804 Series Video Test Generator –User Guide
Page 1
Revision B3
804/804A/804B Video Test Generators
User Guide
Rev: B3

804 Series Video Test Generator –User Guide
Page 2
Revision B3
Table of Contents
1Overview ...................................................................................................................................4
1.1 804, 804A and 804B Models...................................................................................................4
1.2 Intended Use of the Product....................................................................................................4
1.3 Scope of this User Guide.........................................................................................................4
2Customer Support for the 804/804A/804B ............................................................................5
3Descriptions of Input and Outputs –Technical Specifications ...........................................6
3.1 Video Interfaces - Technical Specifications..........................................................................6
3.2 Audio Outputs - Technical Specifications..............................................................................7
3.3 Audio Inputs –Technical Specifications................................................................................8
3.4 Control Interfaces and Devices –Technical Specifications................................................8
3.5 Size and Weight........................................................................................................................9
3.6 Power Considerations.............................................................................................................10
3.7 Environmental Specifications................................................................................................10
4Installation Instructions ........................................................................................................12
4.1 The 804/804A/804B Shipping Box.......................................................................................12
4.2 Ventilation Requirements.......................................................................................................12
4.3 ESD Warning...........................................................................................................................12
4.4 Cleaning Considerations........................................................................................................12
4.5 Desktop Installation Instructions...........................................................................................12
4.6 Rack mount Installation Instructions ....................................................................................12
5Instructions for Use................................................................................................................13
5.1 Powering up the 804/804A/804B..........................................................................................13
5.2 Powering down and uninstalling the 804/804A/804B........................................................13
5.3 Front Panel Display.................................................................................................................15
5.4 Calibrating the LCD.................................................................................................................17
5.5 Front Panel LEDs....................................................................................................................18
5.6 Setting the 804/804A/804B Front Panel Mode...................................................................18
6Using the 804 Series Command Line ...................................................................................20
6.1 Establishing an RS-232 connection to the 804/804A/804B..............................................20
6.2 Sending commands to activate the outputs........................................................................21
7Running Video Pattern Tests................................................................................................23
7.1 Selecting a Signal Type..........................................................................................................23
7.2 Procedures for selecting a resolution and frame rate .......................................................27
7.3 Selecting Test Patterns..........................................................................................................31
7.4 Using Image Caching to render bitmaps quickly................................................................33
7.5 Rendering 3D Test Patterns on an HDTV...........................................................................34
7.6 Using Custom Test Image Packs.........................................................................................35
8Importing Custom Bitmaps...................................................................................................39
8.1 Workflow for Importing Bitmaps through USB....................................................................39
8.2 Procedures for Importing Bitmaps through USB................................................................39
8.3 Workflow for loading bitmaps from the SD card ................................................................41
8.4 Procedures for Loading Bitmaps from SD Card.................................................................41
9Creating and Using Custom Formats...................................................................................43

804 Series Video Test Generator –User Guide
Page 3
Revision B3
10 Creating Custom Menus........................................................................................................47
11 Running Audio Tests .............................................................................................................50
11.1 Testing HDMI Audio on an HDTV or A/V Receiver............................................................50
12 Running Protocol Tests - Using the Front Panel GUI ........................................................57
12.1 Testing HDMI Protocols .........................................................................................................57
13 Using the Keypad ...................................................................................................................66
13.1 Connecting a Keypad .............................................................................................................66
13.2 Enabling and Configuring an RS-232 Keypad....................................................................66
13.3 Keypad Functionality...............................................................................................................66
13.4 Selecting a Format (Timing)..................................................................................................67
13.5 Selecting a Test Pattern (Image)..........................................................................................69
13.6 Programming a Test Sequence using the keypad.............................................................70
13.7 Programming a Test Sequence in the UserKeys file ........................................................72
14 Upgrading the 804/804A/804B ..............................................................................................74
14.1 Upgrading the Firmware and Gateware on your 804/804A/804B ...................................74
15 Command Reference..............................................................................................................77
15.1 Video-Related commands......................................................................................................77
15.2 Administrative Commands.....................................................................................................92
15.3 HDMI Protocol Test Commands...........................................................................................94
15.4 Memory Commands................................................................................................................94
15.5 Image Drawing Commands...................................................................................................95
15.6 Image Cache Commands......................................................................................................95
15.7 Markers Commands................................................................................................................95
15.8 Audio-Related commands......................................................................................................96
16 List of Formats .......................................................................................................................99
17 List of Test Patterns.............................................................................................................110

804 Series Video Test Generator –User Guide
Page 4
Revision B3
1 Overview
This section provides an overview of the 804/804A/804B Video Test Generator and the scope of the User Guide.
1.1 804, 804A and 804B Models
There are three models in the 804 series. The 804 Video Test Generator and the 804A Video Test Generator. The 804
supports HDMI pixel rates up to 165MHz. The 804A model supports pixel rates up to 300MHz (at 24 bit color). The 804A
therefore supports resolutions up to 4K x 2K at 50/60Hz with 4:2:0 pixel encoding as specified by the HDMI 2.0 specification.
The 804B model supports pixel rates up to 600MHz (at 24 bit color) at 50/60Hz with 4:4:4 pixel encoding. Each model
supports deep color.
1.2 Intended Use of the Product
The 804 series video generators are optimized for testing modern HDMI flat panel TVs. They feature 4 HDMI outputs—all
active simultaneously—for testing HDTVs with multiple HDMI inputs. This eliminates the cost of splitters often required for
testing each HDMI input on a TV. Each HDMI interface supports up to 36 bit/pixel (12-bit/component) deep color mode. The
804 series video generators can also output component analog and composite analog.
1.3 Scope of this User Guide
The 804 series Video Test Generator User Guide includes the necessary information to operate your 804 instrument. There is
a Quick Start Guide that covers some of the 804/804A/804B features as well.

804 Series Video Test Generator –User Guide
Page 5
Revision B3
2 Customer Support for the 804/804A/804B
The 804/804A/804B Video Test Generator is manufactured by Quantum Data:
Quantum Data, Inc.
2111 Big Timber Road
Elgin, IL USA
60123
Please check the Quantum Data website for updates to the user documentation and the firmware:
www.quantumdata.com/downloads
If you have a product support request you can contact Quantum Data customer support either by phone or by a web page.
The phone number is: 847-888-0450 x 456
For web support: http://www.quantumdata.com/support/index.asp
Note: This Guide is updated frequently. Please be sure to check the Quantum Data website for updates at:
www.quantumdata.com/downloads or www.quantumdata.com/products/804.asp.

804 Series Video Test Generator –User Guide
Page 6
Revision B3
3 Descriptions of Input and Outputs –Technical Specifications
This section describes the video and audio interfaces on the 804/804A/804B instrument:
3.1 Video Interfaces - Technical Specifications
Table 3-1 below describes the video interfaces on the 804/804A/804B instrument, these interfaces are used to render test
patterns for testing consumer electronic HDTVs and computer displays.
Note: All video interfaces on the 804/804A/804B shall be connected to only SEL V / double insulated circuits of other devices.
Note: SPDIF and Optical audio input connectors are not available on the newer 804 and 804A units.
Table 3-1: 804/804A Video Interfaces
Video Connector
Description
HDMI (4) Output Type A
Menu Selection: HDMI
Bit Depth: 24/30/36 bit.
Video type: RGB, YCbCr.
Sampling: 4:4:4, 4:2:2 (and 4:2:0 for 4K formats on the 804A) .
Pixel rate (804): Timings up to 1080p60 (up to 165MHz).
Pixel rate (804A): HDMI timings up to 4K x 2K at 30Hz (up to 300MHz) as specified by the HDMI 1.4a
specification and 4K x 2K at 50/60Hz with 4:2:0 pixel encoding as specified by the HDMI 2.0 specification.
Pixel rate (804B): HDMI timings up to 4K x 2K at 50/60Hz (up to 600MHz) with 4:4:4 pixel encoding as
specified by the HDMI 2.0 specification.
Audio: LPCM, Dolby Digital and DTS (more details below).
Menu Selection: DVI for DVI Single Link (HDMI to DVI adapter cable).
Video type: RGB.
3 BNC
Menu Selection –Format Type: BNC + S-Video + CVBS (when ED/HD is selected)
Video type: YPbPr.
Bit Depth: 24 bit color depth.
Pixel rates: 27MHz, 27.027MHz, 74.176MHz, 74.25MHz (max 80MHz; resolutions greater than 80MHz
use pixel doubling).
Sync type: Composite.

804 Series Video Test Generator –User Guide
Page 7
Revision B3
VGA D-Sub
Menu Selection: VGA(HD15) Analog YPbPr for CE component analog.
Bit Depth: 24 bit color depth.
Video type: YPbPr (requires converter cable).
Pixel rates: 27MHz, 27.027MHz, 74.176MHz, 74.25MHz (max 80MHz; resolutions greater than 80MHz
use pixel doubling).
Pixel repetition to support higher pixel rates.
Sync types: Composite.
Menu Selection: VGA(HD15) Analog RGB for CE and IT component analog.
Bit Depth: 24 bit color depth.
Pixel rates (804/804A): 27MHz, 27.027MHz, 74.176MHz, 74.25MHz (max 80MHz; resolutions greater than
80MHz use pixel doubling).
Pixel rates (804B): 27MHz, 27.027MHz, 74.176MHz, 74.25MHz, 162MHz (max 162MHz).
Pixel repetition to support higher pixel rates.
Sync types: Separate.
(1) BNC CVBS & S-Video
Analog Composite Output
Menu Selection: BNC + S-Video + CVBS
Encodings: NTSC & PAL
Pixel Range: 13.5-13.52.
Sync type: Composite.
3.2 Audio Outputs - Technical Specifications
Table 3-2 below describes the audio outputs supported on the 804/804A/804B instrument.
Note: All audio interfaces on the 804/804A/804B shall be connected to only SEL V / double insulated circuits of other devices.
Table 3-2: 804/804A/804B Audio Outputs
Interface
Description
HDMI (4) Output Type A
Single link HDMI output connector. Supports the following HDMI features:
Channels: 8.
Bits per sample: 16, 20, 24.
Sampling rates (kHz): 32.0, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0.
Formats: LPCM, Dolby Digital, Dolby Digital Plus, DTS-ES.
LPCM formats - Frequency adjustment: 10Hz to 20kHz in 1Hz increments.
LPCM formats - Amplitude adjustment: -99dB to 0dB in 1dB increments.

804 Series Video Test Generator –User Guide
Page 8
Revision B3
Analog Audio
(2) RCA audio connectors:
Channels: 2 (L/R).
Signal: Sine Wave.
Frequency: 10Hz to 20kHz in 1Hz increments.
Amplitude: -99dB to 0dB in 1dB increments.
3.3 Audio Inputs –Technical Specifications
Table 3-3 below describes the audio inputs supported on the 804/804A/804B instrument.
Note: All audio interfaces on the 804/804A/804B shall be connected to only SEL V / double insulated circuits of other devices.
Table 3-3: 804/804A/804B Digital Audio Inputs
Note: These connectors and the associated functions, are not available on new 804, 804A and 804B units
Interface
Description
SPDIF - RCA
SPDIF RCA audio connector
Optical –JIS FO5
Optical audio connector
3.4 Control Interfaces and Devices –Technical Specifications
The following illustrations and Table 3-4 describe the control interfaces and devices on the 804/804A.
Note: All control interfaces on the 804/804A/804B shall be connected to only SEL V / double insulated circuits of other
devices.

804 Series Video Test Generator –User Guide
Page 9
Revision B3
Table 3-4: 804/804A/804B Control Interfaces and Devices
Interface
Function
RS-232
Command line control or control through Automated Test System (ATS). You can also connect a keypad to the RS-232 port for control
through a keypad. Keypad mode for the RS-232 interface is enabled or disabled through the Preferences menu.
USB Device
Updating firmware and gateware and command line control.
USB Host
Keyboard control.
SD Card
Updating firmware and gateware and loading bitmap test patterns.
3.5 Size and Weight
Table 3-5 provides the dimensions and weight of the 804/804A/804B:
Table 3-5: 804/804A/804B Dimensions and Weight
Parameter
Value
Height
3.25 inches; 8.3 cm
Width
16.5 inches; 41.9 cm
Depth
6.1 inches; 15.5 cm
Weight
6.62 lbs; 3.0 kg

804 Series Video Test Generator –User Guide
Page 10
Revision B3
3.6 Power Considerations
The 804/804A/804B has a rocker style power switch on the front panel and on the rear panel adjacent to the power line
connector. Both have to be on to operate the unit. Refer to the photos below.
Note: If the 804/804A/804B is used in a manner not specified in the guide, the protection provided by the equipment may be
impaired.
Table 3-6 provides the power requirements of the 804/804A/804B.
Table 3-6: 804/804A804B Power Parameters
Parameter
Value/Range
Volts, Power
100 –240 VAC, 24VA
Frequency
50Hz to 60Hz
3.7 Environmental Specifications
Table 3-7 provides the environmental requirements and ratings of the 804/804A/804B.
Table 3-7: 804/804A/804B Environmental Parameters

804 Series Video Test Generator –User Guide
Page 11
Revision B3
Parameter
Value/Range
Operating Temperature Range
0 –40 Deg C
Humidity
30% to 80%
Environmental IP rating
IP20

804 Series Video Test Generator –User Guide
Page 12
Revision B3
4 Installation Instructions
This section describes how to install the 804/804A/804B. The 804/804A/804B can be installed either as a desktop instrument
or it can be rack mounted in a standard 19 inch relay rack.
4.1 The 804/804A/804B Shipping Box
Table 4-1 below describes the video interfaces on the 804/804A/804B instrument, these interfaces are used to render test
patterns for testing consumer electronic HDTVs and computer displays.
Table 4-1: What is in the 804/804A/804B Shipping Box
Item
Part Number
(optional) Cable kit
95-00068
Mounting kit; either or both:
- 804 Desktop kit
(feet already installed)
- 804 Rack Mount Kit (not installed)
95-00066
95-00067
Power cord; one of:
- USA Power Lead
- European Power Lead
- UK Power Lead
30A00400A03
30-00174
30-00175
Quick Start Guide
68-00222
4.2 Ventilation Requirements
The 804/804A/804B has an internal fan and two vents, one in the front and the other in the rear. Please be sure that the vents
are not blocked with debris or by other equipment. Be sure to leave at least 4 inches of room between the 804/804A/804B
vents and any other equipment or object.
4.3 ESD Warning
Uncontrolled electrostatic discharge can damage sensitive electronic equipment. Please follow proper electrostatic control
procedures including using ground straps when working with the model 804/804A/804B. While the 804/804A/804B contains
circuitry to protect it from reasonable electrostatic discharge, it can still be damaged by excessive discharge. Moderate
discharge may degrade operation such as the user display. If that is observed, restarting the unit should eliminate the
problem.
4.4 Cleaning Considerations
Please be sure that the vents are not blocked with debris or dust. Periodically check to ensure that there is no dust or debris
blocking the ventilation openings of the 804/804A/804B.
4.5 Desktop Installation Instructions
If you have ordered the desktop option, the feet will be installed on the bottom of the 804/804A. There will be no mounting
ears included. There are no special installation instructions for a desktop application.
4.6 Rack mount Installation Instructions
If you have ordered the rack mount option, the unit will be shipped with the mounting ears attached but there will be no feet on
the bottom of the 804/804A/804B. You will need to screw the unit into the 19 inch rack using screws appropriate for the rack.
Quantum Data does not provide screws for this purpose.

804 Series Video Test Generator –User Guide
Page 13
Revision B3
5 Instructions for Use
This section provides the Instructions for Use for the 804/804A/804B describes power up and general operation.
Note: If the 804/804A/804B is used in a manner not specified in the guide, the protection provided by the equipment may be
impaired.
5.1 Powering up the 804/804A/804B
The procedures below describe how to power up the 804/804A/804B.
1. Connect the power cable provided with the 804/804A/804B to the connector on the back. Refer to the illustration below.
Note: Any replacement power cord that you use should be certified to the requirements in IEC 60799.
2. Apply power on the power connector switch on the back near the power connector.
3. Power up the 804/804A/804B using the rocker switch on the front panel.
5.2 Powering down and uninstalling the 804/804A/804B
In the event you have to remove the 804/804A/804B from its normal operating location, use the following instructions:
1. Power down the 804/804A/804B using the rocker power switch on the front of the unit.

804 Series Video Test Generator –User Guide
Page 14
Revision B3
2. Turn the power of using the rocker power switch on the back near the power connector.
3. Disconnect the power cable from the rear of the unit. Note that the power cord is easily accessible when fully plugged in
such that an operator can manually remove the power cord.

804 Series Video Test Generator –User Guide
Page 15
Revision B3
5.3 Front Panel Display
The 804/804A/804B has a 480(H) by 272(V), 24 bit color status display shown below. There are two modes of operation: 1)
Manufacturing mode enabled (Status only displayed) and 2) Manufacturing mode disabled (active touch panel display). When
Manufacturing mode is enabled, the display shows the following information:
Active format
Active test pattern
Active interface(s)
Keypad Status
RS-232 Baud Rate
S/W version
FPGA version
Table 5-1 below shows functions available in the top level menu.
Table 5-1: Top Level Menu
Item
Submenu - Pattern
Third Level Menu
Value
Top Menu Bar
Home
See Below
N/A
Preferences
Audible Touch
Off
On
Screen Brightness
Min
25%
50%
75%
Max
USB Mode
COM for commands
Disk for downloading files and upgrades
Startup Mode
Default –Use default menus on touch screen on startup.
Custom Menu –Use custom menus on touch screen on
startup.
AVmute on Format
Change
Enables or disables AVMute on the HDMI output when
there is a format change.
RS-232 Keypad Mode
Off –Keypad operation on the RS-232 interface is disabled.
On –Keypad on the RS-232 interface is enabled.
RS-232 Baud Rate
One of: 1200, 2400, 4800, 9600,14400,19200, 28800,
38400, 57600, 115200, 230400
Help
Upgrades
Erase
Update (Application Flash)
Update (FPGA Flash)
Function Buttons
Video Patterns
See below: Selecting Test Patterns
Audio Tones
See below: Testing HDMI Audio on an HDTV or A/V Receiver
3D Output

804 Series Video Test Generator –User Guide
Page 16
Revision B3
Tests
See below: Testing HDMI Protocols
Bottom Status Buttons
Signal Type
See below: Selecting a Signal Type
Resolution
See below: Procedures for selecting a resolution and frame rate
Video Pattern
See below: Selecting Test Patterns

804 Series Video Test Generator –User Guide
Page 17
Revision B3
5.4 Calibrating the LCD
You can calibrate the touch screen of your 780 if necessary.
Important Note: Please follow the procedures below carefully. Improper calibration can lock the unit up. It is preferable that
you contact Quantum Data Support unless you have learned how calibrated the screen properly.
Use the following procedures to perform the calibration.
1. From the Home menu, navigate to the Help menu by pressing the Help activation button on the upper status bar. The
Home menu is shown below.
The Help menu appears as shown below:
2. Touch select the Calibrate activation button to launch the calibration screen.
Alternatively you can initiate the calibration screen using the following command:
TCAL
The calibration screen instructs you to touch each of four red squares.

804 Series Video Test Generator –User Guide
Page 18
Revision B3
When you finish touch selecting the fourth box, the calibration is completed and you will return to the Home menu.
5.5 Front Panel LEDs
The 804/804A/804B has two LEDs on the front to indicate the status of the Tx and Rx activity of the RS-232 interface. Note
that when you send a command you will see the Tx and Rx lights on the 804/804A/804B front panel flash briefly.
5.6 Setting the 804/804A/804B Front Panel Mode
The 804/804A/804B front panel can be operated in one of two modes: 1) Touch screen mode and 2) 804/804A/804B
Manufacturing (Status only) mode. The Touch Screen mode enables you to fully operate the 804/804A/804B through the
color touch display. The procedures for operating the 804/804A/804B through the front panel are provided in the section
Running Protocol Tests - Using the Front Panel GUI.
Typically you would use the Manufacturing (status only) mode when you were operating the 804/804A/804B through the
command line via either a keypad or an automated test system.
Use the following procedure to set the 804/804A/804B front panel display mode.
1. Set the 804/804A/804B display mode to the Touch Screen mode using the following command.

804 Series Video Test Generator –User Guide
Page 19
Revision B3
MFGM 0
The front panel display will show the Home screen as shown in the following screen shot.
2. Set the 804/804A/804B display mode to the Manufacturing mode using the following command.
MFGM 1
The front panel display will appear as shown in the following screen (example only).

804 Series Video Test Generator –User Guide
Page 20
Revision B3
6 Using the 804 Series Command Line
This section provides procedures on controlling the 804/804A/804B through the command line for testing HDTVs. Refer to the
section entitled, Command Reference for a complete list of commands. You can connect from a PC either through an RS-232
cable or a USB cable.
6.1 Establishing an RS-232 connection to the 804/804A/804B
The procedures below describe how to connect to the 804/804A/804B through the RS-232 interface for command line control
or control from an automated test system.
1. Connect an RS-232 cable between your host PC and the 804/804A/804B. The illustration below shows the location of the
RS-232 interface.
2. (optionally) Connect USB cable between your host PC and the 804/804A/804B on the USB connector on the front. The
illustration below shows the location of the USB interface.
3. Download the .INF file from the Quantum Data website at:
http://www.quantumdata.com/support/804readme.asp#supplemental or
http://www.quantumdata.com/support/804Areadme.asp#supplemental to your PC and unzip the file. Store it in
a convenient location on your PC.
4. Set the USB mode to COM from the Preference menu as shown below. Reboot the 804/804A/804B if you changed this
USB mode from Disk to COM.
