Tecnosicurezza TechMaster User manual

TechMaster
User
Instructions

2 of 27 IU_ TechMaster_04_eng
User instructions
TechMaster
Company
Founded in 1983 with the aim of providing a complete range of professional products,
Tecnosicurezza is now a consolidated reality in the field of locks and security systems for safes.
The experience gained in over 35 years of activity in the security sector has allowed the
designing and manufacturing of high technology and reliability systems, which continue to
receive the approval of an increasingly demanding clientele.
TECNOSICUREZZA is present directly on the Italian, Spanish and US markets and, through an
extensive distribution network, in many European and extra-European countries.
TECNOSICUREZZA is aimed at national and international customers of primary importance,
such as banks, safe manufacturers, cash in transit companies, mass market retailers and post
offices.
Today TECNOSICUREZZA is a leading company focused on the customers’ needs and
constantly in step with technology.

IU_TechMaster_04_eng 3 of 27
User instructions
TechMaster
Table of contents
COMPANY 2
TABLE OF CONTENTS 3
IMPORTANT NOTES! 5
GENERAL INFORMATION 6
OVERVIEW FUNCTIONS 9
OPENING THE LOCKS 10
USERS (OR OVERRIDE USERS): OPENING WITHOUT TIME DELAY 10
USERS: OPENING WITH TIME DELAY 10
MANAGER (OR OVERRIDE MANAGER): OPENING WITHOUT TIME DELAY 10
MANAGER (OR OVERRIDE MANAGER): OPENING WITH TIME DELAY 10
OPENING WITH DYNAMIC CODES (DALLAS KEY OPTION) 11
OPENING WITH DYNAMIC CODES (PIN OPTION) 11
DUAL MODE OPENING WITHOUT TIME DELAY 12
DUAL MODE OPENING WITH TIME DELAY 12
MASTER MENU 12
TIME & DATE SETTINGS 12
TIME LOCK SETTINGS 13
WEEKLY TIME LOCK SETTINGS – ADDING NEW VALUES 13
WEEKLY TIME LOCK SETTINGS – VERIFY OR DELETE VALUES 14
CLOSING PERIODS (OFF DAYS) – ADD NEW VALUES 14
OPENING PERIODS - ADD NEW VALUES 15
OPENING PERIODS - VERIFY OR DELETE VALUES 16
PC CONNECTION 16
MANAGER MANAGEMENT 16
DYNAMIC CODES – ENABLING/DISABLING 17
DYNAMIC CODES ACTIVATION WITH STATIC CODES DELETING 17
MANAGER MENU 17
USERS MANAGEMENT 18
TIME DELAY 18
VARIABLE TIME DELAY – ADDING NEW VALUES 18
VARIABLE TIME DELAY – VERIFY OR DELETE VALUES 19
PC CONNECTION 19
OVERRIDE MANAGER MENU 20
OVERRIDE USERS MANAGEMENT 20
CODE CHANGING 20
CHANGE CODE FOR STANDARD AND OVERRIDE USERS 20
CHANGE CODE FOR MANAGER 21
CHANGE CODE FOR OVERRIDE MANAGER 21

4 of 27 IU_ TechMaster_04_eng
User instructions
TechMaster
CHANGE CODE FOR MASTER 21
TIME MENU 21
OPENING EXTENSION 22
IMMEDIATE TIME LOCK 22
CONFIGURATION MENU 22
INSTALL LOCKS 22
REMOVE LOCKS 23
LOCK RECLOSURE MODE 23
CONFIGURE I/O INTERFACE 24
REMOVE I/O INTERFACE 24
DISPLAY CONTRAST 24
KEYPAD LANGUAGE 24
MEMBRANE TEST 25
SYSTEM INFO 25
NOTES 25
CONTACTS 27

IU_TechMaster_04_eng 5 of 27
User instructions
TechMaster
Important notes!
 Before installing this product, please read carefully the installation and operating
instructions.
 Locks have been designed to correctly operate in a temperature range from -5°C to +
50°C and and in an environment with non-condensing humidity between 25% and 90%.
 The lock must not be oiled/lubricated/greased.
 If installed in normal domestic or office environments, the locks do not require
maintenance; in any case, after 10,000 opening/locking cycles, it is recommended to
run a test that verifies the correct and complete operation of the product.
 Use only DURACELL™ 9 Volt Alkaline batteries, or battery holders with DURACELL™ 1.5
Volt Alkaline batteries. Alternatively, it is possible to use a 12VDC - 1A power adapter
(p.n. N1212) with relative power supply interface (p.n. T6005/W or p.n. T6005).
 A long beep together with the message “LOW BATTERY” on the display, indicate a low
battery level which need immediate replacing.
 It is strongly recommended to change the default codes before the usage and to keep
safely the new codes.
 Do never use codes easy to be guessed such as 123456, birth dates or others, based on
own personal information.
 After changing a code, perform several opening/closing tests before closing the door.
Should the lock label be removed, warranty is void.

6 of 27 IU_ TechMaster_04_eng
User instructions
TechMaster
General information
Using your keypad
 Press any button to power up the keypad. LCD which shows: ENTER CODE
X X – X X X X X X
If more locks are installed, LCD shows:
Enter the lock number to select it.
SELECT LOCK
 To enter a code, power up the LCD and enter the
corresponding digits.
 LCD automatically switches OFF if no buttons are pressed
within 30s.
 To scroll the menu, press .
 To confirm an operation or enter a menu press .
 To leave a menu and come back to the main menu, scroll the
functions until “EXIT?” and press OK.
 To enter a code plus Dallas key (if set), enter the code digits
and insert the Dallas key in the keypad reader.
 To enter a user provided with Dallas key only (if set), insert the
Dallas key in the keypad reader. LCD shows:
DALLAS USER
XX
 To start a time delay counting (if set), enter a code. LCD
shows:
TIME DELAY
00:59
 To stop a time delay counting, press and then confirm
with
STOP DELAY
COUNTING?
After time delay counting, LCD shows open window counting:
Press and enter a code for opening.
OPEN WINDOW
00:01
 If a wrong code is entered, LCD displays the message: WRONG CODE
 If a wrong dynamic/activation code is entered, LCD displays
the message:
WRONG DYNAMIC
CODE

IU_TechMaster_04_eng 7 of 27
User instructions
TechMaster
 If a dynamic/activation code is entered more than 30 minutes
before its beginning validity time, LCD shows:
WRONG DYNAMIC
CODE
 If a dynamic/activation code is entered more than 30 minutes
later than its beginning validity time, LCD shows: WRONG DYNAMIC
CODE
 To open or access the menu in dual mode (if set), enter the
first code. LCD shows:
Then, enter the second code.
ENTER 2° CODE
X X – X X X X X X
Shortcuts
Press and hold for 2 seconds the button related to the needed function:
= Change Manager code (01), users, override users, Master and Manager ovr (if
configured)
= PIN entering for dynamic codes (after dynamic codes activation)
= Test mode
= access to Manager menu, Manager ovr menu (if configured) Change code menu, Time
menu, Configuration menu and Master menu.
= System info and time and date info
= Exit and back to the main menu
= Master menu
User properties and default codes
Users can be set for opening with code only, code + Dallas key or with Dallas key only. It is also
possible to set a dual mode opening: in this case, entering the two users codes is required to
open the lock.
Default codes are:
Master: 1-2-3-4-5-6-7-8.
Manager: 123456.

8 of 27 IU_ TechMaster_04_eng
User instructions
TechMaster
Users from 02 to 90: 02-020202, 03-030303, and so on. They always open with time delay if
set.
Override users: thanks to the setup software, it is possible to configure users in between 10
and 90 (10-101010, 11-111111, and so on) as override users. They always open without time
delay.
The table below reports the main users functions.
Master Manager
Access to Master Menu
Set time and date
Set Time Lock periods
Audit download
Manager Management
Enable/disable OTCs
Change code
PC Link
Access to Manager Menu
Standard users management
Override users management
Set time delay
Set variable time delay
PC Link
Audit download
Opening
Code changing
Set opening extension
Set immediate time lock
Override manager Configuration menu
Access to Ovr. Manager menu
Override users management
Code changing
Install/remove locks
Set display contrast
Change language
Test mode
Check system Informations
Override users Standard users
Opening
Change code
Opening
Set opening extension, if enabled
Set immediate time lock, if enabled
Code changing
This user manual describes the standard programming. According such programming and
unless different requests while ordering the product, an opening can be performed by
entering single users codes (no dual mode) and without time delay. Thus, the user manual
must be adapted according the configuration selected.
It is strongly recommended to change the default codes before using the lock.

IU_TechMaster_04_eng 9 of 27
User instructions
TechMaster
Overview functions
Lock opening
After entering an opening code, it is possible to open the lock within 3 seconds. It’s no
necessary instead with motorized locks: in this case indeed, the motor moves the bolt which
remains in opening position for about 8 seconds before returning in closing position. In the
manual closing version instead, the bolt can be closed by pressing key for few seconds.
Penalty
Four consecutive wrong codes initiate a four minutes penalty time. During this period, LCD
shows the message “PENALTY” and no operation is allowed.
Time Delay
Programmable time delay in between 0 and 99 minutes. Programmable opening window in
between 1 and 19 minutes.
Dallas keys
It can be programmed for any lock. Available as option for Manager and users (not for
Master).
TechMaster keypad only works with Dallas keys created by TECNOSICUREZZA. Upon express
request, the keypad can be set in order to work also with different Dallas keys models.
Power supply
Lock can be powered with:
 an ALKALINE 9V battery located in the battery compartment below the keypad;
 an internal battery box provided by Tecnosicurezza (6 ALKALINE 1.5 batteries);
 A power adapter (ref. N1212) with power supply interface (ref. T6005/W or T6005)
both provided by Tecnosicurezza.
Low battery warning
A long beep together with the message “LOW BATTERY” on the display, indicate a low battery
level which need immediate replacing.
Silent Alarm
It can be programmed on each lock.
Audit
The lock is able to save the last 6000 operations with time, date, user and operations
description. The keypad can save the last 250 operations. It’s possible to download the events
for locks and keypad by using the Tecnosicurezza DMT Audit software. For further information
refer to the IU_DMT_Audit_XX.

10 of 27 IU_ TechMaster_04_eng
User instructions
TechMaster
IMPORTANT
Some options/characteristics reported in this user manual, can only be used if previously
enabled through the setup software. Thus, please refer to the user manual
IU_TechMaster_setup_XX.
Please contact Tecnosicurezza for further information.
Opening the locks
Users (or Override users): opening without time delay
Power up the keypad. Enter an opening code and insert the Dallas
key, if set-up. LCD shows:
OPEN
Open the lock within 3 seconds.
Users: opening with time delay
Power up the keypad. Enter an opening code and insert the Dallas
key, if set-up.
LCD shows the time delay counting:
TIME DELAY
00:59
At time elapsed, the LCD shows the open window counting time. OPEN WINDOW
00:01
Press , LCD shows: ENTER CODE
X X – X X X X X X
Enter an opening code and insert the Dallas key, if set-up. LCD shows: OPEN
Open the lock within 3 seconds.
Manager (or Override Manager): opening without time delay
Power up the keypad. Press for opening with Manager code or
press it two times for opening with Manager Ovr code. LCD shows:
MANAGER CODE
X X X X X X
Enter Manager code and insert the Dallas key, if set-up (or enter
Manager Ovr code and insert the Dallas key, if set-up). LCD shows:
OPEN
Open the lock within 3 seconds.
Manager (or Override Manager): opening with time delay
Power up the keypad. Press for opening with Manager code or
press it two times for opening with Manager Ovr Code. LCD shows:
MANAGER CODE
X X X X X X
Enter Manager code and insert the Dallas key, if set-up (or enter
Manager Ovr Code and insert the Dallas key, if set-up). LCD shows the
time delay counting:
TIME DELAY
00:59
At time elapsed, the LCD shows the open window counting time. OPEN WINDOW
00:01
Press , LCD shows: ENTER CODE

IU_TechMaster_04_eng 11 of 27
User instructions
TechMaster
X X – X X X X X X
Press for opening with Manager code or press it two times for
opening with Manager Ovr code. LCD shows:
MANAGER
X X X X X X
Enter Manager code/Manager Ovr code and insert the Dallas key, if
set-up. LCD shows:
OPEN
Open the lock within 3 seconds.
Opening with dynamic codes (Dallas key option)
Power up the keypad. Insert the Dallas dynamic key in the Dallas
reader. LCD shows: DYNAMIC CODE
X X X X X X X X X
Enter the dynamic code and press . LCD shows: OPEN
Open the lock within 3 seconds.
If set by the software Dyama or DyamaWeb for dynamic codes
creation, LCD shows the closing code when the bolt re-closes. Please
refer to the user manuals IU_Dyama_XX or IU_DyamaWeb_XX for
further information.
CLOSING CODE
179
WARNING: dynamic codes must be used respecting the sequence of
activation time in which they have been created by the software
(Dyama or DyamaWeb), otherwise the last created code deletes all
the previous ones (i.e. if three codes are created and the third one is
used before using the first two ones, those first two codes are
deleted). In this case indeed LCD shows:
DYNAMIC CODE
DELETED
Opening with dynamic codes (PIN option)
Power up the keypad. Press and hold to enter the dynamic user
PIN (optional). LCD shows:
DYNAMIC USER
X X X X
Enter the dynamic user PIN. LCD shows: DYNAMIC CODE
X X X X X X X X X
Enter the dynamic code and press . LCD shows: OPEN
Open the lock within 3 seconds.
If set by the software Dyama or DyamaWeb for dynamic codes
creation, LCD shows the closing code when the bolt re-closes. Please
refer to the user manuals IU_Dyama_XX or IU_DyamaWeb_XX for
further information.
CLOSING CODE
179
WARNING: dynamic codes must be used respecting the sequence of
activation time in which they have been created by the software
(Dyama or DyamaWeb), otherwise the last created code deletes all
the previous ones (i.e. if three codes are created and the third one is
used before using the first two ones, those first two codes are
DYNAMIC CODE
DELETED

12 of 27 IU_ TechMaster_04_eng
User instructions
TechMaster
deleted). In this case indeed LCD shows:
Dual mode opening without time delay
Power up the keypad. Enter an opening code and insert the Dallas
key, if set-up. LCD shows:
2° USER CODE
X X – X X X X X X
Enter the second opening code and insert the Dallas key, if set-up.
LCD shows:
OPEN
Open the lock within 3 seconds.
Dual mode opening with time delay
Power up the keypad. Enter an opening code and insert the Dallas
key, if set-up.
LCD shows the time delay counting:
TIME DELAY
00:59
At time elapsed, the LCD shows the open window counting time. OPEN WINDOW
00:01
Press , LCD shows: ENTER CODE
X X – X X X X X X
Enter an opening code and insert the Dallas key, if set-up.
LCD shows:
2° USER CODE
X X – X X X X X X
Enter the second opening code and insert the Dallas key, if set-up.
LCD shows:
OPEN
Open the lock within 3 seconds.
Master menu
Power up the keypad. Press and hold . LCD shows:
MASTER MENU
X X X X X X X X
Enter Master code (default value 1-2-3-4-5-6-7-8).
Time & date settings
Enter the Master menu. Press until LCD shows: TIME AND DATE
SETTINGS
Press . LCD shows the current time and date. 08:00 FRI
27/01/2006
Press to change time and date. hh:mm _ _ _
GG / MM / YYYY
Enter the new time and date values and press to confirm.
DST Settings

IU_TechMaster_04_eng 13 of 27
User instructions
TechMaster
WARNING: it is recommended to enter this menu always with the
door open.
Power up the keypad. Enter the Master menu. Press until LCD
shows:
AUTOMATIC DST
Press one time and then press to select between ON and
OFF. Press again to confirm.
If the static codes have been deleted, automatic DST can be enabled by using the dynamic
user DST.
Time Lock settings
WARNING:
It is recommended to enter this menu always with the door open;
Master menu, allows to add/delete the settings for time lock/closing periods/opening
periods, only if current time and date values are included in an opening period.
Power up the keypad. Enter the Master menu. Press until LCD
shows: TIME LOCK
SETTING
Weekly time lock settings – Adding new values
Enter Time Lock menu and press . LCD shows: WEEKLY TIME LOCK
T1 SETTING
Press once or two times to set a weekly time lock T2 or T3. Then,
press .
Press . LCD shows:
ADD NEW VALUES
Press . LCD shows the current day of the week. hh:mm FRI
hh:mm
The first one is an opening time while the second one is a closing time.
Enter the new values.
Press to confirm. LCD shows the next day of the week, proposing
the same time values. Press to confirm or to select another
day without entering new time values or else enter the new time
values as previously illustrated.
At the end of the week, LCD shows: END OF LIST
EXIT AND SAVE? 
Press to save or for coming back to the first weekday.
All values entered can be saved only by pressing .
Inside Time Lock menu, opening time intervals are indicated: it means the safe can be
opened by entering a valid code, but only inside the time interval itself (ex. opening time

14 of 27 IU_ TechMaster_04_eng
User instructions
TechMaster
interval from 08.00 to 14.00 from Monday to Friday: the safe can be only opened from
08.00 to 14.00 and only in those days, it cannot be opened before 08.00 and after 14.00.
Moreover, safe cannot be opened on Saturdays and Sundays).
It is possible to schedule up to 4 time intervals per day (ex. Monday from 07.00 to 10.00,
from 12.00 to 13.00, 15.00 to 16.00 and 18.00 to 19.00).
Weekly time lock settings – Verify or delete values
Enter Time Lock menu and press . LCD shows: WEEKLY TIME LOCK
T1 SETTING
Press . LCD shows: ADD NEW VALUES
Press . LCD shows: VERIFY OR DELETE
VALUES
Press . LCD shows the values for the first day. hh:mm FRI
hh:mm
Press to scroll all the schedules list.
Press on a schedule. LCD shows: DELETE VALUES?

Press to confirm or to exit.
At the end of the list, press . LCD shows:
END OF LIST
EXIT?
Closing periods (OFF days) – Add new values
Closing periods are time intervals in which is possible to close the lock even when a time
lock is enabled.
It is possible to schedule up to 60 closing periods (they can be opening or closing periods).
Each one of them has a maximum time length of 14 days.
WARNING: during closing periods, the safe cannot be opened.
Enter Time Lock menu and press until LCD shows: WEEKLY TIME LOCK
T1 SETTING
Press . LCD shows: CLOSING PERIODS
SETTING
Press . LCD shows: ADD NEW VALUES
Press . LCD shows: GG/MM/AA hh:mm
GG/MM/AA hh:mm
The first one is an closing time while second one is an opening time.
Enter the time of start and the ending time for the closing period,
then press to confirm.
Should the year be set, the closing period is not repeated.
Should not the year be set (press ), the closing period is yearly repeated instead.

IU_TechMaster_04_eng 15 of 27
User instructions
TechMaster
Press to delete all values entered.
Repeat the steps above for each closing period.
Closing periods (OFF days) – Verify or delete values
Enter Time Lock menu and press . LCD shows: WEEKLY TIME LOCK
T1 SETTING
Press until the LCD shows: CLOSING PERIODS
SETTINGS
Press . LCD shows: ADD NEW VALUES
Press . LCD shows: VERIFY OR DELETE
VALUES
Press to check the first closing period scheduled. GG/MM/AA hh:mm
GG/MM/AA hh:mm
Press to scroll all the scheduled closing periods.
Press to delete the scheduled closing periods. DELETE VALUES?

Press to confirm or to exit.
At the end of the list, press .
END OF LIST
EXIT?
Opening periods - Add new values
Opening periods are time intervals in which is possible to open the lock even when a time
lock is enabled.
It is possible to schedule up to 60 closing periods (they can be opening or closing periods).
Each one of them has a maximum time length of 14 days.
Enter Time Lock menu and press . LCD shows: WEEKLY TIME LOCK
T1 SETTING
Press until the LCD shows: OPENING PERIODS
SETTINGS
Press . LCD shows: ADD NEW VALUES
Press . LCD shows: GG/MM/AA hh:mm
GG/MM/AA hh:mm
The first one is an opening time while the second one is a closing time.
Enter a date and time for opening and closing, then press to
confirm.
Should the year be set, the opening period is not repeated.
Should not the year be set (press ), the opening period is yearly repeated instead.
Press to delete the values entered.

16 of 27 IU_ TechMaster_04_eng
User instructions
TechMaster
Opening periods - Verify or delete values
Enter Time Lock menu and press . LCD shows: WEEKLY TIME LOCK
T1 SETTING
Press until the LCD shows: OPENING PERIODS
SETTINGS
Press . LCD shows: ADD NEW VALUES
Press . LCD shows: VERIFY OR DELETE
VALUES
Press . LCD shows the first opening period. GG/MM/AA hh:mm
GG/MM/AA hh:mm
Press to scroll all the scheduled opening periods.
Press to delete. LCD shows: DELETE VALUES?

Press to confirm or to exit.
At the end of the list, press .
END OF LIST
EXIT?
PC connection
Use this function to enable the connection between the keypad and PC.
Power up the keypad. Enter the Master menu. Press until LCD
shows:
PC LINK
Press to start the connection with PC.
PC LINK
…
Press to stop the connection with PC.
If the static codes have been deleted, PC connection can be enabled by using the dynamic
user AUDIT.
Manager Management
Power up the keypad. Enter Master menu. Press until the LCD
shows: MANAGER
MANAGEMENT
Press . LCD shows: 1 MANAGER 
2 AMMINISTRAT.
“” installed, “_” deleted, “X” disabled.
Select Manager by entering its reference number and press .
If the Manager is not installed, LCD shows:
01
INSTALL?

IU_TechMaster_04_eng 17 of 27
User instructions
TechMaster
Press to confirm. Then enter the new Manager code and confirm
it. LCD shows:
OPERATION DONE
If the Manager is already installed, press for
disabling/deleting/installing it. Then press to confirm.
Dynamic codes – Enabling/Disabling
WARNING: it is recommended to always perform this operation with door open, to
enable/disable the dynamic codes. Later, dynamic codes can be activated through the red
Dallas key 1971 previously programmed with the software Dyama or DyamaWeb.
Power up the keypad. Enter Master menu. Press until the LCD
shows:
DYNAMIC CODES
Press . LCD shows: DYNAMIC CODES
ENABLED/DISABLED
Press . The LCD shows: DYNAMIC CODES
ENABLE/DISABLE?
Press to confirm. LCD shows: OPERATION DONE
Dynamic codes activation with static codes deleting
WARNING: with this operation, it is possible to delete the static codes for all users and
Manager. Moreover, in depending on the configuration selected, Master static code may be
deleted as well.
Insert the red Dallas key N1971 in the reader. LCD shows: DYNAMIC CODE
XXX XXX XXX
Enter the activation code generated by the software Dyama or
DyamaWeb and press . LCD shows:
DELETE ALL THE
STATIC CODES?
Press . LCD shows: OPERATION IN
PROGRESS…
Once terminated, LCD shows: DYNAMIC CODES
ACTIVE
To re-install the static codes (only for Master and Manager) use the dynamic user
REMOVAL. Later, it is possible to re-install all the other users from the menu Users
management.
Manager menu
Press and then press . LCD shows: MANAGER MENU
X X X X X X
Power up the keypad. Enter Manager code (default code 1-2-3-4-5-6).

18 of 27 IU_ TechMaster_04_eng
User instructions
TechMaster
Users Management
Power up the keypad. Enter Manager menu and press until LCD
shows:
USERS MANAGEMENT
0 1 – X X X X X X
Press and press to scroll users list or enter user ID.
02 03 04 05 06
 x _ _ 
“” user installed, “_” user deleted, “X” user disabled.
Override users 50 ÷ 59 can only be installed when the lock is open.
Press . If the user is not installed LCD shows:
02
INSTALL?
“ ” Dallas key, “ ” code, “+” dual mode, “TL” time lock
Press to confirm or to exit or for switching to the next user.
Enter the new user code and confirm it.
If the selected user is already installed, press to choose
whether to disable it, to delete it or for leaving and selecting
another user. Press to confirm the choice.
Time delay
Power up the keypad. Enter Manager menu and press until LCD
shows:
T. DELAY AND
O. WINDOW
Press to confirm. LCD shows the current values for time delay
and open window.
TIME DELAY 00
OPEN WINDOW 01
Press to exit or to set new values. TIME DELAY mm
OPEN WINDOW mm
Enter the new values and press to confirm. LCD shows: VALUES UPDATED
Time delay can be set in between 0 and 99 minutes, the open window in between 1 and 19
minutes instead.
To set a time delay shorter than the one currently present, lock must be open.
Variable Time Delay
WARNING: lock must always be open to set a variable time delay
Power up the keypad. Enter Manager menu and press until LCD
shows:
VARIABLE TIME
DELAY
Variable Time Delay – Adding new values
Enter Variable Time Delay menu and press . LCD shows: ADD NEW VALUES
Press . LCD shows the current day of the week.
hh:mm VEN

IU_TechMaster_04_eng 19 of 27
User instructions
TechMaster
hh:mm :mm
Enter values for starting time and ending time in which Variable
Time Delay must be active and then enter the values of Variable
Time Delay.
Press to confirm. LCD shows the next day of the week,
proposing the same time values. Press to confirm or to
select another day without entering new time values or else enter
the new time values as previously illustrated.
At the end of the week, LCD shows: END OF LIST EXIT
AND SAVE? 
Press to save the values or for coming back to the first
weekday.
After saving the values, LCD shows:
Press to set new values (max. 4)
ADD NEW VALUES
Variable Time Delay – Verify or delete values
Enter Variable Time Delay menu and press until LCD shows: VERIFY OR DELETE
VALUES
Press . LCD shows the values for the first day.
08:00 DOM
10:00 : 01
Press to scroll all the schedules list.
Press on a schedule. LCD shows: DELETE VALUES?

Press to confirm the deletion or to exit.
At the end of the list, press . LCD shows: END OF LIST EXIT
AND SAVE? 
PC connection
Use this function to enable the connection between the keypad and PC.
Power up the keypad. Enter the Manager menu. Press until LCD
shows:
PC LINK
Press to start the connection with PC.
PC LINK
…
Press to stop the connection with PC.
If the static codes have been deleted, PC connection can be enabled by using the dynamic
user AUDIT.

20 of 27 IU_ TechMaster_04_eng
User instructions
TechMaster
Override Manager menu
Power up the keypad.
Press , then press until LCD shows: OVR MANAGER MENU
X X X X X X
Enter OVR Manager code (default code 6-5-4-3-2-1).
Override Users management
WARNING: to install new override users, lock must be open.
Power up the keypad. Enter Override Manager menu and press
until LCD shows:
OVR USERS
MANAGEMENT
Press and press to scroll users list or enter user ID.
50 51 52 53 54
 x _ _ 
“” user installed, “_” user deleted, “X” user disabled.
Press . If the user is not installed LCD shows: 52
INSTALL?
“ ” Dallas key, “ ” code, “+” dual mode, “TL” time lock
Press to confirm or to exit or for switching to the next user.
Enter the new user code and confirm it.
If the selected user is already installed, press to choose whether to disable it, to delete
it or for leaving and selecting another user. Press to confirm the choice.
Code changing
WARNING: it is recommended to always perform this operation with door open.
Power up the keypad.
Press , then press until LCD shows: CHANGE CODE
Change code for standard and override Users
Power up the keypad. Access Change Code menu and press . LCD
shows:
CHANGE USER
CODE
Press to confirm. LCD shows:
ENTER OLD CODE
X X – X X X X X X
Enter the old code e insert the Dallas key (if set up).
Enter the new code e insert the Dallas key (if set up).
ENTER NEW CODE
X X X X X X
Confirm the new code e insert the Dallas key (if set up). CONFIRM CODE
X X X X X X
