Toa Netcansee N-VR2010 User manual

Network-based surveillance
with outstanding TOA-quality images
and sound
Netcansee
NETWORK CAMERA
SYSTEM
NTSC

With the new TOA Network Camera Sys
you can clearly capture any situation
live and in real time.

NETWORK-BASED SYSTEM ADVANTAGES
•Video surveillance and control from a remote location.
•Simultaneous control of system components and bi-directional audio
signal and video transmission with minimal cables.
•Offers flexible, versatile system expansion.
•Clear, crisp images and high-quality audio through the system's digital
transmission.
tem,
The TOA Network Camera System simultaneously
transmits MPEG-4 format video for real-time monitoring,
enabling smooth flowing images for live monitoring from a
remote location.
The N-CC2360 Network Color Camera features a built-in
condenser microphone, making it possible to simultaneously
transmit both images and high-quality sound from the
surveillance area. This technology is exclusively available in
TOA's Network Camera System, developed by our Audio
Product Engineers.
The N-CC2564 Network Combination Dome Camera is
capable of high-speed PTZ movements, allowing users
immediate access to their desired location.
TOA's Network Camera System is ideal for any application
including hospitals, railway stations, shopping malls,
universities, factories and offices.

N-CC2360 can be connected directly to a LAN
(10 BASE-T/100BASE-TX).
•PoE capability
•Built-in microphone and audio output terminal allows bidirectional
audio transmission
•Wide Dynamic Range and Day & Night functions
•Motion Detection
•Privacy Masking (up to 4 locations)
N-VT2010 can be connected directly to a LAN and transmits
analog camera's video and audio signals over the network.
•Connection for analog camera to digitally transmit images to a network
•12V DC Power Supply (ex. For CV Series Camera)
•PoE capability
•Bidirectional audio transmission (Audio input ×1, Audio output ×1)
N-VR2010 allows displaying digital image data from a network
camera or network video trasmitter on an analog monitor screen.
•12V DC Power Supply (ex. For Remote Controller)
•PoE capability
•Bidirectional audio transmission (Audio input ×1, Audio output ×1)
N-CC2360 Network Color Camera
N-VT2010 Network Video Transmitter
N-VR2010 Network Video Receiver
(Lens is optional)
Simultaneous transmission of MPEG-4 and JPEG
Simultaneous MPEG-4 and JPEG transmission enables monitoring at a
low transmission rate with smooth image movement, along with
simultaneous recording of high-quality JPEG images.
Bidirectional, high-quality audio transmission
The N-CC2360, N-CC2564, N-VT2010 and N-VR2010 are all capable of
bidirectional audio transmission, and the N-CC2360 features a built-in
microphone instead of an audio input terminal. This enables it to capture
sounds in the surveillance area, as well as images, providing monitoring
personnel with a more accurate sense of the atmosphere of the site.
Connecting the audio output terminals on the N-CC2360 or N-CC2564 to
an amplifier with speaker enables audio transmission from the monitoring
party to the surveillance area.
PoE (Power over Ethernet) eliminates the need for
a dedicated power cable.
Because the N-CC2360, N-VT2010 and N-VR2010 are compatible with
PoE, power can be provided over a network. This contributes to
simplification of wiring installation work, and reduction of cost.
N-VT2010 and N-VR2010 are
equipped with 12V DC output.
These units can provide power to compact
cameras (CV Series) and remote
controllers, reducing the number of cables
needed by the system.
Transmission of MPEG-4, JPEG and Sound simultaneously
MPEG-4ASP
QVGA low-resolution images
JPEG
VGA high-resolution images
LAN
MPEG-4
Sound
Sound
JPEG
WAN
N-DR2000
Remote Monitoring
of smoothly moving
Images and Sound
Recording of
High-quality
Images and
Sound
Perform remote surveillance by means of
smoothly moving video images and
high-quality sound.
Sound

N-CC2564 can be connected directly to a LAN
(10 BASE-T/100BASE-TX).
•Bidirectional audio transmission (Audio input ×1, Audio output ×1)
•Rotation range: horizontal 360°continuous; vertical +5°to –185°
•High-speed horizontal and vertical rotations of up to 360°/sec.
•23X optical zoom
•255 preset positions
•Wide Dynamic Range and Day & Night functions
•Motion Detection
•Privacy Masking (up to 8 locations)
N-DR2000 allows images and audio from network cameras, as
well as event data, to be recorded, distributed, and stored over a
network.
•640GB Storage Capacity (320GB x 2)
•Can record images from up to 16 network cameras or network video
transmitters at once
•Up to 8 recorded images and audio tracks can be played back
simultaneously.
•Browser-based setup
N-CC2564 Network Combination Dome Camera
N-DR2000 Network Video Recorder
with Ceiling Mount
Cover C-BC511C
TOA's software decoder allows camera images to be monitored
on a PC without needing a receiver.
N-SD2000
Up to four MPEG-4 images can be displayed simultaneously.
Control of TOA Network Color Camera, Network Combination Dome
Camera, Digital Video Recorder, Multiplexer and Combination Dome
Camera.
N-SD0160
Up to sixteen JPEG images can be displayed simultaneously.
These images can also be recorded directly onto the PC's hard disk.
Software Decoder
BRACKETS AND COVERS
C-BC511A
Ceiling Mount Bracket
C-BC511C
Ceiling Mount Cover
C-BC511C-S
Ceiling Mount Cover
(Smoked)
C-BC511U
Flush Ceiling Mount Bracket
C-BC511U-S
Flush Ceiling Mount Bracket
(Smoked)
C-BC511P
Ceiling Suspension Bracket
C-BC511W
Wall Mount Bracket

TOA's Software Decoder: Versatile and smart software
that optimizes Network Camera System operation
Display of images recorded on the N-DR2000 and easy
search for images users want to view
Motion Detection Function can be easily set and
checked.
Data recorded on the Network Video Recorder can be
exported onto a PC.
Point-view/Zoom-view Functions
While monitoring live images from the combination dome camera,
clicking on any point with the mouse moves that point to the
center of the screen. (Point-view)
An area selected by dragging the mouse is zoomed up for display.
(Zoom-view)
Bidirectional Audio Transmission
Enables pick-up of sound from the surveillance area, as well as
issuing a voice warning to an intruder.
Remote Control
Network Color Cameras, Network Combination Dome Cameras,
Digital Video Recorders and Combination Dome Cameras can be
remotely controlled.
Allows monitoring of MPEG-4 images from four
surveillance cameras at a time. Can handle images
from up to 2,000 surveillance cameras.
■N-SD2000
Can handle images from up to 100 surveillance
cameras (Display only 16 images at a time).
Recording onto the PC hard disk
Up to 5 minutes of the displaying network camera can be
manually recorded onto the hard disk of the PC, as well as up to
30 minutes of recording that starts automatically when an alarm
signal is detected.
Remote Control
Network Combination Dome Camera can be remotely controlled.
Sixteen images from Network Color Camera, Network
Combination Dome Camera and Network Video
Transmitter can be monitored simultaneously.
■N-SD0160

System Example 2
N-VR2010
Network Video Receiver
Box Speaker
System Example 1
C-CV24-2
Compact Color Camera
N-CC2360
Network Color Camera
N-CC2564
Network Combination
Dome Camera
N-DR2000
Network Video Recorder
PC
(Software Decoder is installed)
PoE-compatible
Switching HUB
N-VT2010
Network Video Transmitter
C-CC514/564/574
C-CC714/764/774
Combination Dome Cameras
PC
(Software Decoder is installed)
PoE-compatible
Switching HUB
PoE-compatible
Switching HUB
LAN
RS-485
RS-232C
Video
Audio
N-VT2010
Network Video Transmitter
C-DR161
Digital Video Recorder
C-RM1000
Remote Controller
N-CC2360
Network Color Camera
Amplifier
Amplifier
Microphone
Speaker
N-CC2564
Network Combination
Dome Camera
N-VR2010
Network Video Receiver
Monitor
LAN
Video
12V DC Power Supply
PoE
PoE
PoE
PoE
PoE
PoE
LAN

Specifications are subject to change without notice.
Printed in Japan (0708) 833-52-371-60 u
TOA Corporation
www.toa.jp
Human Society with
Security & Safety
Model No.N-VT2010 Network Video Transmitter
Power Req. 24 V AC, 50/60 Hz or 24 V DC or PoE (IEEE802.3af)
Power Consumption 10 W: at 24 V AC (9 W: PoE, 400 mA: 24 V DC)
Power Output 12 V DC, max. 0.2 A, screwless connector
Serial Port RS-232C: D-sub connector (9 pins, male), RS-485: screwless connector
Network
Video Compression/ MPEG-4: D1 (720 ×480), Half D1 (720 ×240), QVGA (320 ×240)
Resolution JPEG: D1 (720 ×480), Half D1 (720 ×240), VGA (640 ×480),
QVGA (320 ×240), QQVGA (160 ×120)
Frame Rate MPEG-4 (D1, max. 30 fps) + JPEG (D1, max. 5 fps)
Audio Compression/ Sub-band ADPCM, PCM (non-compression)
Decompression
Audio Sampling Frequency 8 kHz, 32 kHz
Simultaneous 5 (MPEG-4: 4, JPEG: 1), In streaming mode: No limit (MPEG-4 only)
Connected Number
Other Function Password authentication, Motion detection function
Finish Case: Surface-treated steel plate, silver, paint
Dimensions 136 (W) ×44 (H) ×127.9 (D) mm (5.35” ×1.73” ×5.04”)
Weight 700 g (1.54 lb)
Accessory CD-ROM (Software decoder: N-SD2000, Manuals (PDF)) ×1,
Power conversion cable ×1
Model No.N-VR2010 Network Video Receiver
Power Req. 24 V AC, 50/60 Hz or 24 V DC or PoE (IEEE802.3af)
Power Consumption 10 W: at 24 V AC (9 W: PoE, 400 mA: 24 V DC)
Power Output 12 V DC, max. 0.2 A, screwless connector
Network
Video Compression/ MPEG-4, D1 (720 ×480), Half D1 (720 ×240), QVGA (320 ×240)
Resolution
Frame Rate MPEG-4: D1, max. 30 fps
Audio Compression/ Sub-band ADPCM, PCM (non-compression)
Decompression
Audio Sampling Frequency 8 kHz, 32 kHz
Image Transfer Rate MPEG-4: 4 Mbps max
Other Function Password authentication
Finish Case: Surface-treated steel plate, silver, paint
Dimensions 136 (W) ×44 (H) ×127.9 (D) mm (5.35” ×1.73” ×5.04”)
Weight 700 g (1.54 lb)
Accessory Power conversion cable ×1
Model No. N-DR2000 Network Video Recorder
Power Req. 110-120 V AC, 50/60 Hz
Power Consumption 57 W (0,8 A)
Recording Storage HDD S-ATA 640 GB (320 GB X 2)
Network
Recording Method Video: JPEG Audio: sub-band ADPCM, PCM
(non-compression)
Number of Simultaneous Up to 16 stations (Network camera or Network video transmitter)
Recording
Other Functions Alert notification via e-mail, time synchronization, operating log
Finish Case: Pre-coated steel plate. black
Dimensions 420 (W) ×88.7 (H) ×320.5 (D) mm (16.54" ×3.49" ×12.62")
Weight 6.1 kg (13.45 lb)
Accessory Power cord (2 m (6.56 ft)) ×1, CD-ROM (Update Disk) ×1
SPECIFICATIONS
Model No. N-CC2360 Network Color Camera
Power Req. 24 V AC, 50/60 Hz or 24 V DC or PoE (IEEE802.3af)
Power Consumption 13 W (at 24 V AC), (8 W:PoE, 350 mA; 24 V DC)
Microphone 0mnidirectional, electret condenser microphone
Camera
Image Device 1/3 type IT-CCD
Number of Effective 768 (H) ×494 (V) (380,000 pixels)
Pixels
Minimum Required 0.5 lx (50 IRE), 0.1 lx (20 IRE) (F 1.0) (sensitivity up: OFF) (color mode)
Illumination 0.01 lx (F 1.0) (sensitivity up: ON) (B&W mode, incandescent lamp)
Other Functions Privacy masking (up to 4), Electronic zoom (2x), Horizontal/Vertical reverse,
Flickering reduction (DIP switch), Focus adjustment switch (DIP switch),
Chroma level: Normal/Manual (MIN – MAX),
Enhancer: Normal/Manual (soft – sharp)
Network
Video Compression/ MPEG-4: D1 (720 ×480), Half D1 (720 ×240), QVGA (320 ×240)
Resolution JPEG: D1 (720 ×480), Half D1 (720 ×240), VGA (640 ×480),
QVGA (320 ×240), QQVGA (160 ×120)
Frame Rate MPEG-4 (D1, max. 30 fps) + JPEG (D1, max. 5 fps)
Audio Compression/ Sub-band ADPCM, PCM (non-compression)
Decompression
Audio Sampling Frequency 8 kHz, 32 kHz
Finish Case: Surface-treated steel plate, sand gray , paint
Dimensions 69.3 (W) ×64.8 (H) ×157.3 (D) mm (2.73” ×2.55” ×6.19”)
Weight 670 g (1.48 lb)
Accessory CD-ROM (Software decoder: N-SD2000, Manuals (PDF)) ×1,
Power conversion cable ×1
Model No. N-CC2564 Network Combination Dome Camera
Power Req. 24 V AC, 50/60 Hz
Power Consumption 20 W (normal operation), 25 W max. (1.6 A max.)
Video Output VBS 1.0 V(p-p), 75Ω, BNC-R jack, NTSC
Camera
Image Device 1/4 type CCD
Resolution Horizontal: 480 lines (at center)
Minimum Required High-sensitivity function OFF: 3 lx (50 IRE), 1 lx (20IRE)
Illumination High-sensitivity function ON: 0.03 lx (50 IRE), 0.01 lx (20IRE)
No. of Preset Positions 255 Positions + Home
Automatic Operation Auto-pan, Preset sequence, Auto-trace (2 preset patterns (60s)),
Tour (16 preset patterns)
Timer Refresh: Starts at the preset time every day or every week by timer settings
Program: Settable 16 actions
Other Functions Auto Flip, Freeze preset, Manual limit, Privacy masking (up to 8),
Motion detection (each 8 presets at each 4 positions)
Lens
Zooming 23x
Effective Focal Length f = 3.6 - 82.8mm (23X)
Effective Angle of View Horizontal: 54°(W) – 2.5°(T)/Vertical: 41.6°(W) – 1.9°(T)
Network
Video Compression/ MPEG-4: D1 (720 ×480), Half D1 (720 ×240), QVGA (320 ×240)
Resolution JPEG: D1 (720 ×480), Half D1 (720 ×240), VGA (640 ×480),
QVGA (320 ×240), QQVGA (160 ×120)
Frame Rate MPEG-4 (D1, max. 30 fps) + JPEG (D1, max. 5 fps)
Audio Compression/ Sub-band ADPCM, PCM (non-compression)
Decompression
Audio Sampling Frequency 8 kHz, 32 kHz
Operating Temperature -10°C to 50°C (+14°F to +122°F)
(Continuously active for operation at temperature below 0°C (+32°F))
Finish Base: PC/ABS resin, cool gray, Camera: PC/ABS resin, black
Dimensions ø168 ×234 (H) mm (ø6.61” ×9.21”)
Weight 2 kg (4.41 lb)
Accessory Camera mounting screw ×4, Safety wire ×1, Category5 shielded coupler (female
to female) ×1, Extension connector (Alarm input, AUX contact output) ×1 each,
CD-ROM (Software decoder: N-SD2000, Manuals (PDF)) ×1
