Teknion Complements Operating and maintenance instructions

Rectangular Wksf. W\ Radius Corners for Routes Quick Connect (WQX)
hiSpace Quick Connect HA Base Only Round Legs (YQX)
Part and Product Identification
A1 - Rect. Wksf. W\ Rad.
Corners for Routes Quick
Connect (C07-7831-X) x1
Section:
Description: Page No:
Date:
Rev. No: 0
HA TABLES - QUICK CONNECT
HEIGHT ADJUSTABLE TABLES
May 2021 1 of 11
COM_138
complements Installation Guides
A4 - #10x0.875"
Screw
(E07-0077) x28
A3 - Leg Mount
Bracket Qi- hiSpace
(N09-9873) x2
A2 - Reinforcement
Bar-hiSpace
(A16-9104) x2
B1 - Kaidi Qi BIFMA
Round Leg (N01-4881) x2 B2 - Routes Foot
Casting (A25-0770) x2
B3 - M6x1x20mm
-SHCS
(E01-1253) x8
B4 - Cam Handle w/
Cotter Pin.
(N09-9814) x2
B11a - #8 x 5/8" Pan
Quad WD Screw.
(E04-0091) x2
B11c - Cable Clamp, BLK
(B02-0558) x2
B11b - #6 x 5/8"
Flat Quad Screw.
(E04-0090) x2
B11 - Kaidi Hardware
Kit, hiSpace
(X05-0548) x1
B10 - M5x0.8, 12mm
Philips Head Screw
(E01-1106) x2
B7 - Right Angle
Connector 1m Lg.
(D06-4277) x2
B8 - 3m Power
Cord
(D06-4136) x1
B9 - Keypad,
hiSpace Table
(D06-4726) x1
B5 - Cable Organizer w/
Felt Cover (N09-8069S) x1
B6 - Control Box w\
Anti Collision Dongle
(D06-4725) x1
A - Rect. Wksf. W\ Rad.
Corners (WQX) x1
B - hiSpace Quick Conect HA Base Only, Round Legs (YQX) x1
A1
A3
B4
NOTE: YQX930726 and
WQX930726NN are used
as for Illustration.
A2
B1
B2
B5
B11 - M5x20mm Philips (E07-0203) x4

Section:
Description: Page No:
Date:
ATTACH LEG MOUNT BRACKET ATTACH REINFORCEMENT BAR
COM_138
2 of 11
May 2021
HA TABLES - QUICK CONNECT
HEIGHT ADJUSTABLE TABLES
complements Installation Guides
STEP 2: Attach the Reinforcement Bars to the Worksurface.
STEP 1: Attach Leg Mounts to Worksurface as shown above.
A2
A1
A4
A4
A4
A3

Section:
Description: Page No:
Date:
ATTACH LEGS TO WORKSUFACE SECURE LEGS TO WORKSUFACE
COM_138
3 of 11
May 2021
HA TABLES - QUICK CONNECT
HEIGHT ADJUSTABLE TABLES
complements Installation Guides
STEP 4: Push Legs to Outer side of the Worksurface.STEP 3: Attach legs to Worksurface as shown above.
B1
B1

Section:
Description: Page No:
Date:
SECURE LEGS TO BRACKET - 1 SECURE LEGS TO BRACKET - 1
COM_138
4 of 11
May 2021
HA TABLES - QUICK CONNECT
HEIGHT ADJUSTABLE TABLES
complements Installation Guides
STEP 6: Insert Cotter Pin and lock the Cam handle as shown above.STEP 5: Install Cam Handle as shown above nad Make sure its Locked in.
B4
Cotter
Pin

Section:
Description: Page No:
Date:
ATTACH FEET TO LEGS
May 2021 5 of 11
COM_138
HA TABLES - QUICK CONNECT
HEIGHT ADJUSTABLE TABLES
complements Installation Guides
STEP 7: Attach Feet to legs as shown above with screws provided.
B2
B3

Section:
Description: Page No:
Date:
REMOVE FELT COVER - 1 REMOVE FELT COVER - 2
COM_138
6 of 11
May 2021
HA TABLES - QUICK CONNECT
HEIGHT ADJUSTABLE TABLES
complements Installation Guides
STEP 9: Remove Felt Cover as shown above.STEP 8: Unscrew lock as shown above.
B5
B5
B5

Section:
Description: Page No:
Date:
ATTACH CABLE MANAGER
ATTACH CONTROL BOX
ATTACH CONNECTOR TO CONTROL BOX
COM_138
7 of 11
May 2021
HA TABLES - QUICK CONNECT
HEIGHT ADJUSTABLE TABLES
complements Installation Guides
STEP 11: Attach the Control Box to the Cable Manager.
STEP 10: Attach the Cable Manager Bracket to the Worksurface using the Screws provided.
STEP 12: Attach the Connector Cable to Control box and to Leg as shown. Wrap the extra
wire around the Cable manager.
NOTE: Use of Magnetic Bit to Fasten
C3 is recommended.
B5
B11
B10
B6
B7
B1
B7
B7

Section:
Description: Page No:
Date:
ATTACH SWITCH AND WIRE MANAGEMENT
May 2021 8 of 11
COM_138
HA TABLES - QUICK CONNECT
HEIGHT ADJUSTABLE TABLES
complements Installation Guides
STEP 13: Plug Wires and Secure Switch with screws as shown above. Make the connections & Wrap around wires around the Stem. Make Sure the Anti Collision Device is attached to the
Control Box.
B11a
B9
NOTE: Make Sure the Anti- Collision
Dongle is attached to the Control Box.
B9
Anti-Collision
Dongle
B8
B8

Section:
Description: Page No:
Date:
PLACE FELT COVER FASTEN FELT COVER
COM_138
9 of 11
May 2021
HA TABLES - QUICK CONNECT
HEIGHT ADJUSTABLE TABLES
complements Installation Guides
STEP 15: Fasten Felt Cover. Turn the Screw Lock Clockwise to lock.
STEP 14: Place back the Felt Cover.
B5

Section:
Description: Page No:
Date:
ATTACH CABLE CLAMPS
May 2021 10 of 11
COM_138
HA TABLES - QUICK CONNECT
HEIGHT ADJUSTABLE TABLES
complements Installation Guides
STEP 16: Place cable Clamps as shown above.
B11b
B11c
B11c

Section:
Description: Page No:
Date:
SET UP SWITCH
May 2021 11 of 11
COM_138
HA TABLES - QUICK CONNECT
HEIGHT ADJUSTABLE TABLES
complements Installation Guides
STEP 17 (Optional): For More information on Setting up hiSpace Table Keypad Switch. Please refer to COM_001.
NOTE: For More information on
Setting up hiSpace Table Keypad
Switch. Please refer too COM_001.
