T&S B-0177 User manual

Installationand
Maintenance
Instructions
FAUCET WITH
NOZZLE AND SPRAY
HOSE ASSEMBLY
B-0177
Deutsch: Installations-und
Wartungsanleitungen
Español: la Instalación y las
Instruccionesde
Mantenimiento
Français: lesInstructions
d’Installation et
d’Entretien
Limited One Year Warranty
T&Swarrantstotheoriginalpurchaser(otherthan
forpurposesofresale)thatsuchproductisfreefrom
defectsinmaterialandworkmanshipforaperiodof
one(1)yearfromthedateofpurchase. Duringthis
one-yearwarrantyperiod, iftheproductis foundto
bedefective,T&S shall,at itsoptions, repairand/
orreplaceit. Toobtainwarrantyservice,products
mustbereturnedto...
T&SBrassandBronzeWorks,Inc.
Attn: WarrantyRepairDepartment
2SaddlebackCove
TravelersRest,SC 29690
Shipping,freight,insurance,andothertranspor-
tationchargesoftheproducttoT&Sandthereturn
ofrepairedorreplacedproducttothepurchaserare
theresponsibilityofthepurchaser. Repairand/or
replacementshallbemadewithinareasonabletime
afterreceiptbyT&Softhereturned product. This
warrantydoesnotcoverItemswhichhavereceived
secondaryfinishingorhavebeenalteredormodi-
fiedafterpurchase, orfordefectscausedbyphysi-
calabuseto ormisuseoftheproduct,orshipment
oftheproducts.
Anyexpresswarrantynotprovidedherein,and
anyremedyforBreachofContractwhichmightarise,
is hereby excluded and disclaimed. Any implied
warrantiesofmerchantabilityorfitnessforaparticu-
larpurposearelimitedtooneyearinduration. Under
no circumstances shall T&S be liable for loss of
useor anyspecialconsequentialcosts,expenses
ordamages.
Somestatesdonotallowlimitationsonhowlong
andimpliedwarrantylastsortheexclusionorlimi-
tationof incidentalorconsequentialdamages,so
theabovelimitationsorexclusionsmay not apply
toyou. Specificrightsunderthiswarrantyandother
rightsvaryfromstatetostate.
P/N: 098-012448-45 Rev.0
Date: 990714
Drawn: CW
Checked: MAB11-12-99
Approved: MVW11-13-99

Exploded View
* Some items are listed for instructional purposes and may not be sold as separate parts.
6
7
8
10
9
11
15
16
17
18
19
20
21
25
22
26
29
32
33
31
27
28
30
23
24
8
12
13
8
14
3
4
1
2
5
2

Part Number Guide
3
Faucet Assembly
1
Asm, Faucet (Rigid)
002829-40
2
Faucet Body (Rigid)
*
3
Asm, Coupling Flange
002893-40
4
Washer
001019-45
5
Asm, Cartridge
LH, w/Spring Checks
002711-40
RH, w/Spring Checks
002712-40
6
Handle, Lever - Hot
001637-45
Handle, Lever - Cold
001636-45
7
Index, Button
Hot (Red)
001661-45
Cold (Blue)
001660-45
8
Screw, Handle
000922-45
21
Nipple, 3/8" X 4"
*
22
Valve Body
*
23
Asm, Cartridge (Cold)
005959-40
24
Handle, 4-Arm
002521-45
25
Grease Tube
*
26
Nipple
002535-25
27 Asm, Vacuum Breaker 3/8" B-0968
28
Adapter, 3/8" MA
000545-25
29
Washer #27
010476-45
30
Asm, Flex S/S Hose
B-0080-H
31
Asm, Spray Head
005969-40
32
Asm, Wall Hook
B-0104-D
33
Screws, Wall Mount
000915-45
Add-On Faucet Assembly
9
Asm, Add-on Faucet
B-0155, B-0156, B-0157
005964-40
10
Nipple, 3/8" X 3"
000358-40
11
Faucet Body
*
12
Asm, Cartridge, Quarter Turn
007947-40
13
Handle, Lever (Blank)
001638-45
8
Screw, Handle
000922-45

Part Number Guide - con’t
4
***Repair kit includes items #16 and #17.
Nozzle Assembly
14
Asm, Nozzle Swing
Nozzle, 6”
059X
Nozzle, 12”
062X
Nozzle, 18”
065X
15
Repair Kit***
011643-45
16
"O"-Ring
*
17
Sleeve, Swivel
*
18
Swivel Piece
*
19
Washer, Swivel Piece
*
20
Nut, Swivel
*

5
General Instructions
Faucet Installation:
1. Drill (2) twoholes, approximately
1-1/4” diameter in countertop with 8”
centers, where you are installing
no.2.
2. Apply Teflon tape or pipe joint
compound to water supply lines.
3.Connect no.2to water supply lines
by screwing no.3(with eccentric
centers) onto nipple (supplied by
others) and tightening no.3against
countertop. (Nut under countertop
to be supplied by others). Trim
supply lines if necessary.
water supply line
countertop
nut
(supplied by others)
8”[20 cm]
3
2
Nozzle Installation:
Note: Nozzles should be installed
first. See diagram below:
Ifinstalling toan existing rigidpre-
rinseunit orbasefaucet
1. Shut off water supply and drain
lines. Remove no.21fromno.2.
Apply Teflon tape or pipe joint
compound to threaded ends of
no.10.
2. Place no.10 into no.2and tighten
firmlybyhand.
To Install Swing Nozzle:
1. Insert no.14 into no.11 and rotate
to desired position at sink.
Note: See Repair Kit 011643-45 for
replacement of no.16 and no.17.
2. Tighten no.20 firmly with a wrench.
14
10
20
11
Enlarged View
16
17
18
21
2

General Instructions
1. Apply Teflon tape on threaded ends of no.21.
Place no.21 into no.22, tighten by hand. Apply
loctite on no.26, insert between no.22 and no.27,
tighten no.27 with awrench.
2. Apply Teflon tape or pipe joint compound to no.21
and place into no.11 and tighten by hand.
1. Apply Teflon tape on no.28 and place onto no.27.
2. Apply Teflon tape to threaded end of no.28. Attach
no.30 to no.28 (make sure no.29 is in place).
3. Turn on water supply and check for leaks.
4. Install no.32 in a convient location.
26
22
21
6
Installation of Control Valve:
Vacuum Breaker and Hose Installation:
27 28 29
30
11

7
Para instalar boquilla
giradora:
1. Inserte la parte No.14 dentro de la
No.11 y gire a una posición deseada
en el lavatorio.
Nota: Vea el estuche de reparos
011643-45 para remplazar las partes
No.16 y No.17.
2.Aprietefirmemente laparteNo.20
con una llave.
Instrucciones
Generales
Instalación de la Canilla:
1. Perfore (2) dos huecos,
aproximadamente1¼” dediámetro
con centros de 8” en el mostrador,
donde la parte No.2será instalada.
2.Aplique cinta deTeflon o
compuesto de coyuntura a las líneas
de surtido.
3.Conecte la parte No.2a las líneas de
surtidoatornillandola parteNo.3
(con centros excéntricos) al tubo
(surtido por otros) y apriete la parte
No.3 contra el mostrador. (La tuerca
debajo del mostrador será surtida
por otros). Si es necesario recorte las
líneas de surtido.
Línea de surtido
Mostrador
Tuerca
(Surtido por otros)
8”[20 cm]
3
2
Instalación de la boquilla:
Nota: Las boquillas deben de ser
instaladas primero. Vea el diagrama
abajo:
Siestainstalandoaunaunidad
existenterígidadepre-enjuageoala
basedeunacanilla
1.Cierre la fuente de agua y desagüe
las tuberías. Remueva la parte No.21
de la parte No.2.Aplique cinta de
Teflon o compuesto de coyuntura a
los extremos con rosca de la parte
No.10.
2. Coloque la parte No.10 dentrola
parte No.2y apriete firmemente a
mano.
14
10
20
11
Vista Ampliada
16
17
18
21
2

Instrucciones
Generales
1.Aplique cinta de Teflon a los extremos con rosca de
la parte No.21. Coloque la parte No.21 dentro de la
parte No.22, y apriete a mano. Aplique Loctite en la
parte No.26, y inserte dentro de las partes No.22 y
No.27, Aprietela parte No.27 con una llave.
2. Aplique cinta de Teflon o compuesto de coyuntura
a la parte No.21 colóquela dentro de la parte No.11 y
apriete a mono.
1. Aplique cinta de Teflon en la parte No.28 y
colóquela dentro de la parte No.27.
2.Aplique cinta deTeflon al extremo con roscas de la
parte No.28. Junte la parte No.30 a la parte No.28
(asegúrese que la parte No.29 este en su sitio).
3. Abra la fuente de agua e inspeccione por
filtraciones.
4. Instale la parte No.32 en un sitio conveniente..
26
22
21
Instalación de la Válvula de Control:
Instalación de la Manguera y Anti-sifón:
27 28 29
30
11
8

9
Instructions
Générales
L’Installation Du Robinet :
1. Percer (2) deux trous, avec un
diamètre de 1-1/4” dans le comptoir
de l’évier avec les centres de 8”, où
vous aller installer Nº.2.
2.Appliquer le ruban en Téflon ou le
composé pour les tuyaux aux filets
des tuyaux qui fournir l’eau.
3.BrancherNº.2auxtuyaux qui
fournir l’eau en branchant Nº.3(avec
les centres excentriques) sur le
raccord (fournir par les autres) et
resserrer Nº.3contrele comptoir.
(L’écrou au-dessous-de comptoir
fournir par les autres). Couper un
peu les tuyaux qui fournir l’eau si
nécessaire.
tuyaux qui fournir l’eau
Le comptoir
l’écrou
(fournir par les autres)
8”[20 cm]
3
2
L’Installation De L’Ajutage:
Noter: Les ajutages devoir être
installer au début.Voir le
diagramme ci-dessous:
Sivousinstaller à l’ élément
Prérinçageexistant ou le robinet
delabase
1.Fermer la réserve de l’eau et
égoutter la tuyauterie. Enlever Nº.21
de Nº.2.Appliquer leruban en Téflon
ou le composé pour les tuyaux à
l’extrémité de Nº.10 avec les filets.
2.ResserrerNº.10 fermementparle
main dans Nº.2.
Pour Installer L’Ajutage
D’Entrain:
1. Insérer Nº.14 dans Nº.11 et tourner
jusqu’à la position désirée de l’évier.
Noter: Voir la trousse àoutils
011643-45 pour remplacer Nº.16 et
Nº.17.
2. Resserrer Nº.20 fermement avec
une clef anglaise.
14
10
20
11
La Vue Aggrandie
16
17
18
21
2

Instructions
Générales
1.Appliquer le ruban en Téflon ou le composé pour
lestuyaux à l’extrémité deNº.21 avec les filets.
Mettre Nº.21 dansNº.22 et resserrer par le main .
Appliquer le “Loctite” sur Nº.26, insérer entre Nº.22
et Nº.27, resserrerNº.27avec une clef anglaise.
2. Appliquer le ruban en Téflon ou le composé pour
les tuyaux à Nº.21 et mettre dans Nº.11 et resserrer
parle main.
1.Appliquer leruban en Téflon sur Nº.28et mettre
surNº.27.
2.Appliquer le rubanen Téflonà l’extrémité de Nº.28
avec les filets.Attacher Nº.30 à Nº.28.( Soyez certain
que Nº.29 être à sa place).
3. Recommencer l’eau et vérifier s’il y a des fuites.
4. Installer Nº.32 dans un emplacement convenable.
26
22
21
Installation de soupape de commande:
L’Installation De Briseur De Vide et Le Tuyau:
27 28 29
30
11
10

11
Allgemeine
Anleitungen
Installation des
Wasserhahnes:
1. Bohren Sie(2) zwei Löcher
ungefähr 3cm(1 1/4") miteinem
Abstand von 20 cm (8") von
Lochmittezu Lochmittein die
Arbeitsplatte in der Sie Nr. 2
installieren.
2.Tragen Sie Teflonbandoder
Rohrkittauf die
Wasserzufuhrleitungenauf.
3.VerbindenSie Nr. 2zu den
Wasserzufuhrleitungen indem Sie
Nr. 3(mit versetzterMitte)auf den
Nippel (nicht in der Lieferung
enthalten) schrauben und Nr. 3 gegen
dieArbeitsplattefestziehen.(Die
Mutter unter der Arbeitsplatte ist
nicht in der Lieferung enthalten).
Falls nötig Wasserzufuhrleitungen
kürzen.
Wasserzufuhrleitungen
Arbeitsplatte Mutter
(nicht in der Lieferung nthalten)
8”[20 cm]
3
2
Installation der Schwenkdüse:
Hinweis:Schwenkdüsensolltenals
erstesinstalliertwerden. SehenSie
dazudasDiagramm unten:
Fallsaneinerbereitsvorhandenen
Vorspüleinheitodereinemeinfachen
Wasserhahn installiert wird
1. Wasserzufuhr abdrehen und Rohre
leerlaufen lassen. Entfernen Sie Nr. 21
von Nr. 2.Tragen SieTeflonband oder
Rohrkitt zu den Gewindeenden der
Nr. 10 auf.
2. Setzen Sie Nr. 10inNr. 2undziehen
Sie es fest von Hand an.
Zur Installation des
Schwenkarmes:
1.FührenSie Nr. 14 in Nr. 11 einund
drehen Sie dieses bis die gewünschte
Position am Becken erreicht ist.
Hinweis:Verweisen Siezum
Reparaturkit 011643-45 für
Ersatzanweisungen der Nr. 16 und
Nr. 17.
2.Ziehen Sie Nr. 20mitHilfeeines
Schraubenschlüssels fest an.
14
10
20
11
Vergrößerte Ansicht
16
17
18
21
2

Allgemeine
Anleitungen
1. Tragen Sie Teflonband auf die Gewindeenden der
Nr. 21 auf. Setzen Sie Nr. 21inNr. 22 und ziehen Sie
dieses von Hand fest an. Loctite auf Nr. 26 auftragen
und zwischen Nr. 22 und Nr. 27einfügen, dann Nr. 27
mit einem Schraubenschlüssel fest anziehen.
2. Tragen SieTeflonband oder Rohrkitt an Nr. 21 auf
und setzen Sie es in Nr. 11, dann von Hand festziehen.
1.Teflonband aufNr. 28auftragen und zur Nr. 27
aufsetzen.
2. Tragen Sie Teflonband zum Gewindeende der Nr. 28
auf. Befestigen Sie Nr. 30 zur Nr. 28 (stellenSie sicher,
daß sich Nr. 29 in der richtigen Position befindet).
3. Wasserzufuhr andrehen und auf Dichtheit prüfen.
4.Installieren SieNr. 32an einer günstig gelegenen
Stelle.
26
22
21
Installation des Kontrollventils:
Vakuumsicherungs- und Schlauchinstallation:
27 28 29
30
11
12

T&S BRASS AND BRONZE WORKS, INC.
A firm commitment to application-engineered plumbing products
2 Saddleback Cove, P.O. Box 1088, T & S Brass-Europe
Travelers Rest, SC 29690 ‘De Veenhoeve’
Phone: [phone] Oude Nieuwveenseweg 84
Fax: [phone] CW Nieuwveen
E-mail: [email protected] The Netherlands
RELATEDT&S BRASS PRODUCTLINE
B-0175
WallMountedFaucet
with12”Swing Nozzle
andSprayUnit
B-0176
Deck Mounted Faucet
with12”Swing Nozzle
andSprayUnit

Pre-Rinse Spray Valve
Limited One Year Warranty
T&S warrants to the original purchaser (other
than for purposes of resale) that such product
is free from defects in material and workman-
ship for a period of one (1) year from the date
of purchase. During this one-year warranty
period, if the product is found to be defective,
T&S shall, at its options, repair and/or replace
it. To obtain warranty service, products must
be returned to…
T&S Brass and Bronze Works, Inc.
Attn: Warranty Repair Department
2 Saddleback Cove
Travelers Rest, SC 29690
Shipping, freight, insurance, and other
transportation charges of the product to T&S
and the return of repaired or replaced product
to the purchaser are the responsibility of the
purchaser. Repair and/or replacement shall be
made within a reasonable time after receipt by
T&S of the returned product. This warranty does
not cover Items which have received secondary
finishing or have been altered or modified after
purchase, or for defects caused by physical
abuse to or misuse of the product, or shipment
of the products.
Any express warranty not provided herein,
and any remedy for Breach of Contract which
might arise, is hereby excluded and disclaimed.
Any implied warranties of merchantability or
fitness for a particular purpose are limited to
one year in duration. Under no circumstances
shall T&S be liable for loss of use or any special
consequential costs, expenses or damages.
Some states do not allow limitations on
how long and implied warranty lasts or the
exclusion or limitation of incidental or conse-
quential damages, so the above limitations or
exclusions may not apply to you. Specific rights
under this warranty and other rights vary from
state to state.
P/N: 098-011027-45 Rev.9
Date: 03-22-12
Drawn: TEH
Checked: JRM 03-26-12
Approved: JHB 03-27-12
Installation and
Maintenance
Instructions
B-0107
B-0107-C
B-0107-J
B-10K
B-10K-C
B-10K-J
UK-0107
UK-10K
EB-0107
EB-0107-C
EB-0107-J
EB-10K
EB-10K-C
EB-10K-J

2
Exploded View
1
2
3
7
8
9
10
11
21
13
14
15
16
17
18
17
19
20
12
25
24
23
5
6
4
22

3
Grey
Grey Part Number Guide
PARTS FOR ANY GREY T&S SPRAY VALVE
1
2
3
4
5
6
Ring, Hold Down
#27 Washer
Body, Spray Valve
Grey Handle
Nut, Handle
Screw, Handle
000907-45
010476-45
000065-40
001120-45
003198-45
003199-45
7
8
9
10
11
22
23
24
22
23
24
25
B-0107 (1.42 GPM)
Nipple
Cup, Spray
Ring, Sprayhead
1.42 GPM Sprayface
Screw, Sprayface
B-0107-C (0.65 GPM)
Assembly, B-0107C Spray Nozzle
0.65 GPM Grey Shield (No Outline Around Lettering)
0.65 GPM Spray Nozzle (0.65 Stamped on Face)
B-0107-J (1.07 GPM)
Assembly, B-0107-J Spray Nozzle
1.07 GPM Grey Shield (Square Outline)
1.07 GPM Spray Nozzle (1.07 Stamped on Face)
Nozzle Holder
000694-40
000019-40
007861-45
001121-45
000913-45
002662-40
002659-45
N/A
N/A
018292-45
N/A
N/A
Bonnet Assembly
Stem
Washer, Seat
Washer, Bonnet Binding
Bonnet
Washer, Bonnet Brass
Stem, Packing
Spring, Bonnet
Push Button
Grease Pack
002856-40
009306-20
012915-45
001040-45
000608-25
000974-45
001100-45
000895-45
000753-25
012665-45
12
13
14
15
16
17
18
19
20
21
1,2,3
PARTS
KIT
1,2,3
1,2,3
1,2,3
1,2,3
1,2,3
1,2,3
1,2,3
PARTS FOR ANY GREY BONNET ASSEMBLY
GREY SPRAY VALVES
1
1
1
2
3
#1 Parts included in B-10K
#2 Parts included in B-10K-C
#3 Parts included in B-10K-J

4
Blue
Blue Part Number Guide
PARTS FOR ANY BLUE T&S SPRAY VALVE
1
2
3
4
5
6
Ring, Hold Down
#27 Washer
Body, Spray Valve
Blue Handle
Nut, Handle
Screw, Handle
000907-45
010476-45
000065-40
011454-45
003198-45
003199-45
7
8
9
11
10
10
22
23
24
22
23
24
25
EB-0107 & UK-0107 Only
Nipple
Cup, Spray
Ring, Sprayhead
Screw, Sprayface
EB-0107 (4-6 GPM)
4-6 GPM Sprayface (No Wording on Face)
UK-0107 (1.42 GPM)
1.42 GPM Sprayface (Flow Rate on Face)
EB-0107-C (0.65 GPM)
Assembly, EB-0107C Spray Nozzle
0.65 GPM Blue Shield (No Outline Around Lettering)
0.65 GPM Spray Nozzle (0.65 Stamped on Face)
EB-0107-J (1.07 GPM)
Assembly, EB-0107-J Spray Nozzle
1.07 GPM Blue Shield (Square Outline)
1.07 GPM Spray Nozzle (1.07 Stamped on Face)
Nozzle Holder
000694-40
000019-40
011475-45
000913-45
011456-45
017288-45
N/A
011499-45
N/A
N/A
018293-45
N/A
N/A
Bonnet Assembly
Stem
Washer, Seat
Washer, Bonnet Binding
Bonnet
Washer, Bonnet Brass
Quad Seal
Spring, Bonnet
Push Button
Grease Pack
010594-40
009306-20
010563-45
010565-45
000608-25
000974-45
014615-45
000895-45
000753-25
010573-45
12
13
14
15
16
17
18
19
20
21
4,5,6,7
PARTS
KIT
4,5,6,7
4,5,6,7
4,5,6,7
4,5,6,7
4,5,6,7
4,5,6,7
4,5,6,7
PARTS FOR ANY BLUE BONNET ASSEMBLY
BLUE SPRAY VALVES
4,7
4,7
4
7
5
6
#4 Parts included in EB-10K
#5 Parts included in EB-10K-C
#6 Parts included in EB-10K-J
#7 Parts included in UK-10K

To replace worn parts:
1. Shut o water supply and drain
lines. For ease of disassembly and
reassembly, the handle grip can be
removed from no.3.
2. Unscrew no.5and no.6to remove
no.4. Unscrew and remove no.16
from no.3.
3. Hold no.20 with pliers in one
hand, and with screwdriver, carefully
unscrew no.13 from no.16.
4. Apply no.21 over smooth portion
of no.13. Replace no.14, no.15, no.17,
no.18 & no.19 with new parts. Dab
no.21 onto valve side of no.19 before
replacing.
3
8. For EB-0107/UK-0107 & B-0107
ONLY: To replace no.9, unscrew
no.11 and disassemble. Make sure
the groove side of no.9ts over
no.8, and no.10 rest on ridge side.
See Figure A.
9. To replace no.2, unscrew handle
grip from no.3and replace with new
no.2.
10. Reassemble; turn on water check
for leaks.
General Instructions
5
1620
5
6
4
16
14
13
18
19
20
17
15
5. Reassemble no.16 by inserting
no.13 through all parts. Hold no.20
with pliers, and carefully screw no.13
into no.20 until screw feels tight. Do
not use excessive force.
6. Reinsert no.16 in no.3and tighten
securely.
7. Reassemble no.4, no.5and no.6
on no.3.
11. For EB-0107-C, EB-0107-J,
B-0107-C & B-0107-J ONLY: To
replace no.23, slide no.23 o no.25,
and slide a new no.23 back onto
no.25. No.23 will snap into groove
on no.25. See Figure B.
* Verify the ow rate on no.23
matches spray tip inside no.25.
Caution: Turn o water supply at
base faucet when not in use.
Figure A
Figure B
11
10
9
8
1
3
23
13
apply no.21
here
2
handle
grip

T&S BRASS AND BRONZE WORKS, INC.
A firm commitment to application-engineered plumbing products
2 Saddleback Cove, P.O. Box 1088, T & S Brass-Europe
Travelers Rest, SC 29690 ‘De Veenhoeve’
Phone: [phone] Oude Nieuwveenseweg 84
Fax: [phone] CW Nieuwveen
E-mail: [email protected] The Netherlands
B-0108
JeTSpray
Spray Valve
RELATED T&S BRASS PRODUCT LINE
B-0108-C
JeTSpray
Low Flow
Spray Valve
