Sunjoy PINEHURST L-GZ1188PST User manual


CountryofOrigin:ChinaProductionNumber:xxxxxxxx





































PINEHURST GAZEBO 10X12 FT
ASSEMBLY INSTRUCTION
ITEM#：L-GZ1188PST
SKU#：810362040
Ifyouhaveanyissueswiththeproduct,donotreturn
theproductbacktothestore
Foranyquestionsorissuesaboutourproduct
CallSunjoyCustomerService
1(866)578‐6569
8:00AMEST–8:00PMPST
Forfurtherassistance,pleasewritetousat
[e-mail]


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
2/28




































Safety Information
More than Two people are required for this
assembly.
Some parts may contain sharp edges. Wear
protective gloves.
When assembling and using this product,
basic safety precautions should always be
followed to reduce the risk of personal
injury and damage to equipment. Please read
all instructions before assembly and usage.

Thelimitedwarrantyisextendedtotheoriginalpurchaserandappliestomaterialandmanufacturer’sdefectprovided
theitemismaintainedwithcareandusedonlyforpersonal,residentialpurposes.
Warranty: 1 Year
WHAT IS COVER?
IMPORTANT
KEEPTHISINSTRUCTIONMANUALFORFUTUREREFERENCE.
CAUTION: Do not climb on top of the
gazebo. Falling off the gazebo can
result in serious injury.
NOTICE: For outdoor use only.
DANGER: This unit is heavy! Do not assemble
this item alone.
WARNING: Do not leave the gazebo where there
is a risk of high wind, as possible damage will
occur to the structure.
WARNING: Keep all flame and heat sources
away from this gazebo fabric. This Gazebo is
made with fabric that meets CPAI-84
specifications for flame resistance. It is not fire
proof. The fabric will burn if left in continuous
contact with any flame source. The application
of any foreign substance to the gazebo fabric
may render the flame-resistant properties
ineffective.


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
3/28




































TOOLS NEEDED
IMPORTANT
How many people needed for the installation work
Provided in hardware pack


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
4/28

EXPLODED DRAWING


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
5/28
Parts List
LabelPart NumberDescription Qty Part Image
A P11101A01100 Post 4
B1 P11002A01100 Left Frame
（Long） 2
B2 P11001A01100 Right Frame
（Long） 2
C1 P11004A01100 Left Frame
（Short） 2
C2 P11003A01100 Right Frame
（Short） 2
D P10301A01100 Slant Beam For
Big Roof 4
E P10401A01100 Middle Beam For
Big Roof（Long）2
F P10401B01100 Middle Beam For
Big Roof（Short）2
G P10801A01100 Middle beam
connector 4
H P10301B01100 Slant Beam End
For Big Roof 4
K1 P10101B01100 Big Top
Connector 1
K2 P10101A01100 Small Top
Connector 1
J P10201A01100 Slant Beam For
Small Roof 4
L P10001A03100 Finial 1
M P12601A01100 Hook 1
N1 P12101A01100 Long Mosquito
Netting Pipe 4
N2 P12102A01100 Short Mosquito
Netting Pipe 4


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
6/28
P P11501A01100 Base Cover 4
Q P11601A01100 Base 4
R P00101B07007Small Canopy 1
S P00102B07007Big Canopy 1
T P00301B02901 Mosquito Netting 1
U P00201B06007Curtain 1



CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
7/28
Hardware Pack
LabelPart NumberDescription Qty Add Part Image
AA H02020C11 Bolt M6*20 32 4
BB H19001C11 Flat washer M6 56 8
CC H02015B11 Bolt M5*15 24 4
DD H19001B11 Flat washer M5 24 4
EE H14001C11 Nut M6 16 4
FF H02035C11 Bolt M6*35 8 2
GG P90701A07007 Plastic ring 104 12
HH P12401B01001 Stake Φ6*230 16 0
JJ P12501A01001
Plug 20*20
（Pre-Assembled
on H）
4 2
KK P12502A01001
Plug 17*17
（Pre-Assembled
on E,F,J）
8 2
WW H00001L12 Wrench M5/M6 2 0


A
ctual Size
A
ctual Size
A
ctual Size
A
ctual Size
A
ctual Size
A
ctual Size


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
8/28



STEP 1:Assembly o
f
Post
P11101A01100
4x
4x
H02020C11
4x 4x
P11501A01100 P11601A01100
H02035C11
8x
H02015B11
H19001C11
H19001B11
8x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
9/28


STEP 2:Assembly o
f
Short Frame
2x
H02020C11
2x
P11002A01100
2x
2x
2x
P11003A01100
P11001A01100
P11004A01100
4x
H02015B11
H02035C11
H19001C11
H19001B11
4x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
10 /28


STEP 3:Assembly of Long Frame
2x
4x
P11002A01100
P11001A01100
2x
2x
H02020C11
H02015B11
H02035C11
H19001C11
H19001B11
4x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
11 /28


STEP 4:Assembly o
f
Middle Beam Connector
4x
4x
P10801A01100
8x
H02020C11
H02015B11
H02035C11
H19001C11
H19001B11
8x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
12 /28


STEP 5:Assembly o
f
Short Mosquito Netting Pipe
4x
P12102A01100
P12101A01100
4x
8x
2x
H02020C11
H02015B11
H02035C11
2x
2x
H19001C11
H19001B11
8x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
13 /28


STEP 6:Assembly o
f
Long Mosquito Netting Pipe
4x
P12101A01100
2x
8x
H02020C11
H02015B11
H02035C11
2x
2x
H19001C11
H19001B11
8x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
14 /28


STEP 7:Assembly of Short Frame and Post
4x
2x
2x
8x
H02020C11
H02035C11


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
15 /28


STEP 8:Assembly of Long Frame and Post
4x
2x
8x
H02020C11
H02035C11


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
16 /28


STEP 9:Assembly o
f
Slant Beam End For Big Roo
f
P10301B01100 P10301A01100
4x
4x 4x
CLICK!


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
17 /28


100°
80°
STEP 10:Assembly o
f
Big Top Connector
4x
4x
P10101B01100
4x
4x
CLICK!
H02035C11
4x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
18 /28
50°
40°


STEP 11:Assembly of Long Middle Beam
2x
P10401A01100
P10401B01100
2x
2x
2x
H02035C11
2x
CLICK!


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
19 /28


STEP 12:Assembly o
f
Short middle beam
P10401B01100
2x
H02035C11
2x
CLICK!
2x
2x


CountryofOrigin:ChinaCall1(866)578‐6569forassistance.       
Orvisitusatwww.sunjoyonline.com
20 /28




STEP 13:Put Big Canopy on Big Roo
f
P00102B07007
1x
P00201B06007
1x
