TECO e510 series User manual

Page 1 of 8 12/06/13
TECO E510 Inverter
Quick Start Guide
1) Ensure that the Inverter & the motor have the correct
KW power and voltage ratings.
Motor full load amps must not exceed the Inverter rating.
2) Ensure that the supply & Motor cables are connected
Correctly prior to power up.
3) For single phase supply, use L1& L3 ( N) on units which
have 3 supply terminals.
On units with two supply terminals L1&L2, connect live to L1
and Neutral to L2.
4) Connect motor cable to terminals T1,T2 &T3.
(Swap two leads If motor runs in reveres direction).
5) Connect supply Earth and the motor Earth to the drive Earth
terminal.
Note:-
I ) For detailed installation
and wiring refer to the
Instruction manual.
This guide is to assist you in installing and running the inverter and verify that it is
functioning correctly for it’s main and basic features.
For detailed information and if there are any doubts please refer to the instruction manual.
Step 1 Supply & Motor connection

Page 2 of 8 12/06/13
Apply power to the drive, the display will briefly show the supply voltage
220V followed by flashing.
This is the default ( factory set) frequency.
If the unit has been used previously then it will show the last frequency
programmed.
Step 2 Apply power to the drive
05.0
Step 3 Test run from keypad
Press RUN KEY to run.
The frequency will ram up to 5.0 Hz or the user pre-set frequency and
according to the default acceleration ramp time.
Press STOP key to stop.
The frequency will ramp down to zero according to the default decel ramp
time.
Step 4 To alter frequency from keypad. (Default setting).
Use the Arrow keys and READ/ENTER
To alter the digits to the required frequency.
eg. 50.0 HZ then use RUN and STOP keys to start/ stop.

Page 3 of 8 12/06/13
Remote speed reference and Remote run
1) Ensure that you have carried out installation & wiring requirements as
per step1 quick start guide on previous page before you proceed.
2) For analogue signal type. 2-10V or 0-10V dc. Use the terminal AVI.
For analogue input type 0-20mA or 4-20 mA.dc. Use the terminal ACI.
.Connect remote potentiometer OR remote 0-10 vdc signal as required.
to terminals AVI.
Terminal 10Vdc is the supply provided for use with the potentiometer.
Terminal AVI for potentiometer wiper connection.
Terminal GND is 0Vdc.
3) Connect remote start switch if required according to diagram in the
instruction manual.
Use terminals +24Vdc & S1 (Forward run).
Use terminals +24Vdc & S2 (Reverse run)
+24Vdc is the common terminal for PNP type inverters.
COM (0Vdc) terminal is common for the NPN type inverters.
Step 1 Remote mode wiring. Speed reference and Run signals.
Step 2 Remote mode Run
1) Power up.
Display will read the frequency from one of the following according to the
Connection made to AVI terminal. Set parameter 00-05 =00-02
a) Remote external potentiometer
b) Remote 0-10VDC analog signal.
Step 3 Check/ verify and alter parameters
Check / verify and alter parameters for remote start & remote frequency
as necessary before you proceed. Parameters 00-02 & 00=05
See quick start parameter list & How to alter parameters.

Page 4 of 8 12/06/13
How to alter parameters
Step 4
RUN using remote speed reference.(Potentiometer,0-10vdc or 4-
20ma
)
1) To run. Activate the remote run switch connected to terminals
S1 ( FWD) or S2 ( REV) as required,. Parameter 00-02=00-01
The frequency will ram up to the frequency set by one of the
following:-
Speed potentiometer on the keypad . Parameter 00-005=1
External potentiometer. Parameter 00-05 = 2
Analog signal (0-10v dc or 4-20ma) Parameter 00-05 = 3 or 4
and according to the set acceleration ramp time.
2) To Stop. De-activate the remote run switch.
The frequency will ramp down to zero and according to decel ramp
time.
How to alter parameters using the keypad
1) To alter parameters:- Press the DISP/FUN key,
until the first parameter 00-00 is displayed.
2) Then use the arrow keys to select the parameter required then
Press READ / ENTER key to read the preset value.
3) Use the and < / RESET keys to alter the setting of the
parameters as per basic quick start parameter list.
Note:- For full parameter list refer to the instruction manual.
4) To save each parameter change, press READ / ENTER key then
the word END will be displayed.
5) Use key to select the next parameter to alter and
follow steps 2 to 4 until all changes are complete.
6) Pressing the DISP/FUN key repeatedly will alternate the display
between the preset frequency ( flashing display) and the last parameter
accessed or other selectable displays 0 to 7 when selected by parameter
12-00 according to the table below.
【0】:Disable display 【1】:output Current
【2】:output Voltage 【3】:DC voltage
【4】:Temperature 【5】:PID feedback
【6】:AVI 【7】:ACID
【8】: Count

Page 5 of 8 12/06/13
Basic Quick Start Parameter List
Parameter Default Range Note
00-00 0 0-1 0: V/F control mode
1: Vector mode (SLV)
00-14 10.0 0.1~3600.0 Acceleration time in Secs
00-15 10.0 0.1~3600.0 Deceleration time in Secs
00-04 000 0-2 0: Forward/Stop-Reverse/Stop
1: Run/Stop-Reverse/Forward
2: 3-Wire Control Mode-Run/Stop
00-12 50/60Hz
0.01~650.00
Max frequency limit.
00-13 0.0 0.00~649.00
Min frequency limit
00-02 00-00 0-2 Start mode:-
Keypad = 00-00
Remote = 00=01
Communication = 00-02
00=05 00-00 0-6
00-00 = keypad
00-01= Potentiometer on keypad
00-02= External AVI analogue signal
00-03= External ACI analogue signal
00-04 =External up/down frequency control
00-05= control by Communication method
00-06=PID output
07-09 000 0-1 Stop method:- 00-00 = Decel to stop
00-01= Coast to stop
02-01 **A **A Motor overload protection
13-08 000 Set to factory setting.
1150 = 50 HZ system.
1160 = 60HZ system
Note:- For Full Parameter List see the Instruction manual

Page 6 of 8 12/06/13
Control Modes & Auto Tune
E510 provides two control modes
Select the relevant control mode for the application, using parameter 00-00 Control mode.
Default control mode is V/f.
V/f can be used for most applications specifically multi-motor
or applications where auto tune is not successful
or when a customized v/f pattern may be required.
Several V/f patterns are available selectable by parameter 01-00.
Select the appropriate V/f pattern based on the application load type and the motor base
frequency of 50 or 60 Hz.
For selections of the V/f patterns . Refer to the instruction manual.
For Vector modes SLV is used for obtaining best performance from a motor.
V/f Mode Parameters:-
Parameter Default Range Note
01-00 F 0-18 0= General Purpose. 50 Hz. System
9= General Purpose . 60Hz. System
For full list of preset patterns set by 01-00,
refer to the manual.
18= Customized V/f.
Set parameters 01-01 to 01-09.
SLV ( vector) mode set parameters in parameter Group 2 .
1) Set the motor parameters in Group 2 parameters from motor name plate data.
2) Ensure that the motor is connected correctly then,
3) Enable auto tune function by setting parameter 02-14= 1 ( auto tune Enable).
Auto tune type is Static. No rotation of the motor.
After Auto tune is completed successfully ( no errors) the motor stator & resistance values will
be stored automatically in parameters 02-15&02-16.
Group 2 Parameters. Motor data & auto tune
No. Description Range Factory
Setting Unit Note
02-00 Motor No Load Current ---- Amps(AC) *4
02-01 Motor Rated Current (OL1) ---- A *4
02-02 Motor rated Slip
Compensation 0.0 ~ 100.0 0.0 % *1
02-03 Motor rated speed ---- Rpm *4
02-04 Motor rated voltage ----
02-05 Motor rated power ----
02-06 Motor rated frequency ----
02-07 Motor number of poles. 2 ~16 4
02-14 Auto Tune 0: Disable 0
1: Start Auto tune function.
02-15 Stator resistance gain ----
02-16 Rotor resistance gain ----

Page 7 of 8 12/06/13
Standard Wiring. Single Phase.
Frequency indicator device
or PID input
Frequency
Indicator
AC
Power
source
Inverter
output
rela
y
Burst absorber
Inductio
n Motor
FWD
(Run/Stop)
NPN
PNP
AI1 AI2
AV1AV2
J
P
1
REV (Run/Stop)
J
P
2
J
P
3
Molded-case
circuit breaker
Molded-case circuit
breaker
Magneti
c
contacto
r
Magneti
c
contacto
r
Safety Function Input
Common point for PNP input
Speed Control
Multifunction Input Terminals
E
EE
PP
Reset
Indicates twisted-pair shield
wire
P
Shows control
circuit
Shows main circuit
Indicates shield wire
*1: Independent protection circuit is suggested to be installed for the purpose of protecting the circuit.
*2: The jumper wire between SF and SG is removed, the inverter stops output.
*3: JP1:NPN/PNP select, JP2:AI1 0~10V/0~20mA select, JP3:AI2 0~10V/0~20mA select
1:Data+
2:Data-
3:Data+
4:Reserved
5:Reserved
6:Data-
7:5V
8:GND
Model:
200V: E510-2P5-H1F/ E510-201-H1F/ E510-202-H1F/
E510-203-H1F.

Page 8 of 8 12/06/13
Single /Three Phase:
Model: 200V: E510-2P5-H/ E510-201-H/ E510-202-H/
E510-203-H
