paulo
4 shelf bookshelf
assembly instructions
style # TGELBC4SWH (weathered white)
dpci # 249-14-3793
tcin # 52384113
style # TGELBC4SGY (weathered smoke)
dpci # 249-14-3363
tcin # 52384115
style # TGELBC4SBR (midtone)
dpci # 249-14-5030
tcin # 53281456

2
Congratulations on your latest Target purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your
room in no time. Good luck—though we’re condent you won’t need it.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Read through and review assembly steps.
4. Gather all tools prior to assembly.
tools needed

3
table of contents
introduction 2
hardware 4
parts list 5
how to use the cam lock system 6
assembly 7-15
QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and dpci number ready when calling.

4
hardware
(H1) x 8
cam
(H2) x 8
cam bolt
(H3) x 20
bolt
(H4) x 22
washer
(H5) x 4
wooden dowel
(H6) x 1
large screw
(H7) x 1
small screw
(H8) x 1
wall strap
(H9) x 1
wall anchor
(H10) x 8
hex bolt
(H11) x 1
allen wrench

5
exploded diagram
ITEM DESCRIPTION QUANTITY
A top panel 1
Bupper xed shelf 2
C back panel 2
Dlower xed shelf 2
E upper left frame 1
F upper right frame 1
G lower left frame 1
H lower right frame 1

how to use the cam lock system
1.
Screw cam bolt into panel
2.
Align cam bolt(s) with cam(s)
and insert all the way into
cross-bored hole(s)
3.
Push cam into panel - arrow feature
on cam top points to panel edge
4.
Rotate cam(s) clockwise 180° to
lock panels together
5.
Panels should be tight against each
other and connection should be rigid
6
1. 2. 3.
4. 5.

7
step 1: attach upper frames to lower frames
(H10) x 8
hex bolt
(H11) x 1
allen wrench
1.1. Align bolts with pre-drilled holes.
1.2. Do not over tighten bolts.

8
step 2: prepare lower xed shelf
(H2) x 4
cam bolt
(H5) x 2
wooden dowel
2.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
2.2. Screw-In cam bolts must be screwed down ush.
2.3. Refer to page 6 for instructions on how to use the cam lock system.
2.4. Do not over tighten bolts.

9
step 3: prepare upper xed shelf
(H2) x 4
cam bolt
(H5) x 2
wooden dowel
3.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
3.2. Screw-In cam bolts must be screwed down ush.
3.3. Refer to page 6 for instructions on how to use the cam lock system.
3.4. Do not over tighten bolts.

10
step 4: attach lower xed shelves to frame
(H3) x 8
bolt
(H4) x 8
washer
4.1. Align bolts with pre-drilled holes.
4.2. Do not over tighten bolts.

step 5: slide in back panels
11
make sure arrows are pointing up

12
step 6: attach upper xed shelves
(H3) x 4
bolt
(H4) x 4
washer
6.1. Align bolts with pre-drilled holes.
6.2. Do not over tighten bolts.

13
step 7: attach top panel
(H3) x 4
bolt
(H4) x 4
washer
7.1. Align bolts with pre-drilled holes.
7.2. Do not over tighten bolts.
Align bolts with pre-drilled holes.

14
step 8: attach back panels
(H3) x 4
bolt
(H4) x 4
washer
(H1) x 8
cam
8.1. Align bolts with pre-drilled holes.
8.2. Do not over tighten bolts.
8.3. Refer to page 6 for instructions on how to use the cam lock system.
8.4. Do not over tighten bolts.

step 9: install anti-tip kit
(H7) x 1
small screw
(H8) x 1
wall strap
(H9) x 1
wall anchor
(H6) x 1
large screw
(H4) x 2
washer
Position against wall
Mark position of strap hole on wall
Drill 1/4” hole
Tap in wall anchor
Fasten anti-tip strap with wall screw
provided
15
(H6) (H4)
(H9)
adjustable leg levelers
(H8)
(H4)
(H7)
(H9)
(H6) (H4)

WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Install tip-over restraint provided.
• Place heaviest items
in the lowest drawers.
• Do not set TV's or other heavy objects
on top
of this product, unless the product is
specifically designed to accommodate them.
• Never allow children to climb or hang
on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
(OR)
• Do not defeat or remove the drawer interlock
system.
Use of tip-over restraints may only reduce,
but not eliminate, the risk of tip-over.
This is a permanent label. Do not remove.
1. This unit has been designed for the weight shown. Exceeding this recommended weight could result in
excessive “sagging” of the top. Extreme overloading can cause failure of the top and possible injury.
2. Furniture Care Instructions: Dust with a clean, lint-free cloth. Use a spray furniture polish as needed.
30 lbs.
30 lbs.
30 lbs.
30 lbs.
30 lbs.
16 QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and DPCI number ready when calling.
