Teknion Interpret Operating and maintenance instructions

PEDESTAL - SUSPENDED (WWGH) Part and Product Identification
Section:
Description: Page No:
Date:
Rev. No: 2
PEDESTAL - SUSPENDED
STORAGE
Feb 2022 1 of 12
INT_105a
interpret Installation Guides
For Customer Support please contact
[email protected]
B
A7
F
NOTE: Suspended Pedestal -
Box/File with Metal Front
shown as an example.
Part B to G will be shipped
pre-assembled.
A4
For Double Sided Frame WWSDC, WWSDB and WWSDF
48" deep and ≤ 72" wide, ONLY one WWGH
Suspended Pedestal can be installed per side.
For Single Sided Bench, WWEDA Data Tray needs to
be 15" shorter than width of Worksurface to provide
clearance for Pedestal.
A1 - 5/16-18x3.0 Length,
Hex Cap Screws
Grade2
(E01-0789) x4
A3 - Worksurface Spacer
Block
(A25-0368) x2
A4 - Suspending Bracket
(A16-1678) x1
A7 - Supporting Bracket
(A16-1679) x1
A8 - 1/4-20x3/8" MACH
Screw, QUAD, PAN
(E01-0014) x2
A2 - 5/16-18 Hex Nut,
1/2 A/F, .265 Thick
(E01-0755) x4
A9 - Bumper .375 DIA
x .125 Height
Clear (BS-34)
(E08-0091) x2
A - (X08-0161) x1
B - Suspended Pedestal
Case Weldment
(N01-3100\16\18) x1
C - Pedestal Double
Lock Bar Kit
(N01-2244\03) x1
D - Pencil/Small Box
Drawer
Sub-Assembly
(N01-2240\18) x1
E - File Drawer,
Sub-Assembly
(N01-2242\18) x1
F - Metal Front, with
Interpret Handle
(N01-3119\4_800) x1
(N01-3119\12_800) x1
or
Wood Front, with
Interpret Handle
(N01-3122SF) x1
G - Pencil Tray
(D04-0049) x1
A5 - 1/4-20x .625 PAN
Head QUAD Screw
(E01-0732) x4
A6 - 1/4-20 UNC. Nut
Hex Keps Zinc
(E03-0059) x4
A11 - 1/4-20 x 1 1/2
Thumb Screw,
Type B, Zinc
(E01-0852) x1
A10 - Suspended Pedestal
Ganging Bracket
(A16-2026) x1
Pre-Assembled
Pre-Assembled
NOTE: Ensure product is leveled
and if Front/Door alignment is
needed, perform the necessary
adjustment for the Fronts/Doors
insuring equal gap.
NOTE: Adjust Front/Door by
Releasing the front mounting
screws, adjust front and tighten the
screws or use the hinge adjustment.

Section:
Description: Page No:
Date:
REMOVE DRAWERS
Feb 2022 2 of 12
INT_105a
PEDESTAL - SUSPENDED
STORAGE
STEP 1: Pull the drawer out. Find levelers located on the sliders and pull up on one side and push down on the other side to release and remove drawer box.
interpret Installation Guides

Section:
Description: Page No:
Date:
SUSPENDING BRACKET ASSEMBLY
Feb 2022 3 of 12
INT_105a
PEDESTAL - SUSPENDED
STORAGE
STEP 2: Align pilot holes on Suspending Bracket and the top of the Case Weldment. Then secure with Screws and Nuts.
NOTE: Make sure the Hook of the Suspending Bracket is facing the back of the Case.
A5
Reverse View
Top View
Underside View
A6
A6
interpret Installation Guides

Section:
Description: Page No:
Date:
BUMPER PLACEMENT FOR MID-GABLE BUMPER PLACEMENT FOR END-GABLE
INT_105a
4 of 12
Feb 2022
PEDESTAL - SUSPENDED
STORAGE
STEP 3b: Align the contacting area on Pedestal and Leg. Paste Bumpers on Pedestal as shown.
NOTE: Pedestal mounting against End-Gable Frame as shown.
STEP 3a: Align the contacting area on Pedestal and Leg. Paste Bumpers on Pedestal as shown.
NOTE: Pedestal mounting against Mid-Gable Frame as shown.
Side View
A9
Reverse View
Mid Gable
A9
Side View
A9
Reverse View
End Gable
A9
NOTE: Paste Bumpers on
the side of Pedestal that will
be mount against Mid-Gable.
NOTE: Paste Bumpers on
the side of Pedestal that will
be mount against End-Gable.
interpret Installation Guides

Section:
Description: Page No:
Date:
MOUNT PEDESTAL
Feb 2022 5 of 12
INT_105a
PEDESTAL - SUSPENDED
STORAGE
STEP 4: Mount Suspending Bracket on Transverse Beam.
NOTE: Make sure the side of Pedestal is mounted against the Leg as shown on Top View.
Transverse
Beam
Top View
Detail View
Before installing Pedestal
on Double Sided Benches
48" deep and ≤ 72" wide,
make sure WWEPTD
Power Tray is moved 1"
away from Pedestal side
to provide adequate
clearance.
interpret Installation Guides

Section:
Description: Page No:
Date:
SECURE FIRST SPACER BLOCK
Feb 2022 6 of 12
INT_105a
PEDESTAL - SUSPENDED
STORAGE
STEP 5a: Mount Spacer Block on Transverse beam, insert Screws from the top and secure with Nuts inside Case Weldment as shown.
A2
Underside View
A1
A3
Top View
A3
interpret Installation Guides

Section:
Description: Page No:
Date:
SECURE SECOND SPACER BLOCK
Feb 2022 7 of 12
INT_105a
PEDESTAL - SUSPENDED
STORAGE
STEP 5b: Mount Spacer Block on Transverse beam, insert Screws from the top and secure with Nuts inside Case Weldment as shown.
A1
A2
Underside View
Top View
A3 A3
interpret Installation Guides

Section:
Description: Page No:
Date:
INSTALL SUPPORTING BRACKET (WITHOUT RECESSED INTERMEDIATE LEG COVER)
Feb 2022 8 of 12
INT_105a
PEDESTAL - SUSPENDED
STORAGE
STEP 6a: Mount Supporting Bracket to the Horizontal Beam on End Gable. Align highlighted holes on Bracket and Case, then secure Bracket with Screws from inside the Case.
A7 A8
Top View
NO Recessed
Intermediate
Leg Cover
interpret Installation Guides

Section:
Description: Page No:
Date:
SUPPORT BRACKET ASSEMBLY (WITH RECESSED INTERMEDIATE LEG COVER)
Feb 2022 9 of 12
INT_105a
PEDESTAL - SUSPENDED
STORAGE
STEP 6b: Mount Supporting Bracket to the Horizontal Beam on End Gable. Align highlighted holes on Bracket and Case, then secure Bracket with Screws from inside the Case.
NOTE: This step ONLY apply to Suspended Pedestal installing beside Recessed Intermediate Leg Cover.
Recessed
Intermediate
Leg Cover
A7
A8
Top View
interpret Installation Guides

Section:
Description: Page No:
Date:
RE-INSTALL DRAWERS
Feb 2022 10 of 12
INT_105a
PEDESTAL - SUSPENDED
STORAGE
STEP 7: Slide out Tracks in Case and align with Tracks on Drawer. Push them against each other to engage the Drawer.
NOTE: Make sure you hear a "click" sound to confirm the Drawer have properly engaged.
Detail View
interpret Installation Guides

Section:
Description: Page No:
Date:
ENGAGE GANGING BRACKET (OPTIONAL)
Feb 2022 11 of 12
INT_105a
PEDESTAL - SUSPENDED
STORAGE
STEP 8: Engage the Ganging Bracket to the bottom of Pedestals as shown.
NOTE: Only applicable to 2 Suspended Pedestals mounted back-to-back under 36" Return Frame for Two Worksurfaces.
Detail View
Detail View
Underside View
A10
interpret Installation Guides

Section:
Description: Page No:
Date:
SECURE GANGING BRACKET (OPTIONAL)
Feb 2022 12 of 12
INT_105a
PEDESTAL - SUSPENDED
STORAGE
STEP 9: Fasten the Thumb Screw to secure Ganging Bracket and Pedestals in place.
NOTE: Only applicable to 2 Suspended Pedestals mounted back-to-back under 36" Return Frame for Two Worksurfaces.
Detail View
A11
Reverse View
A11
