superbrightleds WPA-SW Series User manual

Selectable CCT Adjustable Angle LED Wall Pack
Important: Read all instructions prior to installation. WPA-SW Series
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V1.0 08/24/2021
5yr
User Manual
Specications
CCT Selection
Safety and Notes
Wiring Diagram
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Dim (+)
Dim (-)
Purple
+ +
- -
Pink / Gray
Yellow / Green
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Dim (+)
Dim (-)
Purple
+ +
- -
Pink / Gray
Yellow / Green
• Product should be installed and serviced by a certied electrician in accordance
with applicable national, state, and local building and electrical codes.
• To reduce the risk of electric shock, ensure that the main power source and circuit
breakers are switched o󰀨 before performing any installation or wiring procedures.
Wiring/installation should not be attempted during inclement weather.
• Ensure all mounts are securely attached and will support the weight of the xture.
Failure to properly support xture may result in damage or injury, for which the
manufacturer does not assume responsibility.
• Minimum 90° C supply conductors
Field-selectable CCT can be set
using the internal switch as shown.
Make certain supply power is o󰀨
when performing this procedure.
Model WPA-SW3BxW-H8DBR35
Operating Temperature -40°–122° F (-40°–50° C)
IP Rating IP65
Dimming 0–10 V
WPA-SW3B15W-H8DBR35
Check product label for specific electrical
specifications related to installation.
Improper installation will void warranty.
120–277 VAC Input 0–10 V Dimming

Selectable CCT Adjustable Angle LED Wall Pack
Important: Read all instructions prior to installation. WPA-SW Series
4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com
Rev Date: V1.0 08/24/2021
5yr
User Manual
Installation
Built-in Photocell
Note: Light angle can be adjusted in 15°
increments within a 90° range.
1. Loosen light angle adjustment bolts and rotate light up.
2. Remove two screws that hold front and rear housing
together.
3. Rotate light and front housing out, disconnect photocell,
and lift o󰀨 of rear housing.
4. Drill holes in rear housing as needed.
5. With supply power turned o󰀨, run wiring through rear
housing (junction box) or conduit hole on side of
housing and mount housing to junction box/wall using
included rear gasket.
6. Slide front housing and light back onto the rear housing
in open position and connect wiring.
Note: if unneeded, unplug photocell and cap
connections to bypass it.
7. Close light xture and secure with two screws.
8. Apply power. Use adjustment bolt to set light at desired
angle.
Photocell will turn the light on when ambient light
level falls below 30 lux. When ambient light rises
back above 130 lux (15 W, 30 W, 80 W) or 60 lux
(120 W) the light will turn back o󰀨. The photocell
can be bypassed by unplugging it inside the
housing and capping the wire end plug.
