TAKT T16 Cross Instruction Manual

T16 Cross
Bar Chair
Building Instructions

Important Notice
Only use the listed tools.
Do not use power tools.
Tighten in accordance with
the building instructions.
Avoid over-tightening.
There is no need for strong
force.
2x base frames

1x footrest
1x backrest
1x seat
4x screws (80 or 90mm)
A
4x washers
B
1x seat pad (optional)
E4x screws (16mm)
C2x screws (20mm)
2x metal collars
D
Flat-head screwdriver
(not provided)
1x Allen key (SW4)

Weight
Low version:
6,0 kg
6,8 kg with seat pad
High version:
6,3 kg
7,1 kg with seat pad
Product Information
‘T16 Cross Bar Chair’ is a bar
chair designed for indoor use.
The chair is tested according to
EN-16139 - L1.
Materials
Seat and back: Moulded plywood (oak and beech)
Frame: Solid oak
Footrest: Powder coated steel
Surface treatment: Water based lacquer or oil
Fittings: Steel
Optional
Seat pad: Ecolabelled leather or textile, plywood.
Foam: OekoTex class 1 certified
UK version: Foam contains flame retardants melamine
and TCPP and has been tested according to “BS5852
part 2 ignition source 5 crib”.
OekoTex class 2 certified
Tests & Declarations
The chair has passed the furniture test EN-16139 - L1
The chair is not treated with or containing disinfective
biocides.

455 mm
650 mm
445 mm
445 mm
462 mm
750 mm
895 mm
444 mm
995 mm
451 mm
Dimensions
Low version
High version

6Join the base components. Make sure the half moon marks align.

7
Optional
If you are mounting an upholstred seat pad - place it on the wooden
seat as showed here before mounting it on the metal frame.

8
1
2
3x2
Important!
Turn all screws in sequence 1 to 4 - ONLY two rounds. Make sure the
screw easily grips the thread.
x4 x4
4

9
C
x2
D
Important!
Turn all screws ONLY two rounds. Make sure the screw easily grips
the thread.
Dx2 Cx2

10
1
2
3
4
x2
Note!
Turn footrest so that pinhole
mark is placed at the back
towards the floor.
E
Important!
Turn all screws in sequence 1 to 4 - ONLY two rounds. Make sure the
screw easily grips the thread.
Ex4

Push down on seat and tighten all screws 11

Enjoy your new bar chair.

Warranty
TAKT provides an ex-
tended warranty of 5
years on ‘T16 Cross Bar
Chair’. The warranty
covers breakage of com-
ponents and damage
occurred because of
deficient craftsmanship
under normal use.
The warranty shall lapse
if the product shows
signs of inappropriate
use or other physical
damage. The warranty
does not cover wear or
damage to upholstery,
gliders, wheels, surfaces
and the like.
Maintenance
TAKT maintenance
guide is accessible on
our website
www.taktcph.com/
product-care/
Additional Information
TAKT provides an extended
warranty of 5 years on
‘T16 Cross Bar Chair’.
Spare Parts
TAKT offers spare parts
for ‘T16 Cross Bar Chair’.
Spare parts are avail-
able from TAKT without
charge for a period of 5
years from the date of
purchase if the parts are
found to be faulty during
normal use. If the parts
are damaged by misuse
spare parts can be
bought from TAKT.
TAKT always strives to
deliver spare parts to
you in the fastest and
most efficient way in
order for your furniture
to return to a functional
condition.
Please contact TAKT
for inquiries regarding
spare parts.
Recycling & Disassembly
We hope that your TAKT
product will serve you well
for many, many years.
If you at one point want to
recycle it, please separate
it into components for
sorting.
Untighten screws by
turning the Allen key
counter clockwise to
separate the different
parts.
Metal parts and wooden
parts can be delivered to a
suitable recycling facility
and be recycled.
Mixed material parts can
be delivered to a recycling
facility for suitable
disposal.
[email protected]

1x footrest
(metal)
1x wooden seat
(wood)
4x screws 80 or 90mm
(metal)
2x base frames
(wood)
4x screws 16mm
(metal)
4x washers
(metal)
Optional
1x seat pad (mixed)
1x backrest
(wood)
2x collars
(metal)
2x screws 20mm
(metal)

taktcph.com
