Target hadley FKVSBC2SWH User manual

hadley
2 shelf bookcase
>> assembly instructions
style # FKVSBC2SWH (shell)
dpci # 249-14-3676
tcin # 52107128
style # FKVSBC2SGY (stone gray)
dpci # 249-14-3677
tcin # 52107130
© 2019 Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved.

2
Congratulations on your latest Target purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your
room in no time. Good luck—though we’re condent you won’t need it.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Read through and review assembly steps.
4. Gather all tools prior to assembly.
tools needed

3
table of contents
introduction 2
hardware 4
parts list 5
how to use the cam lock system 6
assembly 7-10
QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and dpci number ready when calling.

4
hardware
(H1) x 12
wooden dowel
(H2) x 8
cam bolt
(H3) x 8
cam
(H4) x 1
allen wrench
(H5) x 21
pan head screw
(H6) x 4
bolt
(H7) x 4
lock washer
(H8) x 6
washer
(H9) x 1
wall anchor
(H10) x 1
wall screw
(H11) x 1
truss head screw
(H12) x 1
wall strap

exploded diagram
ITEM DESCRIPTION QUANTITY
A top panel 1
B left side frame 1
C right side frame 1
D shelf 2
E back panel 1
5

how to use the cam lock system
1.
Screw cam bolt into panel
2.
Align cam bolt(s) with cam(s)
and insert all the way into
cross-bored hole(s)
3.
Push cam into panel - arrow feature
on cam top points to panel edge
4.
Rotate cam(s) clockwise 180° to
lock panels together
5.
Panels should be tight against each
other and connection should be rigid
6
1. 2. 3.
4. 5.

step 1: attach left and right side frames to shelves
(H1) x 8
wooden dowel
(H2) x 8
cam bolt
(H3) x 8
cam
1.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
1.2. Screw-In cam bolts must be screwed down ush.
1.3. Refer to page 6 for instructions on how to use the cam lock system.
77

step 2: attach top panel
(H1) x 4
wooden dowel
(H4) x 1
allen wrench
(H6) x 4
bolt
(H7) x 4
lock washer
(H8) x 4
washer
2.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
2.2. Align bolts with pre-drilled holes.
2.3. Do not over tighten bolts.
88

step 3: attach back panel
Begin by installing all of the screws along one
edge of the back panel. Next, using a square
or tape measure, make sure that the cabinet is
square. (If using a tape measure, the distance
from one corner, diagonally to the other corner
should be the same in both directions.) If not,
apply gentle pressure to the diagonally opposite
corners to shift case into alignment. Re-measure
to ensure equal distances. Install the remaining
screws, starting with the corners.
(H5) x 21
pan head
screw
3.1. Make sure the screws go through the pre-drilled holes properly.
3.2. Do not over tighten screws.
9
hole for anti-tip

step 4: install anti-tip kit
(H11) x 1
truss head
screw
(H12) x 1
wall strap
(H9) x 1
wall anchor
(H10) x 1
wall screw
(H8) x 2
washer
Position against wall
Mark position of strap hole on wall
Drill 1/4” hole
Tap in wall anchor
Fasten anti-tip strap with wall screw
provided
1010
(H10)
(H9)
(H8)
(H8)
(H11)
(H12)
Mark position of strap hole on wall
Fasten anti-tip strap with wall screw
provided
