Teknion Dossier Operating and maintenance instructions

Section:
Description: Page No:
Date:
dossier Installation Guides
H.A Credenza (ZJHC)
A
H
D
E
I
P
Q1
J
M
O
U
W1
W3
S
R
HEIGHT ADJUSTABLE CREDENZAS
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
Sept 2018 1 of 14
DOS_110 Rev. No.: 0

Section:
Description:
dossier Installation Guides
A - Height Adjustable
Credenza Base
B - 1/4-20 x 3/4" SCRW
(E01-0484) x32
C - 8-32 x 1/2"L SCRW
(E01-0495) x8
D - Top Leg Mount
(N09-6486) x2
E - Reinforcement
(A19-1643)
F - Threaded Cap x12
H - Desktop
I - Wire Manager
(A16-5035)
J - Power Module Support
(A16-5048) x2
K - #10 x 0.875" SCRW
(E07-0077)
L - Wire Loom
(A16-5036) x2
M - Control Box
N - #8-5/8 W.S
(E01-0637) x2
Q3 - #8-5/8 W.S
(E01-0637) x8
O - YEPD Power Bar Bracket
(A16-5298) x1
R - W/S Wire Manager
(B03-2380) x1
Q1 - W.M Bracket
(A16-5047) x1
Q2 - 1/4-20 T.S
(D06-4093) x1
P - Power Bar
(YEPD) x1
S - Tek Pier Switch
(I04-0098) x1
W2 - Cable Manager
(A16-3980E) x1
W3 - Cable Tie
(B02-0545) x2
W3 - E-Chain Body
(B02-0648) x1
G - 50 mm
Murakoshi Bolt x12
Q - Wiretray Mounting Bracket Ass.
(N09-6712) x2
W.T Mounting Bracket
(N09-6929) x1
W - E-Chain (N09-6918) x1
Part and Product Identification
T - 90 Deg Mount
(A16-3970) x1
W1 - Cable Manager
(A16-3980E) x1
HEIGHT ADJUSTABLE CREDENZAS
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
Page No:
Date: Sept 2018 2 of 14
DOS_110 Rev. No.: 0

Section:
Description: Page No:
Date:
SCREW BRACKET TO LEG
Sept 2018 3 of 14
DOS_110
HEIGHT ADJUSTABLE CREDENZAS
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
dossier Installation Guides
STEP 1: Place bracket on top of Height Adjustable Leg and use Screws to secure
D
A
C

STEP 3: Fasten Worksurface to Height Adjustable LegsSTEP 2: Connect Credenza to power and raise to maximum height
Section:
Description:
dossier Installation Guides
RAISE LEGS FASTEN BRACKETS TO WORKSURFACE
B
B
D
HEIGHT ADJUSTABLE CREDENZAS
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
Page No:
Date: Sept 2018 4 of 14
DOS_110 Rev. No.: 0

STEP 4: Fasten Wire Manager Bracket and Wire Loom beneath Work Surface
Section:
Description:
dossier Installation Guides
ASSEMBLE WIRE MANAGEMENT
L
Q1
Q3
Q1
L
HEIGHT ADJUSTABLE CREDENZAS
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
Page No:
Date: Sept 2018 5 of 14
DOS_110 Rev. No.: 0

STEP 6: Secure Control Box into place using Control Unit BracketsSTEP 5: Insert Control Box into cut out beneath Work Surface
Section:
Description: Page No:
Date:
INSERT CONTROL BOX SECURE CONTROL BOX
DOS_110
6 of 14
Sept 2018
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
HEIGHT ADJUSTABLE CREDENZAS
dossier Installation Guides
M
J
N

Section:
Description: Page No:
Date:
SECURE POWER BAR
Sept 2018 7 of 14
DOS_110
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
HEIGHT ADJUSTABLE CREDENZAS
dossier Installation Guides
STEP 7: Remove and discard mounting clips from YEPD Power Bar and secure beneath Worksurface using YEPD Power Bar Bracket
P
O
N

STEP 8: Fasten Reinforcement Bar to Worksurface using screws
STEP 9: Fasten 90 Deg Mount and Tek Pier Switch to Underside of Worksurface. Switch may
be installed in either left or right handed orientation.
STEP 10: Run Tek Pier Switch Cable through channel in Worksurface and fasten in place with
Work Surface Wire Manager
Section:
Description: Page No:
Date:
ATTACH REINFORCEMENT BAR ATTACH SWITCH
FASTEN CABLE
DOS_110
8 of 14
Sept 2018
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
HEIGHT ADJUSTABLE CREDENZAS
dossier Installation Guides
E
B
T
S
N
R

STEP 12: Insert YEPD Power Cable into E-Chain GrommetSTEP 11: Remove Access Panel
Section:
Description: Page No:
Date:
REMOVE ACCESS PANEL BRING POWER INTO BASE
DOS_110
9 of 14
Sept 2018
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
HEIGHT ADJUSTABLE CREDENZAS
dossier Installation Guides

STEP 14: Secure Cables with Cable Tie Wrap, Install Clip as shown and fasten with screwsSTEP 13: Feed YEPD Power Cable into E-Chain
Section:
Description: Page No:
Date:
INSTALL POWER CORD INSTALL E-CHAIN TO RUNOFF
DOS_110
10 of 14
Sept 2018
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
HEIGHT ADJUSTABLE CREDENZAS
dossier Installation Guides
W4
W3
K

STEP 16: Fasten E-Chain to Wooden Board in the Base with screwsSTEP 15: Secure Cables with Cable Tie Wrap, install Clip as shown and fasten with screws
Section:
Description: Page No:
Date:
FASTEN E-CHAIN TO WORKSRUFACE FASTEN E-CHAIN TO BASE
DOS_110
11 of 14
Sept 2018
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
HEIGHT ADJUSTABLE CREDENZAS
dossier Installation Guides
W1
K
K

Section:
Description: Page No:
Date:
FASTEN WIRE MANAGEMENT TRAY FASTEN WIRE MANAGEMENT TRAY
FASTEN WIRE MANAGEMENT TRAY
DOS_110
12 of 14
Sept 2018
HEIGHT ADJUSTABLE CREDENZAS
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
dossier Installation Guides
I
Q2
STEP 17: Slide Wire Manager into Wire Manager Bracket and Fasten in place using 1/4-20 Thumb Screws 2 places

STEP 19: Connect cabinets to gables using Murakoshi Bolts and Threaded CapsSTEP 18: Drill holes into cabinets using holes in gables as a guide
Section:
Description: Page No:
Date:
DRILL CONNECTION HOLES FASTEN GABLE TO CABINETS
DOS_110
13 of 14
Sept 2018
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
HEIGHT ADJUSTABLE CREDENZAS
dossier Installation Guides
F
G

Section:
Description: Page No:
Date:
CLOSE ACCESS PANEL
Sept 2018 14 of 14
DOS_110
HEIGHT ADJUSTABLE CREDENZA INSTALLATION
HEIGHT ADJUSTABLE CREDENZAS
dossier Installation Guides
