T2380
• Up to 9 part forms
• Full range of automatic features to minimize user
intervention
• Ideal for ‘ On-Demand‘ and ‘ Batch‘ applications
with zero tear for no wasted forms
• Straight through paper path for easy forms loading
• Parallel and Ethernet (10/100BaseT) standard.
• Optional Interfaces: RS232 Serial; Coax/Twinax;
Ethernet IPDS• Straight through paper path for
easy forms loading
• Compatible with a wide range of operating
systems including Wiindows, UNIX, DOS, SAP R3
and legacy systems
These products are well matched to Microsoft Windows
applications, and highly compatible with other host
operation environments including legacy systems.
Fully automated operation, coupled with the ‚straight
through‘ paper path, allows ease of use and virtually
eliminates errors caused by user intervention.
The T2365 MC and T2380 printers are rugged and powerful
high speed matrix printers for heavy duty operation under
the most extreme conditions. Reliable, heavy workload
output is guaranteed for many years following printer
purchase. The print is crisp, sharp, dark and absolutely
legible, thanks to the 24 pin print head.
Low running costs and durability in the harshest of print
environments make these products excellent value
for money.
Available Configuration:
T2380
T2380 2T with additional rear tractor
T2380 IGP with IGP/PJL Support
Powerful & Rugged for Heavy Duty
Operation

T2380
DASCOM GB Limited
ViewPoint, Basing View,
Basingstoke, Hampshire RG21 4RG
Tel: [phone]
Fax: [phone]
www.dascom.com
All company and product names are
trademarks or registered trademarks of
their respective owner.
Specifications are subject to change
without notice.
Copyright © 2009 DASCOM Europe GmbH
Ver. 1.0
Printed Date: 01.04.10
At 10, 12 cpi: High Speed Draft 800, 1000; Draft 667, 800; NLQ 222, 267
627 pages per hour (ECMA 132)
5, 6, 7.5, 8.6, 10, 12, 15, 17.1, 20 cpi (Emulation dependent)
2, 3, 4, 6, 8, 12 lpi
750 million characters (draft)
128Kb
Bi-directional parallel plus Ethernet 10/100BaseT with 128Kb buffer
RS232 Serial, Adapters, Twinax/Coax, Ethernet IPDS
IBM® Proprinter, Epson® LQ (ESC P/2), Genicom ANSI, MTPL + Barcode/LCP
IGP Version: IGP/PGL, Code V, MT660, Printronix P6000, HP2564C
PCL3 (rugged writer)
HS Draft, Draft, Copy Draft, Courier, Roman, Sans Serif, Prestige, Script, Orator,
Gothic, Souvenir, Kix/Royal, OCR A, OCR B, 22 Bar Codes & scaleable LCP
Ribbon: 20 million characters
Push tractor with paper parking and AGA; 2nd rear push tractor - T2380-2T only
2nd front tractor (user installable), paper pedestal, paper basket, paper cutting
device
Continuous forms
60-120gsm
100 to 420mm wide
Approximately 19Kg
(HxWxD): 280x623x432mm
230V
60W printing
50,000 pages per month
Up to 6-part forms; 2-part forms for rear tractor of T2380-2T
+10° to +35°C
20% to 80%
59dB(A)
2 years, on-site
2nd front tractor (user installable), paper pedestal, paper basket, paper cutting
device
Print Speed
Throughput
Character Density
Line Density
Printhead Life
Memory
Standard Connectivity
Optional Connectivity
Standard Emulation
Optional Emulation
Fonts
Consumables
STD Paper Handling
Optional Paper Handling
Paper Type
Paper Weight
Paper Size
Physical Weight
Physical Size
Power Voltage
Power Consumption
Workload
Number of Copies
Temperature
Humidity
Acoustic
Warranty
Option 1
Note: For OCR applications it is recommended that your readers are tested with print samples supplied by
DASCOMprior to purchase. Paper is a highly variable medium and should be tested prior to purchase. The quoted
consumable life is the average for the printer when used under normal operating conditions.
