Tecnosicurezza Pulse User manual

Pulse
User Instructions

2 of 12 IU_Pulse_03_eng
User instructions
Pulse
Table of contents
TABLE OF CONTENTS 2
IMPORTANT NOTES! 3
GENERAL INFORMATION 4
FUNCTIONS OVERVIEW 5
LOCK OPENING 6
MANAGER &STANDARD USERS: 6
OVERRIDE USER: 6
CHANGE CODE 6
INSTALL/DISABLE/DELETE USERS 7
INSTALL USERS (FUNCTION #1) 7
DISABLE/ENABLE USERS (FUNCTION #2) 7
DELETE USERS (FUNCTION #3) 7
MANAGER CODE CHECK 7
TEST MODE 8
CHANGE LOCK RECLOSURE MODE 8
USERS STATUS 8
AUDIT/CONFIGURATION DOWNLOAD 9
TIME DELAY AND OPEN WINDOW 9
LOCK RESET 10
CORRECT DISPOSAL OF THIS PRODUCT: 12
(WASTE ELECTRICAL & ELECTRONIC EQUIPMENT) 12
CONTACTS 12
Before operating the lock,
please read this manual thoroughly,
and retain it for future reference.

IU_Pulse_03_eng 3 of 12
User instructions
Pulse
Important notes!
Before installing this product, please read carefully the installation and operating
instructions.
Locks have been designed to correctly operate in a temperature range from -5°C (23°F)
to + 50°C (122°F) and in an environment with non-condensing humidity between 25%
and 90%.
The lock must not be oiled/lubricated/greased.
If installed in normal domestic or office environments, the locks do not require particular
maintenance; in any case, after 10,000 opening/locking cycles, it is recommended to run
a test that verifies the correct and complete operation of the product.
Use only DURACELL™ 9 Volt Alkaline batteries, or battery holders with DURACELL™ 1,5
Volt Alkaline batteries. Alternatively, it is also possible to use a stabilized power supply
from 12 V to 24 V and 1 A, with relative power supply interface (p.n. T6006).
A series of acoustic signals during opening indicate a low battery level. In this case, the
battery must be replaced.
Do not use cleaning agents with chemical, abrasive or alcohol-containing additives to
clean the components. Use only a damp cloth.
Do not spray liquid directly onto the components.
It is strongly recommended to change the default codes before usage and to keep the
new codes safe.
Do not use codes easily guessed such as 123456, birth dates or based on personal
information.
After changing a code, perform several opening/closing tests before closing the door.
Should the lock label be removed, warranty is void.

4 of 12 IU_Pulse_03_eng
User instructions
Pulse
General information
Using the keypad
To start a time delay counting (if programmed), enter an opening code:
LED flashes every 2s, indicating the counting.
Press any key to stop the time delay counting.
The opening window is indicated by a flashing and a beep alternating at
1s intervals.
The led remains on if the system is in programming mode.
2 short beeps are produced if an operation/code is correct.
A long beep is produced if an operation/code is incorrect.
If an incorrect operation is performed, wait 5 seconds until the led switches off and try again.
Pre-setup & Configurations
In pre-setup mode, press 1 to open the lock and activate the silent alarm. It’s possible to open
also by input 555555 code, in this case the silent alarm is activated by increasing or decreasing
the last digit by one number of the code (555556 or 555554).
In pre-setup mode, programming can be performed through a Dallas key or by selecting one of
the following 4 preloaded configurations:
No. configuration
Maximum number of users
Dual mode
0
2
No
1
9
No
2
2
Yes
3
9
Yes
Silent alarm option can be activated through a setup Dallas key where the function is enabled,
or by simply connecting an alarm interface to the lock and entering an opening code.
Select a keypad configuration (only in pre-setup status)
Hold press the 2 key for few seconds, enter the code 555555 and select the desired
configuration number.
At the end of the configuration only the Manager is installed, with code 123456.
If all users are blocked and only the manager is enabled, time delay and dual mode (if
programmed) are not available.

IU_Pulse_03_eng 5 of 12
User instructions
Pulse
Users characteristics & default codes
Manager
123456 +
optional Dallas key
Main user : opens, program and change its own code.
Standard users
XXXXXX +
optional Dallas key
Users from 1 to 8 : opens and change their own code.
Override users
XXXXXX +
optional Dallas key or Dallas key only
User #9 : opens without time delay and changes its own code.
By default it’s set in dual mode opening but, upon request, the single mode
opening can also be set.
Functions overview
Lock opening
After entering an opening code, it is possible to open the lock within 3 seconds. It is not
necessary with MotorLock locks: in this case, the motor retracts the bolt which remains in the
open position for 8 seconds before returning to the closed position. In the manual closing
version, the bolt can be closed by pressing any key.
Penalty
Four consecutive wrong codes starts a four minutes penalty time. During this period, the LED
flashes once every 10s. Each time a key is pressed a long beep is produced, no operation is
allowed and the count will restart.
Dallas keys
During the installation (function #1), a Dallas key (model N1982 or N1990) can be associated to
a user by simply placing it in the Dallas reader after entering the ID and related code. The user
is then identified by numeric code + Dallas key.
Power supply
Lock can be powered with:
an ALKALINE 9V battery located in the battery compartement below the keypad;
an internal battery box provided by Tecnosicurezza (6 ALKALINE 1.5 batteries);
A power adapter (ref. N1212) with power supply interface (ref. T6006 or N620/A) both
provided by Tecnosicurezza.
Low battery warning
A series of beeps while opening indicates a low battery which should be replaced immediately.
Silent alarm
With this function enabled, if an user enters an opening code an then increase or decrease the
last digit by one number (i.e. 030304 or 030302 instead of 030303) the lock opens and
simultaneously the output of the alarm interface is activated.
Audit
The lock is able to save the last 100 operations with user and operations description.

6 of 12 IU_Pulse_03_eng
User instructions
Pulse
Function access
Standard mode:
Hold press the key corresponding to the function for two seconds. Led
remains on.
Dual mode:
Input a valid code that’s not the Manager code, hold press the key
corresponding to the function for two seconds. Led remains on.
Note: the functions where the Manager code is needed, can be accessed even by entering
the Manager code and hold-pressing the last digit. Led remains on. Press the key
corresponding the desired function.
Lock opening
It is recommended to change the factory code before use and safely store the new code.
Manager & standard users:
Enter an opening code. The keypad beeps twice.
If programmed, the time delay counting starts.
At the end of time delay, the open window counting starts.
Enter a code during the opening window (2 codes in case of dual mode
opening). The keypad beeps twice and the lock can be opened.
Override user:
Enter an opening code. Time delay counting starts.
Input the override user code (and the Dallas key if needed) or the
override Dallas key (for only Dallas override user). The keypad beeps
twice and the lock can be opened.
Change code
It is recommended to always perform this operation with door open.
Press and hold until the double beep. The led remains on.
Note: it’s also possible to access the function by entering “0 0 0 0 0 0”. The led remains on.
Enter the old code (and the Dallas key if needed). The keypad beeps
twice.
Enter the new code (and the Dallas key if needed). The keypad beeps
twice.
Confirm the new code (and the Dallas key if needed). The keypad beeps
twice and led switches off.
Note: it’s possible to set a new Dallas key and keep the old code. Perform a code change
operation keeping the code unchanged but placing a new dallas key.

IU_Pulse_03_eng 7 of 12
User instructions
Pulse
Install/Disable/Delete users
Install users (function #1)
Hold press until the double beep. Led remains on.
Enter the Manager code (and the Dallas key if needed). The keypad
beeps twice.
Enter the number of the user to be installed. The keypad beeps twice.
Enter the code (and the Dallas key if needed) of the new user. The
keypad beeps twice.
Confirm the code (and the Dallas key if needed) of the new user. The
keypad beeps twice and the led switches off.
Note: it’s only possible to install the override user during the open window counting or if
the time delay is not set.
Disable/Enable users (function #2)
Hold press until the double beep. Led remains on.
Enter the Manager code (and the Dallas key if needed). The keypad
beeps twice. All the users (but Manager) are disabled/enabled.
Note: this function is not available in dual mode opening.
Delete users (function #3)
Hold press until the double beep. Led remains on.
Enter the Manager code (and the Dallas key if needed). The keypad
beeps twice.
Enter the number of the user to be deleted. The keypad beeps twice and
led switches off.
Manager code check
Hold press until the double beep. Led remains on.
A double beep means the factory Manager code (123456) has been
changed.
A long beep means the factory Manager code (123456) has NOT been
changed.

8 of 12 IU_Pulse_03_eng
User instructions
Pulse
Test mode
This function allows to verify the system is working correctly.
Hold press until the double beep. Led remains on.
Enter the following sequence of keys:
Any working button produces 2 short beeps.
A damaged button produces a long beep and the keypad switches off.
Change lock reclosure mode
Only for MotorLock locks: this function allows to change the lock reclosure mode
(automatic/manual).
Lock in presetup mode
Hold press until the double beep. Led remains on.
Enter the code 5-5-5-5-5-5. The keypad beeps twice.
Lock reclosure mode has been changed (from automatic to manual or viceversa).
Lock in setup mode
Hold press until the double beep. Led remains on.
Enter the Manager code (and the Dallas key if needed). The keypad
beeps twice.
Lock reclosure mode has been changed (from automatic to manual or viceversa).
Users status
Hold press until the double beep. Led remains on.
Enter the Manager code (and the Dallas key if needed). The keypad
beeps twice.
Enter the ID of the user to be verified.
A single beep (negative sound) is produced for available users (not
installed) or for disabled/deleted users.
A double beep is produced for installed users.

IU_Pulse_03_eng 9 of 12
User instructions
Pulse
A long beep is produced for blocked users (not possible to install).
To close this function, wait for few seconds without entering any ID. A
long beep is produced. Then, the led switches OFF.
Audit/configuration download
Audit and configuration can be downloaded in two ways:
Using a Dallas key (previously programmed with software Pulse Audit).
Using PC direct connection.
All the necessary hardware and software are provided by Tecnosicurezza.
Hold press until the double beep. Led remains on.
Enter the Manager code (and the Dallas key if needed). The keypad
beeps twice.
Dallas key
Insert the audit Dallas key into the reader and keep it in place (it is
recommended to use a magnetic Dallas key): the keypad beeps twice
and the download begins automatically.
PC direct connection
Hold press again until the double beep. Place the magnetic Dallas connection cable into
the reader and use the software Pulse Audit to start the download.
At the end of audit download (wether direct or through a Dallas) the
keypad beeps twice and the led switches off.
Time delay and open window
Hold press until the double beep. Led remains on.
Enter the Manager code (and the Dallas key if needed). The keypad
beeps twice.
Enter a two digit time delay value and a two digit opening window value
(i.e. 10 and 05). The keypad beeps twice.
Enter again the time delay and opening window values for confirmation.
The keypad beeps twice and the led switches off.
Time delay can be programmed in between 0 and 99 minutes, the open window in between
1 and 19 minutes.
Note: it’s possible to lower or remove time delay only during the open window counting.

10 of 12 IU_Pulse_03_eng
User instructions
Pulse
Lock reset
The reset operation will restore the system in pre-setup mode.
Disconnect the power supply. Press keys to discharge the excess current.
Connect the reset box on the connector 2 of the lock.
Power up the reset box with a 9V battery. The keypad beeps twice.
Lock is reset.
Perform an opening by pressing key.

IU_Pulse_03_eng 11 of 12
User instructions
Pulse
NOTES

Correct disposal of this product:
(Waste Electrical & Electronic Equipment)
Applicable in the European Union and other European countries with separate collection systems.
This marking displayed on the product or its literature indicates that it should not be disposed with other wastes at the end of its
working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Contacts
GLOBAL HEADQUARTERS
USA HEADQUARTERS
SPAIN HEADQUARTERS
Tecnosicurezza SpA
Tecnosicurezza Inc.
Tecnosicurezza Sa
Via Cesare Battisti, 276
50, Thomas Lane
C/Menor, 4 - Nave 10
37057 San Giovanni Lupatoto
Verona
Versailles, KY 40383
Pol. Ind La Mina 28770
Colmenar Viejo
Tel.[phone]
Tel.[phone]
Tel.[phone]
Fax. [phone]
Fax.[phone]
[e-mail]
[e-mail]
[e-mail]
