Assembly Instructions
D-GZ844PCO-I (Black Top) / D-GZ844PCO-I1 (Faux Copper Top)

Congratulations on your purchase of our SUNJOY 12’x12’ Hardtop Gazebo. Our clear, easy to
follow, step-by-step instructions will guide you through the assembly process from start to
finish.
●This unit is heavy. Do not assemble this item alone. 6-8 people are recommended for safe
assembly.
WARNING:
●Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the area of the Gazebo construction.
●Keep assembly area at least 6 feet from any obstruction such as a fence, garage, house,
overhanging branches, laundry line or electrical wires.
●Some parts may contain sharp edges. When assembling and using this product, basic safety
precautions should always be followed to reduce the risk of personal injury and damage to the
product. Please read all instructions before assembly and use.
●Check all bolts for tightness before use, and periodically check and tighten bolts as
necessary.
●Assemble on level ground.
IMPORTANT
Please take time to read these instructions thoroughly and follow each step carefully for safe and easy
operation. Keep this manual for future reference.
For technical assistance on assembly or replacement parts. Please call Sunjoy Industries at 1-866-578-6569
from 8:00 am EST to 8:00 pm PST or fax the replacement part form which is in the box to 1-740-283-3549 or
Email [e-mail] for assistance.

Parts List
Description No. Qty. Picture
Decorative Gutter 1 1A 4
Decorative Gutter 2 1B 4
Middle Beam Bottom Connector 1C 4
Oblique Beam Bottom
Connector 1D 4
Oblique Beam 2A 4
Middle Beam 2B 4
Left Big Roof Long Support 2C 4
Right Big Roof Long Support 2D 4
Left Big Roof Short Support 2E 4
Right Big Roof Short Support 2F 4
Big Roof Up Frame 2G 1
Finial 3A 1
Small Roof Cover 3B 1
Small Roof Sheet 3C 4
Small Roof Cover Presser 3D 4
Small Roof Oblique Beam 3E 4
Small Roof Connector 3F 1
Big Roof Left Big Cover 4A 4
Big Roof Right Big Cover 4B 4
Big Roof Left Middle Cover 4C 4
Big Roof Right Middle Cover 4D 4
Big Roof Left Small Cover 4F 4

Big Roof Right Small
Cover 4E 4
Cover Long Presser 4I 16
Cover Short Presser 4J 8
Hook Beam 4K 1
Hook 4L 1
Tabletting 4M 4
Big Roof Bottom
Press 5A 4
Big Roof Up Press 5B 4
Big Screen 6A 4
Small Screen 6B 4
Top Base 6D 4
Post Cover 6E 4
Curtain Middle
Connector T1 4
Curtain Left
Connector T2 4
Curtain Right
Connector T3 4
Netting and Curtain
Rods T4 16
Hardware Pack 1
BB Flat Washer M6 36 PCS
CC Bolt M6X20 8 PCS

Hardware Pack 2
BB Flat Washer M6 60 PCS
DD Bolt M6X55 12 PCS
EE Nut M6 12 PCS
KK Bolt M6X15 48 PCS
Fig.1: Insert Decorative Gutter (1A) into Decorative Gutter (1B), tighten with Bolt (KK) and Flat Washer BB. (Fig.1)
Note: Do not tighten the other side.
Fig.2: Insert 1 of the rest Decorative Gutter (1A) into baffle on assembled Decorative Gutter (1B), tighten with Bolt
(LL) and Flat Washer (BB) .(Fig. 2).
Fig.3: Lock Middle Beam Bottom Connector (1C) and Curtain Connector (T1) to the middle neck of Decorative
Gutter (1A) into Decorative Gutter (1B) by using Bolt (CC) and Flat Washer (BB).
Fig.3-1: Lock Oblique Beam Bottom Connector (1D) to Decorative Gutter (1A) into Decorative Gutter (1B) by using
Bolt (KK) and Flat Washer (BB).
KK Bolt M6X15 20 PCS
LL Bolt M6X35 8 PCS
WW Wrench 2 PCS

Fig.4-1: Lock Oblique Beam (2A) to Oblique Beam Bottom Connector (1D) by using Bolt (DD) and Flat Washer (BB).
Fig.4-2: Lock Oblique Beam (2A) to Big Roof Up Frame (2G) by using Bolt (KK) and Flat Washer (BB).
Fig.5-1: Lock Middle Beam (2B) to Middle Beam Bottom Connector (1C) by using Bolt (DD), Flat Washer (BB) and
Nut (EE).
Fig.5-2: Lock Middle Beam (2B) to Big Roof Up Frame (2G) by using Bolt (KK) and Flat Washer (BB).
Fig.6-1: Lock Left Big Roof Short Support (2E) and Right Big Roof Short Support (2F) to Oblique Beam
(2A) by using Bolt (KK) and Flat Washer (BB). (The same way to assemble Left Big Roof Long Support
(2C) and Right Big Roof Long Support (2D).)
Fig.6-2: Lock Left Big Roof Short Support (2E) and Right Big Roof Short Support (2F) to Middle Beam
(2B) by using Bolt (KK) and Flat Washer (BB). (The same way to assemble Left Big Roof Long Support
(2C) and Right Big Roof Long Support (2D).)

Hardware Pack 3
BB Flat Washer M6 24 PCS
DD Bolt M6X55 4 PCS
EE Nut M6 4 PCS
FF Bolt M6X40 8 PCS
KK Bolt M6X15 12 PCS
Fig.7-1: Lock Small Roof Oblique Beam (3E) to Small Roof Connector (3F) by using Bolt (DD), Flat
Washer (BB) and Nut (EE).
Fig.7-2: Lock Small Roof Oblique Beam (3E) to Big Roof Up Frame (2G) by using Bolt (KK) and Flat
Washer (BB).
Fig.8-1: Lock Small Roof Sheet (3C) to Small Roof Oblique Beam (3E) by using Bolt (KK) and Flat
Washer (BB).

Hardware Pack 4
AA Bolt M6X20 20 PCS
BB Flat Washer M6 56 PCS
GG Stake Φ8 x 250 8 PCS
JJ Spring Washer M6 24 PCS
KK Bolt M6X15 24 PCS
MM Bolt M6X40 12 PCS
QQ
Expansion Bolt M6X70
8 PCS
Fig.8-2: Lock Small Roof Cover Presser (3D) to Small Roof Oblique Beam (3E) by using Bolt (FF) and Flat Washer (BB).
Fig.8-3: Assemble Small Roof Cover (3B) firstly, then screw Finial (3A) to Small Roof Connector (3F).

Hardware Pack 5
BB Flat Washer M6 96 PCS
FF Bolt M6X40 8 PCS
KK Bolt M6X15 88 PCS
Fig.9-1: Lock Screen (6B) to (6A) by using Bolt (MM) and Washer (BB).
Fig.9-2: Attach Top Base (6D) to Screen (6A/6B) by using Bolt (KK) and Washer (BB), lock tightly.
Fig.10-1: Lift up assembled big roof, then using Bolt (AA) and Flat Washer (BB) to lock Decorative Gutter
1A/1B to Top Base (6D).
Fig.10-2: Lock Oblique Beam Bottom Connector
(1D) to Top Base (6D) by using Bolt (AA) and
Washer (BB).
Fig.10-3: Lock Post Cover (6E) to Top Base (6D)
by using Bolt (KK) and Flat Washer (BB).
Fig.11:
On grass, use Stake (GG) to fasten the gazebo.
On concrete floor, use expansion bolt (QQ) to fasten the gazebo.

Fig.12-1: Screw Hook (4L) to Hook Beam (4K).
Fig.12-2: Cover Big Roof Left & Right Cover on the Roof, then Put Big Roof Right Big Cover (4B)
on Big Roof Left Big Cover (4A).
Fig.12-3: Lock Big Roof Left Big Cover (4A) and Big Roof Right Big Cover (4B) to (2A) by using
Bolt (KK) and Flat Washer (BB).
Fig.12-4: Lock Tabletting (4M) to Hook Beam (4K) by using Bolt (KK) and Flat Washer (BB). (The
Tabletting (4M) need to press on the folding of the Cover).
Fig.13-1: Lock Big Roof Left Middle Cover (4C)/ Big Roof Right Middle Cover (4D) and Big Roof Right
Small Cover (4E)/Big Roof Left Small Cover (4F) to Oblique Beam (2A) by using Bolt (KK) and Flat
Washer (BB).
Fig.13-2: Lock Cover Long Presser (4I) to Decorative Gutter by using Bolt (KK) and Flat Washer
(BB).(Long presser press on the big / middle cover, the shorter presser press on the small cover.)
