Swissvoice ePure TAM User manual

Cordless digital telephone (DECT)
WITH DIGITAL ANSWERING MACHINE
ePure TAM
User manual
Photo may differ from the actual product.

Welcome to Swissvoice
The ePure TAM is a cordless telephone designed for connection to an analog
telephone network. International DECT (GAP)-standard digital technology offers
excellent voice quality.
You can register up to 5 handsets to your base and make internal calls free of charge.
The ePure TAM comes with a built-in digital answer machine.
The ENERGY STAR®program (www.energystar.gov) recognizes and
encourages the use of products that save energy and help protect our
environment. We are proud to mark this product with the ENERGY STAR®
label indicating it meets the latest energy efficiency guidelines.
Warning
Be sure to read this user guide and the safety precautions before using your
telephone. Explain their content and the potential hazards associated with using the
telephone to your children.
ePure TAM
ePure TAM
Use only the charging cradle supplied with the power adaptor/power
cord.
Use only recommended, rechargeable batteries. Failure to do so
could damage your health and cause injury.
Do not charge the handset in charging unit or base station while the
headset is connected.
Using your telephone may affect nearby medical equipment. Be
aware of the technical conditions in your particular environment
(such as a doctor's office).
Do not hold the rear of the handset to your ear when it is ringing or
when the handsfree function is activated. Otherwise, you risk serious
and permanent damage to your hearing.
Do not install the charging cradle in bathrooms or shower areas. The
charging cradle is not waterproof.
Do not use your phone in environments that pose a explosion
hazard (e.g., paint shops).
If you give your phone to someone else, make sure you also give
them the user guide.
Please remove faulty base stations from use, as they could interfere
with other wireless services.
$
ƒ

Contents
Keys 2
Display symbols 3
Range / Location 3
Battery advice 4
Insert the battery 4
Connecting the phone 5
Set date and time 5
Set language 5
Making a call 6
Redial 7
PBX operation 8
Paging – Locate mislaid handsets 8
Phonebook 8
Direct memory 9
Calls list and caller ID (CID) operation 9
Call Waiting 13
Extending the ePure TAM 13
Making a call with several call partners 14
Personal settings 15
Advanced settings 16
Answer machine 17
Appendix 21
ePure TAM
ePure TAM 1

ePure TAM
2ePure TAM
Handset
1 Earpiece
2 Display
3 Redial key
During a call: Mute the microphone
4 Menu/Select key
In standby: open the menu
In a menu or list: select the highlighted
item
5 End call key / back to idle mode
6 Talk key
7 Key 1: Insert a space
8 Digit keys
9 Star key
10 Key 0 / Intercom key
Press 3 sec. for internal calls
11 Microphone
12 Loudspeaker (for ring signal and hands-
free)
13 Hash key
switches between lower and upper case
letters / switches off ringer / press 3 sec.
when editing an entry: insert a pause
14 Flash key (press 3 sec. key "9")
Send a hook flash signal to the currently
connected line
15 Control LED (flashes when you have one
or more missed calls, flashes quickly with
an incoming call)
16 Navigation key / set volume
Base
1 Paging key (on the bottom)
2/3 Adjust volume
4 Repeat message/return to previous
message
5 Start/stop playback
6 Skip to next message
7 Delete message during playback
8 Switch answer machine on/off
Menu / Select
Intercom
Redial
Flash
abc def
ghi jkl mno
pqrs tuv wxyz
16
15
14
13
1
2
3
4
5
8
12
6
11
10
7
9
Keys
1
2 3 4 5 6 7 8

Display symbols
Steady on: batterie’s charge level.
Flashing: batteries have to be charged.
Time.
Call in progress.
Steady on : the caller’s list is open.
Flashing : new calls in the caller’s list.
The phonebook is open.
Scroll up/down in a list or a menu.
Confirmation.
Ringer off.
Handsfree active.
Alarm is set.
Steady on, when the handset is near the base. Flashes, if out of range or
not registered.
Steady on : the answer machine is activated
Flashing : you have new answer machine messages
Range / Location
To obtain the best possible range, we recommend positioning the telephone in a
location central to your sphere of activity. Avoid positioning the telephone in niches,
recesses and behind steel doors.
The maximum range between base station and handset is approximately 900 feet
outdoors. Depending on the surrounding conditions as well as spatial and structural
factors, the range may be smaller. Silent zones can occur due to the digital transmis-
sion in the frequency range used – even within the range, depending on the structural
environment. In this case the transmission quality may be reduced through the
increased incidence of short breaks in transmission. Normal call quality can be
restored if you move slightly out of the silent zone. If the range is exceeded, the call
will be disconnected unless you move back into range within ten seconds.
12:03
ePure TAM
ePure TAM 3

ePure TAM
4ePure TAM
Battery advice
Use only the original battery (Li-Ion 3.7 V / 550 mAh) as well as the original power sup-
ply (7.5 VDC, 300mA).
The handset operating times (standby 150 hours/active 10 hours) and charging times
apply only if the battery is charged to the defined minimum capacity.
Charging is electronically controlled to ensure optimal charging and care of battery in
different charge states. Full capacity is achieved only after several charging cycles.
Insert the battery
The battery compartment is situated in
the handset.
Open the handset cover.
Insert the battery in the battery compart-
ment.
Replace the handset cover.
Note:
Using other rechargeable battery or non-rechargeable battery/primary cells
can be dangerous and cause malfunctions or damage to the telephone. Do
not short-circuit the battery (danger). In particular, avoid inadvertent short-
circuits during storage and transport e.g. bunch of keys, metal panels or
similar objects, and make sure the battery do not come into contact with
greasy materials. When not in the handset, therefore, battery should be
stored only in insulating packaging. Ensure also that the contacts do not
touch greasy parts.
Rechargeable battery can become warm while recharging. This is a normal
occurrence and is not dangerous.
Make sure you install the battery pack and fit the cover the right way round:
- position the 3 metal contacts of the battery pack against the 3 blade
contacts,
- align the green dot on the handset with the one on the cover.
Green dots

ePure TAM
ePure TAM 5
Connecting the phone
• Before you can start using your telephone you must plug in the telephone
connector cable and the mains cable.
• When the phone is delivered, the battery is not yet charged.
• To charge the battery, insert the handset in the base station. The battery will take
around 6 hours to fully charge (initial charge).
Set date and time
After setting up the telephone first, date and time are not set.
• Press , select Clock/Alarm with the navigation key π/†and press OK.
• Select
Date&Time and press OK.
• Enter date and press OK.
• Enter the time and press OK.
Note:
If you are using an out of state VOIP telephone provider you must make sure that the
Caller ID (CID) time and date is sent on your local time.
Please contact your VOIP telephone provider if you are having any problems with your
CID time, date or alarm setting.
Set language
• The language of the display texts can be changed in the menu:
Personal set/Language
Tel. Line
Power
Telephone line socketMains power socket

Making a call
• Dial the desired number using the keypad.
• Press the Talk key .
End the call
Press the End call key.
Receiving a call
• Incoming calls are signalled by a ring tone and a quick flashing of the control LED
on the handset.
• Press the Talk key and conduct your conversation.
End the call
Press the End call key.
Switch ringer off
When a call is coming in, press and hold the key for approx. 3 seconds. The
ringer is switched off for this call.
Mute handset microphone
Press to deactivate the microphone in your handset during a call.
Press the key again to reactivate the microphone.
Set speaker/loudspeaker volume
You can adjust the speaker/loudspeaker volume during a conversation.
Set the desired volume using the navigation key π/†.
Switch handset off
• Press and hold the End call key (approx. 5 sec).
• Press and hold again the End call key to reactivate the handset.
Calls cannot be made if the battery is almost discharged or the handset is
out of range of the base station.
Redial
ePure TAM
6ePure TAM

Set alarm
• Press , select Clock/Alarm using the navigation key π/†and press
OK.
• Select
Set alarm using the navigation key π/†and press OK.
• Select the desired alarm function (e.g. On once), enter the alarm time and press
OK.
Set alarm tone
• Press , select Clock/Alarm using the navigation key π/†and press
OK.
• Select
Alarm tone using the navigation key π/†and press OK.
• Select the desired alarm melody and press OK.
The activated alarm is displayed in standby mode by .
The alarm sounds for 60 seconds or can be deactivated immediately by pressing
any key.
Note:
If you are using an out of state VOIP telephone provider you must make sure that the
Caller ID (CID) time and date is sent on your local time.
Please contact your VOIP telephone provider if you are having any problems with your
CID time, date or alarm setting.
Redial
The Redial list contains up to 10 entries.
• Press and select the desired entry using the navigation key π/†.
• Press the Talk key.
Edit redial list
• Open the Redial list, press OK.
You have the following options:
- Save Number – Add number to the phonebook.
- Delete entry – Delete the entry.
- Delete All – Delete the entire redial list.
Redial
ePure TAM
ePure TAM 7

PBX operation
Your telephone is designed for use in the analogue telephone network and can be
operated on a PBX that supports DTMF dialling and flash signalling. To enter the R key
(e.g. needed to establish a connection) press key for 3 sec.
You can adjust the flash/recall time for key R (see chapter "Advanced settings").
Paging – Locate mislaid handsets
All registered handsets ring for one minute, when the Page key on the base is
pressed. To stop the ring press the End call key on the handset or the Page key
on the base.
Phonebook
You can store up to 100 names and numbers in the phonebook on each handset.
Digits / Characters
Different characters are printed on each key. The entries in the phonebook are sorted
alphabetically.
Key #Change from upper case to lower case letters (ABC/abc).
Press 3 sec. to insert a pause inside a phone number (“P” appears).
Key 1Insert a space.
Add new entries in the phonebook
• Press , select Phonebook and press OK.
• Select
New entry and press OK.
• Enter the desired name and press the navigation key π/†for further input
options.
• Press OK to save the entry.
Edit phonebook
• Press , select Phonebook and press OK.
• Select
View entry and press OK.
• Select the desired entry using the navigation key π/†or enter the first letter of
the name.
• Press the Talk key to call the number.
ePure TAM
8ePure TAM

ePure TAM
ePure TAM 9
In the phonebook menu you have the following options:
- New entry
- View entry
- Delete all
- Direct mem
- Call a programmed direct memory number.
- PB Transfer – Copy phonebook to another handset.
Direct memory
Phone numbers from the phone book can be assigned to numerical keys 1 to 9.
Programming direct memory keys
• Press , select Phonebook and press OK.
• Select
Direct mem and press OK.
• Select the desired memory key and press OK twice.
• Select
Add and press OK.
• Select the desired entry from the phonebook using the navigation key π/†and
press OK.
Calling a direct memory number
To call a direct memory number, press the corresponding key for approx. 3 seconds.
The programed number is called.
Calls list and caller ID (CID) operation
Getting to know your new telephone
IMPORTANT: Subscription to Caller ID (CID)/Call Waiting ID services from your Local
Phone Company is required for using the Caller ID/Call Waiting ID features of ePure
TAM. Your new ePure TAM telephone gives you the ultimate in cordless telephone
sound quality with the luxury of Caller ID and Call Waiting ID.
Some key features are:
• 50 name and number Caller ID/Call Waiting ID memory (Call List)
• 100 name and number programmable memory (Phonebook)
Unlike regular telephones, your cordless telephone does not work during power
failures. We do not recommend that you use a cordless telephone as the only phone in
your residence.

INTRODUCTION to CALLER ID and CALL WAITING ID
The ePure TAM Caller ID/Calling Waiting ID devices allow you to take advantage of the
Caller identification delivery service offered by your Local Telephone Company. For
more information, you can refer to the following Questions and Answers table:
QUESTIONS
What is Caller ID?
What is Caller Waiting ID?
How does Caller ID and Call
waiting ID work?
Who provides Caller
ID service?
How can I activate my
Caller ID?
Receiving a new call
The control LED on the side of the handset flashes when you have one or more
missed calls in the calls list. The calls list can contain up to 50 entries.
• When you receive a new call, the call information is stored in the calls list and the
system displays the caller's information sent by the telephone company, called a
Call Record. The Call Record consists of the following information:
a. The caller’s telephone number
ePure TAM
10 ePure TAM
ANSWERS
Caller ID is a device that identifies the calling party
before you answer a call. This device can be used to
screen unwanted calls and eliminate harassment
from annoying calls.
Call Waiting ID is a device that can also identifies the
call waiting party before you answer a call.
When used with Caller ID/Call Waiting service, the
Caller ID/Call Waiting ID device displays the name (if
available), and the telephone number (if available) of
the person calling before you answer your telephone.
Your local telephone company. However, not all local
telephone companies provide Caller ID service.
Please call you local phone company to confirm that
the service is available before you install the device.
For your Caller ID unit to function, you must first
arrange with your local telephone company to have
Caller ID/Call Waiting ID service installed on you line.
There is an extra charge added to your monthly
telephone bill for this service.
Before using this unit, please read instruction manual
carefully.

b. The caller’s name (if in the phonebook)
c. The date and time of the call
• If there are no call records, the display shows “ Empty ” when pressing the
navigation key π(when opening the calls list).
Note:
If you are using an out of state VOIP telephone provider you must make sure that the
Caller ID (CID) time and date is sent on your local time.
This may also affect the alarm setting in your phone.
Please contact your VOIP telephone provider if you are having any problems with your
CID time, date or alarm setting.
Call a number from the calls lists
• Open the calls list by pressing the navigation key π.
• Select the desired entry using the navigation key π/†.
• Press the Talk key to call the number.
or
• press OK and select a function from the list.
View an entry in the calls list
• Open the calls list by pressing the navigation key π.
• If there is a new call(s), the new call(s) will be displayed first.
• Select the desired entry using the navigation key π/†.
• You can now see the details of the entry (date and time when the missed call came
in) in the 3rd line ot the display.
• Press to exit the calls list.
Note: If no button is pressed within 20 seconds, the display will automatically return to
standby mode.
To use this function, the caller's number must be transmitted (FSK). Contact
your telephone company for further information.
If the caller's number is suppressed, only Withhold is displayed. The call is
not entered in the call list.
ePure TAM
ePure TAM 11

Note:
If you are using an out of state VOIP telephone provider you must make sure that the
Caller ID (CID) time and date is sent on your local time.
This may also affect the alarm setting in your phone.
Please contact your VOIP telephone provider if you are having any problems with your
CID time, date or alarm setting.
Edit an entry in the calls list
• Open the calls list by pressing the navigation key π.
• Select the desired entry using the navigation key π/†.
• Press OK to open the options list.
• Select
Edit entry using the navigation key π/†and press OK to confirm.
• Edit the entry an press OK to save the modified entry.
Store a number from the calls list in the phonebook
• Open the calls list by pressing the navigation key π.
• Select the desired entry using the navigation key π/†.
• Press OK to open the options list.
• Select
Save number using the navigation key π/†and press OK to confirm.
• Enter the name and press OK to confirm.
• The displays shows the corresponding number. Edit the number if necessary and
press OK to confirm.
• Select the desired group melody (
Group A , B , or C ) or No group using the
navigation key π/†and press OK to confirm.
Delete an entry in the calls list
• Open the calls list by pressing the navigation key π.
• Select the desired entry using the navigation key π/†.
• Press OK to open the options list.
• Select
Delete entry using the navigation key π/†and press OK to confirm.
• Repeat the procedure for deleting other single entries.
Delete all entries in the calls list
• Open the calls list by pressing the navigation key π.
• Press OK to open the options list.
• Select
Delete All using the navigation key π/†and press OK to confirm.
• This handset’s calls list is erased. (This does not affect the calls lists saved on any
other handsets).
ePure TAM
12 ePure TAM

ePure TAM
ePure TAM 13
Call Waiting
When you subscribe to Call Waiting Service from your Local Telephone Company, this
telephone will display number and name (if in the phonebook) of the second caller
while you are having a conversation.
If a second call comes in while you are having a conversation, you will hear a
notification tone from the handset. The display will automatically show the number and
name (if in the phonebook) of the second caller.
Accept the waiting call
• Press the flash key for 3 seconds to answer the waiting call. The first call is
put on hold.
• Talk to the second caller and press the flash key for 3 seconds to end this
call and to to continue your conversation with the first caller.
Or
Reject the waiting call
• Press to reject the waiting call and to continue your first call.
Extending the ePure TAM
The delivered handset is already registered on to base station. In standby the internal
number of the handset is displayed.
You can register up to 5 handsets to your base station.
If you register your ePure TAM handset with a "third party" base station or a "third
party" handset on your ePure TAM base station (GAP), you may not be able to use
some functions or only to a limited extent.
Register new handsets
Registering an additional handset with the main base station (the base station you
have connected to the telephone network):
UNREGISTERED
Base station connected to the telephone network
Press
Press and hold down
the Paging key for at
least 10 seconds
2
1
12

If the registration is not successful:
• Interrupt power supply of base and handset (disconnect power adapter/remove
battery).
• Repeat the registration procedure.
Making a call with several call partners
During a call you can make a second internal call (enquiry call), switch between call
partners or simultaneously converse (3-way conference call) without the need for two
telephone lines.
Internal conversation / Internal call
• Press 3 sec. key and enter the desired internal party.
If only two handsets are registered, pressing 3 sec. key will automatically
call the other handset.
Intercom
Intercom
ePure TAM
14 ePure TAM
MAIN MENU
ADVANCED SET
ADVANCED SET
REGISTRATION
REGISTRATION
REGIST. BASE
Move to "REGIST. BASE"
with navigation key and
conrm with
BASE 1 2 3 4
HANDSET X
01/01 00:00
If registration is successful
you will hear the dialling
tone when you press ,
and see handset number on
the display. Repeat this
procedure for every additio-
nal handset.
PIN ?
After a few seconds you will
be asked to enter the PIN.
Enter PIN (default 0000) and
press
Move to "ADVANCED SET"
with navigation key and
conrm with
Select the main base station
(default 1) by pressing the "1"
on your handset
Move to "REGISTRATION"
with navigation key and
conrm with
34
56
78
34
56
78

If you receive an external call while you are on the phone to an internal call partner,
you will hear an incoming call alert. End the internal call by pressing the End call key.
Press the Talk key. You are connected to the external party.
Call transfer to another handset
You are conducting an external call and you want to transfer it to another handset.
• Press 3 sec. key .
• Enter the desired number.
• When the internal party responds press the End call key to transfer the call to the
other party.
Conference
You are conducting an external call.
• Call another internal party (see above).
• The internal party answers.
• Press 3 sec. key to start a conference call. If one of the handsets presses
the End call key, the other handset will be connected to the external call.
Personal settings
• Press , select Personal set and press OK.
• Select a function from the list using the navigation key π/†and press OK.
-Handset tone
- Ring volume
- Ring melody
- Group melody
- Key tone
- Every time a key is pressed, a brief beep is heard.
- First ring - This handset doesn't ring until the second ring (the first one is
withheld).
-Handset name - To better distinguish between handsets, you can give each
handset a name.
-Auto pick-up - Just pick up the handset from the base to answer a call (without
pressing any key).
-Auto hang-up - Just hang up the handset to end a call.
-Language
-Room monitor
- You need two handset to use this function. Place one of the
handsets in the room you wish to monitor. Enable the function at that handset.
You can then establish a connection to this handset from a second handset and
monitor the room acoustically. Dialling the internal phone number of the handset
Intercom
Intercom
ePure TAM
ePure TAM 15

placed in the room starts room monitoring. Room monitoring is stopped again by
either putting the phone down or pressing the Talk key.
Advanced settings
• Press , select Advanced set and press OK.
• Select a function from the list using the navigation key π/†and press OK.
-Recall Time – Select the recall time (flash time) for the analogue network
functionalities in your country.
-Dial Mode – Tone: Normal dialling procedure on analog lines. Pulse: May be
required for connecting older telephone systems. Please refer to the relevant
documentation.
-Call barring – Use this function to ban certain phone numbers from being
dialled. The call barring numbers must be entered separately for each handset.
You can specify bar calls to up to 4 numbers each comprising up to 4 digits. All
phone numbers whose first digits match the specified numbers will be barred.
-Baby call – Use this function to store a set phone number that will be dialled
automatically when any key (except the End call key) is pressed. You must enter
the desired call number.
-Registration - Accessory handsets must be registered to the base station.
-Unregister – Select the handset you want to deregister.
-PIN – You can modify the PIN code (0000 on delivery).
-Reset unit
-Prefix
- Detect digit
- If the first digits of a number you are calling are identical to
the digits stored, they will be suppressed.
- Prefix num. - The prefix number can be 5 digits long. The stored digits are
added in front of the phone number when dialling (with a dialling pause).
-Intrusion - Enabling this function allows you to link in handsets to the call made
with another handset.
-ECO Mode – When ECO Mode is set to ON, the handset’s power transmission is
regulated and a radiation reduction is achieved when it is near the base station.
ePure TAM
16 ePure TAM

Answer machine
Your ePure TAM features an integrated digital answer machine with a max. recording
capacity of 30 minutes. You can operate your answer machine from the base and from
any handset registered to the base. On delivery an outgoing message for each mode
(
Answer & Rec and Answer only ) is pre-recorded. The answer machine is ready to
use.
Activate/deactivate the answer machine (from the base)
Press key on the base station to switch the answer machine on or off.
The LED under key
- lights up when the answer machine is activated
- doesn’t light up when the answer machine is deactivated
- flashes when you have new message(s) on the answer machine
Operating the answer machine (from the base)
If you have new messages, the LED under key is flashing.
The messages are played back beginning with the most recent.
• Press to start playback.
• During playback the following options are available:
Key Function
Activate/deactivate answer machine
Repeat message/return to previous message
Skip to next message
Start/end playback
Delete message during playback
/ Adjust volume
Delete all old messages (from the base)
Impossible during playback. Press and hold key to delete all old messages.
Activate/deactivate the answer machine (from the handset)
• Press , select Answ Machine and press OK.
• Select
Answ On/Off and press OK.
ePure TAM
ePure TAM 17

• Select On or Off using the navigation keys π/†and press OK.
is displayed when the answer machine is switched on.
• You must now select the desired operating mode and record a personal outgoing
message:
Record a personal outgoing message
• Press , select Answ Machine and press OK.
• Select
Answer Mode and press OK.
• Select
Answer & Rec (the caller can leave a message) or Answer only (the caller
cannot leave a message) and press OK.
• Select
Personalized and press OK.
• Select
Record mess and press OK.
• Speak your outgoing message into the handset microphone. Your personal
outgoing messages can be 1 minute long (max.).
• Press OK to end recording. The recorded personal outgoing message is played
back.
Operating the answer machine (from the handset)
If you have new messages on your answer machine the symbol flashes. The
messages are played back beginning with the most recent and over the handset loud-
speaker (the handset loudspeaker activates automatically).
• Press , select
Answ Machine and press OK.
• Select
Play and press OK.
• Press the End call key to end playback.
During playback:
• Press OK to open the
Options menu.
The following options are available:
•
Repeat – repeat the message
•
Next message – skip to next message
•
Prev message – return to previous message
- To restore the standard outgoing message, select Answer & Rec or Answer
only
followed by Predefined and press OK.
- To listen to an outgoing message, select
Answer & Rec or Answer only
followed by Play and press OK. The outgoing message is played back.
- To delete a personal outgoing message, select
Answer & Rec or Answer
only
followed by Delete and press OK.
ePure TAM
18 ePure TAM
