Teleco TVPLT868C80T0 User manual

Warning: The product must be installed only by qualied technician in accordance with the rules
concerning the automatic covers. The system is powered by 230Vac.
Characteristics
• 80W integrated transformer for LED.
• Control unit for one 230Vac motor.
• Selection of the application: awning or pergola covering
• Automatic setting of working time (for pergola application).
• Input for rain and wind sensors (optional).
• Input for two wired external push-buttons, for OPEN and
CLOSE commands.
• Memorization of single or double radio channels, and 7
channels transmitters.
1
TELECO AUTOMATION SRL - Via dell’Artigianato, 16 - 31014 Colle Umberto (TV) ITALY
TELEPHONE: ++39.0438.388511 FAX: ++39.0438.388536 - www.telecoautomation.com
This document is the property of Teleco Automation Srl who reserves all reproduction and copying rights
Product codes:
TVPLT868C80T0 wired input (868.3MHz)
TVPLT916C80T0 wired input (916MHz)
TVPLT868C80TS wired input, wind & rain sensors (868.3MHz)
TVPLT916C80TS wired input, wind & rain sensors (916MHz)
Radio receiver to control one 230Vac motor for awning or pergola covering.
80W integrated transformer to power 24Vdc LED.
DOC.: T734.01
PROD.: TVPLTxxxC80Tx DATE: 02/11/16

2
Warnings
Hereby Teleco automation s.r.l. declares that the product complies with the essential requirements and other
relevant provisions, established by the Directive 1999/5/EC. The declaration of conformity can be consulted
on the web site: www.telecoautomation.com/ce. In the view of a constant development of their products, the
manufacturer reserves the right for changing technical data and features without prior notice.
The above mentioned product must be installed only by qualied technical personnel
in compliance with the standards of automatic openings. All connections must be rated
for a single-phase power supply of 230V. For the disconnection from the power line, use
an all-pole switch with contact with an opening of at least 3.5 mm.
Only suitable materials for the connections must be used to guarantee insulation that complies with
current standards on the subject of electrical safety. The product executes just movement controls; all
the necessary safety devices are to be seen separately.
Incorrect wiring will cause incorrect functioning impairing the safety purpose for which the product has
been designed so that people injuries could occur; failure to follow instructions can cause personal
injury and/or property damage.
Keep the 230V wires from the low voltage safety wires separately.
The earth-wires must be xed by means of an additional fastening nearby the terminals; this fastening has to
be done by qualied technical personnel during the installation phase.
The appliance has been tested with a power supply wire type H05VV-F; the power supply wires for outdoor
use must have better characteristics than the ordinary wires type H05RN-F. The safety devices have to be in
conformity with EN12978. The product is in conformity with the RAEE and RoHS directive.
Index
1. Wiring and adjustments ----------------------------------------------------------- page 3
2. Memorization of transmitters for MOTOR control ----------------------------- page 4
2.1 Memorization of a single channel with OPEN-STOP-CLOSE function
2.2 Memorization of a double channel (pair) with automatic command function
2.3 Memorization of a 7 channels transmitter (only for pergola application)
3. Memorization of transmitters for LED control ----------------------------- page 5
2.1 Memorization of a single channel with ON/OFF - DIM function
2.3 Memorization of a 7 channels transmitter
Changing the preset light scenes of the 7 channels transmitters
4. Transmitters deletion ----------------------------------------------------------- page 6
4.1 Deleting a transmitter
4.2 Deleting all the transmitters
5. Remote functions ----------------------------------------------------------- page 6
5.1 Remote memorization of further radio codes
5.2 Remote deletion of a radio code
6. Conguration of working time (only for pergola application) ---------- page 7
7. Sensors (only for “S” version) ----------------------------------------------------------- page 7
7.1 Wind sensor
7.2 Rain sensor
8. Technical specications ----------------------------------------------------------- page 8
8.1 Technical specications of the control unit
8.2 Technical specications of the box

SIGNAL
1RAIN SENSOR (YELLOW, GND)
2 RAIN SENSOR (BLUE, signal)
3 RAIN SENSOR (WHITE,12V)
4 WIND SENSOR (BLUE)
5 WIND SENSOR (BROWN)
6 LED OUTPUT (-)
7 LED OUTPUT (+24Vdc - max. 70W)
8GND WIRED INPUT
9 CLOSE INPUT
10 OPEN INPUT
11 GND AERIAL
12 RF AERIAL
DIP1 DIP2 WIND SPEED (Km/h)
OFF OFF 40
OFF ON 50
ON OFF 60
ON ON 70
Only for “S” version
AERIAL
230Vac
Power
supply
Dip switch
P1
Prog. button
230Vac
MOTOR
L1 L2 L3
L1: Rain alarm (ON)
L2: wind alarm (ashing)
L3: Not used
TRANSFORMER Rain Sensor
Wind Sensor
Wired input
LED OUTPUT
SIGNAL
15 MOTOR OPEN
16 MOTOR CLOSE
17 MOTOR COMMON
18 NEUTRAL 230Vac
19 LINE 230Vac
20 EARTH CONNECTION
OFF Application = Pergola
ON Application = Awning
3
1. Wiring and adjustments
The control unit can be used for both pergola (louvre) and sun awning applications.
Choose the desired functioning mode by means of DIP4:
In case of pergola application it’s necessary to congure the working time with procedure 6 (pag.7)
FUNCTIONING MODES: PERGOLA OR AWNING

4
2.2 Memorization of a double channel (pair) with automatic command function (MOTOR)
This conguration permits the control of the motor with a transmitter of at least 2 channels.
Pressing a button the system stops if the motor is moving in the opposite direction.
2.3 Memorization of a 7 channels transmitter (MOTOR: only for pergola application)
This memorization permits the control of the motor with a 7
channel transmitter, in which every channel is connected to a
single operation. Attention: in order to move the slats of the
pergola to the angle associated to the buttons CH1..CH4 of
transmitter, it’s necessary congure the working time rst, as
explained in the procedure 6 at page 7.
...
P1
< 1 sec.
----- 3 TIMES -----
...
last
CH1 0 % (CLOSED)
CH2 50 %
CH3 70 %
CH4 100% (OPEN)
CH5 Hold-to-run opening
CH6 STOP
CH7 Hold-to-run closing
CH1
CH2
CH1
CH2
CH4
CH3
CH1
(P3)
Closing (STOP)
Opening (STOP)
CH5 Opening
CH6 STOP
CH7 Closing
7 channels transmitter 3 channels transmitter 2 channels transmitter
CH1 Opening (STOP)
CH2 Closing (STOP)
CH3 Opening (STOP)
CH4 Closing (STOP)
CH5 Opening
CH6 STOP
CH7 Closing
...
P1
< 1 sec.
----- 2 TIMES -----
...
last
• Press twice P1 keeping pressed
the second time.
• The buzzer emits a continuous
sound. Press any button of the pair
to memorize.
• Once the memorization is
successfully completed, the buzzer
emits a fast intermittent sound.
• Press 3times P1 keeping pressed
the third time.
• The buzzer emits a continuous
sound. Press any button of
transmitter to memorize.
• Once the memorization is
successfully completed, the buzzer
emits a fast intermittent sound.
2.1 Memorization of a single channel with OPEN-STOP-CLOSE function (MOTOR)
This conguration permits the control of the motor with a single channel of any transmitter.
• Press once P1 keeping it pressed.
• The buzzer emits a continuous sound.
Press any button of transmitter.
• Once the memorization is successfully
completed, the buzzer emits a fast
intermittent sound.
...
P1
< 1 sec.
----- ONCE -----
...
last

5
3.1 Memorization of a single channel with ON/OFF - DIM function (LED)
This conguration permits the control of the LED with a single channel of any transmitter. With short pulses
(<800 ms.) turn the LED on and off; keeping the button pressed: increase or decrease the intensity.
• Press 8times P1 keeping pressed the
eighth time.
• The buzzer emits a continuous sound.
Press any button of transmitter to
memorize.
• Once the memorization is successfully
completed, the buzzer emits a fast
intermittent sound.
...
P1
< 1 sec.
----- 8 TIMES -----
...
last
3.2 Memorization of a 7 channels transmitter (LED)
This conguration permits the control of the LED with a 7 channel transmitter, in which every channel is
connected to a single operation:
...
P1
< 1 sec.
----- 9 TIMES -----
...
last
CH1 100%
CH2 75 %
CH3 50 %
CH4 25 %
CH5 DIM +
CH6 DIM -
CH7 OFF
• Press 9times P1 keeping pressed
the ninth time.
• The buzzer emits a continuous
sound. Press any button of
transmitter to memorize.
• Once the memorization is
successfully completed, the buzzer
emits a fast intermittent sound.
Changing the preset light scenes of the 7 channels transmitters
adjust new valuepress the scene to modify press and hold more than 5s
3- Press the button CH7 and hold it
down for 5 sec. LED turn off. After 5
sec. buzzer makes a beep and the LED
turn on at the new value.
2- Adjust the new value with
the buttons CH5 and CH6
1- Press the button related to
the scene to modify
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH1
CH2
CH3
CH4
CH5
CH6
CH7

6
4.2 Deleting all the transmitters
• Press 6times P1 keeping pressed
the sixth time.
• The buzzer emits a fast intermittent
sound for about 10 sec.
• Release when the sound becomes
continuous.
5.2 Remote deletion of a radio code
• Press P3 of the transmitter already
memorized. The buzzer emits a
continuous sound.
• Press the button to delete within 10
seconds.
• Once the deletion is successfully
completed, the buzzer stops
sounding.
...
10 sec.
P1
< 1 sec.
----- 6 TIMES -----
...
last
Memorized To delete
within 5 sec.
P3
3 times
...
4.1 Deleting a transmitter
• Press 5times P1 keeping pressed the
fth time.
• The buzzer emits a continuous sound.
Press the button to delete within 10
seconds.
• Once the memorization is successfully
completed, the buzzer emits a fast
intermittent sound.
...
P1
< 1 sec.
----- 5 TIMES -----
...
last
within 10 sec.
5.1 Remote memorization of further radio codes
• Press P3 of the transmitter already
memorized. The buzzer emits a
continuous sound.
• Press the button to copy. The buzzer
stops for 1 second and emits the sound
again.
• Press the button to memorize of the
new transmitter.
• Once the memorization is successfully
completed, the buzzer emits a fast
intermittent sound.
The new transmitter must have the same (or higher) number of buttons as the memorized one.
At the end of procedure it will have the same functioning of the memorized transmitter.
P3
Memorized NEWMemorized
within 5 sec.
...
within 5 sec.
1 sec.

7
7.1 Wind sensor (only for “S” version)
The wind sensor (ANEM4, 4 pulses/rotation) detects if the wind speed exceed the threshold, set with DIP1-2
(pag.3). It has the highest priority among the sensors. If the alarm is active:
7.2 Rain sensor (only for “S” version)
When the sensor detects the rain and the alarm is activated, the device positions the slats of the pergola or moves
the motor of the awning to completely closed position. During the status of alarm L2 is ON and the control unit
does not execute any command. The alarm is off when the sensor doesn’t detect the presence of the rain for 20
seconds.
6. Conguration of working time (only for pergola application)
The conguration of the working time is necessary only for the application PERGOLA. The procedure below will
be applied just in case the DIP4 is set to OFF.
ON
1 2 3
Move DIP3 to ON. The buzzer makes a beep.
The functioning mode automatically switches to “HOLD-TO-RUN”.
P1
Move the awning to the upper limit (application closed).
Press P1 to memorize the limit. Buzzer will make a beep.
Move the awning to the lower limit (application open).
P1
Press P1 to memorize the limit. Buzzer will make a long beep and exits the procedure.
The functioning mode switch back to “AUTOMATIC”.
ON
1 2 3
Move DIP3 to OFF.
DIP4 APPLICATION WIND SPEED (Km/h)
ON Awning The control unit completely closes the awning (MOTOR UP command)
OFF Pergola The control unit moves the slats to complete opening, then at 50% and it stops.
L1 ashes and the control unit does not execute any command.
The system resumes its normal operation 30 seconds after the alarm is OFF (speed lower than the threshold).

8
- Reception frequency 868,3 MHz TVPLT868C80T0, TVPLT868C80TS
916 MHz TVPLT916C80T0, TVPLT916C80TS
- Power supply 230Vac
- Max. power of the motor 350W
- Default working time 90 sec.
- Power of transformer 80W - 24Vdc
- Maximum power of LED output 70W - 24Vdc
- Operating temperature range -20° - +45°C
- Rain sensor power supply 12 Vdc max. 100mA
- Max. number of transmitters 16
8.1 Technical specications of the control unit
8.2 Technical specications of the box
- Protection IP54
- Material of the box and its cover Thermoplastic ABS
- Colour of the box and its cover Grey RAL 7035
- Cable glands M16 (POLIAMMIDE 6.6)
- Sealing ring of cable glands NEOPRENE®
- Self-extinguishing class V2 (UL-94)
Not suitable for direct UV exposure
Teleco Automation S.r.l.
Italy
Tel. [phone]
Fax [phone]
[email protected]
Teleco Automation France
France
Tel. [phone]
Fax [phone]
[email protected]
Teleco Automation GmbH
Germany
Tel. [phone]
Fax [phone]
[email protected]
www.telecoautomation.com
Teleco Automation Oceania Pty Ltd
Australia
Tel. [phone]
[email protected]
56 mm
151 mm
185 mm
70 mm
56 mm
18 mm
Product fastening holes
