superbrightleds EL2-SW User manual

LED Emergency Light
EL2-SW
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Specications
EL2-SW
Operating Temperature 32°–104° F (0°–40° C)
Fixture Weight 1.7 lb (750 g)
Battery Type Ni-Cd (3.6 V/1.2 Ah)
Maximum Mounting Height 10.4 ft (3.1 m)
User Manual
EL2-SW
¹
¹Limited 2-year warranty on battery.
Rev Date: V1 05/06/2021
Testing
Manual Test
Test button can be held to illuminate lights for manual
testing purposes.
Wiring Diagram
Important: Read all instructions prior to installation. SAVE THESE INSTRUCTIONS.
Warning
Important Safeguards
Read and follow all safety instructions. When using electrical
equipment, basic safety precautions should always be followed
including the following:
• Disconnect power before performing work on electrical
equipment.
• For indoor use only.
• Do not let the power cords touch hot surfaces.
• Do not install in hazardous locations or near gas or electric
heaters.
• The use of auxillary equipment not recommended by
manufacturer, may cause and will void the unit’s warranty.
• Do not use this equipment for other than its intended
purpose.
• Servicing of this equipment should be performed by a
qualied service technician
• All electrical connections should be made in accordance
with National and Regional electrical code.
• Equipment should be mounted in locations and heights
where it will not readily be subjected to tampering by
unauthorized personnel.
• Allow battery to charge for 24 hours before rst use.
Battery in this unit may not be fully charged at the time
electrical connection is made. Let the battery charge for at
least 24 hours for normal operation. To check charge, press
the “test” button.
Check product label for specific electrical
specifications related to installation.
Improper installation will void warranty.
Battery
LED2 LED1
Black Wire(L)
AC on indicator
test button
White Wire(N)
120–347 VAC input

Installation Instructions
1. Carefully remove mounting plate by using the release
buttons.
2. Remove appropriate knockouts for wiring and mounting
from rear plate.
3. Run wiring through mounting plate and connect
wiring to junction box.
(refer to wiring diagram)
4. Securely attach mounting plate to surface
or junction box with hardware.
5. Connect battery to board.
6. Reattach light assembly to mounting
panel.
7. Apply power and allow battery pack to charge for at
least 24 hours before initial use/test.
8. After 24-hour period, press test button to make
certain lights are functioning as intended.
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
LED Emergency Light
Important: Read all instructions prior to installation. EL2-SW
User Manual
¹
¹Limited 2-year warranty on battery.
Rev Date: V1 05/06/2021
Plugin
Battery
