TECO E510 Inverter
Quick Start Guide
1) Ensure that the Inverter & the motor have the correct
KW power and voltage ratings.
Motor full load amps must not exceed the Inverter rating.
2) Ensure that the supply & Motor cables are connected
correctly prior to power up.
3) For single phase supply, use L1(L) & L3(N) on units which
have 3 supply terminals.
4) Connect motor cable to terminals T1, T2 &T3.
(Swap two leads if motor runs in reverse direction).
5) Connect supply Earth and the motor Earth to the drive Earth
terminal.
Note:-
I ) For detailed installation
and wiring refer to the
Instruction manual.
This guide is to assist you in installing and running the inverter and verify that it is
functioning correctly for it’s main and basic features.
For detailed information and if there are any doubts please refer to the instruction manual.
Step 1
Supply & Motor connection

Downloaded from https://acdriveshop.co.uk
Page 2 of 9 08/08/14
Apply power to the drive, the display will briefly show the supply voltage
220V followed by flashing.
This is the default (factory set) frequency.
If the unit has been used previously then it will show the last frequency
programmed.
Note:- 50 HZ is set as maximum default frequency. This Provides motor full speed.
Step 2
Apply power to the drive
5.00
Step 3
Test run from keypad
Press RUN KEY to run.
The frequency will ramp up to 5.0 Hz or the user pre-set frequency and
according to the default acceleration ramp time.
Press STOP key to stop.
The frequency will ramp down to zero according to the default decel ramp
time.
Step 4
To alter frequency from keypad. (Default setting).
Use the Arrow keys </RESET and READ/ENTER
To alter the digits to the required frequency.
eg. 50.0 HZ then use RUN and STOP keys to start / stop.

Downloaded from https://acdriveshop.co.uk
Page 3 of 9 08/08/14
Remote speed reference and Remote run
1) Ensure that you have carried out installation & wiring requirements as per
previous page before you proceed.
2) For analogue signals 2-10V / 0-10V dc or 0-20mA / 4-20 mA.dc. Use
either terminal AI1or AI2.
Check & set Jumper bars JP2&JP3 as required to position V (voltage)
or I ( current) as below:
V (Voltage) I (Current)
For remote potentiometer OR remote 2-10V / 0-10V dc signal use the
following terminals:
Terminal 10V. The supply provided for use with the potentiometer.
Terminal AI1 or AI2. Potentiometer wiper connection.
Terminal AGND. 0Vdc.
For 0-20mA / 4-20mA signals use the following terminals:
Terminal AI1 or AI2.
Terminal AGND. 0Vdc.
Step 1
Remote mode wiring. Speed reference .
Step 2
Remote mode Run
1) Remote Run signal can be either a PNP or NPN input type.
Set PNP or NPN selection as required by Jumper JP1 as shown below:
Note: PNP ( positive voltage switching) selection is recommended for use in EU.
PNP NPN
2) Connect remote start switch if required according to diagram in the
instruction manual.
Terminals 24V & S1 (Forward run)
Terminals 24V & S2 (Reverse run)
24V is the common terminal for PNP type inverters.
COM (0Vdc) terminal is common for the NPN type inverters.

Downloaded from https://acdriveshop.co.uk
Page 4 of 9 08/08/14
How to alter parameters
Step 3
Check/ verify and alter parameters
Check / verify and alter parameters for remote start & remote frequency as
necessary before you proceed. Parameters 00-02 & 00-05
See quick start parameter list & How to alter parameters.
Step 4
RUN using remote speed reference. (Potentiometer 0-10vdc or 4 -
20ma )
1) To run. Activate the remote run switch connected to terminals
S1 ( FWD) or S2 ( REV) as required. Parameter 00-02 = 1
The frequency will ramp up to the frequency set by one of the
following selections according to the set acceleration ramp time:-
Potentiometer on the keypad Parameter 00-05 = 1
External potentiometer. Parameter 00-05 = 2(AI1) or 3(AI2)
External Analogue input Parameter 00-05 = 2(AI1) or 3(AI2)
2) To Stop. De-activate the remote run switch.
The frequency will ramp down to zero and according to the decel ramp
time.

Downloaded from https://acdriveshop.co.uk
Page 5 of 9 08/08/14
How to alter parameters using the keypad
1) To alter parameters:- Press the DSP/FUN key,
until the first parameter 00-00 is displayed.
2) Then use the arrow keys </RESET to select the parameter
required then
Press READ/ENTER key to read the preset value.
3) Use the and </RESET keys to alter the setting of the parameters
as per basic quick start parameter list.
Note:- For full parameter list refer to the instruction manual.
4) To save each parameter change, press READ/ENTER key then
the word END will be displayed.
5) Use </RESET key to select the next parameter to alter and
follow steps 2 to 4 until all changes are complete.
6) Pressing the DSP/FUN key repeatedly will alternate the display
between the preset frequency ( flashing display) and the last parameter
accessed or other selectable displays 0 to 7 when selected by parameter
12-00 according to the table below.
【0】:Disable display 【1】:Output Current 【8】:Count Status
【2】:Output Voltage 【3】:DC voltage
【4】:Temperature 【5】:PID feedback
【6】:AI1 【7】:AI2

Downloaded from https://acdriveshop.co.uk
Page 6 of 9 08/08/14
Basic Quick Start Parameter List
Parameter
Default
Range
Note
00-00
0
0-1
0: V/F control mode
1: Vector mode (SLV)
00-14
10.0
0.1~3600.0
Acceleration time in Secs
00-15
10.0
0.1~3600.0
Deceleration time in Secs
00-04
0
0-2
0: Forward/Stop-Reverse/Stop
1: Run/Stop-Reverse/Forward
2: 3-Wire Control Mode-Run/Stop
00-12
50/60Hz
0.01~650.00
Max frequency limit.
00-13
0.0
0.00~649.00
Min frequency limit
00-02
0
0-3
Start mode:-
0: Keypad
1: Remote
2: Communication
3: PLC
00-05
0
0-7
Main frequency source:-
0: Keypad
1: Potentiometer on keypad
2: External AI1 analogue signal
3: External AI2 analogue signal
4: External up/down frequency control
5: Control by Communication method
6: PID output
7: Pulse input
07-09
0
0-1
Stop method:-
0: Decel to stop
1: Coast to stop
02-01
**A
**A
Motor overload protection according to motor
name plate
13-08
0000
Set to factory setting.
1150: 50HZ system
1160: 60HZ system
1112: Reset PLC
Note:- For Full Parameter List see the Instruction manual

Downloaded from https://acdriveshop.co.uk
Page 7 of 9 08/08/14
Control Modes & Auto Tune
E510 provides two control modes
Select the relevant control mode for the application, using parameter 00-00 Control mode.
Default control mode is V/f.
V/f can be used for most applications specifically multi-motor
or applications where auto tune is not successful
or when a customized v/f pattern may be required.
Several V/f patterns are available selectable by parameter 01-00.
Select the appropriate V/f pattern based on the application load type and the motor base
frequency of 50 or 60 Hz.
For selections of the V/f patterns . Refer to the instruction manual.
For Vector modes SLV is used for obtaining best performance from a motor.
V/f Mode Parameters:-
Parameter
Default
Range
Note
01-00
0/9
0-18
0= General Purpose. 50 Hz. System
9= General Purpose. 60Hz. System
For full list of preset patterns set by 01-00,
refer to the manual.
18= Customized V/f.
Set parameters 01-01 to 01-09.
SLV ( vector) mode set parameters in parameter Group 2 .
1) Set the motor parameters highlighted below in Group 2 from motor name plate data.
2) Ensure that the motor is connected correctly then,
3) Enable auto tune function by setting parameter 02-14= 1 ( auto tune Enable).
Auto tune type is Static. No rotation of the motor.
After Auto tune is completed successfully ( no errors) the motor stator & resistance values will
be stored automatically in parameters 02-15 & 02-16.
Group 2 Parameters. Motor data & auto tune
No.
Description
Range
Factory
Setting
Unit
02-00
Motor No Load Current
----
-
Amps(AC)
02-01
Motor Rated Current (OL1)
----
-
A
02-02
Motor rated Slip
Compensation
----
0.0
%
02-03
Motor rated speed
----
-
Rpm
02-04
Motor rated voltage
200V: 170.0~264.0
400V: 323.0~528.0
220.0/440.0
V
02-05
Motor rated power
----
-
KW
02-06
Motor rated frequency
0~650.0
50.0/60.0
Hz
02-07
Motor number of poles.
2 ~16
4
-
02-14
Auto Tune
0: Disable
0
1: Start Auto tune function.
02-15
Stator resistance gain
----
02-16
Rotor resistance gain
----

Downloaded from https://acdriveshop.co.uk
Page 8 of 9 08/08/14
Standard wiring. Single phase
Frequency indicator device
or PID input
Frequency
Indicator
+
T1
10V
AI1
AI2
AGND
0 ~10V
M
0~20mA
-
Inverter
output
Induction
Motor
S3
S4
S5
S6
S2
FWD
(Run/Stop) S1
R2B
250 VAC/1A
(30VDC/1A)
Relay
Output
Relay
Output
RS485
CON2
AO
AGND
+
-0~10VDC
NPN
PNP
AI1 AI2
AV1AV2
J
P
1
Ground
REV (Run/Stop)
250 VAC/1A
(30VDC/1A)
R2A
R1A
R1B
R1C
T2
T3
J
P
2
J
P
3
PBR
Braking resistor
(Option)
+ 24V(PNP)
COM (NPN)
Output disable SG
SF
AO
Speed Control
Multifunction Input Terminals
E
EE
PP
Pin 1 to Pin 8
Reset
Indicates twisted-pair shield wire
P
Shows control circuit
Shows main circuit
Indicates shield wire
*1: JP1:NPN/PNP selection, JP2:AI1 0~10V/0~20mA selection, JP3:AI2 0~10V/0~20mA selection
*1
1:Data+
2:Data-
3:Data+
4:RXD0
5:TXD0
6:Data-
7:5V
8:GND
AC Power
source
L1(L)
Fuse
Main
Switch
Power
input
L3(N)
E
Model:
200V: E510-2P5-H1F (N4S) / E510-201-H1F (N4S) / E510-202-H1F (N4S) / E510-203-H1F (N4S)

Downloaded from https://acdriveshop.co.uk
Page 9 of 9 08/08/14
Three phase
Frequency indicator device
or PID input
Frequency
Indicator
+
T1
10V
AI1
AI2
AGND
0 ~10V
M
0~20mA
-
Inverter
output
Induction
Motor
S3
S4
S5
S6
S2
FWD
(Run/Stop) S1
R2B
250 VAC/1A
(30VDC/1A)
Relay
Output
Relay
Output
RS485
CON2
AO
AGND
+
-0~10VDC
NPN
PNP
AI1 AI2
AV1AV2
J
P
1
Ground
REV (Run/Stop)
250 VAC/1A
(30VDC/1A)
R2A
R1A
R1B
R1C
T2
T3
J
P
2
J
P
3
PBR
Braking resistor
(Option)
Output Disable SG
SF
AO
Speed Control
Multifunction Input Terminals
E
EE
PP
Pin 1 to Pin 8
Reset
*1
1:Data+
2:Data-
3:Data+
4:RXD0
5:TXD0
6:Data-
7:5V
8:GND
+ 24V(PNP)
COM (NPN)
Indicates twisted-pair shield wire
P
Shows control circuit
Shows main circuit
Indicates shield wire
*1: JP1:NPN/PNP selection, JP2:AI1 0~10V/0~20mA selection, JP3:AI2 0~10V/0~20mA selection
AC Power
source
L1
Fuse
Main
Switch
Power
input
L3
L2
E
Model:
200V: E510-202-H3 (N4) / E510-205-H3 (N4) / E510-208-H3 (N4) / E510-210-H3 (N4) / E510-215-H3 (N4) /
E510-220-H3 (N4)
400V: E510-401-H3F (N4S) / E510-402-H3F (N4S) / E510-403-H3F (N4S) / E510-405-H3F (N4S) / E510-
408-H3F (N4S) / E510-410-H3F (N4S) / E510-415-H3F (N4S) / E510-420-H3(F) (N4) / E510-425-
H3(F) (N4)
