TOORX BRX35 User manual

Ed : Rev : Cod:
INSTRUCTION
09/18 GRLDTOORXBRX3500

3

4
ASSEMBLY INSTRUCTIONS
Step 1
Assembly the rear and front stabilizer (F&E)
with 4 bolts (I-6), 4 nuts (I-8) and 4 washers
(I-7).
Step 2
Assemble the left hand pedal (H-L) and the
right hand pedal (H-R) to the hand crank.
Step 3
Connect the saddle (G-3) and the slider
(G-5) with three bolts and washers.
Attach the slider onto the top of the seat post
(G), fix it with one seat knob (G-1) and one
flat washer (G-2).

5
ASSEMBLY INSTRUCTIONS
Step 4
Loosen the four screws (D-4) and four flat
washer (D-3) on the support tube of handle
bar post.
Insert the handle bar post onto the support
tube, connect the tension control cable upper
& lower (C-2) & (D-2), connect the sensor
cable upper & lower (C-1) & (D-1), fix the
handle bar post with four screws and
washers.
Step 5
Attach the handlebar (B) to the handlebar
post between the steel covers, insert the
hand pulse through the hole on hanle bar
post, assemble the plastic cover (I-2) over
the steel cover, secure the steel cover
assembly using one flat washer (I-5), one
spring washer (I-4), one bushing (I-3) and
one T-knob (I-1).

6
ASSEMBLY INSTRUCTIONS
Step 6
Connect the sensor cable (C-1) between the
computer (A) and the handle bar post,
connect the hand pulse cable between the
handle bar and computer. Fix the computer
with two screws (A-1).

7
PARTS LIST
NO.
DESCRIPTION
Q'TY
A
Computer
1PC
A-1
Screw
2PCS
B
Handlebar set
1SET
B-1
Handlebar foam
2PCS
B-2
Handle bar end cap
2PCS
B-3
Hand grip
2PCS
C
Handlebar post
1SET
C-1
Sensor cable(Upper)
1PC
C-2
Tension controller(Upper)
1PCS
D
Main frame
1PC
D-1
Sensor cable(Lower)
1PC
D-2
Tension controller(Lower)
1PC
D-3
Semicircular washer
4PCS
D-4
Hex. Screw
4PCS
D-5
Seat post knob
1PC
D-6
Triangle screw
1PC
D-7
Hex. nut
1PC
D-8
Have tooth washer
1PC
D-9
Left thread
1PC
D-10
Ball retainer
2PCS
D-11
Bottom bracket
2PCS
D-12
Grooved belt
1PC
D-13
Chain cover(R&L)
2PCS
D-14
Screw
4PCS
D-15
Screw
3PCS
D-16
Sleeve
1PC
E
Front stabilizer
1SET
E-1
Front stabilizer end cap
2PCS
F
Rear stabilizer
1SET
F-1
Rear stabilizer end cap
2PCS
G
Seat post
1PC
G-1
Seat knob
1PC
G-2
Flat washer
1PC
G-3
Saddle
1PC

8
G-4
Cap
2PCS
G-5
Slider
1PC
G-6
Fixed screw for slider
1PC
G-7
Flat washer
3PCS
G-8
Screw
3PCS
H-R/L
Pedal
2PCS
I-1
T knob
1PC
I-2
Plastic cover
1PC
I-3
Bushing
1PC
I-4
Spring washer
1PC
I-5
Flat washer
1PC
I-6
Carriage screw
4PCS
I-7
Wave washer
4PCS
I-8
Nut
4PCS
J-1
Plastic belt pully
1PC
J-2
Right thread
1PC
J-3
Crank
1PC
K
Idler clamping
1SET
K-1
Idler wheel
1PC
K-2
Sleeve
1PC
K-3
Idler spring
1PC
K-4
Nylon nut
2PCS
K-5
Hex. screw
1PC
K-6
Flat washer
1PC
L
Magnetic set
1SET
L-1
Hex. screw
2PCS
L-2
Spring washer
2PCS
L-3
Flat washer
2PCS
L-4
C-circle
2PCS
L-5
Wave washer
1PC
L-6
Mandril
1PC
M
Flywheel
1PC
M-1
Deep groove ball bearing 6900
1PC
M-2
Deep groove ball bearing 6000
1PC
M-3
Sleeve
1PC
M-4
Mandril
1PC
M-5
Nut
5PCS
M-6
Star washer
2PCS

9
COMPLETE BIKE ASSEMBLY

10
EXERCISE COMPUTER
Monitor Display
KEY FUNCTION:
MODE: This key lets you to select and lock on to a particular function you want.
FUNCTIONS
SCAN
Automatically scan through each mode in sequence every 6 seconds. The display loop is
SCAN-TIME-DISTANCE-CALORIE-SCAN on the main screen.
TIME
Accumulates total working time from 00:00 up to 99:59.
SPEED
Displays current training SPEED, the maximum is 99.9km/ml,it always displays.
DISTANCE
Accumulates training distance from 0.00 to the maximum 99.99km/ml with each increment
0.01km/ml.
ODO
Press the MODE key until the pointer advance to ODOMETER. The total accumulated distance
will be shown.
CALORIE
Accumulates calories consumption during training from 0 to the maximum 9999 cal with each
increment 1 cal.
PULSE
Press the MODE key until the pointer advance to PULSE. User’s current heart rate will be
displayed in beats per minutes. Place the palms of your hands on both of the contact pads (or
put ear-clip to ear),and wait for 30 seconds for the most accurate reading.
NOTE
1. Without any signal been transmitted into the monitor for 4 minutes, the LCD display will shut off automatically,
and all function values will be kept. You may press mode or start pedaling to have the monitor power on again.
2. If improper display on monitor, please re-install batteries to have a good result.
3. Battery spec: 1.5v um-3 or AAA (2 pcs).
MODE
SCAN
TIME
SPEED
DISTANCE
ODO
CALORIES
PULSE
SET
RESET
