Target TGLNBKCSES User manual

>> assembly instructions
leaning bookcase
espresso
style # TGLNBKCSES
dpci # 249-14-0037
ebony
style # TGLNBKCSEB
dpci # 249-14-0349
white
style # TGLNBKCSWH
dpci # 249-14-0351
midtone / cherry
style # TGLNBKCSMT
dpci # 249-14-0350
All manuals and user guides at all-guides.com
all-guides.com

2
Congratulations on your latest Target purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your
room in no time. Good luck—though we’re condent you won’t need it.
tools needed
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
All manuals and user guides at all-guides.com

3
2
4
5
6-11
QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and dpci number ready when calling.
table of contents
introduction
hardware
parts list
assembly
All manuals and user guides at all-guides.com

4
(H1) x 4
(H7) x 6 (H8) x 2 (H9) x 2(H6 x 2
(H5) x 2
hardware
wooden dowel
16mm at head screw metal bracket mending platewall anchor
38mm at head screw
(H2) x 12 (H3) x 2
bolt binding screw
(H4) x 2
allen wrench
All manuals and user guides at all-guides.com

5
ITEM DESCRIPTION QUANTITY
A
B
C
D
E
F
G
H
I
upper right leg
lower right leg
upper left leg
lower left leg
top shelf
second shelf
third shelf
fourth shelf
bottom shelf
1
1
1
1
1
1
1
1
1
All manuals and user guides at all-guides.com

6
(H8) x 2
metal bracket
(H7) x 2
16mm at head screw
step 1.
1. Align screws with pre-drilled holes.
2. Do not over tighten screws.
!WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent tip-over
the brackets must be installed accordingly.
All manuals and user guides at all-guides.com
all-guides.com

7
(H1) x 4
wooden dowel
step 2.
1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
All manuals and user guides at all-guides.com

8
step 3.
1. Fasten Middle Shelf [G] to the Right Leg Assembly [AB] using bolts and a binding screw.
2. Each remaining shelf is attached using a bolt.
(H3) x 1(H2) x 6(H4) x 2
bolt binding screwallen wrench
All manuals and user guides at all-guides.com

9
step 4.
1. Fasten Left Leg assembly [CD] to Third Shelf [G] using bolts and a binding screw.
2. Use the bolts to fasten the right leg assembly to the remaining shelves.
(H3) x 1(H2) x 6(H4) x 2
bolt binding screwallen wrench
All manuals and user guides at all-guides.com

10
(H9) x 2 (H7) x 4
mending plate 16mm at
head screw
1. Align screws with pre-drilled holes.
2. Do not over tighten screws.
If multiple units have been purchased,
use the provided mending plates to
connect the units together.
step 5.
All manuals and user guides at all-guides.com

11
!
WARNING
Seriousorfatalcrushinginjuries can occur
fromfurnituretip-over.To help prevent tip-
over:
-Installtip-overrestraintprovided.
-Placeheavyitemson lower shelves andas
farbackas possible.
-Placeheaviestitemsin the lowest drawers.
-Unlessspecificallydesignedtoaccommodate,
donotset TVs or other heavy objects on top of
thisproduct.
-Neverallowchildrento climb or hang on drawers,
doors,orshelves.
-Neveropenmorethan one drawer at a time.
(OR)
-Donotdefeatorremove the drawer interlock system.
Useoftip-overrestraints may only reduce,
butnoteliminate,the risk of tip-over.
Thisisapermanentlabel. Do not remove.
(H6) x 2
wall anchor
(H5) x 2
38mm wall screw
Fasten metal brackets to
wall anchors with 38mm
at-head screws provided.
Metal brackets from step 1.
Brackets must be facing as
shown.
Position against wall
Mark position of metal
bracket holes on wall
Drill 1/4’’ holes
Tap in wall anchors
(H6)
(H5)
step 6.
!WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent tip-over
the brackets must be installed accordingly.
All manuals and user guides at all-guides.com
all-guides.com

12
15 lbs.
35 lbs.
30 lbs.
25 lbs.
20 lbs.
QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and DPCI number ready when calling.
1. This unit has been designed for the weight shown. Exceeding this recommended weight could result in
excessive “sagging” of the top. Extreme overloading can cause failure of the top and possible injury.
2. Furniture Care Instructions: Dust with a clean, lint-free cloth. Use a spray furniture polish as needed.
!WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent tip-
over:
- Install tip-over restraint provided.
- Place heavy items on lower shelves and as
far back as possible.
- Place heaviest items in the lowest drawers.
- Unless specifically designed to accommodate,
do not set TVs or other heavy objects on top of
this product.
- Never allow children to climb or hang on drawers,
doors, or shelves.
- Never open more than one drawer at a time.
(OR)
- Do not defeat or remove the drawer interlock system.
Use of tip-over restraints may only reduce,
but not eliminate, the risk of tip-over.
This is a permanent label. Do not remove.
All manuals and user guides at all-guides.com

© 2014 Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved.
