TOORX SRX300 User manual

Ed : 09/17 Rev : 00
INSTRUCTION

2
EXPLOSIVE VIEW

3
PARTS LIST
PART NO.
DESCRIPTION
QTY
1
Computer
1 PC
2
Ipad shelf
1 PC
3
Line plug
3 PCS
4
Handlebar
1 PC
5
Handlebar post
1 PC
6
Brake knob
1 PC
7
Brake trim cover
1 PC
8
Hexagon nut M8
2 PCS
9
Brake rod φ10x225
1 PC
10
Spring Φ14xΦ1.8x31.5L
1 PC
11
Square nut
1 PC
12
Cap nut M10
1 PC
13
Brake bushing φ16
1 PC
14
Bottom cable
1 PC
15
Seat
1 PC
16
Slider
1 PC
17
Seat post
1 PC
18
Washer φ10.5xφ38x4T
2 PCS
19
Knob M10
2 PCS
20
Tube clamp
2 PCS
21
Lock pin M16
2 PCS
22
Sensor
1 PC
23
Sensor cable
1 PC
24
Cable DC
1 PC
25
Step screw
4 PCS
26
Trim cover L
1 PC

4
27
Chain cover L
1 PC
28
Crank (L+R)
1 PC
29
Pedal (L+R)
1 SET
30
Crank plug
2 PCS
31
Flange nut M10
2 PCS
32
Hexagon nut
2 PCS
33
Bearing 6004
2 PCS
34
Axle pipe
1 PC
35
End cap 40x100
4 PCS
36
Hexagon nut M10
4 PCS
37
Foot pad
4 PCS
38
Rear tube
1 PC
39
Axle limit pipe
1 PC
40
Belt pulley φ214 5PK
1 PC
41
Axle
1 PC
42
Hexagon screw M8x15
3 PCS
43
Belt 1340 5PK
1 PC
44
Chain Cover R
1 PC
45
Screw M4x20
6 PCS
46
Screw M4.2x19
7 PCS
47
Screw M5x12
9 PCS
48
Trim cover R
1 PC
49
Hexagon screw M8x38
2 PCS
50
Moving wheel φ70
2 PCS
51
Nylon nut M8
2 PCS
52
Washer
2 PCS
53
Bearing 608
2 PCS
54
Front tube
1 PC
55
Flange nut
2 PCS

5
56
Hexagon nut
2 PCS
57
Magnetic flywheel
1 PC
58
Washer
2 PCS
59
Cable
1 PC
60
Main frame
1 PC
61
Hexagon screw
2 PCS
62
Brake pad
1 PC
63
Screw M5
4 PCS
64
Motor
1 PC
65
Hexagon screw M6×45
2 PCS
66
Hexagon screw M6
2 PCS
67
Flange nut
2 PCS
68
Pipe
2 PCS
69
Hexagon nut
2 PCS
70
Flywheel axle φ15
1 PC
71
Flywheel
1 PC
72
Belt 2
1 PC
73
Bearing 6202
2 PCS
74
Washer
2 PCS
75
Front cover
1 PC
76
End cap
1 PC
77
Sensor cable
1 PC
78
Screw
2 PCS
79
Screw
2 PCS
80
Power supply
1 PC
81
Harpoon wrench
1 PC
82
Hexagon wrench
1 PC

6
ASSEMBLY INSTRUCTION
STEP 1
Attach the rear tube (38) to the main frame(60) using two sets of cap nut(25),
Attach the front tube (54) to the main frame same as the rear tube.

7
STEP 2
Put seat post (17) insert main frame with knob (21)adjust height.
Put seat (15) on the slider(16) and fix it.

8
STEP 3
The pedals (29L and 29R) are marked “L” and “R”-left and right.
Connect them to their appropriate crank set(28L and 28R). The right crank set
is on the right hand side of the cycle as you sit on it.
Note that the Right pedal should be threaded on clockwise and the left pedal
on anti-clockwise.

9
STEP 4
Fix the ipad shelf(2) on the handlebar(4) using screw(78),put computer(1) into
ipad shelf(2), And fix handlebar(4) on handlebar post(5) using washer(18) and
knob(19).
And connect sensor plug (14) and sensor plug (77) ,then insert the sensor
plug(77) into the sensor joint of computer.
Now your spinning bike is finished for use.
1
2
3

DISPLAY FUNCTIONS
ITEM
DESCRIPTION
TIME
.Workout time displayed during exercise.
.Range 0:00 ~ 99:59
SPEED
.Workout speed displayed during exercise.
.Range 0.0 ~ 99.9
DISTANCE
.Workout distance displayed during exercise.
.Range 0.0 ~ 99.9
CALORIES
.Burned calories during workout display.
.Range 0 ~ 999
PULSE
.Pulse bpm displayed during exercise.
.Pulse alarm when over preset target pulse.
RPM
.Rotation per minute
.Range 0 ~ 999
WATT
.Workout power consumption
. In Watt Program mode, computer will remain preset watt value (setting range 0~350)
MANUAL
.Manual mode workout.
PROGRAM
.Beginner, Advance, and Sporty PROGRAM selection.
CARDIO
.Target HR training mode.
KEY FUNCTION
ITEM
DESCRIPTION
Up
‧ Increase resistance level
‧ Setting selection.
Down
‧ Decrease resistance level
‧ Setting selection.
Mode
‧ Confirm setting or selection.
Reset
‧ Hold on pressing for 2 seconds, computer will reboot and start from
user setting.
‧ Reverse to main menu during presetting workout value or stop mode.
Start/ Stop
‧ Start or Stop workout.
Recovery
‧ Test heart rate recovery status.
Body fat
‧ Test body fat% and BMI.
