use only the mounting devices
recommended by the manufacturer.
Power Sources - Connect this product only to the power source described on the
product label. If you are not sure about the type of power supply in your home,
consult your local power company.
Refer to instruction pages for information on using the product with a battery.
Grounding, Polarization - If this product is used with a specified AC adapter, the
adapter may be equipped with a polarized alternating current line plug (a plug with
one blade wider than the other). This safety feature allows the plug to fit into the
power outlet only one way, If you cannot insert the plug into the wall outlet, pull it
out, reverse it, and have the receptacle replaced.

PART 1 • English
3
English
Protecting the Power Cord - The power supply cord should be placed so it will not
be walked on. Never put a heavy object on the power cord or wrap it around the
leg of a table or chair. Keep the area around the power cord connection points, at
the power outlet, and at the product connection, free of all AC adapter or accessory
power cords.
GENERAL PRECAUTIONS - SAFETY PRECAUTIONS
Lightning - If a lightning storm occurs while using a specified AC adapter, remove it
from the wall outlet immediately. To avoid damage from unexpected power surges,
always unplug the AC adapter from the power outlet and disconnect it from the
receiver when the receiver is not in use.
Overloading - Never overload wall outlets, extension cords, power strips, or other
power connection points with too many plugs.
Foreign Objects, Liquid Spillage-To avoid personal injury caused by fire or electrical
shock from contact with internal high voltage points, never insert a metal object
into the product. Avoid using the product where there is a danger of spillage.
Heat - Never use or store this product near any heat source such as a radiator
heat register, stove, or any type of equipment or appliance that generates heat,
including stereo amplifiers.
Servicing - Refer all servicing to qualified personnel. Attempting to remove the covers
or disassemble the product, could expose you to dangerous high voltage points.
Damage Requiring Service - If you notice any of the conditions described below
while using a specified AC adapter. unplug it from the wall outlet and refer
servicing to qualified service personnel:
1. Liquid has been spilled onto the product or some other object has
fallen into the product.
2. The product has been exposed to water.
3. The product does not operate normally despite following operating
instructions. Adjust only the controls described in the operating
instructions ad improper adjustment of other controls could damage
the product and require extensive repair word by a qualified technician.
4. The product has been dropped or damaged in any way.
5. The product exhibits distinct change in performance.
Replacement Parts - When replacement parts are required, mare sure that the
authorized service centre uses only parts with the same characteristics as the
originals, as recommended by the manufacturer. Unauthorized substitution of
parts could result in fire, electrical shock, or create other hazards.
Safety Check - Upon completion of servicing or repairs, ask the service technician
to perform safety checks to determine that the product is in good working order.

PART 1 • English
4
Apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
Where the mains plug or all-pole mains switch is used as the disconnect device,
the disconnect device shall remain readily operable.
1.2 Storage
Your receiver and its accessories are stored and delivered in a packaging designed
to protect against electric shocks and moisture. When unpacking it, make sure that
all the parts are included and keep the packaging away from children.
When transporting the receiver from one place to another or if you are returning
it under warranty make sure to repack the receiver in its original packaging with
its accessories. Failing to comply with such packaging procedures could void your
warranty.
1.3 Equipment Set-up
We recommend you consult a professional installer to set up your equipment.
Otherwise, please follow these instructions carefully:
n Refer to the user manual of your TV and your antenna.
n Make sure that the SCART cable and outdoor components of the
antenna are in a good condition and the SCART connections are
well shielded.
This manual provides complete instructions for installing and using this receiver.
The following symbols will serve as follow.
WARNING Indicates warning information.
Tips Indicates any other additional important or helpful information.
MENU Represents a button on the remote control or the receiver
(Bold Character)
Move to Represents a menu item within a window. (Italic Character)
1.4 Features & Accessories
n For all* digital Free-To-Air TV and Radio programmes (with outdoor- or
indoor antenna)
n Quick and easy installation & user-friendly menu
n Excellent Audio- and Video quality
n 1 000 channels memory capacity

PART 1 • English
5
English
n Fast channel zapping: sorting by alphabet, free/encrypted channels
n Electronic TV Programme Guide (EPG) for on screen programme
information of present/following event information up to 7 days **
n 8 wake-up Timers with 4 modes (once, daily, weekly, monthly)
n Sleep Timer (10, 30, 60, 90, 120 min)
n Booking of events directly from EPG
n Full multi-lingual DVB subtitling and audio track support**
n Support Teletext** via receiver and TV remote control
n 8 Favourite lists for TV- and Radio programmes
n Parental lock function for menu and rating control for channel
n Multi-lingual support on screen menu (OSD), such as English,
German, French, Italian, Spanish, Czech
n USB 1.1 port: for software update, playing video and music files and
viewing photos
n Automatic and manual channel scan options
n Many channel handling options: locking, editing, moving, sorting,
skipping, deleting and searching
n Power on with last viewed channel
n User-friendly Remote Control
n NTSC/PAL converting automatically and manually
n 3 Games (Tetris, Snake, Othello)
n Digital sound through coaxial output (S/PDIF) by connecting to
digital amplifier
n DVB-T compliant, UHF/VHF Tuner with Loop-through function
n Support of active antenna by 5 V output
n Connections: ANT IN, TO TV, TV SCART, S/PDIF Coaxial, USB port
* Depending on local signal conditions
** Availability depending on broadcaster
Accessories:
n 1 User Manual
n 1 Remote control unit
n 2x Batteries (AAA type)
Note: The batteries should not be recharged, disassembled, electrically short-
circuited or be mixed or used with other types of batteries.
If rechargeable accumulators instead of batteries are going to be used, we
recommend using (e.g. NiMH) types with low self-discharge to ensure long time
operation of remote control.

PART 1 • English
6
2.0 CONNECTION
2.1 Connecting to Terrestrial Antenna
To receive the broadcast signal, the terrestrial antenna cable should be connected
to the ANT IN connector at the back of the receiver. (Fig. 1)
2.2 Connecting to TV and VCR
2.3 Connecting to a Digital Audio Amplifier
Connect your Digital Audio Amplifier with the S/PDIF connector on the back of the
receiver (Fig. 2).
3.0 YOUR RECEIVER
3.1 Front Panel
Fig. 3
3.2 Rear Panel
Fig. 4
1.
ANT IN To connect an antenna for reception of broadcasting signal.
2. TO TV To connect a TV set or to connect an extra receiver.
3. S/PDIF (Coax.) To connect your receiver to digital audio amplifier.
4. USB Connects to USB device
5. TV SCART To connect your receiver with your TV set using a SCART
cable.
6. Power Cord Your receiver requires a voltage of 220 – 240 V AC (Auto-
selectable), 50/60 Hz ± 5 %. Make sure to check the power
specification before connecting your receiver to the
wall outlet.
3.3 Remote Control
Fig. 5
1. MUTE Turns the receiver On/Standby
2. POWER Mutes audio output of the receiver
3. PAGE+/PAGE- Page up/down
4. RECALL Back to previous shown channel
5. VOL+/VOL- Volume up/down
6. MENU Opens the main menu/In menu you will get one step back

PART 1 • English
7
English
7. EXIT Exits from the menu or sub-menu
8. pq Menu Off: Change channel to previous/next.
Menu On: Moves the cursor up/down.
9. tu Menu Off: Increases/decreases the volume level.
Menu On: Change settings n specific Menus
10. OK Menu On: Activates the highlighted menu item.
Menu Off: Displays the current channel list
11. EPG Shows the EPG (Electronic Program Guide) in TV mode
12. INFO Shows the actual channel information
13. FAV Favourite group selection
14. SUBTITLE Shows list of subtitled languages
15. [0~9] Channel selection or value input
16. AUDIO Sets the current audio channel to left, right or stereo
17. PAUSE Freeze/Resume picture
18. TV/RADIO Toggles between TV or RADIO mode
19. TXT Shows Teletext on OSD (On Screen Display) if applicable
20. COLOURED BUTTONS for Teletext functions
4.0 FIRST TIME INSTALLATION
If you use the receiver for the first time, the “Easy Install” menu appears. Use the
tu buttons to change settings for setup of Region, OSD Language and Antenna
Power and the pq to select. Then use the pq buttons to move focus to Search
and press OK to proceed with the automatic channel scan.
5.0 MAIN MENU
In viewing mode always press MENU to enter the Main Menu. It consists of
following submenus: Channel, Installation, Setup, Tools and Media+
5.1 Channel
1. Use the pq buttons to select Channel and press OK to enter.
2. Use the pq buttons to highlight the desired item and press OK to select.
3. Press EXIT to exit.
Note: You can also press OK in TV mode to enter channel list.
5.1.1 TV Channel list
1. In Channel submenu select TV Channel List with the pq buttons and
press OK to enter.

PART 1 • English
8
2. Use the tu buttons to change channel group (assumed you have
already set up Favourite groups).
3. With the pq buttons select the channel you want to watch. With OK
you can watch the selected channel in full screen mode.
5.1.1.1 Edit
Use this menu to favour, lock, skip, delete and rename channel list. Press numeric
button [1] to enter edit menu.
With the pq buttons highlight a channel and press OK to select or press numeric
button [0] to select all channels. Selected channels will get marked. This way of
selection can be executed for each of the edit functions.
n Favor: To add selected channel or all channels to a favourite group,
press the [1] button. Use the pq to select a desired group and press
OK. With tu select Yes in the confirmation window and press OK to
save. Selected channels will get marked with folder symbol.
n Lock: To Lock channel or all channels press button [2], with tu
select Yes in the confirmation window and press OK to save. Selected
channel/s will get marked with the œ symbol.
n Skip: To Skip channel or all channels press button [3], with tu
select Yes in the confirmation window and press OK to save. Selected
channel/s will get marked with the … and will be skipped during
channel zapping in full screen mode.
n Delete: To Delete channel or all channels press button [4], with tu
select Yes in the confirmation window and press OK to save.
If you have done all modifications concerning channel editing, press EXIT to cancel.
5.1.1.2 Find
Press the [2] button in to enter Find menu.
Use the pqtu buttons to highlight desired letters or numbers and press OK to
insert. After each character, the channel list will search the channel according your
input and list the matched channel.
Press EXIT to quit Find mode.
5.1.1.3 Sort
Press the [3] button in to enter Sort menu.
Use the pq buttons to highlight desired sort way and press OK to confirm.
Default: Sorting by searched Order (from lowest to highest frequency).
Name (A-Z): Sorting in Alphabetical Order.

PART 1 • English
9
English
Name (Z-A): Sorting in Alphabetical Order.
FTA: First in the list will be Free-To-Air channels.
Lock: First will be listed all unlocked and then the locked channels at
the end.
5.1.1.4 Move
Press the [4] button to activate the Move function.
The selected channel will be marked in a symbol, use the pq buttons to
move the selected channel to the desired position. With tu select Yes in the
confirmation window and press OK to save.
5.1.2 Radio Channel list
Basically, the operation of Radio Channel List is the same as in TV Channel List
only difference is that in Radio Channel List there is no video information, so it will
always display the radio logo at the right preview screen.
5.1.3 Delete all Favourites and Groups
Use this menu to delete all favourite channels. Select Delete All Favourites with the
pq and press OK, with tu select Yes in the confirmation window and press OK
to delete or select No to cancel.
5.1.4 Delete all
Use this menu to delete all channels. Select Delete All with the pq and press OK,
then enter the Password (default: 0000). In the confirmation window select Yes with
tu and press OK to delete or select No to cancel.
5.1.5 Group Rename
In this menu you can change favourite group name. Use the pq buttons to select
Group Rename and press OK to enter.
1. With the pq buttons select a group and press OK.
2. At the appearing Keyboard use the pqtu buttons to highlight
desired letters or numbers and press OK to insert. After you entered
desired group name, highlight OK at the keyboard to confirm
3. Press EXIT button to cancel the group rename.
5.2 Installation
5.2.1 Auto Scan
1. Use the pq buttons to select Installation, press OK button to enter menu.

PART 1 • English
10
2. With the pq buttons select Auto Scan, press OK to enter the menu.
3. Press the tu buttons to change Scan mode, and use the pq to
highlight Search, press OK to start auto scan.
5.2.2 Channel Scan
1. Use the pq buttons to select Installation, press OK to enter the menu.
2. With the pq buttons to select Channel Scan and press OK to enter
the menu.
3. Use the tu buttons to select one of two Scan Modes – By Channel
and By Frequency.
4. When By Channel is selected use the cursor buttons to select Scan
Band and Channel No. When By Frequency is selected use the cursor
buttons to select Frequency and Bandwidth. Select Network Search
to ON or OFF, highlight Search and press OK to start scan. After
Channels are found, they will be stored and receiver switches to the
first one saved in the list.
5.2.3 Antenna Setting
1. Press MENU to enter main menu.
2. Use the pq buttons to select Installation, press OK to enter the menu.
3. With the pq buttons select Antenna setting and press OK to enter.
4. Press the tu buttons to change setting. If On is selected, the receiver
will provide 5 V antenna power (for active antennas).
5. Press EXIT button to exit.
5.2.4 LCN Mode
If LCN (Logical Channel Number) is activated and LCN signal is provided by
operator, then channels will be stored at operator defined order. You can activate/
deactivate the LCN function by setting the "LCN Mode" to ON/OFF.
5.3 Setup
This menu allows you to set OSD Language, TV System, Region and Time, Timer
Setting, OSD Setting and Parental Lock.
1. Press pq buttons to highlight desired menu and press OK button
to enter the setting menus. Then press pq buttons to select desired
item. Settings can be changed by pressing tu buttons. You can get
better overview if press OK first. Now you can select desired setting by
pq buttons and confirm it with OK.
2. Press EXIT button to exit.

PART 1 • English
11
English
5.3.1 OSD Language
This menu allows you to set OSD Language.
5.3.2 TV System
This menu allows to setup different settings concerning your TV set.
Display Mode: PAL/NTSC/AUTO
Aspect Ratio: Use this menu to configure the screen aspect between: 4:3 PS
(Pan&Scan), 4:3 LB (Letter Box) and 16:9 (Wide Screen)
Video Output: Use this menu to switch the video output mode either to RGB
or to CVBS
5.3.3 Region and Time
Here you can set your region and time zone.
Region: This menu is used for changing the region setting.
GMT Usage: This menu is used for usage of GMT.
The options are: Off / User Define / By Region
GMT Offset: This menu is valid only when selected “User Define” in GMT
Usage menu. The GMT offset range is “-11:30 ~ +12:00”,
increasing by half hours progressively.
Date/Time: “Date” and “Time” menus are valid only when selected “Off” in
GMT Usage menu. Press OK then numeric button to change
the date and time.
Time Display:
This menu allow to control whether the time is displayed on
screen or not. The options are: Off/On.
5.3.4 Timer Setting
In this menu you can set a programme timer or sleep timer.
Programme timer
Timer Number: You can set 8 timers
Timer Mode: Off/Once/Daily/Weekly/Monthly
Timer Service: TV Service/Radio Service
Wake-up Channel: You can select a desired channel as wake-up channel.
Month/Date/Day: Press pq buttons to select your desired month, date and day.
Time: Press OK to input the time with the numeric buttons.
When you want to quit programme timer, a saving window appears, with tu
select Yes in the confirmation window and press OK to save or select No to cancel.
Duration: Press OK to input desired duration with the numeric buttons.

PART 1 • English
12
Sleep Timer
You can set the receiver to power OFF in 10 min, 30 min, 60 min, 90 min and
120 min automatically.
5.3.5 OSD Setting
This menu allows you to change settings for: Subtitle Display, OSD Transparency,
and Load Default OSD Setting.
Subtitle Display: To set the subtitle to Standard or OFF.
OSD Transparency: To set the OSD transparency from Off ~ 50 %.
Load Default
OSD Setting: To clear all OSD settings and reset to default value.
5.3.6 Parental Lock
This menu allows you to protect the installation menu, or channels with a
password and you can change the Password. If you want to enter the menu you will
be asked to input the password (default: 0000).
Menu Lock: Locks the installation menu. You can set menu lock to ON/OFF.
Channel Lock: Off/Manual/Age:4 - Age:18
New Password: To change the password.
Confirm Password: To confirm the new password.
5.4 Tools
Select Tools submenu and press OK to enter the menu
Press MENU button to enter main menu. Select “Tools” and press OK button to
enter tools menu.
1. Press pq buttons to highlight the desired menu and press OK
button to enter.
2. Press EXIT button to exit.
5.4.1 Receiver Information
This menu displays some Receiver information like Hardware, Software, Signature
and Remote Control and our Web site www.strong.tv.
1. In Tools menu, select “Receiver Information” and press OK button to
open receiver information window.
2. Press EXIT button to exit.
5.4.2 Game
This menu allows you to play games (Tetris, Snake and Othello) on this receiver.
1. Select “Game” in Tools menu and press OK button to enter game menu.

PART 1 • English
13
English
2. Press pq buttons to select a desired game, and press OK button to
enter the game. Highlight “Start” and press OK button to start the
game. For changing levels highlight “Setup” and use tu buttons.
3. Press EXIT button to quit the game
Note: You can also press OK button to pause playing
5.4.3 Load Factory Default
This menu allows you to reset the receiver back to factory settings, clear all existed
channels.
Note: This option will delete all your settings and channel lists and set your
receiver to factory default!
1. Enter “Tools” menu, select “Load Factory Default” and press OK
button, you are asked to input password.
2. Input a correct password using the numeric buttons (the default
password is “0000”), a confirmation window is displayed.
3. Select “Yes” to return back to factory settings and clear all channels.
Select “No” to cancel.
4. Press EXIT button to exit.
5.4.4 Software Upgrade
1. Enter “Tools” menu, select “Software Upgrade” and press OK button,
Software Upgrade menu is shown.
2. Press pq buttons to select the desired item and press OK button,
you are asked to input password.
3. Input the correct password (the default password is 0000), Software
Upgrade sub- menu is opened. Press OK to start.
4. Press EXIT” button to exit.
5.5 Media+
Select “Media+” and press OK button to enter Media+ menu.
1. Press MENU button to enter main menu. Select “Media+” and press
OK button to enter Media+ menu.
2. Press pq buttons to highlight desired menu and press OK button
to enter.
3. Press EXIT button to exit.
Use the two button rows in bottom of RCU for Player operation. Button´s
description on display.

PART 1 • English
14
5.5.1 Media Player
This function allows you to play MPEG-2, Audio and Photo files from connected
USB device
1. In “Media+” menu, select “Media Player” and press OK button to enter
Media Player menu.
2. Press pq buttons to select a desired item, and press OK or PLAY
button to play the desired files.
3. Press EXIT button to exit.
5.5.2 Safely Remove Storage Device
In “Media+” menu, select “Safely Remove Storage Device” and press OK button to
confirm. Then a window is displayed.
6.0 OPERATION
6.1 Changing Channels
There are 4 ways of channel selection - stepping through the channel list, selection
by number, from the on-screen channel list, and using the electronic programme
guide (EPG).
1. Stepping through the channel list
To move through the channel list, press the pq buttons on the
remote control.
2.
Selected by number
Enter the channel number directly by pressing numeric buttons, and
press the OK button to select desired channel.
3. Selected by on-screen channels list
You can also select the required channel directly from on-screen
channel list. This is displayed using the receiver’s main menu. See
chapter 5.1.1 TV Channel list in this manual for operation detail.
4. Selected by EPG
You can also select the required channel directly from electronic
programme guide (EPG). This is displayed using the receiver’s main
menu. See “Accessing the Electronic Program Guide (EPG)” in this
manual for operation detail.
6.2 Accessing the Electronic Program Guide (EPG)
1. Press EPG button to enter EPG menu.
2. Press numeric button [2] to switch between channel list, events
schedule of the selected channel and now/next events.

PART 1 • English
15
English
3. In the event schedule, press OK button to book the selected event, press
numeric button [3] to open the Detail menu for the selected event.
4. Press numeric button [1] to open the Booking list menu.
6.3 Accessing the favourite channels
1. Press FAV button to enter favorite group menu.
2. Press “UP” or “DOWN” cursor buttons to select the desired favourite group.
3. Press OK button to enter the favorite channels list, and press pq
buttons to select the favourite channel.
A.1 TROUBLESHOOTING
There may be various reasons for the abnormal operation of the receiver. Check the
receiver according to the procedures shown below. If the receiver does not work
properly after checking it, please contact the dealer. Do NOT open the receiver
cover. It may cause a dangerous situation and the warranty will get void.
Problem Possible cause What to do
Standby light not lit Mains lead unplugged
Mains fuse blown
Check mains lead
Check fuse
No signal found Aerial is disconnected
Aerial is damaged/misaligned
Out of digital signal area
Check aerial lead
Check aerial
Check with dealer
No picture or sound Scart/AV is not selected on
your TV
Reduce to another channel
Scrambled channel
message
Channel is scrambled Select alternative channel
No response to remote
control
Receiver off
Handset not aimed correctly
Front panel obstructed
Hand set batteries exhausted
Plug in and turn on plug
Aim handset at front panel
Check for obstructions
Replace handset batteries
Forgotten channel lock code Re-install channels to cancel
channel lock
Forgotten menu lock code Contact help line
After moving the receiver to
another room you find you
are no longer able to
receive digital reception
The aerial feed former new point
may come through a
distribution
system which may reduce the
digital signal now received
by the box.
Try a direct feed from the
antenna

PART 1 • English
16
A.2 SPECIFICATIONS
Demodulator
Demodulator: COFDM;
16-QAM/64-QAM
Transmission mode: 2K, 8K
Video Decoder
Profile level: MPEG-2 MP@ML
Video resolution: 720 x 576 pixels
(PAL), 720 x 480 (NTSC)
Decoding & Video Out: PAL & NTSC
Aspect ratio: 4:3, 16:9
Audio Decoder
MPEG MusiCam Layer II
Sampling rate: 32, 44.1, 48 KHz
Audio mode: Stereo, Joint Stereo,
Dual Mono, Mono
Tuner
Front End: DVB-T, UHF & VHF Tuner
Input frequency range: 174 – 230 MHz
(VHF) and 470 - 862 MHz (UHF)
Loop through frequency range:
47 ~ 862 MHz
Input signal level: -82 ~ -20 dBm
Multimedia
Video playback – MPEG-1 and
MPEG-2 encoded (mpg)
Audio playback – MP3 and WMA
Picture view – JPEG format
Memory and System
Flash memory: 1 MByte
SDRAM: 8 MBytes
Connectors
ANT IN - IEC Female
TO TV - IEC Male
TV SCART (RGB, CVBS)
S/PDIF: coaxial output
USB 1.1 port
General Data
Supply Voltage :220 - 240 V AC
(SMPS), 50/60 Hz
Power Consumption: 4.5 W (typical);
8 W (max)
Power consumption in Standby: 3.4 W
Operating Temperature: 0°~ +40 °C
Storage Temperature: -30°~ +80 °C
Operating Humidity Range: 10 ~ 85 %,
RH, Non-condensing
Net-weight: 0.5 kg
Size (W x D x H) in mm: 180 x 135 x 43
Subject to alterations. In consequence of continuous research and development
technical specifications, design and appearance of products may change. All
product names are trademarks or registered trademarks of their respective owners.
© STRONG 2009. All rights reserved. 04/2009
