TOORX BRXR 90 User manual

Ed : 02/17 Rev : 00
INSTRUCTION

PARTS LIST
Part No Description Q' t y
1 Main frame 1
2 Front stabilizer 1
3 Rear stabilizer 1
Front post 1
5 Handlebar L/R 1/1
6 Computer 1
7 Rear support frame 1
8 Cover for front post 1
9 Middle sensor wire 1
10 Middle pulse wire 1
11 Foam grip for handlebar 2
12 Screw M5*12
13 End cap for handlebar 2
1 Allen screw M8*16 30
15 Curve washer M8*20 8
16 Flat washer Φ8*Φ17 8
17 Lower pulse wire 1
18 Lower sensor wire 1
19 Pedal L/R 1/1
20 Transportation wheel L/R 1/1
21 Allen bolt M8*55
22 Pulse wire 1
23 Cover for rear support frame L/R 1/1
2 Leveling end cap 2
25 Leverage knob 1
26 Self-tapping screw ST5*15 23
27 End cap 20*60 2
28 End cap for sliding tube 30*36 2
29 Sliding tube 1
30 End cap for seat support bracket 2
31 End cap 53.5*23.5 2
32 Seat support bracket 1
33 Seat cushion 1
3 Back cushion 1
35 Quick release knob 1
3

36 End cap Φ31.8 2
37 Handlebar 1
38 Hand pulse sensor 2
39 Flat washer Φ12*Φ5 2
0 Self-tapping Screw ST *20 2
1 Foam grip for handlebar 2
2 Hand pulse wire upper 1
3 Carriage bolt M8* 5 2
Doomed nut M8 2
5 Grommet 1
6 Run disc cover 2
7 France bolt 2
8 Run disc 2
9 Run Disc Support L/R 1/1
50 Back cover for run disc 2
51 Self-tapping Screw ST5*10 10
52 Screw M5*10
53 Fixed wheel 2
5 Allen Screw 6*20
55 Self-tapping Screw ST5*20
56 Chain cover L/R 1/1
57 France nut 1
58 Spring Φ12 2
59 Axle for flywheel 1
60 Flywheel 1
61 Magnetic assembly 1
62 Nylon nut M8 2
63 Bolt M8*55 1
6 C-clip Φ17 2
65 Bearing 6203 2
66 Hex head bolt M6*25 1
67 Hex head nut M6 2
68 Spring 1
69 Spring 1
70 Bolt 1
71 Nut M8 1
72 Idler wheel 1
73 Spacer 1
7 Belt-drive wheel 1
75 Nylon nut M6
76 Axle 1
77 Allen bolt 6*15
78 Sensor bracket 1
79 Belt 1
4

80 Clip 1
81 Nut M8*20 1
82 Motor 1
83 Power wire 1
8 Sensor wire 1
85 Motor wire 1
5

EXPLODED DIAGRAM
6
1
2
3
5R
7
6
5L
8
9
10
11
11 12
13
13
1
1
1
1 1
1
1
1
1
1
1
1
1
15
16
16
16
16
16
15
15
15
17
18
19L
19R
20L
20R
21
21
22
23L
23R
2
2
25
26
26
5
27
27
28
28
29 30
30
31
31
32
33
3
35 36
36
37
38
39
0
0
38
1
1 2
3

7
6
7
8
9
L
5
6
L
5
9
7
57
67
7
5
5
1
9
R
8
7
6
5
0
5
0
5
1
5
2
5
35
5
1
5
2
5
3
5
1
2
6
2
6
2
6
2
6
2
6
2
6
2
6
2
6
2
6
5
75
8
5
8
6
0
6
1
6
2
6
3
6
2
6
6
6
5
6
5
6
6
6
7
6
8
7
0
7
1
7
2
7
3
7
7
8
7
9
5
5
5
5
5
55
55
6
R
8
0
8
1
8
2
8
3
8
8
5
1
7
1
8

PRE-ASSEMBLY CHECK LIST
PART NO DESCRIPTION Q’TY
1 Main Frame 1
2Front stabilizer 1
3Rear stabilizer 1
Front post 1
5Handlebar L/R 1/1
6Computer 1
7Rear support frame 1
8Cover for front post 1
19 Pedal L/R 1/1
23 Cover for rear support frame L/R 1/1
29 Sliding tube 1
32 Seat support bracket 1
8
NO:1 NO:7 NO:32 NO: NO:3
NO:2 NO:5R NO:8 NO:19L/RNO:3 NO:5L
NO:29 NO:33 NO:23L/R NO:6NO:37

33 Seat cushion 1
3 Back cushion 1
37 Handlebar 1
Manual 1
HARDWARE PARTS LIST
No Description Drawing Q’ty
1 Allen screw M8*16 30
15 Curve washer M8*20 8
16 Flat washer Φ8*Φ17 8
21 Allen bolt M8*55
25 Leverage knob 1
35 Quick release knob 1
3 Carriage bolt M8* 5 2
Doomed nut M8 2
Allen Key L6 1
Allen Wrench 1
Above described parts are all the parts you need to assemble this machine Before
you start to assemble, please check the hardware packing to make sure they are
9

included
ASSEMBLY INSTRUCTION
This manual is designed to help you easily assemble, adjust and use this machine. Please
read this manual carefully. For the sake of familiarizing yourself with the parts
identified in the instruction, first study the overview drawing.
Set all parts in a clear area on the floor and remove the packing material. Refer to the
parts list for help to identify the parts.
It will take two people to assemble your unit.
Step 1
Attach front stabilizer (2) to main frame (1). Secure using two allen bolts (21). two curve
washers (15).
Step 2
Attach rear stabilizer (3) to rear support frame (7). Secure using two allen bolts (21). two
curve washers (15).
Connect lower pulse wire (17) to pulse wire (22) then attach the rear support frame (7) to
main frame (1). Secure them together with six allen screws (1 ) and six flat washers (16)
Secure the Cover for rear support frame Left (23L) to the main frame with two self-tapping
screw (26), do the same way for the cover for rear support frame right（23R）.
10
1
15
21
2

Thread the leverage knob (25) to main frame bottom to stabilize the bike on floor.
Step 3
Insert the front post ( ) through the cover for front post (8) into the main frame (1). Then
connect the middle pulse wire (10) to lower pulse wire (17) & middle sensor wire (9) to
lower sensor wire (18). And secure using four allen screws (1 ) & two curve washers (15)
and two flat washers (16).
Attach the Handlebar left (5L) to the front post, secure using two allen screws (1 ), then
attach the handlebar right (5R) to the front post, secure using two allen screws (1 ).
Remove the four screws (12) from the computer(6). Slide the computer onto front post (8)
secure it with four screws(12).
11
1
1
1
1
16
16
16
25 3
7
1
15
21
22
23L
23R
26
26
17
1
1
11
15
16
16
17
18
8
5R
6
5L
9
10
12
1
1
