Technogym SKILLROW User manual

SKILLROW TM
USER MANUAL

2
SKILLROW
CONTENTS
Important safety instructions..........................................................................3
Personal safety ..................................................................................................4
Identication of the manufacturer and equipment .......................................5
Description of the product................................................................................6
Using the product...............................................................................................7
Description of the display...............................................................................13
Using the chest band.......................................................................................17
Place of use ......................................................................................................20
Technical data................................................................................................... 21
Safety stickers .................................................................................................22
Moving the equipment ....................................................................................23
Routine maintenance......................................................................................24
Adjusting the elastic ........................................................................................26
Cleaning the fan ...............................................................................................27
Recharging the battery....................................................................................28
Troubleshooting................................................................................................29
Technical Service .............................................................................................30
Storing the product..........................................................................................31
Disposing of the product.................................................................................31
Disposing of the battery .................................................................................32

3
SKILLROW
IMPORTANT SAFETY INSTRUCTIONS
You should always consult with a qualied and licensed medical professional or healthcare practitioner before starting any nutritional, diet, stretching
or exercise program. You are advised to investigate and inform yourself about any health related actions and choices you make.
Please read all instructions before using the product. These instructions were written to ensure your safety and to protect the product.
Do not allow unsupervised children close to the product.
Close supervision by qualied personnel is necessary when the product is used by, on or near children, invalids or disabled persons.
Use the product only for its intended use as described in the user manual. Only perform the exercises for which the equipment has been designed,
following the instructions given in the manual. Any other use is to be considered improper and therefore dangerous.
Do not use attachments not recommended by Technogym.
Keep hands and feet away from moving parts.
Never drop or insert any object into any opening.
SAVE THESE INSTRUCTIONS

4
SKILLROW
PERSONAL SAFETY
Use of the product is subject to a medical examination in relation to the intended type of exercise, and compliance with the conditions of use laid down
by Technogym.
Persons suering from certain physical conditions may only use the product under the strict supervision of a specialist doctor.
Before starting an exercise, make sure your position on the product is correct, and be careful with any components that might constitute an obstruction.
Choose suitable exercises for your physical characteristics and state of health, starting out with light loads.
Do not overexert yourself or work to exhaustion. Incorrect or excessive exercise may cause serious physical harm or even death. If you feel any pain or
abnormal symptoms, stop the exercise immediately and consult your physician.
Wear proper exercise clothing and shoes during a workout: no garments that impede perspiration and no loose clothing. Tie long hair back. Keep garments
or towels away from moving parts.
During use people must remain at a safe distance.
Do not use the product in the presence of small children or pets.
The person in charge of the gym must explain to the users about proper and improper use of the equipment.
Completely assemble the product before using it. Check the product before each use. Do not continue to use the product if it is not working properly.
Assemble and operate the product on a solid, level surface.
Keep the product in good working condition. If there are signs of wear, contact the Technogym Technical Support service.
Do not attempt to service the product yourself other than following the maintenance instructions found in the user manual.
The installation, maintenance and setting must be done by qualied Technogym sta or persons authorised by Technogym.
Do not put the product in a vertical position.
Do not set anything on the casing or its display.
Technogym is not responsible for any damages due to any failures or damage caused by unauthorized service, misuse, accident, negligence, improper
assembly or installation, debris resulting from any construction activities in the product’s environment, rust or corrosion as a result of the product’s
location, alterations or modications without Technogym’s written authorization or for failure on your part to use, operate and maintain the products
as set out in this User Manual.

5
SKILLROW
Made in Italy
Technogym S.p.A.via Calcinaro 2861, Cesena (FC)
SKILLROW Model no. DJR0ND
S/N DJR0ND17000001 03/17
Contains FCC ID: Z64 - WLSBMOD, ZRX0WQ001147AA
Battery charger: 24V⎓0,5A
Class: SA ISO EN 20957 - 1 EN 957 - 7
Maximum User’s weight: 160 kg
F
C B A G
E
D
IDENTIFICATION OF THE MANUFACTURER AND EQUIPMENT
A- Manufacturer’s name and address
B- Place of manufacture
C- Product description
D- Electrical characteristics
E- Tells you to consult the user manual
F- Serial number and date of manufacture
G- Product model
The SKILLROW is a commercial device, designed for use in
residential and professional environments. It is classied
as a class SA device according to standard ISO EN 20957-1.

6
SKILLROW
D
B
C
A
E
F
G
DESCRIPTION OF THE PRODUCT
Sliding seat (A).
Grip (B).
Pushing platforms (C).
Sliding base (D).
Mode regulator (E).
Phone holder (F).
Display (G).

7
SKILLROW
USING THE PRODUCT
Starting adjustments
Sit on the sliding seat.
Put your feet on the pushing platforms, adjust the heel pad and block your
feet with the belts.
Starting position
Bend your knees to bring your glutei closer to your heels. Your lower leg must
be as vertical as possible.
Bend your chest forwards and grasp the grip with both hands. Your arms are
extended and your back straight.

8
SKILLROW
1 2
3 4
USING THE PRODUCT
Rowing
Push with your feet on the platforms and extend your legs.
When your legs are completely extended, use your abdominal corset
muscles and your thigh biceps to move your chest backwards with an
approximate inclination of 30°.
When your legs are extended and your chest inclined, bend your arms
and bring the grip towards your chest, with your elbows at the back.
Do not use your entire body at once during the exercise; perform the
exercise progressively starting from your legs, passing to your torso
and then end with the arm movement.
Rest time
Extend your arms, move your chest forward and bend your knees to
return to the starting position.
Warnings
Keep your backbone straight during the entire movement.
Keep your knees aligned with your ankles, not wider and not narrower.

9
SKILLROW
USING THE PRODUCT
Mode regulator operation
Two workouts can be performed on the product:
- a ROWING workout
- a POWER workout
In POWER mode, the regulator introduces a supplementary magnetic load. This makes it possible to
perform rowing exercises with an overload and strength exercises.
In ROWING mode: turn the knob to adjust the quantity of intake air; this has an impact on the sensation
of the rowing, not on the intensity.
The intensity of the eort depends on the exercise itself: if you pull stronger, you perceive more
resistance.
Turning the regulator in the ROWING zone changes the rowing sensation.
The eort exerted depends on various factors: temperature, altitude, dust accumulated inside the fan
and on the grilles. For this reason, even if the same rowing level is set, you may perceive dierent
sensations of eort when using dierent SKILLROW devices at dierent moments of the day.
In order to compare the results of dierent workouts by the same person, or compare the workouts
of dierent people, the aspect to take into consideration is the DRAG FACTOR, which is a measurement
of the agility of the "boat".
To view the drag factor, refer to the chapter dedicated to the display.

10
SKILLROW
USING THE PRODUCT
W
Any distractions in the area around the equipment may cause you to lose your balance.
It is the user's responsibility to ensure that the product being used does not interfere with any other mobile goods during use.
Use of the equipment by two people at the same time is prohibited.
The SKILLROW device is only intended for the use for which it was designed and built, which is as a rowing machine, for simulating the rowing
action of a boat. Any other use of the equipment is to be considered improper and therefore dangerous.
Pay attention to the movement of the sliding seat: risk of entrapment and crushing.
Always accompany the grip to the end stop and do not release it during the exercise.

11
SKILLROW
A
B
USING THE PRODUCT
Divide the product into two parts to store it after use.
Pull the lever (A) and press the element (B) at the same time. This releases the sliding base.
Once the two parts are released, they are free to fall: hold them both and pay attention.
Do not position the entire product in a vertical position: risk of instability and tipping over.

12
SKILLROW
USING THE PRODUCT
To ret the product, join the two parts together; the coupling elements will engage automatically.
For the coupling, make sure that the two parts are perfectly aligned.

13
SKILLROW
AVG MAX
bpm
GOAL
MOVE
kcal
VO2
GOAL
REST
min
DRAG
GOAL
TEST
TEST
m
REPS
AVG
MAX
watt
AVG
MAX
spm
/500m
AVG
MAX
DESCRIPTION OF THE DISPLAY
Walk for a few seconds to turn on the display. If the movement of the rotating
belt continues for more than 10 seconds, an exercise will begin.
To switch o the display, stop walking: the rotating belt must remain stopped
for more than 10 seconds.
This symbol indicates that the Wi-Fi connection is active.
If the connection is active, a log-in can be performed.
This symbol indicates that the log-in failed.
It is possible to log-in if the Wi-Fi connection is active.
The log-in can be performed using the TGS key or the mywellness app using NFC, QR-Code, Bluetooth smart.
If the log-in fails, at the end of the exercise the results are saved in the personal board.
The heart symbol indicates that the chest band was paired with the heart rate monitor.
The numerical value next to the heart indicates the beats per minute (bpm).
This symbol indicates the current workout mode, ROWING or POWER.
The numerical value indicates the resistance eort levels (ROWING), from 1 to 10.
The marks to the right of the numerical value indicate the magnetic resistance (POWER), from 1 to 3.

14
SKILLROW
spm
watt
AVG MAX
bpm
GOAL
MOVE
kcal
VO2
GOAL
REST
min
DRAG
GOAL
TEST
TEST
m
REPS
AVG
MAX
watt
AVG
MAX
spm
/500m
AVG
MAX
/500m
DRAG
AVG
MAX
spm
/500m
AVG
AVG
watt
DESCRIPTION OF THE DISPLAY
Data displayed during the exercise
During the exercise, the following instantaneous values are displayed in the rst
column of the display.
- Time elapsed since the beginning of the exercise, expressed in minutes and
seconds.
- Distance covered, expressed in metres.
- Calories burned.
In the second column, the values are divided on 3 pages; to scroll the pages, use the scroll keys on the right.
Speed, expressed in "strokes per minute"
(spm).
Instantaneous value.
Time expected for covering a distance of 500
metres, expressed in minutes and seconds.
Instantaneous value.
Power, expressed in watts.
Instantaneous value.
Speed, expressed in "strokes per minute"
(spm).
Average value from the beginning of the
exercise.
Time expected for covering a distance of 500
metres, expressed in minutes and seconds.
Average value from the beginning of the
exercise.
Power, expressed in watts.
Average value from the beginning of the
exercise.

15
SKILLROW
DESCRIPTION OF THE DISPLAY
On the third page, the values change depending on the workout mode.
- For ROWING workouts, the drag factor, which measures the eective eort made, is displayed.
- For POWER workouts, the number of repetitions and the instantaneous power are indicated.
Data displayed at the end of the exercise
At the end of the exercise, the following total values are displayed in the rst column of the display.
- Time elapsed since the beginning of the exercise, expressed in minutes and seconds.
- Distance covered, expressed in metres.
- Calories burned.
The following values are displayed in the second column of the display.
- Speed, expressed in "strokes per minute" (spm).
- Time expected for covering a distance of 500 metres, expressed in minutes and seconds.
- Power, expressed in watts.
The results of the second column are divided on 3 pages. Each page remains displayed for 5 seconds; then the display turns o.
- Page 1: values measured at the beginning of the exercise.
- Page 2: average values for the entire exercise.
- Page 3: maximum values reached during the exercise.
In the case of exercises carried out in POWER mode, also the total number of repetitions and the MOVE consumption are indicated.

16
SKILLROW
AVG MAX
bpm
GOAL
MOVE
kcal
VO2
GOAL
REST
min
DRAG
GOAL
TEST
TEST
m
REPS
AVG
MAX
watt
AVG
MAX
spm
/500m
AVG
MAX
DESCRIPTION OF THE DISPLAY
How to start an exercise (exercise types)
If you row for at least 3 seconds, without pressing any key, an exercise will start without duration limits. If you stop rowing for at least 3 seconds, the
exercise will be paused; after a 1 minute pause, the exercise ends.
Press the SET key to set other exercise types.
After pressing SET, use the two scroll keys to the right to scroll the dierent types of exercises.
The following exercises and tests are indicated in the following order.
- Exercise with a prexed duration, in minutes.
- Exercise with a prexed distance, in metres.
- Exercise with prexed calorie consumption.
- Interval exercise based on distance: the distance for the eort stage and the duration of the rest phase are set.
- Interval exercise based on duration: the duration for the eort stage and for the rest phase are set.
- Test that lasts 30 seconds.
- Test that foresees running a distance of 2000 metres.
To select an exercise or a test, press the SET key when the exercise is shown on the display.
After selecting the exercise, use the two scroll keys to set the values (duration, distance, calories). Press the
SET key to conrm the value and start the exercise.
No values need to be entered for the tests.
The tests are performed in ROWING mode; if the POWER mode is active, the test will not start.

17
SKILLROW
AVG MAX
bpm
GOAL
MOVE
kcal
VO2
GOAL
REST
min
DRAG
GOAL
TEST
TEST
m
REPS
AVG
MAX
watt
AVG
MAX
spm
/500m
AVG
MAX
USING THE CHEST BAND
There is a receiver in the display that receives the heart rate signals from the telemetric chest band.
The Bluetooth Smart and ANT+ transmission technologies are supported.
In order to have the heart rate value shown on the display, the chest band must be paired with the product.
The pairing must be repeated each exercise.
To pair the chest band, press the heart shaped symbol on the right.
To make the connection easier, move as close as possible to the receiver for 10 seconds.
The heart icon on the display will ash during the pairing operation; once the pairing is successful, the
icon remains on and the instantaneous heart rate is displayed.
The heart rate is expressed in beats per minute.
If log in was completed and the heart rate threshold was recorded in the prole, the 3 reference marks
will turn on.
- 1 mark indicates that the heart rate value detected is between 0% and 33% of the threshold value.
- 2 marks indicate that the heart rate value detected is between 34% and 66% of the threshold value.
- 3 marks indicate that the heart rate value detected is above 67% of the threshold value.

18
SKILLROW
USING THE CHEST BAND
The table shows the optimum heart rate levels in relation to age and the
goal to be achieved.
Theoretical maximum heart rate (100%) is calculated on the basis of age
using the formula: HRmax = 207 - 0.7 x age (R. L. Gelish et al, Med Sci Sports
Exerc., 2007 May, 39 (5): 281).
To read the graph, simply nd your age on the horizontal axis and scan up
the vertical until you reach the 60%, 70% and 90% values.
Aerobic exercise performed at a heart rate between 60% and 70% mainly
burns fat as an energy source.
Whendoing aerobicexerciseataheartrateof70%to90%thecardiocirculatory
component prevails.
For example, if someone aged 30 wants to burn o fat, they should keep
their heart rate between 112 (60%) and 131 (70%) during exercise; if they
want to improve cardio-respiratory capacity, they should keep their heart
rate between 131 (70%) and 168 (90%).
Heart rate per minute
Age
Predominant use of sugars.
Training for competitive athletes (subject to medical assessment).
Combination of sugars and fats burned.
Signicant improvement of aerobic eciency.
Predominant use of fats, and increase in the use of sugars.
Moderate improvement of aerobic eciency.
Predominant use of fats, and minimal use of sugars.
Limited improvement of aerobic eciency.

19
SKILLROW
USING THE CHEST BAND
W
During a workout it is very important that your heart rate never goes above 90% of your maximum rate (unless you are an athlete engaged
in competitive sport).
The sole function of the heart rate monitor is to display the heart rate during exercise and cannot be used for medical cardiac diagnoses of
any kind. The heart rate shown on the display is purely indicative and cannot be considered absolutely certain.
You are advised not to use a chest band with heart rate monitor if you have a cardiac support device such as a pacemaker or similar.
To avoid interference, the products must be kept at least 170 cm from each other.
Heart rate readings may not be accurate near sources of electromagnetic radiation (TVs, mobile phones etc.).
Should you have any doubts about the accuracy of the readings, contact the Technical Support Service.
In the event of diculties connecting the chest band:
- Check that the battery is not at.
- Check that the chest band is not already connected to other devices.

20
SKILLROW
60 cm
PLACE OF USE
To ensure that exercising with the equipment is easy, safe and eective, the place where it is used should comply with certain specic requirements; in
particular, before choosing where to install the unit we recommend that you check that the following conditions are available:
- the temperature is between +10°C and +25°C;
- enough air is circulating to keep humidity during exercise to between 20%
and 90%;
- the lighting is good enough to make the area a safe and relaxing place to
exercise in;
- ample range of free space measuring at least 60 cm all around each piece
of equipment;
- the oor is at, stable and vibration-free, and strong enough to bear the
weight of the equipment plus user.
The place of installation must comply with all binding regulations.
Do not expose the product to direct sunlight.
Do not use outdoors. Do not leave the product outdoors, exposed to the
elements (rain, sun, wind, etc.). Do not expose the product to water jets.
Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
Do not position the product in humid areas, such as near pools, hydromassage
tubs, saunas.
