Teknion Navigate Single-Sided Frame HNBFNZ User manual

height-adjustable bench - Navigate
INDEX
By Section
Product Name
Product
Code
Guide
No.
Last
Updated
Product Name
Product
Code
Guide
No.
Last
Updated
Product Name
Product
Code
Guide
No.
Last
Updated
INSTALLATION SUPPORT DOCUMENTS Navigate End Cover - Metal HNBCCEMN 223c
May 2020
Navigate Base Feed HNBEBF 321c Sep 2019
Typical Installation Sequence Sep 2018 Navigate Mid Cover - Metal HNBCCMMN Navigate Base Feed Cover HNBEBC
NAVIGATE Navigate End Screen Cover - Metal HNBCCSMN 223d
May 2020
Navigate Chicago Base Feed HNBEBFCH
FRAMES AND WORKSURFACE Navigate End of Run Screen - Fabric HNBTEF Navigate Split Base Feed HNBEBFS
Navigate Frame HNBFNA 121 Jan 2020 Navigate End Screen Gable - Metal HNBCGSMN 223e Sep 2019 Navigate Ceiling Feed HNBECF 322a Sep 2019
Navigate Frame Link HNBFNF Navigate End of Run Screen - Fabric HNBTEF Navigate Chicago Ceiling Feed HNBECFCH
Navigate Rectangular Worksurface HNBWRN Navigate Single-Sided Corridor Screen - HNBLSF 224 Sep 2019 Navigate Power Pole - End HNBEPP
Navigate Systems Link HNBFNS 122 May 2019 Fabric Navigate Ceiling Feed HNBECF 322b Sep 2019
Navigate 120 Frame HNBFNT 123
May 2020
Navigate Single-Sided Corridor Screen - HNBLSS Navigate Chicago Ceiling Feed HNBECFCH
Navigate 120 Worksurface HNBWTN Solid Navigate Power Pole - Mid HNBEPP
Navigate Wire Channel HNBFCN Navigate 120 Mid Cover HNBCCMMT 224a May 2019 Navigate Power Pole(Single Sided Bench) HNBEPP
Navigate Power Module HNBEPM Navigate Single-Sided End Cover - Metal HNBCCEMS 225a Sep 2019 Navigate Power Conservation System HNBEPC 323 May 2019
Navigate E-Chain Vertical Cable Manager
HNBEEE Navigate Single-Sided Mid Cover - Metal Navigate Single-Sided Chicago Power HNBEPSCH 324 Sep 2019
Navigate Power Pole HNBEPP Navigate Single-Sided End Screen HNBCCSMS 225b Sep 2019 Module
Navigate 120 Mid Gable HNBCGMMT Cover - Metal Center Electrical Grommet HNBECEG 325 Sep 2019
Navigate Ceiling Feed HNBECF Navigate Single-Sided End of Run HNBTSF
Navigate Single-Sided Frame HNBFNZ 124 Jan 2020 Screen - Fabric
Navigate Single-Sided Rectangular HNBWES Navigate Single-Sided End Screen HNBCGSMS 225c Sep 2019
Extended Worksurface Gable - Metal
Navigate Single-Sided Rectangular HNBWRS Navigate Single-Sided End of Run HNBTSS
Worksurface Screen - Solid
SCREENS AND GABLES Navigate Single-Sided End Gable - Metal
HNBCGEMS 225d Sep 2019
Navigate Desk Edge Screen - Glass HNBCDG 221a May 2019 Navigate Single-Sided Mid Gable - Metal HNBCGMMS
Navigate Desk Edge Screen - Solid HNBCDS 221b May 2019 Navigate Single-Sided End Gable - Solid HNBCGESS 225e Sep 2019
Navigate Desk Edge Screen - Fabric HNBCDF 221c May 2019 Navigate Single-Sided Mid Gable - Solid HNBCGMSS
Navigate Fixed Center Screen - Glass HNBCFG 222a Sep 2019 Navigate Single-Sided Transition Mid HNBCGMMR 225f Sep 2019
Navigate Fixed Center Screen - Solid HNBCFS 222b Sep 2019 Gable - Metal
Navigate Fixed Center Screen - Fabric HNBCFF 222c Sep 2019 Navigate Single-Sided Transition Mid HNBCGMSR 225g Sep 2019
Navigate Cable Channel HNBFCN 223a Sep 2019 Gable - Solid
Navigate End Gable - Metal HNBCGEMN ELECTRICS
Navigate Mid Gable - Metal HNBCGMMN Navigate Power Harness HNBEPH 321a Sep 2019
Navigate Cable Channel HNBFCN 223b Sep 2019 Navigate Chicago Power Module HNBEPMCH
Navigate Mid Gable - Solid HNBCGMSN Navigate Power Module HNBEPM
Navigate End Gable - Solid HNBCGESN Navigate Receptacle Outlet HNBERO
Navigate End Cover - Metal HNBCCEMN 223c May 2019 Navigate I-Connector HNBEIC
Navigate Mid Cover - Metal HNBCCMMN Navigate Chicago Power Module HNBEPMCH 321b Sep 2019
Navigate End Screen Cover - Metal HNBCCSMN 223d Aug 2019 Navigate Single-Sided Chicago Power HNBEPSCH
Navigate End of Run Screen - Fabric HNBTEF Module
*Click on the desired Installation Guide to jump to the Guide
page.
January 2020 PAGE 1 OF 1

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Rev.
Page: 1 of 19
HABN_121
1.6
1.5
1.1
1.2
1.4
1.7
6
NOTE: Refer to COM_151b for Plastic Tray Cable Management
NOTE: Refer to COM_151a for Cable Organizer installation
Navigate Single-Sided Frame (HNBFNZ), Navigate Single-Sided Rectangular Extended Worksurface (HNBWES)

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 2 of 19
HABN_121
ITEM
NO.
PREVIEW DESCRIPTION PART NUMBER QTY.
1. NAVIGATE STANDARD RANGE ELECTRIC FRAME (HNBFNA)
1.1
LEG ASSY, STD RANGE
ELEC, NAVIGATE
ELECTRIC HAB
N09-8583L 2
1.2
LEG ASSY, STD RANGE
ELEC, NAVIGATE
ELECTRIC HAB
N09-8583R 2
1.3
NAVIGATE CROSS
BEAM
A16-6481\76 2
1.4
(400114-X) STRETCHER
ASSEMBLY, HAB
N09-5870\21 2
ITEM
NO.
PREVIEW DESCRIPTION PART NUMBER QTY.
1.5
NAVIGATE STRUT ALU
CAST 23
A25-0630\23 4
1.6
NAVIGATE STRUT
COVER
A25-0631 4
1.7 Contol Box Cover B02-0739 2
1.8
Navigate Programed P-
CBD6SP00020A-109
Control Box
N09-8185YA7S 2
Part & Product Identification

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 3 of 19
HABN_121
OR
OR
ITEM
NO.
PREVIEW DESCRIPTION PART NUMBER QTY.
2. NAVIGATE SINGLE SIDED - HARDWARE KIT (X05-0498) x2
2.1
SCRW 1/4-20X5/8
ZNC PN QD
MCHN (690150)
E01-0992 12
2.2
M6x1, 14mm HEX
DRIVE, FLAT
HEAD SCREW,
ZINK FINISH
E01-1249 16
2.3
MACHINE SCREW,
5/16-18 X 3/4
BUTTON HEAD
SOCKET SCREW
(690151)
E01-1035 4
2.4
M5 X 0.8 -10, FLAT
HEAD CAP SCREW
(680214)
E01-0989 4
2.5
(550105) 3/16”
WIRE CLAMP, YH
ELECTRIC TABLE
B02-0598 4
2.6
(690247) #10 PAN
QUAD SCRW, 2 IN
L
E01-1009 2
2.7
(690123-XM) FLAT
QUAD WD. SCREW
6 X 5/8 TYP A
ZINC
E04-0090 9
2.8
(550092) CABLE
CLAMP 3/8
NYLON 3366 BLK
B02-0558 5
ITEM
NO.
PREVIEW DESCRIPTION PART NUMBER QTY.
2.9
(P-2184)
GROMMET
BUSHING,
LIVELLO HEYCO
P/N: P-2184SP
B02-0557 2
2.10
(P-914759) LINAK
MEMORY 90 DEG.
MOUTING BRKT
A16-3970 1
2.11
(720025) WD
SCREW PAN
QUAD #8x5/8"
BLACK OXIDE
E04-0091 2
2.12
#8 X 1 1/4 WOOD
SCREW, PAN
HEAD, QUADREX
DRIVE, ZINC
E04-0074 2
3
INTEGRATED
POWER BAR FOR
NAVIGATE TABLE
N09-8157
1
NAVIGATE
INTEGRATED
POWER BOX
WITH IEC
OUTLET
N09-8737
Power Bar Hole
Cover
B02-0736 1
Part & Product Identification

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 4 of 19
HABN_121
ITEM
NO.
PREVIEW DESCRIPTION PART NUMBER QTY.
4
MOTOR CABLE PVC
FREE, 500MM
N09-8402\05 2
MOTOR CABLE PVC
FREE, 1000MM
N09-8402/10 2
5
NAVIGATE DIGITAL
SWITCH
N09-8183
2
NAVIGATE SIMPLE
SWITCH
N09-8192
Display Switch with
Up/Down Memory
(55DPF1C00012016)
N09-5600
ITEM
NO.
PREVIEW DESCRIPTION PART NUMBER QTY.
6
NAVIGATE
RECTANGULAR
WORKSURFACE,
HEIGHT-ADJUSTABLE
BENCH
HNBWRN2370X_
NN
2
7. NAVIGATE FRAME LINK, HEIGHT-ADJUSTABLE BENCH (HNBFNF)
7.1
(400151) FRAME LINK
WELDMENT,
LIVELLO HAB
N09-5913 2
7.2
(690037) 1/4-20X3/4
RND TRUSS QUAD
SCREW
E01-1010 8
Part & Product Identification

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 5 of 19
HABN_121
1.2
1.1
1.3
STEP 1: Slide Height-Adjustable Legs into the Cross Beam as shown above.
INSTALL HEIGHT-ADJUSTABLE LEGS

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 6 of 19
HABN_121
2.2
STEP 2: Fasten Screws to secure Legs to Top Channel.
FASTEN SCREWS TO SECURE LEGS

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 7 of 19
HABN_121
2.3
REPEAT STET 1 TO STEP 2
STEP 3: Repeat Step 1 and Step 2, for the other Leg Assembly. STEP 4: Attach Stretcher Bar to Legs as shown above, with screws provided.
ATTACH STRETCHER BAR TO LEGS

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 8 of 19
HABN_121
1.5
2.2
STEP 5: Attach Struts to all Leg Assemblies.
ATTACH STRUTS TO ALL LEG ASSEMBLIES

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 9 of 19
HABN_121
2.4
1.6
STEP 6: attach Struct Covers to Struts installed with screws provided.
ATTACH STRUT COVERS TO STRUTS

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 10 of 19
HABN_121
NOTE: Frame Link is not included with Frame. Must order Separately.
7.2
7.1
STEP 7: Fasten Frame Link to one of the table frame Stretcher Bars first, as indicated. Bring over second frame, and attach Stretcher Bar to Frame Link as shown above.
INSTALL FRAME LINK (OPTIONAL)

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 11 of 19
HABN_121
3
3
3
ATTACH POWER MODULE (OPTIONAL)
STEP 8a: Attach Power Module as shown above. STEP 8b: Attach Power Module Cover as shown above.
ATTACH POWER MODULE COVER (OPTIONAL)

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 12 of 19
HABN_121
2.9
4
5
1.8
NOTE: Make sure that the dongle
is connected to the Control Box.
STEP 9: Connect all the wires
WIRE CONNECTION

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 13 of 19
HABN_121
STEP 10: Attach Worksurface to Frame with screws provided.
ATTACH WORKSURFACE TO FRAME

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 14 of 19
HABN_121
STEP 11: Align Worsurfaces as shown above.
ALIGN WORKSURFACES

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 15 of 19
HABN_121
STEP 12: Attach Switch to Worksurface as shown above, with screws provided.
ATTACH SWITCH TO WORKSURFACE

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 16 of 19
HABN_121
1.13.7
1.13.5
Front View
1.13.6
1.13.7
Rear View
STEP 13: Using Wire/Cable Clips and screws, organize wires as shown above.
ATTACH CABLE CLAMPS

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 17 of 19
HABN_121
STEP 14: Attach Control Box to Worksurface with screws provided.
ATTACH CONTROL BOX TO WORKSURFACE

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 18 of 19
HABN_121
STEP 15: Attach Control Box Cover as shown above.
ATTACH CONTROL BOX

Section:
Date: Jan 2020
FRAMES AND WORKSURFACES
height-adjustable bench
Installation Guides
Page: 19 of 19
HABN_121
NOTE: Refer to COM_151a for Cable Organizer installation
NOTE: Refer to COM_151b for Plastic Tray Cable Management
CABLE ORGANIZER (OPTIONAL)
STEP 16a: Refer to COM_151a for Cable Organizer. STEP 16b: Refer to COM_151b for Dual Plastic Tray Cable Management.
PLASTIC TRAY CABLE MANAGEMENT (OPTIONAL)
