  9. Tern QuadStruts User manual

Tern QuadStruts User manual

Lockstand QuadStruts™
How to Install
Tools Required (not included)
• 3 mm, 4 mm, 6 mm and 8 mm Allen Wrenches
• 8 mm, 10 mm, 13 mm and 17 mm Open Wrenches
To ensure a successful installation, please note the following:
All bolts must be tightened to the appropriate torque.
During the installation process, keep the QuadStruts Legs in the folded position and DO NOT CUT THE CABLE TIES on the spring until instructed.
Check that both tires have a pressure between 40-55 psi.
Identify the left and right QuadStruts Legs. The left leg should be attached to the non-drive side and the right leg should be
attached to the drive side of the bike. Make certain that during installation each leg is attached to the proper side.
The Lockstand Extensions should be installed on the Atlas Lockstand before installation of the Lockstand QuadStruts.
Add anti-seize lubricant to the tip of the bolts before securing the nuts. If anti-seize lubricant is not
available, apply any standard lubricant to reduce friction and prevent thread galling.
For installation on GSD Gen 2 bikes equipped with a derailleur, please shift to the lowest gear.
What’s Included
1. QuadStruts Leg x 2
2. QuadStruts Linkage Rod x 2
3. M6 Bolt Set x 2
4. M8 Bolt Set x 2
5. M10 Bolt Set x 2
If you are unsure how to install this
product, please visit your local dealer.
Please read the instructions
carefully before starting.
The Lockstand QuadStruts can only
be installed on GSD Gen 2 bikes.
ternbicycles.com
8 mm
3 mm
• Ruler
• Scissors
1
43
5
2
RightLeft
1. Install the Lockstand Extensions (sold separately). 2. Remove the plastic plate from the lower deck on the drive side.
17 mm
8 mm
3. Install the right QuadStruts Leg.
5
Torque: 35-40 Nm
10 mm
4 mm
4. Attach the Linkage Rod to the Atlas Lockstand.
3
Torque: 8-9 Nm
6. Rotate the bearing on the end of the Linkage
Rod to adjust the length of the rod.
4
7. Attach the Linkage Rod to the QuadStruts Leg and tighten the bolt by hand.
Lockstand QuadStruts
Atlas Lockstand
Lockstand Extensions
5. Cut the cable tie on the spring.
Scan to view
additional info
Hardware Detail
M6 x 25 Bolt
M6 x 13 x 1 Washer
M6 Nylon Nut
M6 Custom bushing
M8 x 30 Bolt
M8 x 15.9 x 1.5 Washer
M8 Nylon Nut
M10 x 25 Bolt
M10 x 22.2 x 1 Washer
M10 Nylon Nut
3:
4:
5:
Tire pressure must be between
40 - 55 psi and the distance
between the Dome Head Bolt
on the QuadStruts Leg (Gap
B) and the ground must be
properly set in order for the
QuadStruts to function. The
amount of ground clearance will
depend upon total load weight.
Sidekick™Wide Decks
LIMITED PRODUCT WARRANTY INFORMATION: This Product comes with a ONE (1) YEAR Limited Warranty from the date of retail purchase
by the original end-user. If a material or workmanship defect arises and a valid claim is received within the Warranty Period, this Product will be
replaced. Mobility Holdings cannot be held liable for damages to personal property due to misuse or improper care and maintenance. This Product
Warranty does not, under any circumstance, cover the replacement or cost of any third party product used with or connected to the Product.
Tern, the Tern Werd (logotype), the Tern Berd (device), Lockstand and QuadStruts used alone or in combination
are trade names, trade devices or registered trademarks of Mobility Holdings, Ltd.
© 2022. Tern is a trademark of Mobility Holdings, Ltd. All Rights Reserved.
ternbicycles.com
@ternbicycles
ternbicycles.com
How to Adjust Ground Clearance
Make sure the bike is unloaded and on flat ground before making any adjustments.
Make sure that both tires have a pressure between 40-55 psi.
Do not adjust the length of the Linkage Rod. Adjustments should be made in Steps 6-8.
Safety
• Important: Do not exceed the max load limit of 100 kg (220 lb). Please remember the max load limit for both the Atlas
Lockstand and Lockstand QuadStruts includes the total weight of the bike, accessories, cargo and passengers.
• Never leave passengers or pets on a parked bike unattended.
Before Riding
• Using and riding a heavily-loaded GSD is quite different than riding without any additional weight. To become familiar with riding with
a load, gradually add heavier items to the bike. Then ride in a safe location to get a feel how to balance with the additional weight.
• Check that both tires have a pressure between 40-55 psi.
• Check to ensure accessories have been correctly installed and securely fastened.
To Engage the Lockstand QuadStruts
• Hold the handlebar with both hands, use your foot to push the Lockstand Extensions toward the ground and then pull the bike backwards.
• When the bike starts to move up and over the Altas Lockstand, pull back until you feel resistance.
Then push the handlebar downwards until the Altas Lockstand is locked.
• Ensure the Atlas Lockstand is locked before removing your hands.
To Disengage the Lockstand QuadStruts
• Hold the handlebar with both hands, press the remote unlock lever and push the bike forward.
To Park the GSD Vertically
• Disengage the Lockstand QuadStruts before parking the GSD vertically.
8. Measure the distance between the QuadStruts Leg and the frame (Gap A). The recommended clearance is
1-5 mm. Readjust the length of the Linkage Rod as shown in Step 6 until Gap A is 1-5 mm.
If the gap is too wide, the Lockstand Extensions might bottom out while cornering.
A
4
9. Fully tighten the M8 bolt set to the Linkage Rod.
13 mm
13 mm
6 mm
Torque: 18-20 Nm
8 mm
3 mm
11. Reinstall the top plastic
plate on the lower deck.
10. Fully tighten the Nut
on the Linkage Rod.
12. Install the left QuadStruts Leg on the non-
drive side by following Steps 2-11.
13. Adjust the ground clearance on both sides.
17 mm
1. Adjust the length of the Dome Head Bolt until it touches the ground.
2. Loosen the middle M10 nut to create a gap above the rubber spacer. Refer to the table above to determine the height of the gap.
3. Rotate the Dome Head Adjustment Bolt until the rubber spacer touches the upper portion of the Leg.
4. Tighten the middle M10 nut to 20-25 Nm.
Do not rotate the Dome Head Bolt.
Only tighten using the middle M10 nut.
17 mm
1 2 3 4
B
B
Total Load Weight Ground Clearance (Gap B)
30 - 60 kg (66-132 lb) 8 mm (0.32”)
> 60 kg (>132 lb) < 8 mm (<0.32”)
B
How to Use the Lockstand QuadStruts
Torque: 10-12 Nm
