Sunny Health & Fitness NIMBLE SF-T722072 User manual

NIMBLE SMART COMPACT TREADPAD
TREADMILL
SF-T722072
USER MANUAL
IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your
satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US:
[email protected] or 1- 877 - 90SUNNY (877-907-8669).

1
IMPORTANT SAFETY INSTRUCTION
When using an electrical appliance, basic precautions should always be followed, including the
following:
Read all instructions before using this treadmill.
DANGER– To reduce the risk of electrical shock:
Always unplug this appliance from the electrical outlet immediately after using and before cleaning.
WARNING – To reduce the risk of burns, fire, electric shock, or injury to persons:
1. The treadmill should never be left unattended when plugged in. Unplug from the outlet when not in
use and before putting on or removing parts.
2. Use this treadmill only for its intended use as described in this manual. Do not use attachments
not recommended by the manufacturer.
3. Never operate this treadmill if it has a damaged cord or plug, if it is not working properly, if it has
been dropped or damaged, or dropped into water. Return this treadmill to a service center for
examination or repair.
4. Keep the cord away from heated surfaces.
5. Never operate the treadmill with the air openings blocked. Keep the air openings free of lint, hair,
and alike items.
6. Never drop or insert any object into any opening.
7. Do not use outdoors.
8. Do not operate where aerosol (spray) products are being used or where oxygen is being
administered.
9. To disconnect, turn the treadmill off, then remove plug from outlet.
10. Connect this treadmill to a properly grounded outlet only. See grounding instructions.
11. This appliance is not intended for use by persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Keep children
under the age of 13 away from this machine.
12. Household use only.
13. REMOVE CONTROL BOX (OR KEY, OR SAFETY PIN, AS APPLICABLE) WHEN NOT IN USE,
AND STORE OUT OF REACH OF CHILDREN.
14. Do not carry this appliance by supply cord or use cord as a handle.
CAUTION:
To avoid injury, use extreme caution when stepping onto or off of a moving belt. Read instruction
manual before using.
SAVE THESE INSTRUCTIONS

2
IMPORTANT SAFETY INFORMATION
We thank you for choosing our product. To ensure your safety and health, please use this equipment
correctly. It is important to read this entire manual before assembling and using the equipment. Safe
and effective use can only be achieved if the equipment is assembled, maintained, and used properly.
It is your responsibility to ensure that all users of the equipment are informed of all warnings and
precautions.
1. Before starting any exercise program, you should consult your physician to determine if you have
any medical or physical conditions that could put your health and safety at risk or prevent you from
using the equipment properly. Your physician’s advice is essential if you are taking medication that
affects your heart rate, blood pressure or cholesterol level.
2. Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. Stop
exercising if you experience any of the following symptoms: pain, tightness in your chest, irregular
heartbeat, shortness of breath, lightheadedness, dizziness, or feelings of nausea. If you do
experience any of these conditions, you should consult your physician before continuing with your
exercise program.
3. Keep children and pets away from the equipment. The equipment is designed for adult use only.
4. Use the equipment on a solid, flat level surface with a protective cover for your floor or carpet. To
ensure safety, the equipment should have at least 8 feet (240CM) of free space behind it and 2 feet
(60 CM) on each side. Do not place the treadmill on any surface that blocks air openings. To
protect the floor or carpet from damage, place a mat under the treadmill.
5. Ensure that all nuts and bolts are securely tightened before using the equipment. The safety of the
equipment can only be maintained if it is regularly examined for damage and/or wear and tear.
6. Always use the equipment as indicated. If you find any defective components while assembling or
checking the equipment, or if you hear any unusual noises coming from the equipment during
exercise, discontinue use of the equipment immediately and do not use until the problem has been
rectified.
7. Wear suitable clothing while using the equipment. Avoid wearing loose clothing that may become
entangled in the equipment.
8. Do not place fingers or objects into the moving parts of the equipment.
9. The maximum weight capacity of this unit is 245 pounds (110 kgs).
10. The equipment is not suitable for therapeutic use.
11. To avoid bodily injury and/or damage to the product or property, proper lifting and moving is
required.
12. Your product is intended for use in cool, dry conditions. You should avoid storage in extreme cold,
hot or damp areas as this may lead to corrosion and other related problems.
13. This equipment is designed for indoor and home use only. It is not intended for commercial use!

3
IMPORTANT OPERATING INSTRUCTIONS
1. Insert the power plug directly into the socket.
2. Read the manual before operating the equipment.
3. Changes in speed do not occur immediately. Set your desired speed using the adjustment keys on
the remote control. The speed will increase gradually.
4. While on the treadmill, move with caution as distractions may cause you to lose balance and stray
from walking in the center of the belt. This may result in serious injury.
5. This unit starts at a very low speed. To begin use, stand on the side rails while it starts up, then step
onto the belt once it’s in motion.
6. A safety key is provided for emergency use. The treadmill will function only if the safety key is
inserted into the console. In case of emergency, remove the safety key to immediately stop the belt
and shut off the treadmill. The display screen will reset once the safety key is reinserted.
7. This equipment is designed for adult use only! Children should not be allowed to use or play near
this equipment. When present, children should always be supervised by an adult.
8. Women who are pregnant or nursing should consult a physician before attempting to begin any
exercise program.
9. Always stay hydrated during and after exercise.
10.Do not lift the treadmill.
11. The treadmill will automatically stop after about 5 seconds if user is not standing on it.
IMPORTANT NOTE:
The belt must be lubricated before the first use! Please see Page 7 for instructions on how to
properly apply lubricant.

4
PRE-ASSEMBLY CHECK LIST
Before you start to assemble, please make sure all parts are included.
No.
Description
Spec.
Qty.
A
Main Frame
1
E07
Remote Control
1
E13
Power Cord
1
E19
Safety Key
1
B
Lubricant
20ml/bottle
1
C
Tablet Holder
1
D
Manual
1
E
Thank You Card
1

5
ASSEMBLY INSTRUCTIONS
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [email protected] or 1-877-90SUNNY
(877-907-8669).
STEP 1:
Open the carton and remove contents. Place
the Main Frame (No. A) on level ground,
ensure that you have a work area that is clean
and has adequate space.
Take the T-Shape Wrench (No. C24) out from
Tablet Holder Bottom Cover (No. C21).
STEP 2:
Loosen the 2 Screws (No. B07) on
Handlebar Tube (No. A02)
counter-clockwise with T-Shape Wrench
(No. C24).
STEP 3:
Support the Handlebar Tube (No. A02) with
your hands to prevent it from falling.
Attach Handlebar Tube (No. A02) to the
Main Frame (No. A) with 2 Screws (No.
B07) clockwise by using T-Shape Wrench
(No. C24).

6
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [email protected] or 1-877-90SUNNY
(877-907-8669).
STEP 4:
Insert the Tablet Holder (No. C) to Tablet
Holder Top and Bottom Covers (No. C20 &
C21).
STEP 5:
Insert the magnet end of Safety Key (No.
E19) onto the Motor Top Cover (No. C01).
When you are running, you can put the wire
of Safety Key (No. E19) through Lead Wire
Buckle (No. C23) on the Handlebar Tube
(No. A02) and slip to your clothes.
IMPORTANT NOTE!
You will need to lubricate your
treadmill before the first use. See
Page 7.
STEP 6:
When the height of each pad or because of
individual machine placed on the ground is
not even, you need to adjust the Foot Pad
Sleeve (No. C22) to level the machine on the
ground.
The Remote Control (No. E07) can attach the
Tablet Holder (No. C) directly.
The assembly is complete!

7
LUBRICATING THE TREADMILL
IMPORTANT NOTE:
You will need to lubricate your treadmill before the first use.
RUNNING BELT & TREADMILL LUBRICANT:
Lubricating the Running Board (No. E21) and Running Belt (No. C07) is essential as the friction
affects the life span and operations of the treadmill. Inspect the Running Belt (No. C07) and Running
Board (No. E21) regularly. If you find any wear on the Running Board (No. E21), please contact us at:
[email protected].
WARNING: Always unplug the treadmill from the electrical outlet before cleaning, lubricating, or
repairing the unit.
HOW TO LUBRICATE:
1. Raise the Running Belt (No. C07) up on one side and apply lubricant to the Running Board (No.
E21). Use a rag to thoroughly wipe the lubricant over the Running Board (No. E21). Repeat this
process for the other side.
2. The moving parts should turn freely and quietly. Abnormal moving parts will affect the safety of the
equipment. Inspect and tighten bolts regularly.
3. To better maintain the treadmill and prolong its lifespan, it is suggested that maintenance be done
on a regular basis.
4. DO NOT LOOSEN OR MAKE ANY ADJUSTMENTS TO THE RUNNING BELT WHILE APPLYING
LUBRICANT. A loose Running Belt (No. C07) will result in the runner sliding off during use, while
too tight of a Running Belt (No. C07) will negatively affect the motor’s performance and create
more friction between the roller and Running Belt (No. C07). The most suitable tightness for the
Running Belt (No. C07) is when it is pulled out 50-75mm from the Running Board (No. E21).
The following time table is recommended:
Light user (less than 3 hours/ week) every six months
Medium user (3-5 hours/ week) every three months
Heavy user (more than 5 hours/ week) every two months

8
HOW TO FOLD THE MACHINE
STEP 1:
Pull out the Tablet Holder (No. C) from Tablet
Holder Top and Bottom Cover (No. C20 &
C21).
STEP 2:
Loosen the 2 Screws (No. B07) of the
Handlebar Tube (No. A02) counter-clockwise
by using T-Shape Wrench (No. C24).
Pull the Handlebar Tube (No. A02)
downward (in the direction specified by the
arrows on the diagram).

9
STEP 3:
Attach the 2 Screws (No. B07) on Handlebar
Tube (No. A02) to the Main Frame (No. A)
clockwise by using T-Shape Wrench (No. C24).
STEP 4:
Insert the magnet end of Safety Key (No. E19)
into the Motor Top Cover (No. C01).
When you are running, you can put the wire of
Safety Key (No. E19) through Lead Wire
Buckle (No. C23) on the Main Frame (No. A)
and slip to your clothes.
