T3DSOH1000 and T3DSOH1000-ISO
Handheld Oscilloscope
User Manual

1 T 3 D S O H 1 0 0 0 / I S O U s e r M a n u a l
Copyright Information
Declaration
© 2023 Teledyne LeCroy, Inc. All rights reserved.
Teledyne Test Tools is a brand and trademark of Teledyne LeCroy, Inc. Other product or brand names are
trademarks or requested trademarks of their respective holders. Specifications, prices, availability and delivery
subject to change without notice.

2 T 3 D S O H 1 0 0 0 / I S O U s e r M a n u a l
Contents
COPYRIGHT INFORMATION.............................................................................................................1
GENERAL SAFETY SUMMARY ........................................................................................................4
SAFETY TERMS AND SYMBOLS .....................................................................................................6
MEASUREMENT CATEGORY DEFINITIONS ...................................................................................6
WORKING ENVIRONMENT .............................................................................................................11
GENERAL CARE AND CLEANING .................................................................................................12
QUICK START ..................................................................................................................................13
INTRODUCTION OF SCOPE PANEL ..............................................................................................17
INTRODUCTION OF METER PANEL ..............................................................................................22
INTRODUCTION OF RECORDER PANEL ......................................................................................24
INTERFACE GLANCE......................................................................................................................27
VERTICAL SYSTEM.........................................................................................................................28
HORIZONTAL SYSTEM ...................................................................................................................34
ACQUISITION SYSTEM ...................................................................................................................37
TRIGGER ..........................................................................................................................................52
TRIGGER TYPE................................................................................................................................60
SERIAL TRIGGER AND DECODE...................................................................................................83
REFERENCE WAVEFORM ............................................................................................................ 111
MATH...............................................................................................................................................114
CURSORS.......................................................................................................................................127
MEASURE.......................................................................................................................................130
DISPLAY..........................................................................................................................................139
SAVE AND RECALL.......................................................................................................................146
SYSTEM SETTING .........................................................................................................................154
SEARCH..........................................................................................................................................166

3 T 3 D S O H 1 0 0 0 / I S O U s e r M a n u a l
FACTORY SETUP...........................................................................................................................192
TROUBLESHOOTING....................................................................................................................192
COMPLIANCE INFORMATION ......................................................................................................194

4 T3DSOH1000/ISO User Manual
General Safety Summary
This document contains information and warnings that must be followed by the user to
ensure safe operation and to keep the instrument in a safe condition. Use of this
equipment in a manner not specified by the manufacturer may impair protection provided
by the equipment. Review the following safety precautions to avoid injury and prevent
damage to this product or any products connected to it. To avoid potential hazards, use
this product only as specified.
Safety Precautions
•Use only as Specified. The product can only be operated under the safe
conditions and positions specified by the manufacturer.
•Use only within operational environment listed. When powered by a power
adapter, the product can only be used indoors. Do not use this product in or
near a heat source, and the ambient temperature cannot exceed the maximum
temperature in the document or datasheet.
•Use only accessories compatible with the product. Use only the power
adapter, battery, probes and accessories specified by the manufacturer.
•Do not damage the insulation protection layer of the product and
accessories. Doing so may cause electric shock.
•Do not operate with suspected failures. Ensure the power cords and the
probes are in good condition before use. If the power cords or the probes are
damaged, do not use the product.
•Voltages higher than 30 V RMS, or 42 V peak, or 60 V DC are regarded as
hazardous contact voltages. When working with hazardous contact voltages,
use protective measures to preclude direct contact with the measurement setup:
oDo not touch exposed connections and components when power is
applied.
oUse only insulated voltage probes, test leads and adapters.
•Do not remove the product casing. Removing the cover or any part of the
shell while the product is in operation will expose circuits and components and
may cause personal injury, fire, or damage to the product.

5 T3DSOH1000/ISO User Manual
•Do not operate the instrument in wet, damp or explosive atmospheres. Make sure
that all connectors are completely dry before connecting the inputs
Battery Usage
This product contains a rechargeable lithium battery pack. If misused, there is a risk of
explosion, fire and / or serious personal injury, and even death in some cases. Please
observe the safety precautions before operating the product.
•The battery should not be disassembled or crushed.
•The battery or battery pack should not be exposed to high temperature or fire.
Keep the battery clean and dry. Use a dry, clean cloth to clean contaminated
connectors.
•The battery or battery pack should not be short-circuited.
•Batteries or battery packs should not be stored in an environment that can easily
cause a short circuit, such as boxes and drawers containing metal debris.
•Batteries and battery packs should not be exposed to any mechanical shock that
exceeds the allowable level.
•If the battery leaks, do not let the liquid contact the skin or eyes. If contact occurs,
wash the contact area with plenty of water and seek medical assistance.
•Use the power adapter specified by Teledyne Test Tools.
•Charge the product in a well-ventilated room. Ensure the product is not covered
by objects (such as blankets, towels, clothes) during charging, which will affect
the heat dissipation effect and cause a serious fire.
•Improper battery replacement may cause an explosion. For the reliability and
safety of the oscilloscope, always use the replacement battery specified by
Teledyne Test Tools.
•Used batteries and battery packs must be recycled and separated from residual
waste. Batteries contain hazardous waste, and local regulations on waste
disposal and recycling must be followed.

6 T3DSOH1000/ISO User Manual
Safety Terms and Symbols
The meaning of symbols
symbol
meaning
symbol
meaning
Warning
Power Switch
Hazardous Voltage
Equipment meeting double
insulation or reinforced
insulation
Earth Ground
Indoor use only
Lithium battery failure
EU label for separately
recycled electrical and
electronic equipment
Measurement Category Definitions
IEC61010-2-030 defines the measurement category to rate the ability of measuring
instruments to withstand short-term transient overvoltage outside of the working voltage.
This product and its accessories can only be used in the environment of the nominal
measurement category.
Measurement Category III (CAT III) applies to test and measuring circuits connected to
the distribution part of the building’s low-voltage mains installation.
Measurement Category II (CAT II) applies to test and measuring circuits connected
directly to utilization points (socket outlets and similar points) of the low-voltage mains
installation.
‘O’ - No Rated Measurement Category applies to other circuits that are not directly
connected to the mains supply.

7 T3DSOH1000/ISO User Manual
T3DSOH1000 Measurement Category
T3DSOH1000 can work under the measurement category listed in the table below.
Observe all voltage and current ratings of the instrument, the probes, and the
accessories. The lowest rated component defines the rating of the complete
measurement setup.
T3DSOH1000
Max Input Voltage
At BNC Input
CAT II 300Vrms Between BNC Signal and BNC GND.
CAT II 300Vrms Between BNC Signal and Protective Earth.
CAT II 30Vrms Between BNC GND and Protective Earth.
With Probe
CAT II 300Vrms Between Probe Signal and Probe GND.
CAT II 300Vrms Between Probe Signal and Protective Earth.
CAT II 30Vrms Between Probe GND and Protective Earth.
Multimeter
CAT III 300Vrms, CATII 600Vrms.
SCD10A*
60Vrms.
SCD600MA*
60Vrms.
*SCD10A is a 10A current adapter for the Multimeter to measure a current up to 10A.
SCD600MA is a 600mA current adapter for the Multimeter to measure a current up to
600mA. Refer to the DCI/ACI chapter for more information.

8 T3DSOH1000/ISO User Manual
INPUT A INPUT B
System GND
Protecting GND
CAT II 300V
CAT II 30V
CAT II 300V
CAT II 30V
Probe Input BNC Input
Measurement Category for T3DSOH1000 Scope
COM V
Ω
Meter
Input
CAT III 300V
CAT II 600V
CAT III 300V
CAT II 600V CAT III 300V CAT II 600V
Protecting GND
Measurement Category for T3DSOH1000 Multimeter
WARNING
Electrical Shock Hazard!
The reference ground of T3DSOH1000 series CH1 and CH2 are connected
together and hence share a common ground. Please use caution when
connecting a voltage higher than 30Vrms. Connecting higher voltage on
one channel and touching the other will result in an electric shock.
Protective Earth
Protective Earth
Multimeter
Input

9 T3DSOH1000/ISO User Manual
T3DSOH1000-ISO Measurement Category
T3DSOH1000-ISO can work under the measurement category listed in the table below.
Observe all voltage and current ratings of the instrument, the probes, and the
accessories. The lowest rated component defines the rating of the complete
measurement setup.
T3DSOH1000-ISO
Max Input Voltage
At BNC Input
CAT III 300Vrms Between BNC Signal and BNC GND.
CAT III 600Vrms/CAT II 1000Vrms Between BNC Signal and
Protective Earth.
CAT III 600Vrms/CAT II 1000Vrms Between BNC GND and
Protective Earth.
With Probe
CAT III 600Vrms, CAT II 1000Vrms.
Multimeter
CAT III 600Vrms, CAT II 1000Vrms.
SCD10A*
60Vrms.
SCD600MA*
60Vrms.
*SCD10A is a 10A current adapter for the meter using to measure a current up to 10A,
SCD600MA is a 600mA current adapter for the meter using to measure a current up to
600mA. Refer to the DCI/ACI chapter for more information.

10 T3DSOH1000/ISO User Manual
INPUT A INPUT B
CAT III 600V
/CAT II 1000V
CAT III 600V
/CAT II 1000V
GND A GND B
Protecting GND
Probe Input BNC Input
CAT III 300V
CAT III 600V
/CAT II 1000V
Measurement Category for T3DSOH1000-ISO Scope
COM V
Ω
Meter
Input
CAT III 600V
CAT II 1000V
CAT III 600V
CAT II 1000V
CAT III 600V
CAT II 1000V
Protecting GND
Measurement Category for T3DSOH1000-ISO Multimeter
Multimeter
Input
Protective Earth
Protective Earth

11 T3DSOH1000/ISO User Manual
Working Environment
General requirement
Environment
This product is intended for indoor use and should be operated in a clean, dry
environment.
It can be stored in a waterproof/dustproof environment rated up to IP51.
Temperature
Operating: 0℃ to +40℃
Not operating:-20℃ to +60℃
Note: Direct sunlight, radiators, and other heat sources should be taken into account
when assessing the ambient temperature.
Humidity
85% RH max up to 30 ℃, derates to 75% RH max above 30℃ and 45% RH max above
40℃
Altitude
Operating: less than 2 Km
Non-operation: less than 5 Km
Pollution Degree
The product should be operated in environments of Pollution Degree II.
Note: Pollution degree II refers to a working environment which is dry and non-
conductive pollution occurs. Occasional temporary conductivity caused by condensation
is expected.
IP Rating
IP51 (as defined in IEC 60529).

12 T3DSOH1000/ISO User Manual
AC Power Requirement
The power adapter operates with a single-phase, 100 to 240 Vrms (+/-10%) AC power
at 50/60 Hz (+/-5%).
Depending on the type and number of options and accessories (probes, PC port plug-
in, charging etc.), When powered by adapter, the product can consume up to 35 W of
power.
Use the power cord and adapter provided by the manufacturer. Use of other non-
designated products may cause personal injury.
General Care and Cleaning
Care
Do not store or leave the instrument in direct sunshine for extended periods of time. To
avoid damages to the instrument or probes, please do not expose them to fog, liquid, or
solvents.
Cleaning
Please perform the following steps to clean the instrument and probes regularly in
accordance with its operating conditions.
Disconnect the instrument from all power sources and then clean with a soft wet cloth.
Clean the loose dust on the outside of the instrument and probe with a soft cloth. When
cleaning the LCD, take care to avoid scratching it.
To avoid damage to the surface of the instrument and probe, please do not use any
corrosive liquid or chemical cleansers.
Make sure that the instrument is completely dry before restarting it to avoid potential
short circuits or personal injury.

13 T3DSOH1000/ISO User Manual
Quick Start
Product Appearance
T3DSOH1000
T3DSOH1000-ISO

14 T3DSOH1000/ISO User Manual
Battery Installation
To protect the battery from over discharging, the battery may be delivered separately.
Please install the battery before use as follows:
1. Remove the three screws on the battery cover with a screwdriver, as shown in Figure
1.
2. Remove the battery cover, as shown in Figure 2.
3. Put the battery into the battery slot, as shown in Figure 3.
4. Lock the screws with the screwdriver, as shown in Figure 1, and then turn on the
oscilloscope to check whether the battery is installed successfully.
5. Connect the DC-DC adapter to the connector on the left side (top view) of the
oscilloscope and fully charge the battery.
Figure 1
Figure 2
Figure 3

15 T3DSOH1000/ISO User Manual
Measurement Connection
The T3DSOH1000 and T3DSOH1000-ISO series handheld oscilloscope measurement
accessories include oscilloscope probes, multimeter probes, current adapters.
1. Oscilloscope probe
All oscilloscope probes should be properly compensated before their first use with the
oscilloscope. The following steps illustrate the proper probe compensation procedure.
1) Connect probe to the CH1 Input Terminal and the Compensation Signal Output
Terminal on the right side panel.
2) Check the displayed waveforms and compare them with the following figure.
3) Adjust the probe until the waveform matches the "Compensated Correctly” waveform
above.
Under
Compensated
Compensated
Correctly
Over
Compensated

16 T3DSOH1000/ISO User Manual
2. Multimeter probe
Before using the multimeter probe, please select the measuring range of the multimeter
first, then plug the red probe and black (grounding terminal) probe into the corresponding
input terminals according to the marking prompt of the front panel. When measuring the
current, please select the correct accessories according to the current.
3. Current Adapter
To test current, insert a current adapter between the meter input and the meter probe.
There are two different adapters, SCD600MA and SCD10A, which have built-in sampling
resistors and fuses, and can be used with the multimeter's mA meter and A meter
respectively.

17 T3DSOH1000/ISO User Manual
Introduction of Scope Panel
LCD Display
Trigger Control
Menu Softkey
Single function Control Buttons
Multifunction Control Buttons
Power Button
Universal Knob
Multimeter Inputs
Vertical Control
Oscilloscope Analog Inputs
Horizontal Control

18 T3DSOH1000/ISO User Manual
Vertical Control
Analog channel on/off or channel is selected to change.
Push to increase the vertical scale of selected channel
Push to decrease.
Push to increase the vertical offset of selected channel
Push to decrease.
When is lit, press to set offset to zero quickly.
Horizontal Control
Push to increase the timebase
Push to decrease
Push to move the waveform to left
Push to move to right.
When is lit, press to set delay to zero
quickly.
Trigger Control
Push to open trigger menu. This
oscilloscope provides various trigger
types. Detailed usage of trigger control is
described in the user manual.
Push to light up the button light, adjusting
the universal knob can change the trigger
level
Universal Knob
During menu operation, when the light in the upper left corner of the knob is
on, you can turn the knob to select among the submenus under the current
menu, and press down to select the current submenu. Additionally, it can also
be used to modify parameters and input filenames.

19 T3DSOH1000/ISO User Manual
Introduction of Multi function Menu
Button
Description
Shift
Press to illuminate the button light, and then by pressing the
multifunction button one can activate the alternate function shown
above the function button.
When the shift light is off, press these buttons to enter/exit the following functions.
Scope
Push this button to enter the scope mode.
Meter
Push this button to enter the meter mode. It provides eight
measurement types.
Recorder
Push this button to enter the recorder mode. It provides two modes,
Sample Logger and Measurement Logger.
Measure
This menu provides various measurement types and measurement
statistics functions.
Cursors
This menu provides manual and track cursor mode.
Print
Quick print picture. It is preferentially stored in USB flash disk or local
path.
Menu On/Off
Controls the hiding and display of the screen menu.
Clear Sweeps
Press this button to clear the measurement statistics, clear the
persistence, refresh the waveform and other clear functions.
When the shift light is on, press these buttons to enter/exit the following functions.
Search
This button opens the search function. It can search the acquired
data for a user-specified event, which is displayed with a black
triangle symbol.
History
This button opens the history function. In history mode, It can record
up to 80000 frames of waves.
Navigate
This button opens the navigate function. It supports three navigate
types: time, search event, history frame.
