Technogym TEAMBEATS User manual

TEAMBEATS
INSTALLATION MANUAL
Rev. 1.1 - (ApRIL 2017)

TEAMBEATS:
Installation Manual - Rev. 1.1
Pag. 3
e-mail: [email protected]
Index
1. GENERAL WARNINGS.......................................................................................................... 7
.  ..................................................................................................
.  ..................................................................................................
. .....................................
.. 
2. TEAMBEATS INSTALLATION .......................................................................................... 9
.  .................................................................
. ..........................................................
.. 
..  
.  .............................................................................................
      
.................................................................................................................... 13
.  .........................................................................................
.  ........................................
. ..............................................................................
. ..................................
..  
..  
 34
 38
. ..............................................................
. ......................................................
      
........................................................................................................................ 47
.  .........................................................................................
.  ........................................
. ..............................................................................
. ....................................
..  
 59
 65
..  
. ..............................................................
. ......................................................

TEAMBEATS:
Installation Manual - Rev.1.1
Pag. 4
e-mail: [email protected]
 .............................................................. 79
.  .........................................................................................
.  .................................................................................................................
..  
..  
  ................................................................... 81
. ...................................................................................................
.  ...................................................................................
.  .................................................................................................................
.  ......................................................................................................
.  .........................................................................................
.  .................................................................................................
.  ..........................................................................................................
.  .........................................................................................
  ....................................................... 85
. .........................................................................................................

The information in this manual is intended for QUALIFIED TECHNICAL PERSONNEL, who have
been specically trained by TECHNOGYM and are qualied to carry out ne tuning and start-up
of the equipment, as well as major maintenance work and repairs, requiring in-depth understand-
ing of the equipment, how it works, its safety devices and maintenance procedures.



 
The information contained in this document may be changed without prior notication.
This document contains proprietary information that is covered by copyright. All rights reserved.
No part of this document may be photocopied, reproduced or translated into another language
without the prior wrien consent of Technogym.
Technogym® is a trademark owned by Technogym S.p.A.
TEAMBEATS:
Installation Manual - Rev. 1.1
Pag. 5
e-mail: [email protected]

Blank Page.
TEAMBEATS:
Installation Manual - Rev.1.1
Pag. 6
e-mail: [email protected]

1. GENERAL WARNINGS
1.1 INTRODUCTION
This document has been prepared specically for Technogym After Sales Service, with the aim
of providing authorised personnel with the information for carrying out maintenance and repair
operations in the correct manner.
A thorough understanding of the technical data contained herein is absolutely fundamental in
order for the operator to achieve the highest level in professional training.

 
CAUTION: Regulation that may lead to damage to the equipment if not complied with.
WARNING: Information regarding the operation in progress.
 
TEAMBEATS:
Installation Manual - Rev. 1.1
Pag. 7
e-mail: [email protected]

1.2 USEFUL ADVICE

Carefully assess the impressions reported by the Customer regarding the equipment’s operating
faults and ask questions suitable to clarify the signs of the defect.
Clearly diagnose the causes of the problem. This manual provides the fundamental theoretical ba-
sis, which must then be integrated by personal experience and aendance at the training courses
periodically oered by Technogym.
Plan the repair work in a rational manner so as to avoid wasting any time, e.g. collecting spare
parts, preparing tools and equipment etc.
Access the component to be repaired, avoiding any unnecessary operations. On this point, it will
be extremely helpful if you consult the disassembling sequences shown in this manual.
1.3 GENERAL REGULATIONS REGARDING SERVICE WORK
1. Check the serial number of the equipment, comparing it with the one on the work order.
2. Always mark any parts or positions which may be confused with each other at the time of
reassembly.
3. Use original Technogym spare parts and lubricants of the recommended brands.
4. Use special tools where specied.
5. Consult the Technical Newsleers and News Flashes, which may contain more up-to-date
information on adjustments and maintenance than those contained in this manual.
6. Before starting the repair procedure, make sure that the recommended tools are available and
in good condition.
7. For the procedures described in this manual, use only the specied tools.
 
and safe operation.
1.3.1 PERSONAL PROTECTIVE EQUIPMENT
For details, refer to the Health&Safety After Sales procedure, available on TG Direct.
TEAMBEATS:
Installation Manual - Rev.1.1
Pag. 8
e-mail: [email protected]

2. TEAMBEATS INSTALLATION
2.1 PRE-INSTALLATION REQUIREMENTS
        

2.2 PRODUCTS OF A TYPICAL INSTALLATION
The Products and codes to be ordered are detailed in the marketing communication.
A typical installation of TEAMBEATS requires:
1. a UNITY SELF for each classroom,
It must be used a UNITY SELF 2016 EXCITE+/ARTIS OR LATER VERSION.
2. an ANT+ UPGRADE KIT for each UNITY SELF,
3. one or more CLASS ANTENNA for each classroom,
4. the TEAMBEATS license that enables the TEAMBEATS app on UNITY SELF for the entire
facility;
5. Heart Rate devices (Arm band - Chest band).
2.2.1 CLASS ANTENNA
There are two dierent models of Class Antenna, either for Wi-Fi or LAN:
- WASP POE for LAN.
Figure 1
TEAMBEATS:
Installation Manual - Rev. 1.1
Pag. 9
e-mail: [email protected]

Figure 2: detail of WASP-POE MAC Address
- 
WASP-N + box + screws + double-sided tape
Figure 3
Adapter Cable
TEAMBEATS:
Installation Manual - Rev.1.1
Pag. 10
e-mail: [email protected]

Figure 4
2.2.2 UPGRADE KIT ANT+
- Cable USB ANT+.
- Velcro.
Figure 5
2.3 NECESSARY TOOLS
Medium Phillips screwdriver.
TEAMBEATS:
Installation Manual - Rev. 1.1
Pag. 11
e-mail: [email protected]

Drill.
Moreover:
Artis USB Upgrade key, just synchronized with PC SYNCH.
POLAR H7 or ANT+ Transmier to test the application.
iOS device or Windows 10 PC.
TEAMBEATS:
Installation Manual - Rev.1.1
Pag. 12
e-mail: [email protected]

3. TEAMBEATS INSTALLATION PROCEDURE WITH CLASS ANTENNA
WASP-POE (LAN)
3.1 UNITY SW UPDATING
1. Position the UNITY SELF, according to the layout of the club.
1
2. Remove the display
rear guard (1).
The pictures refer to
the EXCITE+ UNITY
SELF.
3. Switch ON the UNITY SELF.
TEAMBEATS:
Installation Manual - Rev. 1.1
Pag. 13
e-mail: [email protected]

4. In the stand-by
screen, press and hold
the touch screen to the
right of the HOME
logo.
5. Enter the number
corresponding to the
following password on
the virtual keyboard:
2501 (SERVICE Menù).
6. Insert the updated
USB Artis upgrade key,
just synchronized with
PC Synch, in the USB
Plug.
7. Select VERSIONS: Upgrade UNITY. Update the sw version through the USB upgrade key,
inserted in the USB Plug. 
TEAMBEATS:
Installation Manual - Rev.1.1
Pag. 14
e-mail: [email protected]

8. Do NOT touch the
device during these
processes and wait un-
til all the UPGRADE
phases have been com-
pleted.
9. Remove the USB Artis upgrade key, from the USB Plug.
10. Switch o and reboot the UNITY SELF.
3.2 INSTALLATION OF TEAMBEATS APP AND KIT ANT+

1. Access to the site pro.mywellness.com. In the section Technogym App Store, select the APP
TEAMBEATS and download it. Launch the application.
TEAMBEATS:
Installation Manual - Rev. 1.1
Pag. 15
e-mail: [email protected]

2. , It is shown the following message: “INSTALLATION IS COM-
PLETE! Please insert the ANT+ receiver upgrade kit to start using Teambeats. 
.”
, It will be shown only the rst part of the message: “INSTALLA-
TION IS COMPLETE! Please insert the ANT+ receiver upgrade kit to start using Teambeats.”
3. Proceed with the installation of the kit ANT+, as described below.
4. Disconnect the USB cable from the USB connector of the CPU board.

In the USB connector of the CPU board, you’ll have to connect the new cable USB ANT+.
So, you’ll have to disconnect the old USB cable from the USB connector. 
will remain dangling.

TEAMBEATS:
Installation Manual - Rev.1.1
Pag. 16
e-mail: [email protected]

USB connector detail.
2
5. Open the plug (2) of
the display, removing
the two screws.
TOOL: medium Phillips
screwdriver.
TEAMBEATS:
Installation Manual - Rev. 1.1
Pag. 17
e-mail: [email protected]

6. Aach the adhesive
of velcro to the ANT+
connector.
7. Aach the adhesive
of velcro to the plug.
8. Aach the ANT+
connector to the plug,
through the velcro.
TEAMBEATS:
Installation Manual - Rev.1.1
Pag. 18
e-mail: [email protected]

9. Connect the black
connector of the Cable
USB ANT+ to the USB
connector of the CPU.
The Cable USB ANT+
must pass internally to
the plate.
TEAMBEATS:
Installation Manual - Rev. 1.1
Pag. 19
e-mail: [email protected]

USB connector details.
Cable USB ANT+ con-
nected.
10. Fix the plug of the
display, through the two
screws.
TOOL: medium Phillips
screwdriver.
