Titan TTB773HTG User manual

EN
Original Instructions_TTB773HTG
TTB773HTG
2000W Heat Gun
EAN: 5059340118321
WARNING: Read the instructions before using the product!
BX220IM
_GB_V5_220117

EN
02
29
28
26
21
19
In more detail...
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
18
02
03
13
14
14
Getting started...
Technical and legal information
Your product
Technical specications
Before you start
These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Let’s
get started...
30
Guarantee

EN
TTB773HTG by TITAN
Getting started...
03
Safety information
Safety warnings
1. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
2. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.
3. If the supply cord is damaged, it must be replaced by
persons in order to avoid a hazard.
General power tool safety warnings
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.

EN
04
Getting started...
Safety information
Safety warnings
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
A
moment of inattention while operating power tools
may result in serious personal injury.
TTB773HTG by TITAN

EN
Getting started...
05
Safety information
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
3. Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your nger on the
switch or energising power tools that have the switch
on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
in personal injury.
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
Power tool use and care
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
2. Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
TTB773HTG by TITAN

EN
06
Getting started...
Safety information
Safety warnings
3. Disconnect the plug from the power source before
making any adjustments, changing accessories,
or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool
accidentally.
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users.
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
Service
1. Have your power tools serviced by a qualied
repair person using only identical replacement
parts. This will ensure that safety of the power tool is
maintained.
TTB773HTG by TITAN

EN
Getting started...
07
Safety information
Safety warnings for heat gun
1. The tool must be placed on its stand when not in use.
2. A re may result if the product is not used with care,
therefore
be careful when using the product in places where
there are combustible materials;
do not apply to the same place for a long time;
do not use in presence of an explosive atmosphere;
be aware that heat may be conducted to combustible
materials that are out of sight;
place the product on its stand after use and allow it
to cool down before storage;
do not leave the product unattended when it is
switched on.
Additional safety warnings for heat gun
1. Keep other people as well as pet out of the working
area during operation and before the work area is
cleaned thoroughly.
2. Do not use the product near ammable liquids or in
explosive atmospheres, such as near fumes, gases or
dust. The ameless heat from the product may ignite
the dust or fumes. Remove materials or debris that
may become ignited from work area.
3. Hidden areas such as behind walls, ceilings, oors,
soft boards and other panels may contain ammable
materials that may ignite when using the product in
these locations. Ignition of these materials may not be
readily apparent and could result in property damage
and personal injury. Check these areas before applying
heat. If in doubt, use a different method.
4. Keep away from the hot air outlet. This product
releases an air stream of high temperature that can
cause serious burns and personal injury.
TTB773HTG by TITAN

EN
08
Safety information
Getting started...
Safety warnings
5. Clean up all paint scrapings and dust. Do not sweep,
dry dust or vacuum to avoid the paint dust will be thrown
up into the air where it can be inhaled or contaminate
other areas. Wet mop oors. Use a wet cloth to clean
all walls, sills and other surfaces where paint and dust
have accumulated.
6. Dispose of paint scrapings properly.
7. Do not obstruct either the air vents or nozzle outlet,
as this may cause excessive heat build up resulting in
damage to the product.
8. Do not direct the hot air blast at persons.
9. Do not aim the hot airow at the same area for prolonged
periods. Working with plastic, paint, varnish or similar
materials may produce easily ammable gases.
10. Safely place the power tool on the storage surfaces
after use and let it cool completely before packing it
away. The hot nozzle can cause damage.
11. Do not leave the switched-on power tool unattended.
12. Keep your work area well-ventilated. The gas and
steam produced during work are often harmful to one’s
health.
13. Do not use the power tool as a hair dryer or attempt to
dry pets.
14. The distance between the nozzle and the workpiece
depends on the material you are working on (metal,
plastic, etc.) and the intended working method. Always
test the amount of air and temperature rst.
15. If operating the power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
TTB773HTG by TITAN

EN
Getting started...
09
Safety information
16. Safety Warnings for stripping paint. Before stripping
any paint, you should determine whether the paint
contains any lead. Paint containing lead should be
removed by a professional and not by using a heat
gun.
17. Ideally move the workpiece to an outdoor location.
If this is not possible, ensure the work area is well
ventilated.
18. Wear an approved dust respirator mask or dual lter
mask for dust and fumes. Ensure that the mask ts
properly. Disposable paper masks are not adequate.
19. Keep the gun moving when in use to avoid excessive
heat build up.
20. Keep food and drink out of the work area. Wash hands
and face thoroughly before eating or drinking.
The following information applies to professional users
only but is good practice for all users:
Vibration and noise reduction
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and
low-noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
1. Only use the product as intended by its design and
these instructions.
2. Ensure that the product is in good condition and well
maintained.
3. Use correct attachments for the product and ensure
they are in good condition.
4. Keep tight grip on the handles/grip surface.
5. Maintain this product in accordance with these
instructions and keep it well lubricated (where
appropriate).
TTB773HTG by TITAN

EN
Getting started...
10
Safety information
Safety warnings
6. Plan your work schedule to spread any high vibration
tool use across a longer period of time.
7. Prolonged use of the product exposes the user
to vibrations that can cause a range of conditions
collectively known as hand-arm vibration syndrome
(HAVS) e.g. ngers going white; as well as specic
diseases such as carpal tunnel syndrome. To reduce
this risk when using the product, always wear protective
gloves and keep your hands warm.
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
1. Always be alert when using this product, so that
you can recognise and handle risks early. Fast
intervention can prevent serious injury and damage to
property.
2. Switch off and disconnect from the power supply if
there are malfunctions. Have the machine checked
by a qualied professional and repaired, if necessary,
before you operate it again.
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers
can arise in connection with the structure and design
of this product:
1. Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
TTB773HTG by TITAN

EN
Getting started...
Safety information
11
2. Injuries and damage to property due to broken
attachments or the sudden impact of hidden objects
during use.
3. Danger of injury and property damage caused by ying
objects.
WARNING! This product produces an
electromagnetic eld during operation! This eld
may under some circumstances interfere with
active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!
Symbols
On the product, the rating label and within these instructions you will nd among
others the following symbols and abbreviations. Familiarise yourself with them to
reduce hazards like personal injuries and damage to property.
V~ Volt, (alternating voltage)
Hz Hertz
W Watt
/min or min-1 Per minute
mm Millimetre
kg Kilogram
dB(A) Decibel (A-rated)
yyWxx Manufacturing date code; year of manufacturing (20yy) and week
of manufacturing (Wxx).
Lock / to tighten or secure.
Unlock / to loosen.
Note / Remark.
Caution / Warning.
TTB773HTG by TITAN

EN Safety information
Getting started...
12
Symbols
Read the instruction manual.
Wear hearing protection.
Wear eye protection.
Wear respiratory protection.
Wear protective gloves.
Switch the product off and disconnect it from the power supply
before assembly, cleaning, adjustments, maintenance, storage
and transportation.
Hot surface!
This product is of protection class II. That means it is equipped
with enhanced or double insulation.
The product complies with the applicable European directives and
an evaluation method of conformity for these directives was done.
WEEE symbol. Waste electrical products should not be disposed
of with household waste. Please recycle where facilities exist.
Check with your Local Authority or local store for recycling advice.
TTB773HTG by TITAN
UK Conformity Assessed.

EN
Getting started...
13
Your product
Your product
11
10
9
8
7a
12
3
4
5
6
7
7b
1. Hot air outlet
2. Air vents
3. Stand
4. On/off switch
5. Handle
6. Power cable with
hanging hook
7. Scraper
a. Blade
b. Handle
8. Concentrator nozzle
9. Spreader nozzle
10. Glass protector nozzle
11. Reector nozzle
TTB773HTG by TITAN

EN
Getting started...
14
Technical specications / Before you start
Technical specications
General
> Rated voltage/frequency : 220 – 240 V ~ / 50 Hz
> Rated input : 2000 W
Temperature/air ow setting
> Switch position I : 50 °C
> Switch position II : 450 °C
> Switch position III : 600 °C
> Protection class : II
> Weight : 0.74 kg
Rating Label Explanation
TTB773HTG
TT= TITAN
B = 240AC
Unpacking
> Unpack all parts and lay them on a at, stable surface.
> Remove all packing materials and shipping devices if applicable.
> Make sure the delivery contents are complete and free of any damage. If you
nd that parts are missing or show damage do not use the product but contact
your dealer. Using an incomplete or damaged product represents a hazard to
people and property.
> Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts!
There is a danger of choking and suffocation!
773 = Version number
TTB773HTG by TITAN
HTG = Heat gun

EN
Getting started...
Before you start
15
You will need
(items not supplied)
Suitable personal protective equipment
(items supplied)
Blade (7a)
Handle (7b)
Concentrator nozzle (8)
Spreader nozzle (9)
Glass protector nozzle (10)
Reector nozzle (11)
Assembly
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to power supply before it is completely
assembled!
NOTE: Take care of small parts that are removed during assembly or
when making adjustments. Keep them secure to avoid loss.
Scraper
> Remove the outer nut (7c) from the thread of handle (7b) (Fig. 1).
> Place the blade (7a) on the thread.
> Screw the nut back until the blade is properly fastened.
7c 7a 7b
Fig. 1
WARNING! Do not touch the blade as it becomes very hot during
use and remains hot for up to 30 minutes after use.
TTB773HTG by TITAN

EN Before you start
Getting started...
16
Accessories
Different nozzle attachments can be used depending on the work being conducted.
WARNING! Always use accessories according to the intended use!
Some accessories are very sharp and become hot during use! Handle
them carefully! Wear safety gloves when handling accessories in
order to avoid injuries like burns and cuts!
Illustration Description Application
Concentrator nozzle
(8)
Direct hot air onto small specic
areas.
Spreader nozzle (9) Directing a long narrow heat pattern
to the workpiece.
For removing paint or varnish from
large at surfaces such as skirting
boards, doors, stairs etc.
To be used in conjunction with the
scraper.
Glass protector
nozzle (10)
Deects the heat away from glass or
other fragile areas and back onto the
workpiece.
Stripping paint and varnish on
window sills.
Reector nozzle (11) Direct hot air onto hard to reach,
awkward areas or to spread the heat
more evenly around copper pipes.
TTB773HTG by TITAN

EN
Getting started...
Before you start
17
Attaching accessories
> Align the required nozzle (8 - 11) with the hot air outlet (1) and attach it. Ensure
8
9
10
11
1
Fig. 2
Removing/replacing accessories
> After use, let the nozzle cool down before removing it.
> Remove the nozzle (8 - 11) from the hot air outlet (1) and attach a new nozzle
as required.
WARNING! Do not touch the nozzle as it becomes very hot during
use and remains hot for up to 30 minutes after use.
Connection to power supply
> Make sure the on/off switch (4) is in its off position ("0").
> Connect the plug with a suitable socket.
WARNING! Check the voltage! The voltage must comply with the
information on the rating label!
> Your product is now ready to be used.
TTB773HTG by TITAN

28
29
30
26
21
19
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
18
EN
In more detail...
In more
detail...
TTB773HTG by TITAN

EN
19
EN
In more detail...
Product functions
Intended use
This heat gun TTB773HTG is designated with a rated input of 2000 Watts.
This product is intended for removing paint, forming and bending of plastic tubes,
and the warming of heat-shrinkable tubing, using the respective nozzles. The
product is also suitable for soldering and tinning, loosening adhesive joints and
defrosting water pipes.
This product must not be used on clothing or drying the hair or other body parts
of pets and humans.
operation and to observe all the instructions therein.
Stand
Always place the product on its stand (3) after operation (Fig. 3).
3
Fig. 3
On/off switch
Set the on/off switch (4) to desired position.
Position Setting Applications
“0” – Off Cleaning and storage
TTB773HTG by TITAN
–

EN
20
EN Product functions
In more detail...
On/off switch
Position Setting Applications
“I” – On
Cool-off
position
50°C
Change the mode from high
temperature to cool temperature
quickly.
Reducing the cooling time of the
product before changing accessories
Reducing the cooling time of the
product before storage
Reducing the cooling time of the
workpiece
“II” – On,
450°C
Removing paint
Shrinking plastic sleeves
Soldering pipes
Bending plastic tubes
“III” – On,
600°C
Removing stickers
Defrosting taps and tubes
NOTE: If you are not sure about the correct setting, start with a low
temperature setting and gradually increase the temperature until you
achieve optimum results.
Thermal protection
This product is equipped with a self-resettable safety cut-out which will operate to
cut off the power supply to the heating elements if the internal temperature gets
too high. It will reset automatically when the product has cooled down.
TTB773HTG by TITAN
