Technogym RECLINE PERSONAL D9673 User manual

1
Carried out by Fabrizio Frattini Revision 1/1
Approved by Andrea Borghesi
MACHINE INSTALLATION MANUAL
RECLINE PERSONAL D9673
EQUIPMENT NECESSARY FOR THE INSTALLATION
•T-handle wrench 2-2.5-3.5-3-5
•Articulated T5 wrench
•Scissors
•Trolley and/or “dolly”
N.B.
•The hardware is located in the backrest box in special bags
PEOPLE NECESSARY FOR THE INSTALLATION

2
Carried out by Fabrizio Frattini Revision 1/1
Approved by Andrea Borghesi
UNPACKING MACHINE
DO NOT USE A CUTTER
Phase 1
Operators A-B:
•Cut the 3 straps with scissors, remove cardboard packaging box, remove the cover,
pick up the cardboard on the short sides, lifting it parallel to the floor making sure
not to scratch the right and left water bottle holders.
NO

3
Carried out by Fabrizio Frattini Revision 1/1
Approved by Andrea Borghesi
Phase 2
Operator A
•Cut the strap and eliminate with video support protection bag.
•Position backrest box unit in the installation area (the box service is inside it)
Operator B
•Position video grp box in installation area (side marked upwards)

4
Carried out by Fabrizio Frattini Revision 1/1
Approved by Andrea Borghesi
Phase 3
Operators A-B
•To position the machine in the installation area (or on any “dolly”) grasp a hold in
the front under the support “feet”, and in the rear under the support feet and/or the
sliding seat frame
front
backback

5
Carried out by Fabrizio Frattini Revision 1/1
Approved by Andrea Borghesi
Phase 4
Operator A
•Make sure that the seat unit is in position 30 (by raising the side handle) in order to
avoid damaging the housing with the T5 wrench while tightening the backrest (F1)
•Pick up the backrest box, open the side marked, remove the backrest and insert it
in the special guides under the seat. (F2_F3)
•Position the backrest about 1 cm from the stop (F4)
•Remove the hardware bags and components from the backrest box and place in
installation area (F5)
•Take out 2 black screws + 2 flared washers, insert and brace into the backrest (F6)
•Tighten the backrest with the T5 wrench until it stops (F7)
F1 F2
F3
F4
F5
F6
F7

6
Carried out by Fabrizio Frattini Revision 1/1
Approved by Andrea Borghesi
Operator B
•Remove the front guard by loosening (without unscrewing completely) the screw
with the T2 wrench thereby release the slotted plate (F1_F2)
•Place the bag used to protect the cables in the slit which formed after the removal
of the housing in order to avoid dropping the screws inside the machine (F3)
•Unscrew 2 screw with the T2.5 wrench and remove the plate (F4_F5)
•Release the cables (F6)
F1
F2
F3
F4 F5 F6

7
Carried out by Fabrizio Frattini Revision 1/1
Approved by Andrea Borghesi
Phase 5
Operator A
•Take out the “box TV”, open the site marked (F1)
•Remove the napaplan protection (F2)
•Extract the TV unit from the box, leaving the cardboard protection (F3)
•Position the video unit taking it snug on the video unit column (get help from
operator B) (F4)
•Rest the video unit on video column (get help from operator B) (F5)
•Remove 3 black screws 0Z717 + 3 Belleville washers 0M000198AA + 3 washers
0Z304 sequence screw_spring_washer) + 6 screws 0Z121 from the bag
•To tighten the hardware, following the sequence described below: first the lower
black screw, then the top right black screws, then the top left black screw, then the
6 iron screws from bottom to stop starting on the right side (make sure not to drag
the T5 articulated wrench in the housing) (F5_F6)
•Proceed to the wiring: 5 connectors + antenna cable (F7)
•Take plate 0N002203AA out of the hardware box and tighten it with the T3 wrench
with 2 0Z136 screws to the frame, placing inside it all the wires (F8)
•Fasten the metal plate from the bag, using T2.5 wrench, with 1 screw so that the
silver-plated housing can be positioned afterwards by levering the lower housing
(F9)
•Take the upper silver plated cover 0N001666AB-K
•from the hardware box, insert it in the place levering on the housing of the video
unit column (F10_F11)
•Tighten the metal plate with T2.5 wrench using 2 screws
•Insert slotted housing into the plate
•Tighten the housing with the T2 (F12) wrench
F1 F2 F3
F4

8
Carried out by Fabrizio Frattini Revision 1/1
Approved by Andrea Borghesi
3
7
6
5
4
1
2
8
9
F10 F11
F12
F9
F5 F6 F8F7

9
Carried out by Fabrizio Frattini Revision 1/1
Approved by Andrea Borghesi
Operator B
•Remove the magnetised cap (F1)
•Insert and lock with supply cable clamp (F2)
•Insert and lock with antenna cable clamp (F2)
•Eliminate the excess part of the clamps (F3)
•Remove the film from the cap and reposition the cap (the tab goes on the left side)
(F4_F5_F6)
•Check the adjustment of the backrest and the sliding of the seat
F1
F2
F3
F4 F5 F6

10
Carried out by Fabrizio Frattini Revision 1/1
Approved by Andrea Borghesi
Phase 6
Operator A
•To connect the machine with power, position the general switch in Phase 1 (F1)
•To start the machine running, gently touch the switch (F2)
•Programme the TV and radio
•Test the machine: Check the hand sensor and the increase and decrease of the
pedalling resistance with the + and - keys both on the video and the handles
•Explanation to customer
Operator B
•Reposition equipment and clean installation area
F1
F2

11
Carried out by Fabrizio Frattini Revision 1/1
Approved by Andrea Borghesi
Machine technical data
Power supply 100+240 Vac 50/00 Hz
Power absorbed from the network 160 VA max
Fuses 2 x 3.15A (F)
Weight of the equipment 70 kg (154 lb)
Maximum weight of the user 160 kg (353 lb)
Braking power at 70 rpm 40 ÷ 400 W ± 10%
Time 0 ÷ 999 W ± 1%
Distance 0÷99,99 km ± 5% (0÷91,99 mi ± 5%)
Degree of protection IP 20
Operating temperature from +5°C to +35°C
Class of electric insulation Class I
Labels and certifications CE –UL
(*)
Hardware box
Code
Description
Quantity
Hardware
0Z717 0Z121
0Z136
0M000198AA
0Z304
Screw M8x20 ZN 7380
Screw M6X16 8.8 Z 5931
Screw M4X8 8.8 Z 5931
Flanged spring 8.2X15X0.8 2093
Grummet 8.4x16x1.6 Z
3
6
2
3
3
Components 0N002203AA
0N00166AB-K Plate housing 1 1
Time (minutes) installation standard conditions
Triplet code
Tot persons
T installation
T handling
CFD 2 20 10
