Teledyne T3DSO1000 User manual

User Manual
T3DSO1000 Series Digital
Oscilloscope

User Manual I
Copyright and Declaration
Copyright
Teledyne LeCroy. All Rights Reserved.
Trademark Information
Teledyne Test Tools is the registered trademark of Teledyne LeCroy.
Declaration
Teledyne Test Tools products are protected by patent law.
Teledyne Test Tools reserves the right to modify or change parts of or all the
specifications or pricing policies at company’s sole decision.
Information in this publication replaces all previously corresponding material.
Any way of copying, extracting or translating the contents of this manual is not allowed
without the permission of Teledyne Test Tools.
Product Certification
Teledyne Test Tools guarantees this product conforms to national and industrial
standards and other international standards.
Contact Us
Teledyne LeCroy (US Headquarters)
700 Chestnut Ridge Road
Chestnut Ridge, NY. USA
10977-6499
Phone: [phone] or 845-425-2000
Fax Sales: 845-578-5985
Email Sales: [e-mail]
Email Support: [e-mail]
(Oscilloscopes, Waveform Generators, Signal Integrity)
Web Site: http://teledynelecroy.com/
Phone Support: 1-800-553-2769
Teledyne LeCroy (European Headquarters)
Teledyne LeCroy GmbH Im
Breitspiel 11c
D-69126 Heidelberg, Germany
Phone: + 49 6221 82700
Fax: [phone]
Fax Sales: [phone]
Fax Service: [phone]
Email Sales: [email protected]
Email Service: [email protected]m
Email Support: [email protected]
Web Site: http://teledynelecroy.com
Phone Service: [phone]
Phone Support: [phone]

II User Manual
Safety Information
General Safety Summary
Carefully read the following safety precautions to avoid any personal injury or
damage to the instrument and any products connected to it. To avoid potential
hazards, please use the instrument as specified.
Use Proper Power Line
Only the power cord designed for the instrument and country should be used.
Ground the Instrument
The instrument is grounded through the protective earth conductor of the power line. To
avoid electric shock, please make sure the instrument is grounded correctly before
connecting its input or output terminals.
Connect the Signal Ground Wire Correctly
The potential of the signal ground wire is equal to earth, so do not connect the signal
ground wire to a high voltage.
Look Over All Terminal Ratings
To avoid fire or electric shock, please look over all ratings and sign instructions of the
instrument. Before connecting the instrument, please read the manual carefully to gain
more information about the ratings.
Use Proper Overvoltage Protection
Make sure that no overvoltage (such as that caused by a thunderstorm) can reach the
product, or else the operator might be exposed to the danger of electrical shock.
Electrostatic Prevention
Operate in an electrostatic discharge protective environment to avoid damage induced by
static discharge. Always ground both the internal and external conductors of any cables to
discharge static before connecting.
Keep Ventilated
Inadequate ventilation may cause increasing product temperature, which will eventually
damage the instrument. So keep well ventilated and inspect the intake and fan regularly.
Avoid contact with Exposed Circuit or Components
Do not touch exposed contacts or components when the power is on.

User Manual III
Use proper Fuse
Use only the specified fuse.
Do Not Operate Without Covers
Do not operate the instrument with covers or panels removed.
Do Not Operate With Suspected Failures.
If you suspect damage occurs to the instrument, have it inspected by qualified service
personnel before further operations. Any maintenance, adjustment or replacement
especially to circuits or accessories must be performed by Teledyne Test
Tools authorized personnel.
Do Not Operate in Wet Conditions.
In order to avoid short circuiting the interior of the device or electric shock, please do
not operate in a high humidity environment.
Do Not Operate in an Explosive Atmosphere.
In order to avoid damage to the device or personal injuries, it is important to operate the
device away from an explosive atmosphere.
Keep Product Surfaces Clean and Dry.
To avoid the influence of dust and/or moisture in the air, please keep the surface of the
instrument clean and dry.
Handling Safety
Please handle with care during transportation to avoid damages to buttons, knob
interfaces and other parts on the panels.
Only probe assemblies which meet the manufacturer’s specifications shall be used.
When using 2X/…/10000X probe assemblies, the probe assemblies shall be insulated
from the measured circuits by double or reinforced insulation.
All probe assemblies should meet the requirements of UL 61010-031 and
CAN/CSA-C22.2 No. 61010-031-07.
If the equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.

IV User Manual
Safety Terms and Symbols
Terms in this Manual. These terms may appear in this manual:
WARNING
Warning statements indicate the conditions or practices that could
result in injury or loss of life.
CAUTION
Caution statements indicate the conditions or practices that could
result in damage to this product or other property.
Terms on the product. These terms may appear on the product:
DANGER Indicates direct injuries or hazards that may happen.
WARNING Indicates potential injuries or hazards that may happen.
CAUTION Indicates potential damage to the instrument or other property that may
happen.
Symbols on the product. These symbols may appear on the product:
Hazardous protective Earth Warning Test Power Switch
Voltage Terminal Ground
If find such symbols appear on the product, consult the manual to find out the nature
of the potential hazard and the actions which have to be taken.

User Manual V
Measurement Category
Measurement Categories
This oscilloscope can make measurements in circuits that are not directly connected
to mains.
WARNING
This oscilloscope can only be used for measurements within its specified
measurement categories.
Do not use the product for measurements within other measurement
categories, such as CAT II, CAT III, CAT IV.
Do not use the equipment for measurements on mains circuits
Measurement Category Definitions
Measurement category II is for measurements performed on circuits directly connected to
the low voltage installation. Examples are measurements on household appliances,
portable tools and similar equipment.
Measurement category III is for measurements performed in the building installation.
Examples are measurements on distribution boards, circuit-breakers, wiring, including
cables, bus-bars, junction boxes, switches, socket-outlets in the fixed installation, and
equipment for industrial use and some other equipment, for example. Stationary motors
with permanent connection to the fixed installation.
Measurement category IV is for measurements performed at the source of the low-voltage
installation. Examples are electricity meters and measurements on primary over current
protection devices and ripple control units.

VI User Manual
Working Environment
Temperature
Operating: 10℃ to +40℃
Non-operation:-20℃ to +70℃
Humidity
Under +35℃:≤90% relative humidity
+35℃ to +40℃: ≤60% relative humidity
WARNING
To avoid short circuit inside the instrument or electric shock, please do not
operate in humid environment.
Altitude
Operating: less than 3 Km
Non-operation: less than 15 Km
Degree of protection
IP20
Installation (over voltage) Category
This product is powered by mains conforming to installation (overvoltage) category II.
WARNING
Make sure that no over voltage (such as that caused by thunderbolt) can reach
the product, or else the operator might expose to the danger of electric shock.
Installation (over voltage) Category Definitions
Installation (over voltage) category I refers to signal level which is applicable to equipment
measurement terminals connected to the source circuit. In these terminals, precautions
are done to limit the transient voltage to the corresponding low level.
Installation (over voltage) category II refers to the local power distribution level which is
applicable to equipment connected to the AC line (AC power).

User Manual VII
Ventilation Requirement
This oscilloscope uses a fan for cooling. Please make sure that the air intake and
exhaust areas are free from obstructions and have free air. When using the oscilloscope
in a bench-top or rack setting, provide at least 10 cm clearance beside, above and behind
the instrument for adequate ventilation.
WARNING
Inadequate ventilation may cause temperature increase which would damage
the instrument. So please keep the instrument well ventilated during operation
and inspect the intake and fan regularly.

VIII User Manual
General Care and Cleaning
Care
Do not store or leave the instrument in direct sunshine for long periods of time.
WARNING
To avoid damage to the instrument or probe, please do not leave them in fog,
liquid, or solvent.
Cleaning
Please perform the following steps to clean the instrument and probe regularly according
to its operating conditions.
1. Disconnect the instrument from all power sources, and then clean it with a soft wet
cloth.
2. Clean the loose dust on the outside of the instrument and probe with a soft cloth.
When cleaning the LCD, take care to avoid scarifying it.
WARNING
To avoid damage to the surface of the instrument and probe, please do not
use any corrosive liquid or chemical cleanser.
WARNING
Make sure that the instrument is completely dry before restarting it to avoid
short circuits or personal injuries.

User Manual IX
Document Overview
This manual describes how to use the digital oscilloscope in detail.
Quick Start Provide information about preparation before
using the instrument and a brief introduction to
the instrument.
Set the Vertical System Introduce the functions of the vertical system of
the oscilloscope.
Set the Horizontal System Introduce the functions of the horizontal system
of the oscilloscope.
Set the Sampling System Introduce the functions of the sampling system
of the oscilloscope.
Trigger the Oscilloscope Introduce the trigger mode, trigger coupling,
trigger hold off, external trigger and various
trigger types of the oscilloscope.
Serial Trigger Introduce how to trigger on serial input signals.
Save Reference Waveforms Introduce how to save and display REF
waveforms.
How To Make Math Operations Introduce the math operation function of the
oscilloscope.
How To Make Cursor Measurements Introduce how to use cursors to make
measurements.
How To Use Measurement Functions Introduce how to use the measurement function
to measure the waveform parameters.
Display Settings Introduce how to set up the oscilloscope
display.
Save and Recall Introduce how to save and recall the
measurement result and the settings of the
oscilloscope.
System Settings Introduce how to adjust the system setup.
Default Introduce the Default setup of the oscilloscope
Troubleshooting Introduce how to deal with common failures of
the oscilloscope.
