Timago JMC-C 5300KD User manual

1
INSTRUCTIONS FOR USE
Toilet safety rail
Product code: JMC-C 5300KD
1. Characteristics
Toilet safety rail is made of ultra light anodized aluminium. It is height
and width adjustable in order to meet user’s needs.
The set includes:
•Left frame
•Right frame
•Connector
Elements of the commode chair:
a. armrest
b. width adjustment
c. mounting element
d. height adjustment – locking pin
e. anti-sliding tips
2. Application
Toilet safety rail is ancillary equipment which helps the user to perform
physiological activities. The rail is recommended to people with
dysfunctions and for those who lost the ability of unassisted sitting
down and standing up. Owing to height and width adjustment, the
frame can be adjusted to the size of the toilet.
3. Assembly
•Firstly, disassemble toilet seat; unscrew mounting screws of the
toilet bowl.
•Place mounting element of the toilet rail so that it matches with
the mounting openings of the toilet bowl.

2
•Install frame of the toilet rail.
•To adjust the width, press the metal pin at the mounting element,
select appropriate width, and lock the position of the tubes
relative to each other.
•To adjust the height, press the metal pin in the leg, select
appropriate height, and lock the position of the tubes relative to
each other.
•Assemble the toilet seat.
Note! The pins must be set on the same level in each leg. Legs should
stand stably on the ground.
4. Technical data
Overall width
53-63 cm
Overall depth 44 cm
Height 64-74 cm
Seat dimensions 47 cm x 42 cm
Weight 0.4 kg
Maximum capacity 100 kg
Frame colour silver
5. Notes
Timago International Group does not bear responsibility of improper
use of the toilet safety rail, failure to comply safety regulations and
misuse.
6. Maintenance
Reviews
Systematically make visual inspection of all the joining elements
(clamps, hinges) including:
•the condition of locking pins
•stability and look of the frame

3
Cleaning
Control the technical condition of the toilet safety rail regularly:
•Clean the rail regularly using only water and mild detergents. Dry
thoroughly.
•Do not use for cleaning: strong polishing agents and detergents,
abrasive agents, bleach, petrol or solvents (it may cause frame
damage, visible defects and in consequence - loss of warranty
rights).
7. Storage and transport conditions
Device should not be exposed to direct sunlight, water or moisture.
8. Warranty information
All products distributed by our company are covered by a warranty, the
terms of which are described in the warranty card available on our
website. Please contact the retailer from whom you purchased the
product. Please, keep in mind that for warranty purposes, the proof of
purchase (receipt or invoice) should be retained
9. Labels
Reference
number
Manufacturer
LOT number Manufacture date
Serial number Medical device
Note
Please read the
instruction
The manufacturer checked for compliance with
essential medical devices requirements.

4
Our complete line of products is available from our distributors.
Learn more at: www.timago.com. Thank you for choosing Timago!
Timago International Group
Spółka z o.o. i Spółka – Spółka komandytowa
ul. Karpacka 24/12
43-316 Bielsko-Biała, Polska
T.: [phone]
F.: [phone]
E.: [e-mail]
Rev. II, date 20.05.2021
